General Tools HG15 User Manual
HydroGuage
Manometer
Gas Pressure Guage
No. HG15
INDUSTRIAL
Instruments
No. HG15
U P C 41225
FILLS LIKE A
WATER GLASS
No more
troublesome
air bubbles
MAGNETIC
MOUNTING
DIRECT READING
No Plus or Minus
read ings to add
together as in
old fashioned
“U” tube
• Measures gas pressure easily and
efficiently
• Direct reading, no plus or minus readings
to add together as in old fashioned
U-tubes
• Replaces ordinary U-tube manometers
• Fills like a glass of water,
no more troublesome air bubbles
• Strong magnet for mounting
• Heavy-duty construction
• Made of industrial grade,
flexible PVC plastic
• Lightweight
• Easy to use
• No assembly required
SPECIFICATIONS:
• HG15 water column height: 15"
• Plastic: 30" to 36" of industrial grade
flexible plastic
• Hose fitting: All brass
• Includes: Mounting magnet
6
810 35 412 25
1
Avoid injury: Always wear OSHA/ANSI approved eye
protection (goggles, face shield) when using tools.
www.generaltools.com
Made in China
©2009 GENERAL TOOLS & INSTRUMENTS
™
New York, NY 10013
Montreal, Canada H9R 1E1
• Measures gas
pressure easily
and efficiently
• Direct reading,
no plus or minus
readings to add
together as in
old fashioned
U-tubes
• Replaces ordinary
U-tube manometers
• Fills like a glass
of water, no more
troublesome
air bubbles
• Strong magnet
for mounting
• Heavy-duty
construction
• Made of industrial
grade, flexible
PVC plastic
• Lightweight
• Easy to use
• No assembly
required
+3
+2
+1
0
-1
-2
-3
