GENPOWER GBG 10i, GBG 20i User Manual

INVERTER PORTABLE GENERATOR
USER MANUAL
PLEASE READ THIS MANUAL CAREFULLY.
IT CONTAINS IMPORTANT SAFETY INFORMATION.
Adres / Adress : ASO 2. Org. San. Böl. 2010 Cad. No:18
06909 Temelli Sinca n / ANKARA
Tel / Phone : +90 (312) 641 32 22 (pbx)
: +90 (312) 641 32 32 - 35
Faks / Fax : +90 (312) 641 32 23
E-Posta / E-mail info@genpower.com.tr
Web www.genpower.com.tr
1
Thank you for buying GENPOWER Invert er Generator.
This book includes the operation and maintenance of GBG 10i and GBG 20i. T ells you to make the correct use and maintenance of the generator set.
GENPOWER ret ains its right to amend t his guide, thus will not notify later or bear any responsibility. No duplicator is permitted without written permission.
As one permanent part of t he generator, the guide will be kept with the generator when the generator is transferred.
Please pay special attent ion to the following words:
WARNING: This sign indicat es that if you do not operate according to the guide, serious accidents involving casualties can be caused.
LOO K O UT: T his sign indicat es that if casualty is caused or the equipment is damaged by incorrect operation, you can contact with the store
where you bought the product, if you have any questions about the generat or.
NO TE: If t here is any failure of the generator, or if you have any questions about it , please consult the st ore where you bought t he product.
WARNING: Warning as long as you operat e according to the guide, the GENPOWER generator will be safe and reliable.
Please read and understand the guide without fail before you use it, or else casualties or damage of the equipment will be caused by incorrect operat ion.
2
INDEX PAGE
1. SAFETY
3
2. CO MPONENTS IDENTIFICATIO N
5
3. CHECK BEFO RE O PERA TION
7
4. STAR T TH E ENGIN E
11
5. USAGE O F TH E ENGINE
15
6. TURN OFF TH E ENGINE
21
7. MAINTENANCE
23
7.1 Change the oil
24
7.2 Maintenance of the air filte r
25
7.3 Maintenance of the spark plug
27
8. TRANS PO RT / STO RAGE
29
9. EXAMINE AND REPAIR TH E BREAKDOWN
31
10. TECHNICAL SPEC IFICATION
33
3
1. SAFETY
For safe operation;
WARNING:
-If you operate t he GENPOWER generator according to t he guide, the generator will run safely. P lease read and understand the guide without fail before you use it, or else casualties or damage of the equipment will be caused by incorrect
operation.
-T he exhaust contains toxic CO. Do not run the generator in insufficient ventilated area. Make sure to provide enough air.
-T he gasoline is very easy t o burn or explode under specific conditions. Keep away from cigarettes or spark when refueling the generator. Always refuel in a
well-vent ilated location and turn off the engine before refuel. Clean the overflowed gasoline immediately.
-Each time before you start the engine, you must do check it first, avoiding accident s or damage of the equipment.
-T he generator must be run at a place at least one meter away from t he buildings or other equipments. Children and pets must be kept away from the operating
area. Keep away from rot at ing parts while t he generator is running.
- Operate the generator on a level surface. If the generator is tilted, fuel spillage may result.
- Do not operate the generat or in the rain or in the snow, preventing wetting it.
- Know how to stop the generator quickly and understand operation of all the controls. Never permit anyone to operat e the generat or without proper
instructions.
4
Environmental Prote ction Measures
• Be careful when choosing a generator to run the place, for not to disturb the environment and in order to avoid noise pollution.
Generator would disturb the environment less, do not do the sound use echo.
• Engine oil drain into a suitable container not to ground or water canal.
Safe ty Labels
These labels warn you of those latent dangers that can cause serious accidents involving casualties. Read carefully the labels, the safety warnings and
precautions described in this manual carefully. If a label comes off or becomes hard to read, please cont act the store where you bought the product and change them.
