General Tools DBAR110 User Manual [en, fr, es]

DBAR110
USER’S MANUAL
Wireless
Weather Station
& Forecaster
Thank you for purchasing General Tools & Instruments new generation electronic weather station. Designed and engineered with the state-of-art technology and components, this instrument will provide accurate and reliable measurements of in/out temperatures and air pressure. Calendar alarm clock is included.
Read this manual carefully to fully explore the features and functions of this product.
DBAR110 MANUAL-FINAL-100407 10/4/07
NAME AND FUNCTIONS OF BUTTONS:
Press Hold Functions 3 seconds
CH (Channel) No function Cancel
current sensor
SET Zone Time/ Clock set
Home Time ALARM Read Alarm Alarm set MEM Read maximum/ minimum
memory for temperature + 1 step Fast
advance advance
Alarm on/off
- 1 step Fast
backward backward
°C/°F SNOOZE/LIGHT Trigger snooze alarm &
backlight
BATTERY INSTALLATION
HOME RECEIVER: Lift off the battery cover at the back,
install 2 “AA” batteries according to the polarity indicated, close the battery cover.
REMOTE SENSOR: Lift off the bracket stand, loosen the
4 screws with a small screwdriver, insert 2 “AAA” batteries according to the polarity indicated. Replace the cover and tighten the 4 screws.
SETTING UP THE WIRELESS THERMOMETER:
• For the initial installation, always insert
batteries to the home unit and then the remote sensor.
DBAR110 MANUAL-FINAL-100407 10/4/07
• Press the Tx button on the back of
remote sensor to verify the RF reception.
°F/°C SELECTION (Back of Unit)
Press “ – ” to select °C/°F
CLOCK & CALENDAR SETTING
Hold “SET” button for 3 seconds to enter clock set. Using “ + , - ” to adjust and “ SET ” to confirm, the following values can be set in sequence: Year > Month > Date > Hr > Min > 12/ 24 > confirm & exit.
HOME TIME & WORLD (ZONE) TIME
If a zone time is entered, during the normal mode, press SET to select home time and world time.
ALARM SETTING (Front & Back of Unit)
Hold “ALARM“ for 3 seconds. Press “ +, - ” to enter the desired Hr/ Min values and press “ALARM” to confirm setting.
To view alarm time, repeat press “ALARM” button at normal mode. Alarm time 1 or 2 will display for 5 seconds and resume to normal clock thereafter.
To turn Alarm on and off, repeat press “ + ” button at normal mode.
SNOOZE/LIGHT (Top of Unit)
Press SNOOZE/LIGHT to trigger snooze alarm. To stop alarm for one day, press “ALARM” key. At normal mode, press SNOOZE/LIGHT for an extended backlight.
DBAR110 MANUAL-FINAL-100407 10/4/07
MEM (MAX/MIN MEMORY)
Press the ”MAX/MIN“ to view the maximum values (In/Out Temp and Humidity) for 5 seconds, press again to view the minimum memory. Memory will be cleared automatically every 0:00.
TEMPERATURE TREND INDICATOR:
The icons will indicate Rising, Steady, Falling
PRESSURE HISTORY
The unit will display the moving pressure history of the past 12 hours, providing a clear & detail picture for pressure tendency.
WEATHER FORECAST
The unit predicts weather condition of the next 12 – 24 hours based on the change of atmospheric pressure. The coverage area is around 18-30 miles (30 – 50 km). The weather forecast is based on atmospheric pressure change and is about 70-75% correct. As weather conditions cannot be 100% correctly forecasted, we cannot be responsible for any loss caused by an incorrect forecast.
SUNNY SLIGHTLY CLOUDY CLOUDY RAINY STORMY
BATTERY DISPOSAL
Replace only with the same or equivalent type recommended by the manufacturer.
Please disposal of old, defective batteries in an environmentally friendly manner in accordance with the relevant legislation.
