Clamp, drill and fasten
in one simple set-up!

This easy-to-use system simplifi es fabrication and increases productivity
of face frames, cabinet doors and other woodworking assemblies. In
one simple operation, you can align, securely clamp, bore pocket
holes and screw components together—right out of the box.

Now available through Woodcraft Supply:

woodcraft.com/generaltools

This is the cutting-edge
Face Frame Jig System

The E•Z Pro™
Pocket Hole Jig

has everything you need to
make fl ush, corner and angle
pocket hole joints.

#850

The E•Z Pro

™

Doweling Jig

lets you make perfectly aligned
dowel joints every time.

#851

The E•Z Pro

™

Dovetail Jig

lets you make dovetail
and box joints —
through or half-blind.

#861

The E•Z Pro

™

Mortise & Tenon Jig

lets you make perfectly
matched mortise & tenon
joints with one jig.

#870

Crown King
Crown Molding Jig

helps you make seamless,
perfectly mitered interior
and exterior corner joints.

#880

Face Frame Jig

WOOD JOINING TOOLS

4

General Tools & Instruments

UPC NO.

02194 6 8561 Face Frame Jig System X1
02195 3 8562 Face Frame Jig System X2
02191 5 856 Face Frame Jig
02193 9 856T Heavy Duty T-Track
02192 2 856S Carriage Stops (2)
00052 2 32 Step Drill
02122 9 8492 Square Drive Screwdriver Bit
08498 9 8598 Square Drive Fasteners (100)

PROFESSIONAL FACE FRAME PROFESSIONAL FACE FRAME
JIG SYSTEMJIG SYSTEM

Professional Face Frame Jig System X1 - #8561

Professional Face Frame Jig System X2 - #8562

• Accommodates Stock from 1-1/4" to 2-1/2" Wide

•

Pocket Hole Spacing Adjustment 3/4" to 1-1/2"

• Stock Thickness Adjustment 3/4" to 1"

• Includes Step Drill with Locking Collar

and Face Frame Fasteners

•

Patent # US 6,394, 712 B1

• 2 Face Frame System Jigs

• 2 Face Frame System Heavy Duty T-Tracks (20”)

• 1 Face Frame System Carriage Stop Set (2 Stops)

• 1 Face Frame System Step Drill

• 1 Face Frame System Square Drive Screwdriver Bit

• 1 Face Frame System Square Drive Fasteners (100 Fine)

• 1 Face Frame System Jig

• 1 Face Frame System Heavy Duty T-Track (20")

• 1 Face Frame System Carriage Stop Set (2 Stops)

• 1 Face Frame System Step Drill

• 1 Face Frame System Square Drive Screwdriver Bit

• 1 Face Frame System Square Drive Fasteners (100 Fine)

Assemble
professional
quality face
frames and
cabinet doors
using General’s

NEW patented

Face Frame
Jig System

SAVE TIME!

INCREASE

PRODUCTIVITY!

SAVE TIME!

INCREASE

PRODUCTIVITY!

THE

FIRST

OF ITS KIND:

Clamp, Drill and Fasten In One Simple Set-Up

Crown Molding Jig

WOOD JOINING TOOLS

5

General Tools & Instruments

Professionally Cut Perfectly Mitered Interior and Exterior
Corner Joints – in the same alignment as they are installed
on the wall

Eliminates:

• Difficult angle calculations

• Coping of joints

• Compound-angle cutting

• Auxiliary fences

• Confusing upside-down

miter box positioning

CEILING

WALL

Create the Crown in Four Easy Steps

1. Measure

2. Set-Up

3. Cut

4. Install

45º Spring Angle
Crown Molding Jig with
Adapter for 52º and 38º Spring Angles

UPC NO.

02200 4

881

A Cutting Guide For Crown Moldings

No. 881

Mortise & Tenon Jig

WOOD JOINING TOOLS

6

General Tools & Instruments

General Tools offers one of the best assortments of wood
joining jigs available including our new Mortise and Tenon
Jig, The Dovetailer II Jig, and the award-winning EZ Pocket
Hole Jig and EZ Jointer Clamp Kits. These heavy-duty

woodworking tools are ideal for furniture building,
cabinetry making and other professional carpentry
projects. In addition, we offer plenty of wood joining
accessories such as screws, plugs and drill bits.

The Mortise & Tenon joint has been used for thousands of years. Not until now has
someone figured out how to provide a fast and straightforward all-in-one solution
for cutting both a matching mortise & tenon with a single affordable jig.
General’s E•Z Pro

™

Mortise & Tenon Jig is ready to use right out­of-the-box to produce the widely used 1/4” mortise and
tenon joint. Using a plunge router with the jig,
woodworkers of all levels can quickly and easily
cut both mortises and tenons ranging from
1/4" to 1/2" thick, and from 1" to 3"
wide. Without difficulty, this unit
can easily handle wood stock
ranging from 1/2" to 1­1/2" thick and can cut
multiple mortises in a
single long piece.

No. 870

Patent Pending

● Create professional matching Mortise & Tenon Joints
Right Out of the Box

● The first of its kind,
all-in-one precision
machined Mortise &
Tenon Jig

● Produce 1/4", 3/8" and
1/2" Mortise and Tenons

● Includes: 1/4" high-speed
steel spiral upcut router bit and User’s Manual

• Length: 14-1/2" Width: 4-1/2" Height: 4" Weight: 2-1/2 lbs

• Kit includes: 1/4" Spiral upcut router bit, Bushing kit, Wrench, User’s manual

UPC NO.

26008 3

870

7

General Tools & Instruments

Dovetail Jig

WOOD JOINING TOOLS

“The Easy Way to Make

Professional Furniture Joints”

THE

• Self-aligning design ensures that both ends of the

dovetail joint match-up evenly every time

• Sturdy machined one piece aluminum construction

• Easily adjusts the dovetail interference to create

loose or tight joints

• Portable to your worksite or home workshop

• Use with hand or table router

• New table router control knobs assure safe,

comfortable and accurate use

• No need to bolt to the jig onto workbench like many

expensive dovetail jigs

• Integrated clamps allow precise clamping of jig to

work piece

• Accommodates boards of any widths

• Length: 12"; Width: 3"; Height: 3";

Weight: 2-lbs. 1.1oz.

Kit includes

: 1/2" Dovetail Router bit, User’s Manual

UPC NO.

00861 9

861

With the E•Z Pro

™

Dovetailer II and your router, you can cut

Professional Dovetail Joints, Simply and Accurately ...

Right Out Of The Box!

Patent No. 7828024

No. 861

DOVETAIL JIG

Cuts Through Joints

Cuts Half-Blind Joints

Pocket Hole Jig

WOOD JOINING TOOLS

8

General Tools & Instruments

Pocket hole joints are sturdy and simple to make
with a drilling jig. By drilling steeply pitched counter
bores in one joint member, you can drive self-

tapping screws into the other without pilot holes.
Ideal for leg and rail connections and face frame
cabinet construction.