5
2. CO MPONENT IDEN TIFICATIO N
6
Controlling Panel
Intelligent gas-saving valve:
When the engine is disconnect ed from the electrical equipment, the velocity of the generator will slow down automat ically; when it is connected with it, the
electric charge will make t he generator ret urn to a proper rotate speed. This installation is used to reduce t he fuel consumption during t he running process.
WARNING:
-When the elect rical equipment needs disconnect ing from t he electric power, the intelligent gas-saving system can not run effect ively.
-When the generat or is connect ed with the high electric charge at the same time, turn off the intelligent gas-saving valve to minish the change of middle
pressure.
-When the generat or is operated under direct current, please turn off the intelligent gas-saving valve.
Close “off” position: It means the intelligent gas-saving system is closed, and the rot ate speed of the generator is kept on a level higher t han t he standard
rotat e speed.
7
3. CHECK BEFO RE O PERA TION
WARNING: Check the generator, keep it on a horizontal surface without fail, and ensure that the engine is turned off.
1. Check the Engine Oil Level:
WARNING: Using nondet ergent engine oil or 2-stroke engine oil may shorten t he generator’s service life.
Please use high-detergent, premium quality 4-stroke engine oil, certified to meet or exceed U.S. automobile manufacturer’s requirements for API (American
Petroleum Instit ute.) Service Classification SG, SF.
Please choose t he appropriate viscosity for the average temperature in your area.
SAE Viscosity Grades
AMBIENT TEMPERATURE
Loosen t he cover screw and remove the side maintenance cover.
Remove t he oil filler cap, and wipe the dipstick wit h a clean rag. Check the oil level by inserting t he dipstick in the filler hole without screwing it in.
If the oil level is below the end of t he dipstick, refill wit h recommended oil up to the top of t he oil filler neck.
8
WARNING:
-Running the engine with insufficient oil can cause serious engine damage.
NO TE: T he “ Oil Alert System” will automat ically stop the engine before the oil level falls below the safe limit. However, to avoid the inconvenience of an unexpected shutdown, it is st ill advisable t o visually inspect the oil level
regularly.
2. Check the Fuel Level:
- Only use specified gasoline.
- Check the fuel level, if the fuel level is low, refuel the fuel t ank until the level as specified.
- Never use machine oil, gasoline mixture or non-clean gasoline.
- Dirt, dust or water intake should be avoided from the fuel tank.
- After refueling, tighten the fuel filler cap securely.
9
WARNING:
-T he gasoline is very easy to burn or explode under specific conditions. Be careful not to spill fuel when refueling. Spilled fuel or fuel vapor may ignit e.
If any fuel is spilled, make sure the area is dry before starting the engine. Screw down t he gas filler cap after filling the gasoline.
- Refuel in a well-ventilated area with the engine st opped. Do not smoke or allow flames or sparks in the area where the engine is refueled or where gasoline is stored.
-Avoid repeated or prolonged cont act with skin or breathing of vapor. Keep out of reach of children.
Fuel tank capacity: GBG 10i: 2,1 liter GBG 20i: 3,2 liter
10
3. Check the air filter
Check the air cleaner element to be sure it is clean and performs well. Dismantle the repair cover, loosen the screw on the cover of the air filter, and
then dismantle the cover of the air filter to check the cleaner element. P lease clean or change the element if necessary.
LOO K O UT: Never run the engine without the air cleaner element. Rapid engine wear will result from contaminants, such as dust and dirt, being
drawn through t he carburetor, into the engine, resulting in quick wear and t ear of the engine.
11
4. STAR T TH E ENGIN E
Before st arting the engine, cut off the load from the alt ernat ing current socket on the engine.
a) T urn the fuel cap lever fully clockwise t o the ON (open) posit ion.
NO TE: T urn the fuel cap vent lever to the OFF (close) position when
transporting the generator.
12
b) T urn the engine swit ch to the ON (open) position.
c) Turn the choke lever to the ST ART position.
NO TE: Do not use the choke when t he engine is warm or the air temperature is
high.
13
d) Pull t he starter grip lightly until you feel resistance, then release the hold slowly by hand.
e) Move the choke lever to the RUN position as the engine warms up.
WARNING: If the engine stops and will not rest art, check the engine oil level before troubleshooting in other areas.
