George Foreman RPGF3601BKX User guide
serving REMOVABLE-PLATE GRILL
porciones
4
USE AND CARE MANUAL
MANUAL DE USO Y CUIDADO
GUIDE D’UTILISATION ET D’ENTRETIEN
RPGF3601BK SERIES
portions PLAQUES-AMOVIBLES GRIL
PLACA-REMOVIBLE PARRILLA
www.georgeforemancooking.com
1
PLEASE READ AND SAVE THIS USE AND CARE BOOK.
IMPORTANT SAFEGUARDS.
When using electrical appliances, always follow basic safety precautions to
reduce the risk of fire, electric shock, and/or injury, including the following:
• Read all instructions.
• Do not touch hot surfaces. Use handles or
knobs.
• The appliance is not intended to be operated by
means of an external timer or separate remotecontrol system.
• To protect against electrical shock do not
immerse cord, plugs or appliance in water or
other liquid.
• Close supervision is necessary when any
appliance is used by or near children.
• Unplug from outlet when not in use and
before cleaning. Allow to cool before putting
on or taking off parts and before cleaning the
appliance.
• Do not operate any appliance with a damaged
cord or plug, or after the appliance malfunctions
or has been damaged in any manner. Contact
customer support or call the appropriate toll-free
number in this manual.
• The use of accessory attachments not
recommended by the appliance manufacturer
may cause injuries.
• Do not use outdoors.
• Do not let cord hang over edge of table or
counter, or touch hot surfaces.
• Do not place on or near a hot gas or electric
burner, or in a heated oven.
• Extreme caution must be used when moving an
appliance containing hot oil or other hot liquids.
• To disconnect, remove plug from wall outlet.
• Be sure removable plates are assembled
and fastened properly (see ATTACHING
THE PLATES).
• Do not use this appliance for other than
intended use.
• The appliance is only to be operated in the
closed position.
• This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or lack
of experience and knowledge, unless they have
been given supervision or instruction concerning
use of the appliance by a person responsible for
their safety.
• Children should be supervised to ensure that
they do not play with the appliance.
SAVE THESE INSTRUCTIONS.
This product is for household use only.
POLARIZED PLUG
This appliance has a polarized plug (one blade
is wider than the other). To reduce the risk of
electric shock, this plug is intended to t into a
polarized outlet only one way. If the plug does
not t fully into the outlet, reverse the plug. If it
still does not t, contact a qualied electrician.
Do not attempt to modify the plug in any way.
TAMPER-RESISTANT SCREW
Warning: This appliance is equipped with a
tamper-resistant screw to prevent removal of
the outer cover. To reduce the risk of re or
electric shock, do not attempt to remove the
outer cover. There are no user-serviceable
parts inside. Repair should be done only by
authorized service personnel.
2
ELECTRICAL CORD
a) A short power-supply cord is provided to
reduce the risks resulting from becoming
entangled in or tripping over a longer cord.
b) Extension cords are available and may be
used if care is exercised in their use.
c) If an extension cord is used:
1) The marked electrical rating of the extension
cord should be at least as great as the
electrical rating of the appliance;
2) If the appliance is of the grounded type, the
extension cord should be a grounding-type
3-wire cord; and
3) The cord should be arranged so that it will
not drape over the counter top or tabletop
where it can be pulled on by children or
tripped over.
Note: If the power cord is damaged, please
contact the warranty department listed in these
instructions.
GETTING TO KNOW YOUR GRILL
1. Grill cover
2. Power indicator light
3. Preheat indicator light
4. Handle
5. Grill plate release handles
(both sides)
† 6. Removable grill
plate (top) (Part # RPGF3602-01)
† 7. Removable grill plate
(bottom) (Part # RPGF3602-02)
† 8. Nested drip tray
(Part # RPGF3602-03)
9. Dual grill position stand
Note: † indicates consumer replaceable/
removable parts.
Product may vary slightly from what is
illustrated.