DBAR110 MANUAL-FINAL-100407 10/4/07
SPECIFICATIONS
Range of temperature measurement: Indoor Unit: 32° to 122°F
(0° to +50°C) Humidity: 20% to 99% RH Remote Sensor: -4° to 140°F
(-20° to +60°C)
Transmission:up to 100ft (30M) open
area, RF434 MHz Resolution: 0.1 degree for temperature Clock: Quartz Power: 2 “AA” batteries for Home Unit,
2 “AAA” batteries for Remote Sensor
DBAR110 MANUAL-FINAL-100407 10/4/07
DBAR110
MODE D’EMPLOI
Station météo sans
fil avec prévisions
météorologiques
Merci d’avoir acheté la nouvelle génération de station météorologique électronique de General Tools & InstrumentsMC. Conçu et développé avec une technologie et des composantes d’avant-garde, cet instrument vous donnera des relevés précis et fiables de la température à l’intérieur et à l’extérieur, et de la pression de l’air. Une horloge avec calendrier est incluse.
Lisez attentivement ce guide pour explorer entièrement les caractéristiques et les fonctions de ce nouveau produit.
DBAR110 MANUAL-FINAL-100407 10/4/07
NOMS ET FONCTIONS DES BOUTONS :
Fonctions Fonctions en appuyant en appuyant
pendant 3 secondes
CH (canal) Aucune Annuler le
fonction capteur actuel
SET Temps dans ce Réglage de
fuseau/ Temps l’horloge chez moi
ALARM Relevé du Réglage du
temps du réveil réveil
MEM Relevé de la mémoire de
température maximum/ minimum
+ Avance Avance rapide
par étape March/arrêt pour le réveil
- Recul par étape Recul rapide
°C/°F
SNOOZE/ Déclencheur du rappel ALARM d’alarme et du rétroéclairage
INSERTION DES PILES :
RÉCEPTEUR DANS LA MAISON : Soulevez le couvercle du compartiment
à piles sur le dos de l’appareil, insérez 2 piles AA selon la polarité indiquée et fermez ensuite le couvercle du compartiment à piles.
CAPTEUR À DISTANCE : Desserrez les 4 vis à l’aide d’un petit
tournevis et insérez 2 piles AAA selon la polarité indiquée. Remettez le couvercle en place et serrez solidement les 4 vis.
DBAR110 MANUAL-FINAL-100407 10/4/07
PRÉPARATION DU THERMOMÈTRE SANS FIL :
• Lors de l’installation initiale, insérez
toujours en premier les piles de l’appareil pour la maison et insérez ensuite celles du capteur à distance.
• Pour vérifier la réception RF, appuyez
sur le bouton de transmission « Tx » situé sur la surface arrière du capteur à distance.
SÉLECTION DE °C/°F
Appuyez sur « – » pour sélectionner °C/°F
RÉGLAGE DE L’HORLOGE ET DU CALENDRIER
Appuyez sur le bouton « SET » pendant 3 secondes pour accéder le mode de réglage de l’horloge. En appuyant sur « + ou – » pour les réglages et sur « SET » pour confirmer les choix, vous pouvez régler les valeurs suivantes une après l’autre : Année (Year) > Mois (Month) > Date > Heure (Hr) > Min > 12/ 24 > confirmer et sortir.
HEURE CHEZ MOI ET HEURE DANS LE MONDE (FUSEAU HORAIRE)
Si un fuseau horaire est entré en mode normal, appuyez sur « SET » pour sélectionner l’heure chez moi ou l’heure dans le monde.
RÉGLAGE DU RÉVEIL
Appuyez sur le bouton « ALARM » pendant 3 secondes. Appuyez sur « + ou – » pour entrer les valeurs de l’heure et des minutes désirées et appuyez ensuite sur « ALARM » pour confirmer les réglages.
DBAR110 MANUAL-FINAL-100407 10/4/07
Pour voir les temps réglés pour le réveil, appuyez sur le bouton « ALARM » en mode normal. Le temps 1 ou 2 réglé pour le réveil, sera affiché pendant 5 secondes et l’heure actuelle sera affichée ensuite.
Pour mettre le réveil en fonction ou hors fonction, appuyez sur le bouton « + » en mode normal.
RAPPEL D’ALARME/ ÉCLAIRAGE (SNOOZE/ LIGHT)
Appuyez sur « SNOOZE/ LIGHT » pour mettre le réveil en fonction. Pour arrêter le réveil pour un jour, appuyez sur le bouton « ALARM ». En mode normal, appuyez sur « SNOOZE/ LIGHT » pour allumer le rétroéclairage.