14
O peration at high altitudes
At high alt itudes, the standard carburetor air or gas mixture will become excessively dense, causing the decrease of the engine's functions, and increase
of gas consumption.
To enhance the performance of the engine in high-alt it ude areas, you can make special adjust ments to carburetor. If you use the engine at an altit ude of over 1500 meters (5000 feet ), please ask the authorized agent of GENPOWER to
modify the carburetor.
Even though you use the proper nozzle, the horsepower of the engine will still decline 3.5% as the altit ude increases every 300 meters (1000 feet). If these
adjustments are not made, the altitude will have greater influence on power.
WARNING: The nozzle of the engine is designed for high altit ude areas. If it is put to use in low altitudes, the outputting power may decline and become too hot, and even the engine will be damaged seriously because the
rat io of the air and burning gas is too low.
15
5. USAGE O F TH E ENGINE
WARNING:
- In order to prevent getting an elect ric shock because of incorrect operation, the engine should be eart hed. T he earth port of the engine and the outside earth source are connected by a thick cable.
- As spare elect rical source for buildings, the connection between generator and other elect ric power system must be operated by professional elect ricians.
And the operation must comply with the relat ed laws and electric regulations. Otherwise, the current of the engine may feed back to the public circuit. In this case, if the workers from electric power company or other people t ouch the wire
when transmitting electricity, they may be shocked by electricity to death. On t he other hand, when public electricity power is stored, t he engine may burn, explode, or cause fire to the building's electric power syst em.
LOO K OUT:
- Do not exceed rated power, and the total watt of the connected electrical equipments should be considered.
- Do not exceed the fixed current limit of socket.
- Do not link the engine household circuit, or else t he engine or the household circuit would be damaged.
- DO NOT MODIFY the engine for other unrealized purposes.
16
Please comply with the following regulations:
- When an extension cable is required, be sure to use a tough rubber sheathed flexible cable (IEC 245 or equivalent).
- Limit length of extension cables; 60 m for cables of 1.5 mm² and 100 m for cables of 2.5 mm² . Long extension cables will lower usable power due to
resistance in the ext ension cable.
- Keep the generat or away from other electric cables or wires such as commercial power supply lines.
WARNING:
- The alt ernat ing and the direct electrical source can be used at the same time. If you use bot h at the same time, be sure not to exceed the total power for AC
and DC. The DC receptacle can be used while t he AC power is in use. Most appliance motors require more than t heir rated wattage for startup.
Use of al ternating current
1. St art the engine, and make sure the indicator light (green) is on.
2. Make sure that the switch of the electrical equipment to be used has been turned off, and then plug the generator into the electrical equipment.
17
LOO K OUT:
- Substantial overloading that continuously light s the overload indicator light (red) may damage the generator. Marginal overloading that temporarily lights
the overload indicator light (red) may shorten the service life of the generat or.
- Be sure t hat all appliances are in good working order before connecting t hem to the generator. If an appliance begins to operat e abnormally, becomes
sluggish, or stops suddenly, turn off the generator engine switch immediately. Then disconnect the appliance, and examine it for signs of malfunct ion.
The outputting and overloading indictor lights
- If in a good working order, the outputting indicator light (green) is on.
- If t he generator overloads or there is short circuit inside the electrical machine it links to the outputting indicator light (green) will go out, while the
overloading indicator light (red) will lighten. At this t ime, t he current that transmits to the linked electrical equipment will be cut off. If the red indicator light is on, you should turn off the engine, and examine why it is overloaded.
Before connect ing an appliance to the generator, check that it is in good order, and t hat it s electrical rating does not exceed that of the generat or. T hen connect
the power cord of the appliance, and start the engine.
18
WARNING: After the generator is st arted, the red and the green light s may lighten at the same time. If t he red light goes out aut omat ically in five
seconds, it is in working order. If the red light is still on, please consult the authorized agent of GENPOWER.
Use of the dire ct current:
The direct current stock is only applicable t o charge the automatic battery (12V).
During the operat ion process of the direct current, turn the intelligent gas-saving valve to the OFF (close) posit ion.