No. 849

No. 850

• Ideal for leg-and-rail connections, cabinet construction, sneaking
screws into tight-squeeze spots or fastening picture frame miters

• Heavy-duty aluminum extrusion and hardened steel bushings

• By drilling steeply pitched counterbores in one joint member, you can
drive self-tapping screws into the other joint member without pilot
holes

• Built to be portable or bench mounted

849 KIT INCLUDES

• 1 Pocket Hole Jig; 3/8" Step Drill Bit; 1 3/8" Drill Stop and Hex Wrench;

6" Steel Square Drive Bit; Square Drive Screws, Instructions

UPC NO.

00515 849

UPC NO.

00850 0 850

850 KIT INCLUDES

• 1 Pocket Hole Jig; 3/8" Step Drill Bit; 1 3/8" Drill Stop and Hex Wrench;

6" Steel Square Drive Bit; 25 Course Square Drive Screws;
25 Fine Square Drive Screws; 25 Wooden Pocket Hole Plugs, Hard Molded
Carrying Case and Instructions

Pocket Hole Jig Kits

Pocket Hole Jig

WOOD JOINING TOOLS

9

General Tools & Instruments

SMART DESIGN

• Heavy-duty aluminum extrusion

& hardened steel drill bushings

• Built to be portable or bench

mounted, and designed with a
built-in clamping system

THREE TYPES OF
POCKET HOLE JOINTS

• Flush, Corner & Angle

For the Professional and the Do-It-Yourselfer

Photos property of

Woodworker’s Journal

Patent No. 6,254,320

For more information visit generaltools.com/joiningtools

Award Winning Ingenuity!

850

849

Woodworking

Pocket Hole Jig Kit

Doweling Jig Kits

WOOD JOINING TOOLS

10

General Tools & Instruments

Our E•Z Pro Doweling Kits includes everything you
need to make beautiful wood joints like a pro! This
heavy-duty aluminum jig simplifies the doweling
process, allowing you to create Edge-to-Edge,

Right Angle and Edge-to-Surface joints with little
effort. No. 8401 Dowel Accessory Kit can be used
with both the No. 840 and No. 841 Doweling Jigs.

• Dowels add mechanical strength to butt joints and
keep miters lined up during clamping

• The pointed notches on the working edges
of our jig centers the drill bit automatically
for precise registration

• Create 3 types of dowel joints: Edge to edge, right
angle, edge to surface, as well as 3 sizes of dowel
joints; 1/4", 5/16" and 3/8"

• Ideal for 5/8", 3/4" and 1" thick stock

• Kit includes: 1 Dowel Jig; 3 Brad Point Drill Bits;
1/4", 5/16", 3/8"; 3 steel stop collars, 1/4", 5/16"
and 3/8" with Hex Wrench, 6 Dowel Center Points;
2 each of 1/4", 5/16" 3/8", supply of wood dowels,
Instructions

UPC NO.

000317

841

Photos property of Woodworker’s Journal

Patent No. 7,001,118

851 DELUXE DOWELING JIG KIT

The Deluxe Doweling Jig Kit allows users to produce three types of strong, precision dowel joints in
three sizes (1/4 in., 5/16 in. and 3/8 in.) with little effort. Whether creating edge-to-edge, right angle corner
or right angle edge-to-surface dowel joints, the heavy duty aluminum jig effectively simplifies the process
and is anodized in a gold color to impede corrosion. The pointed notches on the working edges of the jig
center the drill bit automatically for precise registration. The included wood dowels add mechanical strength
to butt joints and keep miters lined up during clamping.

DOWELING JIG KITS

• Kit includes: 1 Dowel Jig; 3 Brad Point Drill Bits (1/4 in., 5/16 in. and 3/8 in.
diameter); 3 Steel Stop Collars (1/4 in., 5/16 in. and 3/8 in. diameter) with Hex
Wrench; 3 Bushings (1/4 in., 5/16 in. and 3/8 in. diameter); 6 Dowel Center
Points (2 each of 1/4 in., 5/16 in. and 3/8 in. diameter); 3 sets of 1-1/2 in. long
Wood Dowels (24 each of 1/4 in., 5/16 in. and 3/8 in. diameter); Wood Glue;
Instructions

UPC NO.

08401 9 851

No. 841

No. 851

841 DELUXE DOWELING JIG KIT

11

General Tools & Instruments

For clean joints that need to be strong and fastener-free, there’s almost
no substitute for the dowel joint. However, if dowel holes are even
slightly askew, the dowels won’t mesh rendering the joint unusable.
General’s Pro Doweling Jig offers a simple, versatile way to produce
precision edge-to-edge, right angle, or edge-to-surface joints. The Kit
features: three size dowels (1/4", 5/16" and 3/8"), and the jig has three
different drilling positions designed for stock of 5/8", 3/4" and 1" thick.
Steel stops allow you to vary the depth of the cut. Perfect for joints that
will be press fit or glued.

PRO-DOWELING KIT

• A precision jig that assures accurate line up of dowel holes in
furniture and carpentry

• Revolving hardened sintered turret has six twist drill sizes

• Instructions included

• Drill sizes:

3/16", 1/4", 5/16", 3/8", 7/16", 1/2"

• Kit includes:
1 Doweling Jig;
3 Brad Point Drill Bits, 1/4", 5/16", 3/8";
Dowel Centers Set from 3/16" ID to 1/2" OD;
3 Drill Stops, 1/4", 5/16", 3/8";
30 Dowel Pins, 10 each 1/4", 5/16", 3/8";
Wood Glue

UPC NO.

24120 7 840

840

General’s Pro Doweling Jig is a precision jig that
assures the accurate line-up of dowel holes in
furniture and carpentry. Simply clamp the jig onto

your workpiece to quickly and accurately drill
holes for dowel pins requiring exact alignment in
the edge, end or surface of your work.

PRO-DOWELING KIT

Pro Doweling Kit

WOOD JOINING TOOLS

WOOD JOINING TOOLS

12

General Tools & Instruments

Jointer Clamps

General’s E•Z Pro™Jointer Clamp Kit is the alternative to
expensive jointers. Now, you can straight-line rip crooked
boards using your table saw! Just attach your crooked
board to a piece of straight stock using the Jointer

Clamps and run the stock along the rip fence to rip the
crooked board. Works in two easy passes. Great for use
with long stock. Patented swing arm design allows you to
accurately rip wide boards with ease.

• The long awaited alternative to expensive jointers!

• Straight line rip crooked boards on your table saw

• Get a dead-flat edge every time, with no extra waste

• The jointer clamps work on any length stock up to 2" thick

• Instructions included

UPC NO.