Storage
Flip the dual grill position stand
underneath the unit. Then wrap
the cord around cord hooks to
keep it tidy.
Stand the grill vertically to save
storage space.
3
HOW TO USE
This product is for household use only.
GETTING STARTED
• Remove all packing material, any stickers, and the plastic band around the
power plug.
• Remove and save literature.
• Please go to www.prodprotect.com/georgeforeman to register your
warranty.
USING DUAL GRILL POSITION STAND
1. For sloped cooking of foods like burgers or chicken: Flip
the Dual Grill Position Stand out away from the grill. (A)
2. For horizontal cooking of foods like paninis or hot
dogs: Flip the stand to store underneath the grill.
ATTACHING THE PLATES
Important: This appliance must always be used with
both cooking plates securely attached.
Caution: Attach grill plates when the appliance is cool.
1. Securely attach top grill plate using the release tabs on each side. To
secure the plate, insert the tabs at the bottom of the plate into the slots
closest to the hinge. Push the plate onto the grill until the release tabs
snap into place.
2. Securely attach bottom grill plate using the release tabs as described in Step 1.
PREHEATING THE GRILL
• Slide drip tray under front of grill.
• Close lid and plug cord into outlet.
• Allow grill to preheat approximately 4½ minutes before grilling. When
grilling temperature is reached, the green preheat indicator light turns on.
GRILLING
• Using a pot holder, carefully open the lid.
Note: Aerosol cooking spray should not be used on nonstick surface.
Chemicals that allow spray to come out of a can build up on surface of grill
plates and reduce their efficiency.
• Carefully place foods to be cooked on lower grilling plate. Close lid.
Note: Do not overload grill.
• Close cover and allow food to cook for desired time. (See cooking chart.)
Note: Always use heatproof plastic, nylon or wood utensils to avoid scratching
nonstick surface of grill plates. Never use metal skewers, tongs, forks or knives.
• When finished cooking, unplug the appliance to cool it down.
4
A
• Using a potholder or oven mitts, carefully open the lid and remove the food.
• Allow the drip tray to cool before removing it from under the grill. Wash
and dry the drip tray after each use. It can also be washed in the upper
rack of the dishwasher.
USING ADJUSTABLE COOKING HEIGHT
This grill has a unique hinge that allows the grill cover to adjust to the
thickness of food. For even browning and cooking, when grilling more than
one sandwich or piece of meat, it is important that the thickness of each be
about the same.
SUGGESTED COOKING CHART
The cooking times and temperatures in the below chart are meant to be used
as a guideline only. Cooking time will depend upon the food thickness and
cut being used. Use a meat thermometer to test for doneness by inserting the
thermometer into the thickest portion of the meat. For reasons of personal
preference, you may choose to cook food to a higher temperature.
Rare
63 ˚C (145 ˚F)
Medium
71 ˚C (160 ˚F)
Well
76 ˚C (170 ˚F)
Salmon Steak 6 oz 4 min.
Burgers 4 oz 4 - 5 min. 5 - 7 min. 6 - 8 min.
Chicken Breast 6 oz
9 min.
Steak 7 oz 4 - 6 min. 5 - 7 min. 6 - 8 min.
CARE AND CLEANING
Caution: To avoid accidental burns, allow your grill to cool completely before cleaning.
This product contains no user serviceable parts. Refer service to qualified
service personnel.
1. Empty the drip tray, clean with warm, soapy water. Wipe dry.
2. To remove the plates, press the release tabs on both sides of the plates and
remove from the grill. The plates can be washed in the dishwasher or by
hand with hot, soapy water; always dry plates thoroughly before reattaching.
3. Wipe outside of unit with a warm, wet sponge. Dry with soft, dry cloth.
4. DO NOT use steel wool, scouring pads or abrasive cleaners on any part of the grill.
5. DO NOT immerse in water or any other liquid.
6. Make sure to hold the lid open by hand while cleaning to prevent
accidental closing and injury.