First connected the charging cable to the direct current socket of the generat or, and then link t o the junct ion side of the battery.
19
WARNING:
- In order to prevent spark appearing around the battery, first link the charging wire to t he generator, and then to the battery. The dismantlement should start
from t he battery.
- Before you link the charging wire to the battery which is installed on the car, first disconnect the battery’s ground wire until the charging cable is dismantled.
Such operation will help t o prevent short circuit or spark when you contact the junction side of the battery with t he car’s frame or body uncertainly.
LOO K O UT:
- Do not try to start the motor when the generator is still connected with the batteries, or else the generat or will be damaged.
-T he positive pole of the charging cable should be connected to t he negative pole of the battery. Do not confuse of t he polarity of t he charging cable, otherwise serious results such as damage of the generator and the batt ery will be
caused.
WARNING:
-T he battery will release explosive gas, so it must be kept away from spark, flame or cigarettes. Please charge it in the well-ventilated area.
-T he battery contains vitriol (electrolytic cell). Once your skin or your eyes have direct contact wit h it, they will be burnt. Please wear exposure seat and
mask. If the elect rolyte spatters on your skin, clean it with water immediat ely. If the electrolyte spatters on your skin, clean it with water immediately for at least 15 minutes, and go to the doctor on once.
-T he elect rolyte is toxic. If you swallow it, drink a lot of water or milk at once. T hen drink magnesia
latex or vegetable oil, and go to the doctor at once.
-Keep the children away from it.
20
Start the engine:
LOO K OUT:
- The DC receptacle can be used while the AC power is in use.
- An overload DC circuit will trip the DC circuit protector (push button comes out). If this happens, wait a few minutes before pushing in the circuit protector
to resume operation.
Low oil level alarming system
Low oil pressure alarming system is designed to prevent engine damage caused by an insufficient amount of oil in the crankcase. Before the oil level in the
crankcase falls below a safe limit , the oil alarming system will automatically shut down the engine (the engine swit ch will remain in the ON position).
Aft er low oil pressure alarming system has closed the engine, if you operat e the starter again, the low oil pressure alarming light will lighten, and the engine will
not run. If this happens, please add machine oil.
21
6. TURN OFF TH E ENGINE
If you want to stop the engine urgently, t urn the switch of the engine to the OFF (close) position.
Normal use:
1. Switch off the connected equipment and pull t he inserted plug.
2. T urn the engine switch to the OFF position.
22
3. T urn the fuel cap vent lever fully counterclockwise to the “OFF” position.
LOO K O UT:
- Be sure the fuel cap vent lever and the engine switch are ‘‘OFF’’ when stopping, transporting and/or storing the generat or.
23
7. MAINTENANCE
The purpose of the maintenance and adjustment schedule is to keep the generator in the best operating condition. Inspect or service as scheduled in the
table below.
WARNING:
Please turn off the engine before you carry out any repair. If the engine needs to run when repairing, make sure the operat ing area is well ventilated, as the exhaust cont ains toxic CO.
LOO K O UT:
Use genuine GENPOWER parts or their equivalent. The use of replacement parts which are not of equivalent quality may damage the generator.
The Plan Chart for Maintenance
ITEM
Maintaining time by st ages
please maintain the generat or in specified months or hours
either month or hour is ok
usage at a
time
the first
month or 20
hours Every 3 months or 50
hours
every 6 months or
100 hours
every yearor
200
hours
Machine oil
check
change
√ Air filt er
check
clean
(1)
Spark plug
clean
-
adjustment
√ change
Burning container
clean
Every 300 hours (2)
Valve Clearance
clean
-
adjustment
(2)
Fuel
tank and filter
clean
(2)
Fuel line
check
Every 2 years (p
lease change if necessary
).
NO TE:
1. If used in dirty places, the generator should be maintained more regularly.
2.Unless the user has proper tool or he is a specialist on machine, the maintenance of the above items should be one by the authorized agent of
GENPOWER.
24
3. When it is used for business purpose, you should write down the operating hours of t he generator to confirm the correct maintenance cycle.
7.1 Change the oil
Drain the oil while the engine is still warm t o assure rapid and complete draining.
