George Foreman GFS0172SBC User guide
GFS0172SB
GFS0172SBC
GFS0090SB
SMOKELESS GRILL
PARRILLA SIN HUMO
GRIL SANS FUMÉE
USE AND CARE MANUAL
MANUAL DE USO Y CUIDADO
GUIDE D’UTILISATION ET D’ENTRETIEN
GFS0090SB
GFS0172SB
GFS0172SBC
www.georgeforemancooking.com
1
PLEASE READ AND SAVE THIS USE AND CARE BOOK.
IMPORTANT SAFEGUARDS.
When using electrical appliances, always follow basic safety precautions to
reduce the risk of fire, electric shock, and/or injury, including the following:
• Read all instructions.
• Do not touch hot surfaces. Use handles
or knobs.
• The appliance is not intended to be
operated by means of an external timer or
separate remote-control system.
• To protect against electrical shock do not
immerse cord, plugs, control probe, or
appliance in water or other liquid.
• Close supervision is necessary when any
appliance is used by or near children.
• Unplug from outlet when not in use and
before cleaning. Allow to cool before putting
on or taking off parts and before cleaning
the appliance.
• Do not operate any appliance with a
damaged cord or plug, or after the
appliance malfunctions or has been
damaged in any manner. Contact customer
support or call the appropriate toll-free
number in this manual.
• The use of accessory attachments
not recommended by the appliance
manufacturer may cause injuries.
• Do not use outdoors.
• Do not let cord touch hot surfaces or hang
over edge of table or counter.
• Do not place on or near a hot gas or electric
burner, or in a heated oven.
• Extreme caution must be used when moving
an appliance containing hot oil or other hot
liquids.
• Always attach control probe to appliance
first, then plug cord in the wall outlet. To
disconnect, adjust the heat setting dial to
the O position (Off), then remove plug from
wall outlet.
• Be sure the nonstick grill plate, drip tray, and
probe are assembled to the base properly
(see HOW TO USE).
• Do not use this appliance for other than
intended use.
• This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities,
or lack of experience and knowledge,
unless they have been given supervision or
instruction concerning use of the appliance
by a person responsible for their safety.
• Children should be supervised to ensure
that they do not play with the appliance.
For model GFS0172, use only George
•
Foreman temperature-control probe (part
no. GFS0172-02). For model GFS0090, use
only George Foreman temperature-control
probe (part no. GFS0090-02).
SAVE THESE INSTRUCTIONS.
This product is for household use only.
GROUNDED PLUG
As a safety feature, this product is equipped
with a grounded plug, which will only t into a
three-prong outlet. Do not attempt to defeat
this safety feature. Improper connection of the
grounding conductor may result in the risk of
electric shock. Consult a qualied electrician
if you are in doubt as to whether the outlet is
properly grounded.
TAMPER-RESISTANT SCREW
Warning: This appliance is equipped with a
tamper-resistant screw to prevent removal of
the outer cover. To reduce the risk of re or
electric shock, do not attempt to remove the
outer cover. There are no user-serviceable
parts inside. Repair should be done only by
authorized service personnel.
2
ELECTRICAL CORD
a) A short power-supply cord is provided to
reduce the risks resulting from becoming
entangled in or tripping over a longer cord.
b) Extension cords are available and may be
used if care is exercised in their use.
c) If an extension cord is used:
1) The marked electrical rating of the extension
cord should be at least as great as the
electrical rating of the appliance;
2) If the appliance is of the grounded type, the
extension cord should be a grounding-type
3-wire cord; and
3) The cord should be arranged so that it will
not drape over the counter top or tabletop
where it can be pulled on by children or
tripped over.
Note: If the power cord is damaged, please
contact the warranty department listed in these
instructions.
