George Foreman RPGV3201BK User guide
New logo April 2016
serving GRILL & PANINI
porciones
8
USE AND CARE MANUAL
MANUAL DE USO Y CUIDADO
GUIDE D’UTILISATION ET D’ENTRETIEN
RPGV3201BK SERIES
RPGV3201BK_IB_21957.indd 1 6/21/18 2:51 PM
portions GRIL ET PANINI
PARRILLA Y PANINI
www.georgeforemancooking.com
PLEASE READ AND SAVE THIS USE AND CARE BOOK.
IMPORTANT SAFEGUARDS.
When using electrical appliances, always follow basic safety precautions to
reduce the risk of fire, electric shock, and/or injury, including the following:
• Read all instructions.
• Do not touch hot surfaces. Use handles
or knobs.
• The appliance is not intended to be operated
by means of an external timer or separate
remote-control system.
• To protect against electrical shock do not
immerse cord, plugs or appliance in water or
other liquid.
• Close supervision is necessary when any
appliance is used by or near children.
• Unplug from outlet when not in use and
before cleaning. Allow to cool before putting
on or taking off parts and before cleaning the
appliance.
• Do not operate any appliance with a
damaged cord or plug, or after the appliance
malfunctions or has been damaged in any
manner. Contact customer support or call the
appropriate toll-free number in this manual.
• The use of accessory attachments not
recommended by the appliance manufacturer
may cause injuries.
• Do not use outdoors.
• Do not let cord hang over edge of table or
counter, or touch hot surfaces.
• Do not place on or near a hot gas or electric
burner, or in a heated oven.
• Extreme caution must be used when moving an
appliance containing hot oil or other hot liquids.
• To disconnect, adjust the variable
temperature control to the MIN position, then
remove plug from wall outlet.
• Be sure removable plates are assembled
and fastened properly (see ATTACHING
THE PLATES).
• Do not use this appliance for other than
intended use.
• The appliance is only to be operated in the
closed position.
• This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities,
or lack of experience and knowledge,
unless they have been given supervision or
instruction concerning use of the appliance
by a person responsible for their safety.
• Children should be supervised to ensure that
they do not play with the appliance.
SAVE THESE INSTRUCTIONS.
This product is for household use only.
POLARIZED PLUG
This appliance has a polarized plug (one blade
is wider than the other). To reduce the risk of
electric shock, this plug is intended to t into a
polarized outlet only one way. If the plug does
not t fully into the outlet, reverse the plug. If it
still does not t, contact a qualied electrician.
Do not attempt to modify the plug in any way.
TAMPER-RESISTANT SCREW
Warning: This appliance is equipped with a
tamper-resistant screw to prevent removal of
the outer cover. To reduce the risk of re or
electric shock, do not attempt to remove the
outer cover. There are no user-serviceable
parts inside. Repair should be done only by
authorized service personnel.
RPGV3201BK_IB_21957.indd 2 6/21/18 2:51 PM
ELECTRICAL CORD
a) A short power-supply cord is provided to
reduce the risks resulting from becoming
entangled in or tripping over a longer cord.
b) Extension cords are available and may be
used if care is exercised in their use.
c) If an extension cord is used:
1) The marked electrical rating of the extension
cord should be at least as great as the
electrical rating of the appliance;
2) If the appliance is of the grounded type, the
extension cord should be a grounding-type
3-wire cord; and
3) The cord should be arranged so that it will
not drape over the counter top or tabletop
where it can be pulled on by children or
tripped over.
Note: If the power cord is damaged, please
contact the warranty department listed in these
instructions.
2
GETTING TO KNOW
YOUR GRILL
1. Grill cover
2. Power indicator light
3. Preheat indicator light
4. Grill plate release tabs
(both sides)
5. Handle
† 6. Nested drip tray
(Part # RPGV3201-03)
7. Variable temperature control
† 8. Removable grill
plate (top) (Part # RPGV3201-01)
† 9. Removable grill plate
(bottom) (Part # RPGV3201-02)
10. Dual grill position stand
Note: † indicates consumer replaceable/
removable parts.
Product may vary slightly from what is
illustrated.
Storage
Flip the dual grill position stand
underneath the unit. Then wrap
the cord around cord hooks to
secure.
Stand the grill vertically to save
storage space.
3
RPGV3201BK_IB_21957.indd 3 6/21/18 2:51 PM
HOW TO USE
This product is for household use only.