00001 0

846

Photos property of
Woodworker’s Journal

TRU-EDGER JOINTER CLAMPS

E-Z Jointer Clamp Kit (Model 846) under US Patent #7000519, is the long-awaited alternative
to expensive jointers. Now, you can straight-line rip or joint crooked boards using your table
saw! Just attach your crooked board to a piece of straight stock using the Jointer Clamps
and run the stock along the rip fence to rip the crooked board. The Jointer Clamp works in
two easy passes and is great for use with long stock.

Patented Swing Arm design allows you to accurately rip wide boards with ease

Precision Drill Guide

WOOD JOINING TOOLS

13

General Tools & Instruments

• Attaches to all 3/8" and 1/2" power drills

• Cross slide lock for accurate shaping and carving

• 3/8" capacity drill chuck with key

• Positive stop for accurate drill depth control

• Dual locking knob and handle holds precise angle setting

• Folds flat for tool box storage

• Easy-to-read protractor scale has 5° graduations (0° - 45° left or right)

• V-guides automatically center round stock for drilling

• Self centering channel for edge drilling

UPC NO.

23059 1 36/37

45°– 0° 0°–45°

TM

36/37

The AccuDrill Precision Drill Guide adds a whole new level of
accuracy to your standard power drill. The AccuDrill is great
for angle drilling, doweling, plug cutting and even edge
sanding. With the easy-to-use protractor scale, you can

adjust the Drill Guide in five degree increments from 0-45°,
left and right. In addition, V-Guides on the base permit
drilling through dowel or other rounded stock. Attaches to
all 3/8" and 1/2" power drills. Folds for tool-box storage.

 For Round Bar Center Drilling  Straight Edge Center Drilling



PRECISION DRILL GUIDE







Pocket Hole Accessories

WOOD JOINING TOOLS

14

General Tools & Instruments

Pocket-hole joinery or pocket-screw joinery is one of
the best methods for joining two pieces of wood to
ever come down the pike. Fixing a squeaky chair, or
a wiggly table, is as easy as adding a few pocket

holes and screws to pull the separating pieces
together. General’s Pocket Hole Screws No. 8497
and 8498 are used specifically for this purpose and
are offered in both fine and coarse thread.

POCKET HOLE PLUGS

Pocket Holes are often hidden from sight on the back
surface of a face frame, under a table top, or on the
back of picture frame. What do you do about
unattractive pocket holes that will be visible on a
finished product the answer? Pocket hole plugs!
These wood plugs, made from 100% hardwood,
can make the pocket holes beautifully disappear.

UPC NO. DESCRIPTION QTY.

02123 6 8495 Pocket Hole Plugs, Hardwood 50

8495

E•Z™ PRO STEP DRILL BIT

The E-Z Step Drill Bit is great for creating pocket
hole joints or counter boring. The 3/8" bit is made
of high speed steel and includes a drill stop and
hex wrench for accurate setting of drill depth.
This item can also be used as a replacement bit
for General’s Pocket Hole Jig Kit (#849).and
Deluxe Pocket Hole Jig Kit (#850).

• 3/8" x 6" (9.5 x 152mm) step drill bit

• High speed steel

• Ideal for creating pocket hole joints and
counter-boring

• Includes 3/8" (9.5mm) steel drill stop with
hex wrench

UPC NO.

00052 2 32

32

8497
8498

No. 8497 shown
actual size of 1-1/4"

POCKET HOLE SCREWS

• Self-tapping

• Use a coarse thread screw in soft material (8497)

• Use a fine thread screw in hardwoods (8498)

• Nickel-plated

• Pan Head

• Size: 1-1/4"

UPC NO. DESCRIPTION QTY.

08497 2 8497 Coarse Screws 100
08498 9 8498 Fine Screws 100

8497 shown

Pocket Hole & Dowling Accessories

WOOD JOINING TOOLS

15

General Tools & Instruments

PLUG CUTTERS

Whether you’re building cabinets, toys, decks, furniture
or railings, wooden plugs are a neat way to cover up the
screw heads. Made from hardened alloy steel, General’s
Plug Cutters will cut a 3/8-inch plug from any wood
stock and eject it, whether it's chucked in a press or
hand-held drill. This is a great economical bit, perfect
for homeowners.

• General’s Plug Cutters produce accurate plugs
for covering screw holes in decking, flooring
and other woodworking projects

• Permits choice of matching or contrasting plugs
for decorative effect

• Engineered to start cutting plugs easily with
hand-held drills or drill press

• Cutter will produce and eject straight plugs
from stock up to 3/4" thickness

• Made of hardened alloy steel

• Individual sizes:

UPC NO. SHANK DIA.

23024 9 31A 3/8" 3/8" dia.
23030 0 31B 3/8" 1/2" dia.
23033 1 31C 3/8" 5/8" dia.

• Set of 3 Diameters - 1/4", 3/8", 1/2":

UPC NO. SHANK

23036 2 S31 3/8"

31B

31C

31A

SQUARE DRIVE BITS

For use with General’s Pocket Hole Screws. These
drive bits are essential for building decks, benches,
tables and other woodworking projects. General’s
Square Drive Bits have a hardened steel tip that
assures perfect fit and lasts longer.

• #2 Square drive bits

• 3" (76mm) length

• 6" (152mm) length

• Use with deck screws

DOWEL CENTERS

• General’s dowel centers are the quickest and
most accurate method to locate, transfer and
match dowel holes

• Made of nickel plated steel

• Set includes: 8 pcs., two of each size:
1/4", 5/16", 3/8", 1/2" diameter

UPC NO.

25099 5 888 Dowel centers

888

DRILL STOP SET

• For use on twist or brad point drills to prevent
excessive drill penetration

• Positive depth control assures exact hole depths
for multiple drilling jobs

• Black oxide finish on cold rolled steel

• Includes hex wrench

UPC NO. SIZES INCLUDED

23096 6 S838 3/16" dia.,1/4" dia.,

5/16" dia., 3/8" dia.,
7/16" dia., 1/2" dia.

S838

DOWEL ACCESSORY KITS

• 8401 Kit includes: 3 Drill Bits - 1/4", 5/16", 3/8"; 3 Drill Stop
Collars, 6 Dowel Centers,
10 ea. Fluted Dowel Pins 1/4", 5/16", 3/8"

• Replacement bit for General’s E•Z Pocket Hole Jig Kit (No. 849)

• Accessories Kit for General’s Pro Doweling Kit (No. 840) and
E•Z Dowel Kit (No. 841)

• 841014 Kit includes: 12-1/4" Dowel Pins,
1-1/4" Brad Point Drill Bit, 1-1/4" Drill Stop Collar, 2-1/4"
Dowel Centers, 1 Hex Key

• 841516 Kit includes: 12-5/16" Dowel Pins,
1-5/16" Brad Point Drill Bit, 1-5/16" Drill Stop Collar, 2- 5/16"
Dowel Centers, 1 Hex Key

• 841038 Kit includes: 10-3/8" dowel Pins,
1-3/8" Brad Point Drill Bit, 1-3/8" Drill Stop Collar, 2-3/8"
Dowel Centers, 1 Hex Key

UPC NO.