GETTING TO KNOW YOUR GRILL
GFS0172SB
4
5
GFS0090SB
1
2
3
4
7
† 1. Nonstick grill plate
(part no. GFS0172-01)
(part no. GFS0090-01)
2. Probe receptacle (not shown)
† 3. Control probe
(part no. GFS0172-02)
(part no. GFS0090-02)
4. Handle
5. Base
† 6. Drip tray
(part no. GFS0172-03)
(part no. GFS0090-03)
6
8
7. Heat setting dial
8. Signal light
† 9. Rubber feet (under base)
(part no. GFS0172-04)
(part no. GFS0090-04)
Note: † indicates consumer replaceable/
removable parts.
Product may vary slightly from what is
illustrated.
3
HOW TO USE
This product is for household use only.
GETTING STARTED
• Remove all packing material, any stickers, and the plastic band around the
power plug.
• Remove and save literature.
• Please visit www.prodprotect.com/georgeforeman to register your warranty.
BEFORE FIRST USE
1. Wash grill plate, drip tray, and base in warm
water and dish soap. Dry thoroughly. Do not
get the probe wet.
Note: When using the grill for the rst time, you
may notice smoke or a slight odor during the rst
few minutes if there is still oil on the plates from
the manufacturing process. This is normal.
Caution: Control probe must always be
completely dry before use.
2. Place drip tray into base. (A)
3. Fit the grill plate onto the base. It only ts
with the curved end of the grill plate over the
curved indentation of the base. (B)
TO OPERATE
1. Insert control probe into probe socket (C) and
plug the cord into a standard electrical outlet.
2. Turn the heat setting to the desired setting.
See Cooking Guide for suggestions. The
signal light will come on to indicate the unit is
heating.
3. When the signal light goes out, the unit is
ready.
4. Signal light will cycle on and off during
cooking as the unit operates to maintain the
desired temperature.
Tips
• To avoid damaging the nonstick surface, do not use aerosol nonstick spray,
sharp utensils or cut food on the cooking surface of the unit. Use silicone, heat-
resistant rubber or wooden utensils.
Caution
• Because some countertop nishes are more affected by heat than others, use
care not to place grill on surfaces where heat may cause a problem.
• Grill surface is hot during use.
• Do not use the grill without the drip tray or base.
A
B
C
4
COOKING GUIDE
The following chart is meant to be used as a guideline only. Cooking time will
depend on the thickness of the food. To be sure your food is cooked, USDA
recommends using a meat thermometer to test for doneness. Insert the meat
thermometer into the thickest part of the meat until the temperature stabilizes.
FOOD SETTING
(preheat)
TIME
(minutes)
NOTES
Bratwursts (brats) High 25-30 minutes This is the cook time for raw
brats. If you rst boil the
brats in water (or beer) for 12
minutes, you can reduce the
grill time to 5-10 minutes.
Hamburgers (4 oz)cooked to 140F
High 6-12 minutes Time varies due to thickness
of the hamburger and your
preferred level of doneness.
Steaks (12 oz) High 8-15 minutes Time varies due to the
thickness of the steak and your
preferred level of doneness.
Salmon (6 oz) High 13-20 minutes Time varies due to the
thickness of the salmon.
Pork Chops (8 oz):
Thick cut ribeye
Chicken breast
(6oz)
High 10-25 minutes Time varies due to the
thickness of the pork chop.
High 15-25 minutes Time varies due to the
thickness of the chicken
breast.
Vegetables
(zucchini, yellow
Medium or
High
6-12 minutes Time varies due to thickness of
the vegetable slices.
squash, red onions,
and bell peppers)
Warming
hamburger or
hotdog buns
Low or
Medium
4-6 minutes Open and atten buns. Turn
to warm both sides halfway
through the time.
The GFS0090SB and GFS0172SB grills produce up to 80% less smoke than the
George Foreman indoor/outdoor grill (GFO201) when grilling 1/4 lb. beef burgers
(20% fat, 80% lean) with clean grill plates and drip trays.