MÉMOIRE MIN/MAX (MEM)
Appuyez sur le bouton « MAX/MIN » pendant 5 secondes pour voir les valeurs maximales (température à l’intérieur et à l’extérieur et humidité) et appuyez sur ce bouton encore une fois pour voir les valeurs minimales. La mémoire sera effacée automatiquement à toutes les 0:00 .
INDICATEUR DE TENDANCE DE LA TEMPÉRATURE : Les icônes indiqueront si la température augmente, de descend ou si elle demeure stable.
HISTORIQUE DE LA PRESSION
L’appareil affichera l’historique de la pression de l’air durant les 12 heures précédentes, vous fournissant un relevé clair et précis des tendances de la pression de l’air.
DBAR110 MANUAL-FINAL-100407 10/4/07
PRÉVISIONS MÉTÉOROLOGIQUES
L’appareil peut prévoir les conditions météorologiques pour les 12 à 24 heures suivantes selon les changements dans la pression atmosphérique. La portée est d’environ 30 à 50 km (18 à 30 milles). Les prévisions météorologiques sont basées sur les changements dans la pression atmosphérique et ont une précision d’entre 70 et 75%. Puisque les conditions météorologiques ne peuvent pas être prévue à une précision de 100%, nous ne pouvons pas être responsable des pertes causées par une prévision incorrecte.
ENSOLEILLÉ LÉGÈREMENT TROUBLE TROUBLE PLUVIEUX IMPÉTUEUX
ÉLIMINATION DES PILES USÉES
Ne remplacez les piles qu’avec des piles neuves du même genre ou des piles équivalentes recommandées par le fabricant.
Veuillez éliminer les piles usées ou défectueuses d’une manière respectueuse de l’environnement, selon les directives de la loi en vigueur.
SPÉCIFICATIONS
Gamme de températures : Appareil dans la maison : 0° à 50°C
(32° à 122°F) Humidité : HR de 20% à 99% Capteur à distance : -20° à +60°C
(-4° à 140°F)
Transmission :Jusqu’à 30 m (100 pi) dans
une région ouverte, RF434 MHz
DBAR110 MANUAL-FINAL-100407 10/4/07
Résolution : 0,1 degré pour la
température Horloge : À quartz Alimentation : 2 piles “AA” pour l’appareil
dans la maison, 2 piles “AAA” pour le capteur à distance
DBAR110
MANUAL DEL USUARIO
Estación y
pronosticador
inalámbrico
del clima
Gracias por comprar la estación climatológica electrónica de nueva generación de General Tools & Instruments
. Este instrumento diseñado y fabricado con tecnología y componentes de avanzada le proveerá mediciones precisas y confiables de las temperaturas interior y exterior y de la presión atmosférica. Incluye reloj con alarma y calendario.
Lea este manual cuidadosamente para aprender todas las características y funciones de este nuevo instrumento.
DBAR110 MANUAL-FINAL-100407 10/4/07
NOMBRE Y FUNCIONES DE LOS BOTONES:
Oprimir para Oprimir 3 Funciones segundos
CH (Canal) No tiene función Cancelar
sensor actual
SET Zona Horaria/ Programar (Programar) Hora local reloj
ALARM Leer Alarma Programar
alarma
MEM Leer memoria de
temperatura máxima/mínima
+ 1 paso adelante Avance rápido
Activar/desactivar alarma
_ 1 paso atrás Retroceso
rápido
°C/°F
SNOOZE/ Gatillo de alarma
LIGHT y luz de fondo
INSTALACIÓN DE PILAS
UNIDAD BASE: Levante la tapa del compartimiento de
pilas e instale 2 pilas AA respetando la polaridad indicada y cierre la tapa.
SENSOR REMOTO: Saque la tapa de atrás aflojando los 4
tornillos con un desatornillador pequeño, instale 2 pilas AAA respetando la polaridad indicada, cierre la tapa y ajuste los 4 tornillos.
DBAR110 MANUAL-FINAL-100407 10/4/07
PROGRAMACIÓN DEL TERMÓMETRO INALÁMBRICO:
• Para la instalación inicial, siempre
instale las pilas en la unidad base primero y después en el sensor remoto.
