TM
User’s
Manual
Models: 5000, 5500
Digital
Wireless
Headset
®
2
TM
* See “Switching Volume Control Buttons” on page 11.
BACK VIEW
FRONT VIEW
TOP VIEW
Volume control (+)
(*switch feature)
Ear tip
SIDE button
Ear hook
Dual microphone array
Charging port /
Audio input port (Model 5500)
Ear tip
PINCH button
Volume control (-)
(*switch feature)
3
TM
Powerful acoustic processing in a wireless headset!
Congratulations on your purchase of an nXZEN™ headset – the most technically
advanced hands-free wireless headset in the world. Your nXZEN headset delivers
the clearest voice quality, even in noisy traveling conditions. Your nXZEN headset
contains the most powerful Digital Signal Processor (DSP) available in any
Bluetooth® headset, enabling high performance and advanced features and
functions that keep you clearly connected with your world.
FrontWave™ Technology – the “cocoon of quality” around your voice
The nXZEN wireless headset uniquely shields your voice from extraneous noise
using twin microphones and the FrontWave Extreme patented algorithm.
FrontWave generates a "cocoon of quality" around your voice, using a near-field
acoustic beam that only transmits the sounds coming from the area of your mouth.
For optimum results, face away from the loudest or closest noise sources when
practical. This will significantly improve the quality of your transmitted voice, and
ensures a clear conversation in even the noisiest situations.
We hope you enjoy your new nXZEN wireless headset and will delight in the
clearly connected comfort that only the nXZEN wireless headset delivers!
4
TM
Contents
Powerful acoustic processing in a wireless headset! .......................................................... 3
FrontWave™ Technology – the “cocoon of quality” around your voice .............................. 3
Quick Start
Wearing Your Headset With the Ear Hook.......................................................................... 8
Wearing Your Headset Without the Ear Hook..................................................................... 8
Charging the nXZEN Headset............................................................................................. 9
Low Battery State Notification....................................................................................... 9
Turning the Headset On and Off ....................................................................................... 10
Adjusting the Digital Volume Control................................................................................. 10
Switching Volume Control Buttons ............................................................................. 11
Pairing the Headset and Multiple Pairings ........................................................................ 12
Initiate Bluetooth Connection...................................................................................... 13
Switching Between Previously Paired Devices........................................................... 13
Changing the Ear Tip ........................................................................................................ 14
Changing the Ear Hook..................................................................................................... 14
5
TM
Features
Answering a Call ............................................................................................................... 15
Making a Call .................................................................................................................... 15
Mobile Phones with Voice Dial ................................................................................... 16
Last Number Redial.................................................................................................... 16
Muting and Un-Muting the Microphone While on an Active Call................................. 17
Ending a Call..................................................................................................................... 17
Transferring the Call between Mobile Phone and Headset............................................... 18
Call Waiting ....................................................................................................................... 18
Advanced Features
Stereo Music Audio Input (Model 5500)............................................................................ 19
Graphic Equalizer (Model 5500) ....................................................................................... 20
Safety Warnings ................................................................................................................21
Limited Warranty ...............................................................................................................22
FCC Notice ........................................................................................................................ 24
Industry Canada Notice ..................................................................................................... 24
EU Notice .......................................................................................................................... 25
Specifications .................................................................................................................... 26
Gennum Contact Information ............................................................................................ 27
6
TM
Contents of this package
• 1 nXZEN Digital Wireless Headset
• 4 Ear Tips – 2 Small, 1 Medium, 1 Large
• 1 User's Manual
• 1 AC Wall Charger
• 2 Ear Hooks (different sizes)
• 1 Quick Reference Card
• 1 USB Charging Cable
• 1 Stereo Audio Cable (Model 5500 only – to connect to your CD/MP3 player)
• 1 Installation CD (Model 5500 only)
7
Quick Start
TM
Quick Start
The headset can be worn on either ear. Rotate the ear hook to wear the headset
on the left or right ear.
The volume control buttons can be switched so that the volume (+) button is
always the top button. See “Switching Volume Control Buttons” on page 11.
To change the ear tip, see “Changing the Ear Tip” on page 14.
To change or remove the ear hook, see “Changing the Ear Hook” on page 14.
8
Quick Start
TM
Wearing Your Headset With the
Ear Hook
1. Loop the ear hook behind your ear.
2. Press the headset's ear tip into your ear
until you have a snug fit.
3. Point the headset's microphones toward
your mouth.
Wearing Your Headset Without
the Ear Hook
1. Press the
headset's ear
tip into your
ear until you
have a snug fit.
2. Point the
headset's
microphones
toward your
mouth.
1
2
1
3
2
9
Quick Start
TM
Charging the nXZEN Headset
Before use, charge the headset using the supplied charger. The headset contains
a rechargeable battery.
1. Turn the headset off.
2. Connect the charger to the headset.
3. Connect the charger to the electrical wall outlet. The light indicator turns on
during charging. The light indicator turns off when the charge is complete
(approximately 2 hours).
4. Disconnect the charger from the wall outlet and the headset.
Low Battery State Notification
When you hear a beep (tone) every minute, your headset is warning you that
there is 15 minutes of battery life left. The warnings increase to every 10 seconds
when there is 5 minutes or less battery life. When the battery holds no charge the
headset powers off and needs to be recharged.
Caution: The nXZEN headset includes a lithium polymer rechargeable battery.
Use only the included charger and specified method for charging the battery. If
the headset is damaged beyond repair or the battery has reached the end of its
useful lifespan, dispose of the used battery in accordance with local regulations.