5
CARE AND CLEANING
Caution: To avoid accidental electric shock and burns, unplug from
outlet before cleaning, allow your grill to cool completely.
This product contains no user serviceable parts. Refer service to qualied
service personnel.
1. Unplug, remove control probe and allow the unit to cool completely before
cleaning.
2. Wipe control probe with a damp cloth and dry thoroughly. Do not immerse
control probe in water.
3. Remove grill plate. Lift out and empty drip tray.
Wash the base in warm water with dish soap.
Drip tray and grill are dishwasher-safe (D) or
can be hand washed. Dry thoroughly. Do not
immerse the unit in water unless control probe
has been removed.
4. Do not use steel wool pads or other abrasive
cleaners on the cooking surface as they may
damage the nonstick coating. To remove
cooked-on food, use a plastic bristle brush or
nylon mesh pad.
D
E
STORAGE
1. Once all the parts of the unit are clean and
dry, insert the control probe into the probe
socket to lock pieces together. (E)
2. To save space, store unit on its side as
shown. (F)
F
6
WARRANTY AND CUSTOMER
SERVICE INFORMATION
For support or any questions regarding your appliance, call the appropriate 800
number listed within this section. Please DO NOT return the product to the place of
purchase. Also, please DO NOT mail product back to manufacturer, nor bring it to a
service center. You may also want to consult our Product Protection Center at www.
prodprotect.com/georgeforeman .
Three-Year Limited Warranty
(Applies only in the United States and Canada)
What does my warranty cover?
• Your warranty covers any defect in material or workmanship provided; however, the liability
of Spectrum Brands Inc. will not exceed the purchase price of product.
How long is the warranty period?
• Your warranty extends three years from the date of original purchase with proof of
purchase.
What support does my warranty provide?
• Your warranty provides you with a reasonably similar replacement product that is either
new or factory refurbished.
How do you get support?
• Save your receipt as proof of date of sale.
• Visit the online service website at www.prodprotect.com/georgeforeman, or call toll-free
1-800-947-3745, for general warranty service.
• If you need parts or accessories, please call 1-800-738-0245.
How does state law affect my warranty?
• This warranty gives you specific legal rights. You may also have other rights that vary from
state to state or province to province.
What does my warranty not cover?
• Damage from commercial use
• Damage from misuse, abuse or neglect
• Products that have been modified in any way
• Products used or serviced outside the country of purchase
• Glass parts and other accessory items that are packed with the unit
• Shipping and handling costs associated with the replacement of the unit
• Consequential or incidental damages (Please note, however, that some states do not allow
the exclusion or limitation of consequential or incidental damages, so this limitation may
not apply to you.)
Are there additional warranty exclusions?
• This warranty shall not be valid where it is contrary to U.S. and other applicable
laws, or where the warranty would be prohibited under any economic sanctions,
export control laws, embargos, or other restrictive trade measures enforced by the
United States or other applicable jurisdictions. This includes, without limitation,
any warranty claims implicating parties from, or otherwise located in, Cuba, Iran,
North Korea, Syria and the disputed Crimea region.
7
POR FAVOR LEA ESTE INSTRUCTIVO ANTES DE USAR EL PRODUCTO.
INSTRUCCIONES IMPORTANTES
DE SEGURIDAD.
Al utilizar cualquier aparato eléctrico siempre deben tomarse precauciones
básicas de seguridad, incluyendo las siguientes:
• Lea todas las instrucciones.
• No toque superficies calientes. Use las asa o
las perillas.
• Este aparato no esta diseñado para ser
operado por un reloj marcador de tiempo
externo o sistema de control remoto.
• A fin de protegerse contra una descarga
eléctrica, no sumerja el cable, los enchufes o
el aparato en agua ni ningún otro líquido.
• Todo aparato utilizado cerca de los niños o por
ellos mismos, requiere la supervisión cercana
de un adulto.