GETTING STARTED
• Remove all packing material, any stickers, and the plastic band around the
power plug.
• Remove and save literature.
• Please visit www.prodprotect.com/georgeforeman to register your warranty.
• Before rst use, wash grill, plates, and grease tray according to instructions in
the CARE AND CLEANING section of this manual.
USING DUAL GRILL POSITION STAND
1. For sloped cooking of foods like burgers or chicken: Flip
the Dual Grill Position Stand out away from the grill. (A)
2. For horizontal cooking of foods like paninis or hot dogs:
Flip the stand to store underneath the grill.
ATTACHING THE PLATES
Important: This appliance must always be used with both cooking plates securely
attached.
Caution: Attach grill plates when the appliance is cool.
1. Securely attach top grill plate using the release tabs on each side. To secure
the plate, insert the tabs at the bottom of the plate into the slots closest to the
hinge. Push the plate onto the grill until the release tabs snap into place.
2. Securely attach bottom grill plate using the release tabs as described in Step 1.
A
PREHEATING THE GRILL
• Slide drip tray under front of grill.
• Close lid and plug cord into outlet. The red “power” indicator light turns on.
• Allow grill to preheat until green ready indicator light illuminates.
• Using a pot holder, carefully open the preheated grill.
Note: Aerosol cooking spray should not be used on grill plates. Chemicals can build
up on surface of grill plates and reduce their efciency.
• Carefully place foods to be cooked on lower grilling plate. Close lid.
Note: Do not overload grill.
• Close cover and allow food to cook for desired time. (See COOKING GUIDE.)
• When nished cooking, unplug the appliance to cool.
• Using pot holder or oven mitts carefully open lid and remove food.
Note: Always use heatproof plastic, nylon or wood utensils to avoid scratching nonstick
surface of grill plates. Never use metal skewers, tongs, forks or knives.
• Allow the drip tray to cool before removing it from under the grill. Wash and dry
the drip tray after each use. Drip tray is dishwasher safe on top rack.
4
RPGV3201BK_IB_21957.indd 4 6/21/18 2:51 PM
USING ADJUSTABLE COOKING HEIGHT
This grill has a unique hinge that allows the grill cover to adjust to the thickness
of food. For even browning and cooking, when grilling more than one sandwich or
piece of meat, it is important that the thickness of each be about the same.
USING THE VARIABLE TEMPERATURE CONTROL
The Minimum setting (far left) is 300˚F, the Medium (center) setting is 350°F, and the
Max (far right) setting is 400°F. If you don’t know what temperature you wish to grill
at, try a medium setting (temperature setting midway between). You may later adjust
the temperature to be lower (left) or higher (right) to your preference.
COOKING GUIDE
The following chart is meant to be used as a guideline only. Cooking time will
depend on the thickness of the food. To be sure your food is cooked, USDA
recommends using a meat thermometer to test for doneness. Insert the meat
thermometer into the thickest part of the meat until the temperature stabilizes.
Food Variable Temperature Control Position
Minimum (left) Medium (center) Max (right)
Chicken: 6 oz.
boneless, skinless
Cooked to 165°F
Salmon: 4 oz.
Cooked to 145°F
Beef Burger: 4 oz.
Cooked to 145°F
NY Strip Steak: 7 oz.
Cooked to 145°F
(1/2” thick steak: It will
take longer if thicker cut.)
Sirloin Steak: 7 oz.
Cooked to 145°F
Tenderloin Steak: 7 oz.
Cooked to 145°F
Hot Dogs 3–5 minutes 2–4 minutes 2–4 minutes
Bacon: Cooked to
desired crispness
Grilled Vegetables: 4 oz.
Cooked to desired
doneness
8–10 minutes 6–8 minutes 4–6 minutes
3½–5 minutes 3–4½ minutes 2½–4 minutes
5–6 minutes 4–5 minutes 3–4 minutes
5–6 minutes 5–7 minutes 3–5 minutes
9–11 minutes 7–9 minutes 6–8 minutes
7–9 minutes 6–8 minutes 3–5 minutes
14–18 minutes 8–12 minutes 5–9 minutes
5–7 minutes 4–6 minutes 3–5 minutes
5
RPGV3201BK_IB_21957.indd 5 6/21/18 2:51 PM
CARE AND CLEANING
Caution: To avoid accidental electric shock and burns, unplug from
outlet before cleaning, allow your grill to cool completely.