08401 9 8401 Dowel Accessory Kit
02119 6 841014 1/4" Dowel Accessory Kit
02120 2 841516 5/16" Dowel Accessory Kit
02121 9 8410383/8" Dowel Accessory Kit

8401

841516

UPC NO. DESCRIPTION

02122 9 8492 2-#2 Square Drive Bits

3" and 6" long

Wood Joinery

WOOD JOINING TOOLS

16

General Tools & Instruments

As an FSC (Forest Stewardship Council), certified
company, General’s Wood Joining Program includes wood
based products that are manufactured in accordance with
FSC standards. The FSC is an independent, non-

governmental, not-for-profit organization established to
promote the responsible management of the world’s
forests and is nationally represented in more than
50 countries around the world.

FLUTED DOWEL PINS

A fluted dowel pin has a series of parallel grooves
cut along its length providing channels through
which excess glue—that is used to secure the
dowel pin in its hole—can escape as the dowel is
inserted. This relieves the hydraulic pressure that
might otherwise split the timber when the mating
pieces are clamped together. General’s fluted
dowels are ideal for creating strong and secure
joins in furniture, cabinets, trim and special
woodworking projects.

● Made of straight-grained solid hardwood

● Expands when used with water-based glue for

extra tight join

● Fluted for easy insertion

UPC NO. DESCRIPTION QTY.

02101 4 840014 1/4" Fluted Dowel Pins 72
02102 1 840516 5/16" Fluted Dowel Pins 50
02103 8 840038 3/8" Fluted Dowel Pins 35
02104 5 840012 1/2" Fluted Dowel Pins 20

FLAT HEAD PLUGS

● Premium Flat Head Screw hole Plugs have a
tapered tenon to insure a tight fit

● Designed to form a flush finish in furniture and
other woodworking applications

● Paint or stain for a perfect wood-color match or
for accentuated contrast

UPC NO. DESCRIPTION QTY.

02109 0 313038 3/8" Flat Head Plugs, Oak 50
02110 6 313012 1/2" Flat Head Plugs, Oak 50
02113 7 315516

5/16" Flat Head Plugs, Hardwood

50

02114 4 315038

3/8" Flat Head Plugs, Hardwood

50

02115 1 315012

1/2" Flat Head Plugs, Hardwood

40

BUTTON HEAD PLUGS

Button Head plugs are ideal for filling in those
unsightly screw holes and can be installed easily
with wood glue. Button head plugs can be used
for a variety of craft, wood working and furniture
projects.

● When fully-seated, the domed, button head
protrudes above the wood surface and over the
screw hole edge adding a more decorative look

● Slightly tapered plug body to ensure a tight
secure fit

● Wood grain runs in the direction of the plug
width for best match

● Paint or stain for a perfect wood-color match or
for accentuated contrast

UPC NO. DESCRIPTION QTY.

02105 2 311038 3/8" Button Plugs, Oak 50
02106 9 311012 1/2" Button Plugs, Oak 50
02107 6 312038 3/8" Button Plugs, Hardwood 50
02108 3 312012 1/2" Button Plugs, Hardwood 50

840014
840516
840038
840012

313038
313012
315516
315038
315012

311038
311012
312038
312012

840014 shown

313038 shown

311038 shown

Wood Joinery

WOOD JOINING TOOLS

17

General Tools & Instruments

The important characteristics of wood joints are
strength, flexibility, toughness and appearance. Both
exterior and interior temperature changes can cause
major shifts in the moisture content of wood and can

compromise the strength and longevity of a joint.
General’s wood based joining products have been
developed to provide strong joints that adjust to
every day environmental changes.

ROUND HEAD PLUGS

● Premium Round Head Screw hole Plugs with
tapered tenon to insure tight fit

● Designed to form a slightly raised round finish
in woodworking applications

● Paint or stain for a perfect wood-color match or
for accentuated contrast

UPC NO. DESCRIPTION QTY.

02112 0 314038 3/8" Round Head Plugs, Oak 50
02116 8 316038

3/8" Round Head Plugs, Hardwood 50

02117 5 316012

1/2" Round Head Plugs, Hardwood 40

BISCUITS

Wood Biscuits, sometimes referred to as Wood
Plates or Wafers, are used for edge or corner­jointing. When General’s biscuits come into
contact with water based glue they swell, thus
creating a ‘locked’ joint for a strong secure fit.

• Used for Wood Joinery with Biscuit Joiners

• Great for furniture, cabinets and trim

• Biscuits soak up water-based glue for a
tighter wood joint

UPC NO. DESCRIPTION QTY.

02134 2 318000 Size #0 50
02135 9 318010 Size #10 50
02136 6 318020 Size #20 50
02133 5 318050 Size FF 50

318000

314038
316038
316012

314038 shown

SHAKER PEGS

Made from solid hardwood, General’s Classic
Shaker pegs can be useful throughout the entire
house. Install them in the foyer or mud-room,
kitchen, bathroom, child’s room etc. Hang your
favorite coffee mugs, towels, hats, neck ties, toys
and even herbs!

● Create customized pegboards to better organize
your work and living spaces

● Use General’s Shaker pegs to replace damaged
pegs in your pegboards

● Paint or stain for a perfect wood-color match or
for accentuated contrast

UPC NO. DESCRIPTION QTY.

02118 2 317000 Shaker Pegs 2

317000

Shown Actual Size

3-1/2"

Circle Cutters

WOOD WORKING TOOLS

18

General Tools & Instruments

General’s Circle Cutters produce precision circles in
sheet metal, brass, copper, soft steel, aluminum,
plastic, wood and composition materials. Bodies are
constructed of heat treated tool steel for durability.

The replaceable cutter blades are made of high­speed steel for precise and clean cuts. Circle Cutters
are adjustable for cutting various diameter holes.
A hex wrench is included for adjustments.