LOO K O UT:
- Before you discharge the oil, make sure the swit ches on the ventilat ing pole of the gas burning lid and the engine is on the OFF position.
1. Loosen t he screw, and dismantle the repair cover.
2. Dismant le the gas-filling cap.
3. Discharge the dirty oil thoroughly into a container.
4. Fill the recommended machine oil, and check t he machine oil level.
5. Reinstall the repair cover and screw.
25
Please clean your hands wit h soap after dealing with the machine oil.
WARNING:
Please dispose of used motor oil in a manner that is compatible wit h the environment. We suggest you t ake it in a sealed cont ainer to your local service stat ion for reclamation. Do not t hrow it in the trash or pour it on the ground.
7.2 Maintenance of the air filte r
Dirty air filter will block the clean air from entering t he carburetor. In order to prevent the carburetor from failure, please maintain the air filter regularly. If the
generator is used in very dirty places, it will thus need to be maintained more regularly.
WARNING: Do not use gasoline or solvent wit h low burning point to clean the engine, as they are easy to burn and explode under specific conditions.
LOO K O UT:
Never run the generator without the air cleaner. Rapid engine wear may result.
26
1. Loosen t he screw on the repair cover, and dismantle the repair cover.
2. Loosen the screw on the cover of the air filter, and then dismantle the cover of the air filt er.
3. Wash the element in a non-flammable or high flash point solvent and dry it thoroughly.
4. Soak the element in clean engine oil and squeeze out the excess oil.
5. Reinstall the core of air filter and its cover, and screw the screw on the cover.
6. Reinstall the repair cover and tighten the cover screw securely.
27
7.3 Maintenance of the spark plug
Recommended spark plug: A7RC To ensure the engine to work in good order, t he clearance of the spark plug
must be correct, and has no accumulated charcoal.
1. Remove the spark plug maintenance cover.
2. Remove the spark plug cap.
3. Clean any dirt from around the spark plug base.
4. Use a spark plug wrench to remove the spark plug.
28
5. Examine the spark plug with your naked eyes. If the insulator has crazed or has fragments, you should discard the spark plug. If t he old spark plug needs to
be used continually, you must clean it up wit h a brush.
6. Measure the clearance of the spark plug wit h a gauge. T he clearance should be 0.6mm to 0.7mm.
7. Install the spark plug carefully, by hand, to avoid cross-threading.
8. After a new spark plug has been seated by hand, it should be t ightened 1/2 turn with a wrench to compress its washer.
If a used plug is being reinstalled, it should only require 1/8 t o ¼ turn aft er being seated.
9. Reinstall the repair cover of the spark plug.
The spark plug must be securely tight ened. An improperly tight ened plug can become very hot and possibly damage t he generator.
29
8. TRANS PO RT / STO RAGE
To prevent fuel spillage when t ransport ing or during t emporary storage, the generator should be secured upright in its normal operating posit ion, with the
engine switch OFF.
The fuel cap vent lever is turned fully count erclockwise to the OFF position.
LOO K O UT:
When transport ing the generator:
-Do not let the gas spill out of the gasoline tank. (The top of the gas-filling t ank should have no gas.)
-When the generator is placed on vehicle, do not run t he engine. You should take the generator down from the car and operate it in the draught .
-When you take the generator to the car, avoid exposing it to sunshine. If it is put in sealed carriage for a long time, the high temperat ure of the carriage may cause t he gas to boiling away, thus leads t o burn.
-Do not drive on a rough road for an extended period with the generator on board. If you must t ransport the generator on a rough road, drain the fuel from
the generator before hand.
Before storing the unit for an extende d period:
1. Make sure the storage area is clean and dry.
2. Drain all gasoline from t he fuel tank into an approved gasoline container.
LOO K O UT:
- Gas is very easy t o burn or explode under specific conditions.
- Smoke and flame are strictly forbidden near the gas.
A. Discharge the gas in the gasoline tank t horoughly into a proper container. B. T urn t he engine swit ch t o the OFF position, and tighten the drain screw securely.