This product contains no user serviceable parts. Refer service to qualied
service personnel.
1. Empty the drip tray, clean with warm water and dish soap. Wipe dry.
2. To remove the plates, press the release tabs on both sides of the plates and
remove from the grill. The plates can be washed in the dishwasher or by hand
with warm water and dish soap; always dry plates thoroughly before reattaching.
3. Wipe outside of unit with a warm, wet sponge. Dry with soft, dry cloth.
4. DO NOT use steel wool, scouring pads or abrasive cleaners on any part of the grill.
5. DO NOT immerse in water or any other liquid.
6. Make sure to hold the lid open by hand while cleaning to prevent accidental
closing and injury.
7. Any servicing requiring disassembly other than the above cleaning must be
performed by a qualied service personnel.
6
RPGV3201BK_IB_21957.indd 6 6/21/18 2:51 PM
RECIPE
GRILLED SAUSAGE AND PEPPER QUESADILLAS
These little bites are packed with avor and can be prepared in less than an hour,
making them the perfect solution to busy weeknights or last-minute company.
Prep Time: 15 minutes
Cook Time: 30 minutes
Total Time: 45 minutes
Yield: 16 servings
Ingredients:
2 red peppers, seeded and quartered
2 green peppers, seeded and quartered
2 red onions, sliced into 1/4-inch rounds
3 Tbsp. olive oil
1/2 tsp. each salt and freshly ground black pepper
6 mild Italian sausages
2 cups shredded Cheddar cheese
2 cups shredded mozzarella cheese
8 large our tortillas
Sour cream
Salsa
Directions:
Preheat grill with the variable control in the Max position. Toss together red and
green peppers, onions, 2 Tbsp. of the oil, salt and pepper.
Grill sausages and vegetables for 20 minutes or until sausages are cooked through
and vegetables are tender; let cool slightly. Chop vegetables and slice sausage;
toss with Cheddar and mozzarella. Arrange evenly over one side of each tortilla; fold
tortilla over to enclose lling.
Brush outside of each quesadilla with remaining oil; grill for 3 to 5 minutes or until
tortillas are golden brown and cheese is melted. Let stand for 1 minute. Cut each
tortilla into 4 wedges; serve with sour cream and salsa.
Tip: Omit sausage for a vegetarian-friendly version of this recipe.
7
RPGV3201BK_IB_21957.indd 7 6/21/18 2:51 PM
WARRANTY AND CUSTOMER
SERVICE INFORMATION
For support or any questions regarding your appliance, call the appropriate 800
number listed within this section. Please DO NOT return the product to the place of
purchase. Also, please DO NOT mail product back to manufacturer, nor bring it to a
service center. You may also want to consult our Product Protection Center at
www.prodprotect.com/georgeforeman .
Three-Year Limited Warranty
(Applies only in the United States and Canada)
What does my warranty cover?
• Your warranty covers any defect in material or workmanship provided; however, the liability of
Spectrum Brands Inc. will not exceed the purchase price of product.
How long is the warranty period?
• Your warranty extends three years from the date of original purchase with proof of purchase.
What support does my warranty provide?
• Your warranty provides you with a reasonably similar replacement product that is either
new or factory refurbished.
How do you get support?
• Save your receipt as proof of date of sale.
• Visit the online service website at www.prodprotect.com/georgeforeman, or call toll-free
1-800-947-3745, for general warranty service.
• If you need parts or accessories, please call 1-800-738-0245.
What does my warranty not cover?
• Damage from commercial use
• Damage from misuse, abuse or neglect
• Products that have been modied in any way
• Products used or serviced outside the country of purchase
• Glass parts and other accessory items that are packed with the unit
• Shipping and handling costs associated with the replacement of the unit
• Consequential or incidental damages (Please note, however, that some states do not allow
the exclusion or limitation of consequential or incidental damages, so this limitation may
not apply to you.)
How does state law affect my warranty?
• This warranty gives you specic legal rights. You may also have other rights that vary from
state to state or province to province.
RPGV3201BK_IB_21957.indd 8 6/21/18 2:51 PM
8
POR FAVOR LEA ESTE INSTRUCTIVO ANTES DE USAR EL PRODUCTO.
INSTRUCCIONES IMPORTANTES
DE SEGURIDAD.