7. Any servicing requiring disassembly other than the above cleaning must be
performed by a qualified service personnel.
5
RECIPES
STICKY SOY PORK CHOPS
Ingredients:
2 Tbsp. brown sugar
1 Tbsp. rice wine vinegar
1 Tbsp. soy sauce
1 Tbsp. minced ginger
1 Tbsp. vegetable oil
1 tsp. sesame oil
4 bone-in pork loin chops, frenched (about 1/2-inch thick)
1/4 tsp. each salt and freshly ground pepper
2 Tbsp. sesame seeds
2 green onions, nely chopped
Directions:
1. Stir brown sugar with rice wine vinegar, soy sauce, ginger, vegetable oil and
sesame oil until combined. Toss marinade with the pork chops. Marinate for 10
minutes. Remove pork from marinade. Transfer marinade to small saucepan and
cook set over medium heat for 3 to 5 minutes or until syrupy and thick.
2. Meanwhile preheat George Foreman Grill for 5 minutes with lid closed. Season
pork all over with salt and pepper. Place on grill, cook for 8 to 10 minutes or until
internal temperature reaches 160°F for medium.
3. Brush cooked marinade over pork chops. Garnish with sesame seeds
and green onions.
Tip: Get your butcher to French the pork chops or substitute boneless pork loin
chops, if desired.
HARVEST HAM PANINI
Ingredients:
2 slice of whole grain bread
2 ounces deli ham
½ apple or pear, thinly sliced
¼ cup shredded 2% cheddar cheese
1 tablespoon butter
(optional) Thinly sliced onion
Directions:
Spread ½ tablespoon butter to each slice of bread. Place one slice of bread, butter
side down, on grill. Top one slice of bread with ham, apple/pear, onion, cheese. Add
remaining slice of bread, butter side up, to Panini. Preheat your George Foreman
grill and grill for 4 to 7 minutes or until golden brown.
6
®
WARRANTY AND CUSTOMER SERVICE INFORMATION
For service, repair or any questions regarding your appliance, call the
appropriate 800 number in this book. Please DO NOT return the product to the
place of purchase. Also, please DO NOT mail product back to manufacturer,
nor bring it to a service center.
You may also want to consult the website listed on the cover of this manual.
Three-Year Limited Warranty
(Applies only in the United States and Canada)
What does it cover?
• Any defect in material or workmanship provided; however, Spectrum Brands,
Inc.’s liability will not exceed the purchase price of product.
For how long?
• Three years after the date of original purchase.
What will we do to help you?
• Provide you with a reasonably similar replacement product that is either new
or factory refurbished.
How do you get service?
• Save your receipt as proof of date of sale.
• Check our on-line service site at www.prodprotect.com/georgeforeman, or
call our toll-free number, 1-800-947-3745, for general warranty service.
• If you need parts or accessories, please call 1-800-738-0245.
What does your warranty not cover?
• Damage from commercial use
• Damage from misuse, abuse or neglect
• Products that have been modified in any way
• Products used or serviced outside the country of purchase
• Glass parts and other accessory items that are packed with the unit
• Shipping and handling costs associated with the replacement of the unit
• Consequential or incidental damages (Please note, however, that some
states do not allow the exclusion or limitation of consequential or incidental
damages, so this limitation may not apply to you.)
How does state law relate to this warranty?
• This warranty gives you specific legal rights, and you may also have other
rights that vary from state to state or province to province.
7
POR FAVOR LEA ESTE INSTRUCTIVO ANTES DE USAR EL PRODUCTO.
INSTRUCCIONES IMPORTANTES
DE SEGURIDAD.
Al utilizar cualquier aparato eléctrico siempre deben tomarse precauciones
básicas de seguridad, incluyendo las siguientes:
• Lea todas las instrucciones.
• No toque las superficies calientes. Use las asas o
las perillas.
• Este aparato no está diseñado para funcionar a
través de un reloj automático externo o con un
sistema de control remoto separado.