30
C. Screw down the oil-discharging screw on the lid of the spark plug. With the drain screw loosened remove the spark plug cap, and pull the starter grip 3 to 4
times t o drain t he gasoline from the fuel pump. Reinstall the spark plug cap on the spark plug securely.
3. Change the machine oil.
4. Remove the spark plug and pour about a tablespoon of clean engine oil into the cylinder. Crank t he engine several revolutions to distribut e the oil, then
reinstall t he spark plug.
5. Slowly pull t he starter grip until resist ance is felt. At this point, the piston is coming up on its compression stroke and bot h the intake and exhaust valves are
closed.
Storing t he engine in this position will help to prot ect it from internal corrosion.
31
9. EXAMINE AND REPAIR TH E BREAKDOWN
When the engine will not start:
Is there fuel in the tank? If not, fill gas into the gas tank
Yes
Is the switch of the generator on the If not, switch of the engine. ON position?
Yes
Is there enough machin e oil in the If not, add enough machine engine? oil.
Yes
Is there any spark outside the sp ark If not, change the spark plug? plug.
If not, send the generator to the store where No You bought the product.
WARNING: Make sure that t here is no gas spilling out of the spark
plug. The overflowed gas may catch fire.
Control: Dismantle the spark plug, clean out the filth around it. Dismantle the spark plug, enclose it into the cover of it. Earth the side pole on the lid of the air cylinder. When you pull the staring hold, the spark must spray from the
clearance.
32
If the engine can not be started;
Does the outputting indicator If not, fill gas into the gas light lighten? tank.
No No
Does the overloadin g indicator light lighten?
Examine whether the electrical equipment or installations have any breakdown?
Have breakdown If not, send the generator tp the store where you bought the product.
Change the electrical equipment or installations or ask Someone to repair.
Turn off the engine and r estart it.
No electric power in the direct current socket:
Is the defender of the direct circuit If not, open the defender of open? the direct circuit.
If yes, send the generator to the store where you bought the product.
33
10. TECHNICAL SPEC IFICATION
Engine
GBG 10i
GBG 20i
Model
144F
Engine type
4 stroke, OHV, one cylinder
Bore x stroke
(mm)
43.
5 x 36
Compression ratio
8.
5:1 Rotate speed
5200 rev (intelligent accelerograph closes)
Cooling system
Force air
-
cooled
Ignition system
Transist or
Lubricat ion oil capability
(liter
) 0.25 0.4 Capability of gasoline tank
(liter
) 2.1 3.2 Spark plug
A7RC
Noise level (ISO8528
-
10) 64dB/7m
• Fuel hand pump for easy start at cold weather.
• Choke syst em.
34
Generator
GBG 10i
GBG 20i
Frequency (Hz)
50
Rated voltage (V)
230 Rated current (A)
3.7 7.4 Rated output (kVA)
0.85 1.7
Max. output (kVA)
0.95 1.9
Power
fact or cosΦ
0.8
Direct current
12 V, 6A
Phase number
One
phase
(mono
phase)
Ignition system
Electronic
Starting system
Recoil
Engine rot ation speed
3600 d/d
Continuous operating time
5 hours
Fuel consumption (lt / hour)
0.66 1.1
Dimension (cm)
48x26x38
55x30x46
Noise level (dbA)
64 dB/7m (LWA 90 dB)
Intelligent gas
-
saving valve:
Available
AC circuit breaker
Electronic
Oil warning
Available
Overload warning
Available
High capacity air filter
Available
• Inverter t ype
• Sensitive automat ic voltage regulator (AVR)
• Insulat ion class: H
• Frequency regulation max ±2%.
• 2 items, 230 V - 7 A earted AC outlet plug
• Elect ronic overload circuit breaker
• Intelligent gas saving valve
• DC battery charge output socket , DC overload current protection
• Low oil indicator light, overloading indicator light, out-putting indicator light
• Earth t erminal
• Heat and impact resistant poly carbon exterior plastic body
• Super silent running, lightweight
• Low fuel consumption with intelligent gas-saving valve, environment friendly
• Easy start with recoil
• External possibility of battery chargers with 12, 6A DC outlet
35
Loading...
