INTRODUCTION

The IRT3 is a small and lightweight non-contact thermometer
that measures the surface temperature of an object from a
distance by using an IR sensor to measure its thermal
radiation. A laser pointer indicates the target area (spot)
whose temperature is being measured.

SAFETY INSTRUCTIONS

The IRT3’s targeting laser is a Class 2 type that emits less
than 1mW of power at a wavelength of 655nm. Avoid direct
eye contact with laser light radiation. U.S. law prohibits
pointing a laser beam at aircraft; doing so is punishable by
a fine of up to $10,000 and imprisonment.

WHAT’S IN THE BLISTER PACK

The IRT3 comes in a plastic blister pack with two
pre-installed batteries and this user’s manual.

PRODUCT OVERVIEW

Figure 1 shows the locations of the controls, indicators and
physical features of the IRT3.

E

D

F

I

G

A

B

2

H

C

Fig. 1. The IRT3’s controls, indicators
and physical features

A. Meas. (measure) button B. MODE button
C. Wrist strap attachment bar
D. Laser pointer E. IR sensor window
F. LCD
G. Thermometer battery compartment
H. Laser battery compartment
I. Laser Identification/

Certification/Warning/
Safety Labels
(on upper back of unit)

AB C D

Fig. 2.
All possible display
indicators and
their meanings

G

A. Low Battery icon
B. Laser Enabled icon
C. Indicates operation in Scan mode

(with Meas. button pressed and held)
D. Indicates measured value is being held
E. Celsius unit selected
F. Fahrenheit unit selected
G. Measured value

E

F