4" MAX CIRCLE CUTTER

• Round shank circle cutter

• Replaceable high-speed steel cutting blade and
replaceable 1/4" pilot drill

• All adjustments are made with a hex wrench
which is included

• Maximum safe speed is 500 RPM

• For use with drill press only

UPC NO. DESCRIPTION

21003 6 04 4" Circle Cutter
27006 1 4 Replacement Drill
27003 0 4/5 Replacement Blade

• Capacity: 7/8" to 4"

• Shank: 3/8" Round

04

06

5B

55

WHEEL AND CIRCLE CUTTER

• General’s Wheel and Circle Cutter is the only
one that cuts the exact diameter you need
anywhere from 1" to 6" (26 to 152mm)

• Ideal for woodworkers, model builders,
clockmakers, and hobbyists

• Produces precision circles and holes in sheet
metal, brass, copper, aluminum, plastic, wood,
and composition materials

• Change from circle to wheel cutting by simply
reversing the double ended blade

• Sturdy round shank for use in any drill press or
drill stand with 3/8" chuck

• Replaceable double ended 9/32" cutter
blade is made of high-speed steel for
precise clean cuts

• All adjustments are made with a hex
wrench which is included

• Maximum safe speed is 500 RPM

• For use with drill press only

UPC NO. DESCRIPTION

21010 4 06 Circle Cutter
21014 2 5/6/55 Replacement Drill
21013 5 6 Replacement Wheel

• Capacity: 1" to 6"

• Shank: 3/8" Round

6" MAX CIRCLE CUTTER

• Has been a General Tools customer favorite for
more than 30 years

• Adjusts from 1" to 6" (26 to 152mm)
diameter circles

• Replaceable high-speed steel blade and
replaceable 1/4" pilot drill

• All adjustments are made with a hex wrench
which is included

• Maximum safe speed is 500 RPM

• For use with drill press only

UPC NO. DESCRIPTION

21009 8 5B Circle Cutter
21014 2 5/6/55 Replacement Drill
27003 0 4/5 Replacement Blade

• Capacity: 1" to 6"

• Shank: 3/8" Round

WASHER AND GASKET CUTTER

• This tool cuts washers and gaskets in leather,
rubber, cork, graphite, fiber, copper and other
soft materials

• Combination round and square shank permits
use with bit brace or hand drill

• Made of steel with graduated beam to
adjust to diameters from 5/8" to 6-1/2"
(16 to 165mm)

• Replaceable tool steel Cutter Blades
No. 11B

• Two independently adjustable cutter
blades cut inside and outside diameters
simultan eously

• Maximum safe speed is 100 RPM

• For hand held variable speed drills only

UPC NO. DESCRIPTION

21024 1 11
27024 5 11B Replacement blades (Pair)

• Capacity: 5/8" to 6-1/2" (16 to 165mm)

HEAVY-DUTY CIRCLE CUTTER

• General’s industrial quality cutter is most
preferred by professionals

• 1/2" round shank for drill press use

• Replaceable high-speed tool steel blade
and replaceable 1/4" pilot drill

• Markings on beam for easy measurement

• All adjustments are made with a hex wrench
which is included

• Maximum safe speed is 500 RPM

• For use with drill press only

UPC NO. DESCRIPTION

21012 8 55 Circle Cutter
21014 2 5/6/55 Replacement Drill
27015 3 55 Replacement Blade

• Capacity: 1-3/4" to 7-7/8"

• Shank: 1/2" Round

11

Countersinks, Drill Bits, Gages

WOOD WORKING TOOLS

19

General Tools & Instruments

Pilot Bits, countersink and counterbore precision
screw holes in a single operation. Self-Centering
Hinge Bits drill highly accurate pilot holes in cabinet
and door hinges.

Stair gages assure fast and uniform layout in
repetitive work including angle cuts on rafters
and stair stringers.

• The rose pattern cutting flutes assure
chatter free countersinking on steel, brass,
aluminum, plastic, wood & other materials

• Made of high-speed steel with five flutes

• 82° point angle

• Stepped shank for use with 1/4" and 3/8"
chucks

UPC NO.

23047 8 195-1/2
23053 9 195-5/8
23050 8 195-3/4 "

UPC NO. DRILL SIZE DRILL DEPTH SCREW SIZE

22154 4 291 5/64" 1/8" 3 & 4 screw size
22149 0 292 7/64" 7/32" 5 & 6 screw size
22150 6 293 9/64" 5/16" 8 & 10 screw size

195-1/2

195-5/8

CB

A

195-3/4

293

292

291

JIFFY CENTERING PUNCH

• For quickly starting screw holes when attaching
countersunk hardware such as hinges, hasps,
hangers and drawer pulls

• Countersunk end ensures starting hole is
centered in hardware screw hole

• Hardened steel pin

• Length:

2-1/2" (68mm)

• Body diameter: 3/8" (10mm)

UPC NO.

24018 7 806

STAIR GAGE SET

• Brass plated steel stair gage assures fast and
uniform layout in repetitive work including angle
cuts on rafters and stair stringers

• Attaches easily to all metal rafter squares

• Set of 2 pieces

UPC NO.

24009 5 803

806

803

SELF-CENTERING HINGE BITS

• Highly accurate bits are used for drilling pilot
holes in cabinet and door hinges, door butts
and all large and small hardware

• Spring loaded outer guide keeps the high speed

drill centered for perfect pilot holes

• Adjustable drill depth

NO. A B C

195-1/2 1/2" 3/8" 1/4"
195-5/8 5/8" 3/8" 1/4"
195-3/4 3/4" 3/8" 1/4"

ADJUSTABLE PILOT BITS

Drill, countersink and counter-bore precision
screw holes in a single operation with General’s
Adjustable Pilot Bit Set. Featuring four high-speed
bits with adjustable lengths, this set can be a
great time saver for fine carpentry and
woodworking. The 1/4” hex shank allows the set
to be used in both electric drills and power
screwdrivers.

• Drill, countersink and counterbore precision
screw holes in a single operation when doing
fine carpentry and woodworking

• Hardened high-speed pilot bits give long life

• Black oxide finish deters rust

• 1/4" hex shanks prevents slippage in
electric drills and can be used in power
screwdrivers

• Adjustable drill and high performance angle
on countersink

UPC NO. SCREW SIZES

23041 6 34ST Set of 4 Pilot Bits

(Sizes 5 – 14)

34ST

Digital Layout Tools

WOOD WORKING TOOLS

20

General Tools & Instruments

● Digital stainless steel angle rules make precise measurements for easy woodworking

● Calculates interior (inside) and exterior (outside) angles easily and accurately in seconds

● Lock and reverse angle features: for all types of work

● Large easy to read LCD display

● Hinge mechanism allows a full 360 degrees to measure inside/outside and reverse

angles

● Can be zeroed at any point in the swing

• Overall Length for 822: 7" Width: 1-3/8" Depth: 6/8"

• Overall Length for 823: 10-7/8" Width 1-3/8" Depth: 6/8"

UPC No.

00822 7 822 5" Digital Angle Finder
00823 4 823 10" Digital Angle Finder

General has a full range of specialized digital tools
designed for measurement operations necessary
in construction jobs, cabinet making and fine

carpentry. Woodworkers trust the quality, accuracy
and value that General Tools gives them. It’s your job
. . . General Tools make it easier.