• A fin de protegerse contra un choque eléctrico y
lesiones a las personas, no sumerja el cable, los
enchufes ni el aparato en agua ni en ningún otro
líquido.
• Todo aparato eléctrico usado en la presencia
de los niños o por ellos mismos requiere la
supervisión de un adulto.
• Desconecte el aparato del tomacorriente cuando
no esté en uso y antes de limpiarlo. Espere que
el aparato se enfríe antes de instalarle o retirarle
piezas y antes de limpiarlo.
• No use ningún aparato eléctrico que tenga el
cable o el enchufe averiado, que presente un
problema de funcionamiento o que este dañado.
Acuda a un centro de servicio autorizado para
que lo examinen, reparen o ajusten. O bien, llame
al número gratuito apropiado que aparece en la
portada de este manual.
• El uso de accesorios no recomendados por el
fabricante del aparato puede ocasionar incendio,
choque eléctrico o lesiones a las personas.
• No use este aparato a la intemperie.
• No permita que el cable cuelgue del borde de la
mesa o del mostrador ni que entre en contacto
con superficies calientes.
• No coloque el aparato sobre ni cerca de las
hornillas de gas o eléctricas ni adentro de un
horno caliente.
• Tome mucha precaución al mover de un lugar
a otro un aparato que contenga aceite u otros
líquidos calientes.
• Para desconectar, retire el enchufe del
tomacorriente.
• Asegúrese de que las placas removibles estén
colocadas y ajustadas correctamente (INSERTE
LAS PLACAS DE LA PARRILLA).
• Este aparato se debe usar únicamente con el fin
previsto.
• Este aparato se debe ser utilizado cerrado
solamente
• Este aparato no está diseñado para ser usado por
personas (incluído niños) con capacidad limitada
física, mental o sensoriales disminuidas y falta de
experiencia o conocimiento que les impida utilizar
el aparato con toda seguridad sin supervisión o
instrucción.
• Se debe asegurar la supervisión de los niños para
evitar que usen el aparato como juguete.
CONSERVE ESTAS INSTRUCCIONES.
Este aparato eléctrico es para uso doméstico solamente.
ENCHUFE POLARIZADO
Este aparato cuenta con un enchufe polarizado (un
contacto es más ancho que el otro). A n de reducir
el riesgo de un choque eléctrico, este enchufe encaja
en un tomacorriente polarizada en un solo sentido. Si
el enchufe no entra en el tomacorriente, inviértalo y
si aun así no encaja, consulte con un electricista. Por
favor no trate de alterar esta medida de seguridad.
TORNILLO DE SEGURIDAD
Advertencia: Este aparato cuenta con un tornillo
de seguridad para evitar la remoción de la cubierta
exterior del mismo. A n de reducir el riesgo de
incendio o de choque eléctrico, por favor no trate
de remover la cubierta exterior. Este producto no
contiene piezas reparables por el consumidor. Toda
reparación se debe llevar a cabo únicamente por
personal de servicio autorizado.
8
CABLE ÉLECTRICO
a) Un cable de alimentación corto es provisto para reducir los
riesgos de enredarse o tropezar con un cable más largo.
b) Existen cables de extensión disponibles y estos pueden
ser utilizados si se toma el cuidado debido en su uso.
c) Si se utiliza un cable de extensión:
1) La clasicación eléctrica marcada del cable de
extensión debe ser, como mínimo, igual a la
clasicación eléctrica del aparato;
2) Si el aparato es del tipo de conexión a tierra, el cable
de extensión debe ser un cable de tres alambres de
conexión a tierra; y
3) El cable debe ser acomodado de manera que no
cuelgue del mostrador o de la mesa para evitar que un
niño tire del mismo o que alguien se tropiece sin darse
cuenta.
Nota: Si el cable de alimentación está dañado, por favor
llame al número del departamento de garantía que aparece
en estar instrucciones.
Loading...