• Oprima el botón “Tx” atrás del sensor
remoto para verificar la recepción de la frecuencia radial (RF).
SELECCIÓN DE °C/°F
Oprima el botón “–” para seleccionar °C o °F
PROGRAMACIÓN DEL RELOJ Y CALENDARIO
Oprima el botón “SET” por 3 segundos para entrar en modo para programar el reloj. Para seleccionar, oprima los botones “+” o “–” y el botón “SET” para confirmar. Los siguientes valores pueden programarse secuencialmente: Año > Mes > Día > Hora > Min > 12/24 > confirmar y salir.
HORA LOCAL Y ZONA HORARIA MUNDIAL
Si se ingresa la zona horaria; durante el modo de operación normal, oprima el botón “SET” para seleccionar la hora local y la zona horaria mundial.
PROGRAMACIÓN DE LA ALARMA
Oprima el botón “ALARM” por 3 segundos, luego los botones “+” o “–” para programar la hora y los minutos y después el botón “ALARM” para confirmar.
Para ver la hora programada para la alarma; durante el modo de operación
DBAR110 MANUAL-FINAL-100407 10/4/07
normal, oprima el botón “ALARM”. La hora de alarma 1 ó 2 aparecerá por 5 segundos y regresará a la operación normal del reloj. Para activar o desactivar la alarma: estando en modo normal, oprima el botón “+”.
ALARMA Y LUZ
Para hacer sonar la alarma, oprima el gatillo “SNOOZE / LIGHT”. Para cancelar la alarma por un día, oprima el botón “ALARM”. Para prolongar la duración de la luz de fondo, en el modo de operación normal. oprima el botón “SNOOZE/LIGHT”.
MEM (MEMORIA DE MAX/MIN)
Para ver los valores máximos de temperatura interior, exterior y humedad; oprima le botón “MAX/MIN” por 5 segundos; y vuélvalo a oprimir para ver los valores mínimos. La memoria se despejará automáticamente cada 0:00.
INDICADOR DE TENDENCIA DE TEMPERATURA: Los íconos indicarán Aumento, Estable o Caída.
HISTORIA DE LA PRESIÓN
La unidad indicará la historia de la variación de presión durante la últimas 12 horas, anunciando su tendencia clara y detalladamente.
PRONÓSTICO DEL CLIMA
La unidad predice las condiciones climatológicas para las siguientes 12 a 24 horas en base al cambio de la presión atmosférica para un radio de 30 a 50 km (18 a 30 millas). El pronóstico del clima se basa en los cambios de la presión
DBAR110 MANUAL-FINAL-100407 10/4/07
atmosférica y es acertado un 70% a 75%. Como las condiciones climatológicas no pueden pronosticarse con 100% de precisión, no nos responsabilizamos por pérdida o daño alguno debido a un pronostico incorrecto.
SOLEADO PARCIALMENTE SOLEADO NUBLADO LLUVIOSO TORMENTOSO
DESECHO DE LAS PILAS
Cambie las pilas sólo por otras iguales o de tipo equivalente recomendadas por el fabricante.
Deseche las pilas viejas o defectuosas en forma que no afecte al medioambiente y de acuerdo a la legislación pertinente.
ESPECIFICACIONES
Rango de temperatura: Unidad Interior: 0° a 50°C (32° a 12°F) Humedad relativa: 20% a 99% Sensor remoto: -20° a 60°C
(-4° a 140°F)
Alcance: Hasta 30m (100’) en zonas
abiertas, RF de 434 MHz Resolución: 0,1 grado de temperatura Reloj: Cuarzo Pilas: 2 “AA” para la unidad base y
2 “AAA” para la unidad remota
DBAR110 MANUAL-FINAL-100407 10/4/07
GENERAL TOOLS
& INSTRUMENTS
80 White Street
New York, NY 10013-3567
PHONE (212) 431-6100
FAX (212) 431-6499
TOLL FREE (800) 697-8665
e-mail: sales@generaltools.com
www.generaltools.com
DBAR110 User’s Manual
Specifications subject to change without notice
©2007 GENERAL TOOLS & INSTRUMENTS
NOTICE - WE ARE NOT RESPONSIBLE
FOR TYPOGRAPHICAL ERRORS.
MAN#DBAR110 10/07