1702

828

823

DIGITAL PRECISION PROTRACTOR

The Digital Protractor displays absolute and relative angle
measurements in a large, easy-to-read LCD window

• Installing crown molding, cabinetry, counters, staircases, roofs,
windows or flooring

• Takes the guesswork out of measuring, marking, reading and
transferring angles

• 6" (150mm) stainless steel protractor arm with knurled locking nut

• Large, easy-to-read display

• Absolute and relative measurements

• Range: 0 to 180° • Resolution: 0.05° • Accuracy: 0.1°

• Display can be inverted for easy reading

• Measurement hold function

• Power Source: 1 “CR2023” (3.0V) battery (included)

UPC NO.

26008 6

1702

5" AND 10" DIGITAL ANGLE FINDER RULES

Patent Pending

Patent Pending

DIGITAL SLIDING T-BEVEL

• 2 Tools in 1 - Digital Sliding T-Bevel and
Protractor

• Large digital angle readout

• Holds measurement for transfers

• Reverse Display button, Flip Display button,
Locking Knob for manual measurement

transfer

• 4 function control buttons

• Auto Shut off feature

• 8" Stainless Steel blade

• Impact resistant ABS handle

• Full LCD Display

• Measures and transfers angles

• Range: 0-360°

• Resolution: .05°

• Accuracy: 0.3°

• Voltage: DC 2.5V-3.2V

• Power Source:
1 “CR2032” 3V Lithium battery (included)

UPC NO.

08280 7 828

822

THE 1st

OF ITS KIND!

Calipers & Squares

WOOD WORKING TOOLS

21

General Tools & Instruments

820

SINGLE BAR MARKING GAGE

• 6" (153mm) adjustable bar is nickel plated steel
graduated in 16ths

• Die-cast head

• Fine needle point for precision marking

UPC NO.

24050 7 820

UTILITY COMBINATION SQUARE

• Economy version of the carpenter’s combination
square is perfect for the do-it-yourselfer and
home mechanic

• 12" x 1" (305 x 26mm) steel blade is
graduated in 8ths, 16ths, and 32nds

• Heavy zinc cast head with level and scriber

GRADS

UPC NO. FRONT BACK

24030 9

811

8ths, 16ths 16ths, 32nds

PROFESSIONAL CARPENTER’S
COMBINATION SQUARE

• Specially designed for carpenters and the
woodworking trades

• Machined and enameled cast iron head has
precision level and scriber for producing right
and 45° angles

• 12" x 1" (305 x 26mm) steel blade is
graduated in 8ths, 16ths, and 32nds

• Conforms to government specifications:
GGG-S-656C

GRADS

UPC NO. FRONT BACK

24036 1 812 8ths, 16ths 16ths, 32nds
22193 3 812-CA Clamp Assembly

45°

90°

45°

90°

• No. 147, No. 1478, No. 14712 are heavy-duty
stainless steel construction

• No. 146, No. 1433 are constructed of
non-marring carbon fiber

• Convenient auto-off feature

• Three mode digital display: Decimal Inches,
Fractional and Metric

• Inside, outside, depth & step measurements

• Accuracy: +/- 0.001" +/- 0.02mm

• Resolution: 0.0005", 0.01mm, 1/64"

• Power Source: 1 “SR44” battery (included)

UPC NO. RANGE

01433 7 1433 0 - 3" (0 - 76mm)
01460 3 146 0 - 6" (0 - 153mm)
01470 2 147 0 - 6" (0 - 153mm)
01478 3 1478 0 - 8" (0 - 203mm)
14712 7 14712 0 - 12" (0 - 305mm)

DIGITAL FRACTIONAL CALIPERS

147

812

811

General’s newest “Fraction +” Caliper has a three
mode digital display. Measuring in inches, metric and
fractions it offers everything for the hobbyist to
the professional.

The Combination Squares are specifically designed
for carpenters, the woodworking trade, the
do-it-yourselfer and home mechanics. A necessary
tool for every carpenter and home workshop.

The 146 & 1433 Digital Display The 147, 1478 & 14712

Fractional Display

Layout Tools

WOOD WORKING TOOLS

22

General Tools & Instruments

10" CONTOUR GAGE

• Extra length is ideal for woodworking, linoleum
installation, ceramic tile installation or any job
where contour duplication is essential

• Gage will fit profiles up to 10" long

• Inch/mm graduations on body

• 3" (76mm) deep fingers will measure profiles
up to 1-1/4" (32mm)

• Made from tough, durable plastic

UPC NO.

08330 2 833

General’s Contour Gages can duplicate any shape.
The pins on our gage slide to conform to irregular
surfaces. This tool can be used for pattern and
mold making, duplicating parts and contours.

Great for fitting carpet, floor tiles and linoleum
against door casings and pipes. The ANGLE-IZER™can
replace the need for making templates and can be
used again and again. The Ultimate Template Tool.

6" CONTOUR GAGE

• Ideal for woodworking, linoleum installation, or
any job or hobby where contour duplication is
essential

• Inch graduation on body

• Stainless steel pins

• Component parts are enamel painted and
brass plated

• Size is 6" x 3-1/2" (152 x 89mm) with an
overall travel of 5-1/4" (133mm)

UPC NO.

24116 0 837

837

833

MARKING LUMBER ANGLES FOR PAVER

BRICKS

SPACING AND GAUGING TILING

THE ANGLE-IZER

™

• The unique and versatile ANGLE-IZER

™

The Ultimate Template Tool eliminates
the need for making templates and can
be used again and again. Instructional CD
included.

• The ANGLE-IZER

™

can be set-up in seconds

not only improving quality but saving time

• Just form the tool into the shape of your work
area, then use it to mark your
work-piece to be cut

• Repeat accurate marking for creating bulls
eyes, arches, repetitive angles or shapes

• Tool can be set to mark bricks, tiles,
lumber and laminates

• All the arms are dual-calibrated in inches and
metric measures

• Unique tightening mechanism for one­handed operations

• Fiberglass filled nylon for added strength
and flexibility

UPC NO.

08360 9 836

REPETITIVE MARKING

Patent No. Des. 402,217

836

Layout Tools

WOOD WORKING TOOLS

23

General Tools & Instruments

29

OUTSIDE, INSIDE & SLOPED
ANGLE PROTRACTOR

• Use this protractor/angle finder to measure and
mark the degrees of an angle on outside, inside
and sloped angles

• Fine black graduations from 0° to 165° in
opposite directions

• Brass lock nut

UPC NO.

22148 3 29

PROFESSIONAL QUALITY T-BEVEL

• Our T-bevel is the tool preferred by the craftsperson who wants the finest
quality tools

• Solid mahogany 5-1/2" (140mm) handle with brass trim and locking wing nut

• 10" (254mm) blade

• Conforms to government specifications: GGG-B-211b

UPC NO.