Al utilizar cualquier aparato eléctrico siempre deben tomarse precauciones
básicas de seguridad, incluyendo las siguientes:
• Lea todas las instrucciones.
• No toque las superficies calientes. Use las
asas o las perillas.
• Este aparato no está diseñado para funcionar
a través de un reloj automático externo o con
un sistema de control remoto separado.
• A fin de protegerse contra un choque eléctrico
y lesiones a las personas, no sumerja el
cable, los enchufes ni el aparato en agua ni en
ningún otro líquido.
• Todo aparato eléctrico usado en la presencia
de los niños o por ellos mismos requiere la
supervisión de un adulto.
• Desconecte el aparato del tomacorriente
cuando no esté en uso y antes de limpiarlo.
Espere que el aparato se enfríe antes de
instalarle o retirarle piezas y antes de limpiarlo.
• No use ningún aparato eléctrico que tenga el
cable o el enchufe averiado, que presente un
problema de funcionamiento o que este dañado.
Acuda a un centro de servicio autorizado para
que lo examinen, reparen o ajusten. O bien,
llame al número gratuito apropiado que aparece
en la portada de este manual.
• El uso de accesorios no recomendados por el
fabricante del aparato puede ocasionar incendio,
choque eléctrico o lesiones a las personas.
• No use este aparato a la intemperie.
• No permita que el cable cuelgue del borde
de la mesa o del mostrador ni que entre en
contacto con superficies calientes.
• No coloque el aparato sobre ni cerca de las
hornillas de gas o eléctricas ni adentro de un
horno caliente.
• Tome mucha precaución al mover de un lugar
a otro un aparato que contenga aceite u otros
líquidos calientes.
• Para desconectar, ajuste el control de
temperatura variable a la posición MIN, luego
retire el enchfure del tomacorriente.
• Asegúrese de que las placas removibles
estén colocadas y ajustadas correctamente
(INSERTE LAS PLACAS DE LA PARRILLA).
• Este aparato se debe usar únicamente con el
fin previsto.
• Este aparato se debe ser utilizado cerrado
solamente
• Este aparato no está diseñado para ser usado
por personas (incluído niños) con capacidad
limitada física, mental o sensoriales disminuidas
y falta de experiencia o conocimiento que les
impida utilizar el aparato con toda seguridad sin
supervisión o instrucción.
• Se debe asegurar la supervisión de los niños
para evitar que usen el aparato como juguete.
CONSERVE ESTAS INSTRUCCIONES.
Este aparato eléctrico es para uso doméstico solamente.
ENCHUFE POLARIZADO
Este aparato cuenta con un enchufe polarizado (un
contacto es más ancho que el otro). A n de reducir
el riesgo de un choque eléctrico, este enchufe encaja
en un tomacorriente polarizada en un solo sentido. Si
el enchufe no entra en el tomacorriente, inviértalo y
si aun así no encaja, consulte con un electricista. Por
favor no trate de alterar esta medida de seguridad.
TORNILLO DE SEGURIDAD
Advertencia: Este aparato cuenta con un tornillo
de seguridad para evitar la remoción de la cubierta
exterior del mismo. A n de reducir el riesgo de
incendio o de choque eléctrico, por favor no trate
de remover la cubierta exterior. Este producto no
contiene piezas reparables por el consumidor. Toda
reparación se debe llevar a cabo únicamente por
personal de servicio autorizado.
RPGV3201BK_IB_21957.indd 9 6/21/18 2:51 PM
CABLE ÉLECTRICO
a) Un cable de alimentación corto es provisto para reducir los
riesgos de enredarse o tropezar con un cable más largo.
b) Existen cables de extensión disponibles y estos pueden
ser utilizados si se toma el cuidado debido en su uso.
c) Si se utiliza un cable de extensión:
1) La clasicación eléctrica marcada del cable de
extensión debe ser, como mínimo, igual a la
clasicación eléctrica del aparato;
2) Si el aparato es del tipo de conexión a tierra, el cable
de extensión debe ser un cable de tres alambres de
conexión a tierra; y
3) El cable debe ser acomodado de manera que no
cuelgue del mostrador o de la mesa para evitar que un
niño tire del mismo o que alguien se tropiece sin darse
cuenta.
Nota: Si el cable de alimentación está dañado, por favor
llame al número del departamento de garantía que aparece
en estar instrucciones.
9
Loading...