• Desenchufe el aparato del tomacorriente
cuando no esté en uso y antes de limpiarlo.
Permita que se enfríe antes de instalarle o
retirarle las piezas y antes de limpiarlo.
• No opere ningún aparato que tenga un cable
o enchufe dañado o después de presentar un
fallo en su funcionamiento o si ha sido dañado
de manera alguna. Póngase en contacto con
servicio al cliente o llame al número gratis
apropiado que aparece en este manual.
• El uso de accesorios no recomendados por
el fabricante del producto podría ocasionar
lesiones personales.
• No utilice en el exterior.
• No permita que el cable toque superficies
calientes ni que cuelgue del borde de la mesa
o del mostrador.
• No coloque el el aparato sobre o cerca de una
hornilla de gas o eléctrica caliente ni dentro de
un horno caliente.
• Se debe tener extrema precaución al mover un
aparato que contenga aceite caliente u otros
líquidos calientes.
• Siempre instale primero la sonda del control
de temperatura al aparato y luego enchufe
el cable al tomacorriente. Para desconectar,
ajuste el control de temperatura a la posición
“0” (apagado), luego retire el enchufe del
tomacorriente.
• Asegúrese de que la placa de cocción
andiadherente y la sonda estén ensambladas
correctamente en la base (ver la sección de
CÓMO USAR).
• No utilice el aparato para otro fin que no sea
para el que ha sido diseñado.
• Este aparato no está diseñado para ser
utilizado por personas (incluyendo los niños)
con su capacidad física, sensorial o mental
reducida, o que no tengan experiencia ni
conocimiento, a no ser que hayan sido
supervisadas o instruidas acerca del uso del
aparato por una persona responsable por su
seguridad.
• Los niños deben ser supervisados para
asegurar que estos no jueguen con el aparato.
• Para el modelo GFS0172, solo use la sonda
del control de temperatura de George
Foreman (pieza no. GFS0172-02). Para el
modelo GFS0090, solo use la sonda del
control de temperatura de George Foreman
(pieza no. GFS0090-02).
CONSERVE ESTAS INSTRUCCIONES.
Este aparato eléctrico es para uso doméstico solamente.
ENCHUFE DE TIERRA
Como medida de seguridad, este producto está
equipado con un enchufe de tierra que se conecta
a un tomacorriente de tres patas. No trate de
alterar esta medida de seguridad. La conexión
impropia del conductor de tierra puede resultar
en el riesgo de descarga eléctrica. Consulte a
un electricista calicado si tiene alguna duda en
cuanto a si la salida es correcta a tierra.
TORNILLO DE SEGURIDAD
Advertencia: Este aparato cuenta con un tornillo
de seguridad para evitar la remoción de la cubierta
exterior del mismo. A n de reducir el riesgo de
incendio o de choque eléctrico, por favor no trate
de remover la cubierta exterior. Este producto no
contiene piezas reparables por el consumidor. Toda
reparación se debe llevar a cabo únicamente por
personal de servicio autorizado.
8
CABLE ÉLECTRICO
a) Un cable de alimentación corto es provisto para reducir los
riesgos de enredarse o tropezar con un cable más largo.
b) Existen cables de extensión disponibles y estos pueden
ser utilizados si se toma el cuidado debido en su uso.
c) Si se utiliza un cable de extensión:
1) La clasicación eléctrica marcada del cable de
extensión debe ser, como mínimo, igual a la
clasicación eléctrica del aparato;
2) Si el aparato es del tipo de conexión a tierra, el cable
de extensión debe ser un cable de tres alambres de
conexión a tierra; y
3) El cable debe ser acomodado de manera que no
cuelgue del mostrador o de la mesa para evitar que un
niño tire del mismo o que alguien se tropiece sin darse
cuenta.
Nota: Si el cable de alimentación está dañado, por favor
llame al número del departamento de garantía que aparece
en estar instrucciones.
Loading...