24100 9

829

829

3-1/2"

6"

PRECISION PENCIL COMPASS

• Carpenter quality compass is made of long
lasting die-cast rust proof metal

• Spring tension adjustment for marking up
to 9" (229mm) diameters

• Scribe guide for edge marking

• For use with pencil (included) or slim
ballpoint pen

UPC NO. CAPACITY

24126 9 842 9" (229mm)

PENCIL COMPASS AND SCRIBER

• Designed for marking contours and circles

• Positive wing nut adjustment

• Full-length hardened steel pin in metal frame
for greater rigidity

• Constructed of brass plated steel

UPC NO. CAPACITY

24132 0 843/1 8" (203mm)

843/1

842

General’s Compasses and Layout Tools are
designed for the specialized operations of
measuring and layout necessary in construction

jobs, cabinet-making and fine carpentry.
Woodworkers trust the quality and the value
that General Tools provides.

HOBBY DRILL GAGE

• Heavy gage stainless steel gage
conveniently identifies drill bit sizes

• Etched graduations are filled in black to
give high contrast and will not wear off

• Gage measures 2-3/8" x 6-3/4"
(60 x 172mm) overall

• Stainless steel will not rust

UPC No. SPECIFICATIONS:

22011 0 24 Fractional size drills

1/16" to 1/2" x 64ths

24

Trammels

WOOD WORKING TOOLS

24

General Tools & Instruments

General’s Adjustable Trammels accurately measure
and mark distances that are too great for conven ­tional compasses and dividers. Trammels will
accurately transfer measurements, scribe arcs

and lay out circles. Points can be replaced with
pencils, ballpoint pens, crayons or soap-stone sticks
for marking various materials.

• Draw large circles and measure sizable
distances with the accuracy of a divider

• Fine adjusting screw sets points accurately

• Points are removable and may be replaced with
the pencil holder

• Die-cast bodies with hardened and ground
3" (76mm) needlepoint legs

• Clamp opening for beam is 3/8" x 3/4"
(10 x 19mm)

• Conform to government specifications:
GGG-T-661b

UPC NO.

23090 4 520
31104 7 84P Replacement points (12 per pkg.)

ADJUSTABLE TRAMMELS

• General’s adjustable trammels accurately
measure and mark distances that are too great
for conventional compasses and dividers

• For layouts, marking templates, and drawing
large circles

• 6" (153mm) eccentric points provide fine
adjustments

• Points can be replaced with pencils, ballpoints
pens, crayons, or soapstone sticks for marking
various materials

• Clamps onto beam 5/8" to 1-1/2"
(16 to 38mm) thick of any length

UPC NO.

23093 5 523

PRECISION TRAMMEL SET

• Will accurately transfer measurements, scribe arcs,
and lay out circles too large for conventional
compasses

• Will fit any scale, 1/2" to 1-1/8" (13 to 29mm) wide

• Two scriber points and two pencil points included

• Up to four points can be stored in body

• Free-wheeling thimble for greater precision

• Aluminum knurled body

• Steel collet holds replacement leads, scribers

and crayons

• Points reverse into body for safety

• Ruler not included in set

UPC NO.

23095 9 524

PRECISION ADJUSTABLE TRAMMELS

520

524

523

PROFILE VIEW

PROFILE VIEW

PROFILE VIEW

Accessories

WOOD WORKING TOOLS

25

General Tools & Instruments

General’s Scratch Awl is made from the finest
materials for long life. This tool is designed for
scribing and layout work, starting screw holes and
piercing soft materials.

The Chisel/Plane Blade Sharpener keeps blades razor
sharp. The graduated settings maintain the correct
30° cutting angle necessary for these blades.

CHISEL/PLANE BLADE SHARPENER

• Keeps chisel and plane blades razor sharp

• Graduated settings maintain correct 30° cutting angle on chisel or plane blade

• Spring clamp locks in blades up to 2-5/8" (67mm) wide

• Made of high impact fiberglass reinforced Lexan

®

• Folds for storage

UPC NO.

24024 8 809

809

818

HARDWOOD HANDLE SCRATCH AWL

• Alloy steel blade runs through the handle and is securely
fastened to both the plated steel ferrule and the cap

• Hardwood fluted handle is contoured for comfortable grip

UPC NO. A B

24047 7

818 6-1/2" (165mm) 3-3/4" (95mm)

B

“ORIGINAL” DRILL GRINDING ATTACHMENT

• Engineered to permit sharpening of drill bits to factory accuracy

• Extends the life of drill bits

• Angle adjustments lock in to grind drill bits for more accurate drilling in

a variety of materials

• Automatically adjusts to give correct clearance angle

• For use with ANSI, OSHA, and UL approved standard electric bench

grinders or surface grinders

• Equally at home in machine shop and home workshop

• Instructions included

UPC NO. CAPACITY

24070 5 825 Fractional drills 1/8" to 3/4", Number size drills 30 to 1

Letter size drills A to Z, Millimeter size drills 3.0 to 19.0

FIBERGLASS FOLDING RULE

• Constructed of tough, flexible high-impact plastic,
with fiberglass reinforcement for added durability

• 72" (1929mm) folding ruler with a 6" (152mm)
extension for accurate inside measurements

UPC NO. GRADS

25300 2 7200 Outside readings 16ths

graduated in 16ths.

7200

A

825

Professional Moisture Meters

WOOD WORKING TOOLS

26

General Tools & Instruments

Whether you’re a professional contractor or a conscientious
homeowner, General’s ultra-sensitive hand-held pin or
pinless Moisture Meters help you to easily detect hidden
leaks in wood, concrete, plaster and carpet. Available as

both analog and digital models, the Meters provide
accurate moisture level readings and are great for new
home inspections, locating roof leaks or even selecting
dry lumber at the yard.

FEATURES:

• 10-LED display

• Two measurement ranges:
7 to 15% and 16 to 35%

• Protective cap doubles as calibration checker

• Full and low battery indications

• CE and RoHS approved

SPECIFICATIONS:

♦

Low Measurement Range: 7 to 15% WME
(Wood Moisture Equivalent)

♦

High Measurement Range: 16 to 35% WME

♦

Measurement Accuracy: ±1 LED (~1%)

♦

Dimensions:

6.5 x 2.7 x 1 in. (164 x 69 x 26mm)

♦

Weight: 3.2 oz. (91g) w/out battery

♦

Power Source: 1 “9V” battery (included)

Includes: • Protective Cap

• Battery

• User’s Manual

• 1-Year Limited Warrantyl

UPC NO.

