Pulse
WiFi Repeater/Extender
Quick Installation Guide
Router range
Pulse placement
Pulse range
The Pulse can be used in two different
setups: either you can connect via an
Ethernet cable or via a wireless connection to
your router.
A connection via Ethernet cable gives the
best performance.
1. Placement
In the house illustration above, the router
range indicates the range of your own router.
For optimal performance of your Pulse, it
is advised to place your Pulse in the Pulse
placement area. Make sure placement is
within range of your router while providing
the most coverage to your house.
The Pulse can be placed on a desk or
mounted on a wall.
For the best performance, it’s recommended
to place the Pulse ‘free’ from obstacles
or objects.
If desired, it is possible to mount your Pulse
on a wall using the wall mount points on the
back of the device.
The Drilling Template can be downloaded
from the Genexis website at:
https://genexis.eu/download-portal/#pulse
2. Connect to the power
Connect the supplied power adapter to
your Pulse and plug the adapter into an AC
power socket.
3. Turn on your Pulse
Turn on your Pulse by fl ipping the switch on
the side of the device.
After approximately 1.5 minutes the Status
LED should turn green and stop blinking.
Your Pulse if now ready for use.
4. Synchronize with your network
Synchronizing with your wireless home
network can be done using two different
methods:
• Automatically via WPS pairing
• Manually via your web browser
2.4GHz
5GHz
Internet
Status
WPS
Status
Internet
2.4GHz button
5GHz button
WPS button
Initiate WPS pairing on your router
› Press the WPS button on your router.
You may need to consult your router’s
manual on how to initiate WPS on
your router.
› After approximately 1 minute the
internet LED on your Pulse should turn
yellow and the WPS LED should turn off.
› Your Pulse is now synchronized with your
home network.
If the internet LED turns red or off, retry to
initiate WPS pairing on your Pulse and on
your router.
WPS pairing
Initiate WPS pairing on your Pulse
› Press and hold the WPS button on your
Pulse until the LEDs start blinking.
› After approximately 30 seconds the WPS
LED should be the only LED blinking.
› The device is now ready to pair with
your router.
SSID: Genexis-xxxx
WiFi-Key:
**************
WARNING: POWER RATING:12V 2A
GUI: http://Genexis-xxxx
Username: user
Password: user
Made in China
Model: Pulse
P/N: 99618025
Version: 1.0
Date: 2018-05
Manual pairing
Connect to your Pulse WiFi
Consult the information label at the bottom
of your Pulse. It shows the SSID of the WiFi
network (i.e. Genexis-xxxx). Connect to this
WiFi network with your computer.
Login to your Pulse settings page
Open a web browser on your computer and
login to the following page by replacing the
fi eld “xxxx” in http://Genexis-xxxx with your
SSID. Use the following login credentials:
Username: user
Password: user
Confi gure network settings
You will now be presented with the screen
above. From that screen, select your home
network and fi ll in the login credentials of
your home network.
After approximately 2 minutes the internet
LED turns yellow.
You have now connected your Pulse to your
home network. Your connection to the web
interface will be interrupted.
To continue using internet on your computer,
connect to your home network again.
5. Connect Pulse to your router
To get the best performance of your Pulse,
connect one side of an Ethernet cable to the
WAN port of your Pulse and to one of the
LAN ports of your router.
Hereby, Genexis declares that the radio
equipment type Pulse is in compliance with
Directive 2014/53/EU. The full text of the EU
declaration of conformity is available at the
following internet address:
https://genexis.eu/red/pulse
www.genexis.eu
Revision 1.7. - September 2018
Copyright © 2018 Genexis B.V. All rights reserved.
From now on the web interface for your
Pulse can only be reached by connecting to
your home network. Continue with the steps
described by “Login to your Pulse settings
page”.
For more information about your Pulse, have
a look at the Full Installation Guide
(https://genexis.eu/download-portal/#pulse)
or contact your service provider.