10188 9 MM1E

PIN-TYPE LED BAR GRAPH MOISTURE METER

Ideal for use in woodworking, building construction and home inspection. Examples include:

• Checking for moisture in carpets and sub-flooring

• Checking wood, drywall and concrete before painting/wallpapering, sealing or treating

• Locating water leaks in roofs, floors and walls

• Selecting dry lumber

FEATURES:

• 99.9 count LCD w/0.4 in. high digits

• Wood/building materials selection switch

• Low, Medium and High moisture tones and
on-screen icons

• Data hold + auto power off + low battery
indicator

• Replaceable stainless steel pins (#PIND4E)

• Auto power off

SPECIFICATIONS:

♦

Overall Moisture Measurement Range: 5 to 50%
for wood, 1.5 to 33% for building materials

♦

Wood Moisture Scales: 5 to 11.9% (low);
12 to 15.9% (medium); 16 to 50% (high)

♦

Building Materials Scales: 1.5 to 16.9% (low);
17 to 19.9% (medium); 20 to 33% (high)

♦

Measurement Accuracy: ±3% of reading

♦

Measurement Resolution: 0.1%

♦

Dimensions:

6.0 x 2.6 x 0.8 in. (152 x 66 x 20 mm)

♦

Power Source: 1 “9V” battery (included)

Includes: • Protective cap

• Battery • User’s manual

• 1-Year Limited Warranty

UPC NO.

41447 7 MMD4E
01499 8 PIND4E Replacement pins

PIN-TYPE LCD MOISTURE METER

Ideal for use in woodworking, building construction, home inspection, lumber selection,
water-damage restoration.

FEATURES:

• Non-invasive measurement technique

• Jumbo display

• Wide measurement range

• Intuitive on-screen icons: Low/Medium/High
moisture content; wood/concrete mode

• Data hold

• Audible peak reading alert

• Auto Power Off

• Low and very low battery warnings

SPECIFICATIONS:

♦

Measurement Ranges: 0 to 99.9% WME (Wood
Moisture Equivalent) for wood; 0 to 56.5% for
building materials

♦

Measurement Accuracy / Resolution: ±3% / 0.1%

♦

Measuring Depth: 3/4 in. (20mm)

♦

Display Type/Size: 99.9 count LCD with 0.4 in.
(10mm) high digits

♦

Operating Temperature:
32° to 122°F (0° to 50°C) @ <80%RH

♦

Dimensions: 5.75 x 2.6 x 0.75 in.
(146 x 66 x 19 mm)

♦

Power Source: 1 “9V” battery (included)

Includes: • Battery • User’s Manual

• 1-Year Limited Warranty

UPC NO.

40142 2 MMD5NP

PINLESS LCD MOISTURE METER

Ideal for measuring moisture content of wood and other construction materials.

MM1E

MMD4E

MMD5NP

RoHS

RoHS

Professional Moisture Meters

WOOD WORKING TOOLS

27

General Tools & Instruments

FEATURES:

• Separate settings for drywall, masonry,
softwood and hardwood

• 2 in. backlit LCD + 3-color LED bar graph

• Non-invasive technology with
3/4 in. maximum sensing depth

• ±4% accuracy on wood

• Auto calibrating

• Data hold

• Separate out-of-range alarms for wood and
building materials

• Auto power off

SPECIFICATIONS:

♦

Measurement Ranges: 0 to 53% for softwood;
0 to 35% for hardwood

♦

Measurement Accuracy / Resolution: ±4% / 1%

♦

Maximum Sensing Depth: 3/4 in.

♦

Dimensions: 6.7 x 2.9 x 1.2 in.

♦

Weight: 5.4 oz. (152g) without battery

♦

Power Source: 1 “9V” battery (included)

Includes: • Battery

• User’s Manual

• 1-Year Limited Warranty

UPC NO.

01583 4 MMD7NP

PINLESS LCD MOISTURE METER W/TRICOLOR BAR GRAPH

Ideal for measuring moisture content of wood and other construction materials.

FEATURES:

• Readings are species-specific, derived from
industry-standard moisture-resistance curves
for 48 popular species of wood

• Joystick makes species selection fast and easy

• Also measures and displays ambient
temperature (in °F or °C) and RH

• Measurements can be compensated for
ambient temperature, improving precision

• Super-bright yellow OLED (organic light­emitting diode) dot matrix display

• 99 record memory with manual or automatic
(time-based) recording

• Multiple display options, including analog bar
graph

• Measurement hold button

• Audible moisture alarm

• Pin cover doubles as calibration checker

• Replaceable pins

SPECIFICATIONS:

♦

Moisture Measurement:

• Range: 5.3 to 40%WME (Wood Moisture
Equivalent)

• Accuracy / Resolution: ±(3% of reading
+5 digits)/0.1%

♦

Ambient Temperature Range / Accuracy:

• 0° to 176°F (-18° to 80°C)

• ±1.8°F (1°C) / 0.1°

♦

RH Range / Accuracy / Resolution:

• 20 to 95%RH

• ±5% typical / 1%

♦

Temperature Compensation Range / Resolution:
0° to 255°F (-18° to 124°C) / 5°F

♦

Display Type: Yellow OLED in 128 x 64 dot
matrix format

♦

Display Size: 1.54 in. (39mm) diagonal

♦

Pin Length: 0.2 in. (5mm)

♦

Power Source: (1) “9V” battery (included)

PRECISION MULTI-SPECIES WOOD MOISTURE METER

Ideal for measuring the moisture content of wood before painting, wallpapering, sealing,
treating or joining.

RoHS

FEATURES:

• Two displays: Red LED bar graph and LCD
display with 0.62 in. (51mm) high digits

• Optional remote probe available

• Replaceable 0.44 in. (11mm) long pins

• Min/Max memory + data hold

• Heavy-duty housing

• Low battery indicator

SPECIFICATIONS:

♦

Two measurement ranges: 0 to 100% for
concrete and non-wood materials, 6 to 40%
moisture for wood

♦

Measurement Accuracy / Resolution:
± (5% of reading + digits)/0.1%

♦

Dimensions:

8.4 x 2.7 1.2 in. (216.5 x 68.5 x 29.7mm)

♦

Weight: 8.8 oz. (251g)

♦

Power Source: 1 “9V” battery (not included)

Includes: • 10 Pairs of Extra Pins

• Protective Cover

• User’s Manual

• 1-Year Limited Warranty

UPC NO.

07003 1 MMD7003
01255 0 MP7003 External Pin-Type Probe (optional)

PIN-TYPE LCD MOISTURE METER W/BAR GRAPH

Ideal for measuring moisture content of wood, timber and concrete.

Includes: • Battery

• User’s Manual

• 1-Year Limited Warranty

UPC NO.

01638 1 MMD8P

MMD7003

MMD8P

MMD7NP

General Tools & Instruments

GeneralToolsNYC

99 Washington Street
Melrose, MA 02176

Phone [phone]
Toll Free 1-800-517-8431

Visit us at www.TestEquipmentDepot.com
