General Tools DAF4207SD User Manual

DAF4207SD

USER’S MANUAL

ANEMOMETER-THERMOMETER

WITH DATALOGGING SD CARD

Please read this manual carefully and thoroughly before using this product.

TABLE OF CONTENTS

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Key Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Operating Instructions . . . . . . . . . . . . . . . . . . . . . . 4 –9

What’s in the case . . . . . . . . . . . . . . . . . . . . 4 –5

Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 –8

Normal Operation . . . . . . . . . . . . . . . . . . . . . 8 –9

Holding and Storing Measurements. . . . . . . . . . 9

Automatic vs. Manual Datalogging . . . . . . . . . 10

Transferring Data from the SD Card

to a Computer . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Maintenance & Troubleshooting Tips . . . . . . . . . . . . 13

Optional Accessories. . . . . . . . . . . . . . . . . . . . . . . . . 13

Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . 13

Return for Repair Policy . . . . . . . . . . . . . . . . . . . . . . 14

2

INTRODUCTION

Thank you for purchasing General Tools & Instruments’ DAF4207SD Anemometer­Thermometer with Datalogging SD Card. Please read this user’s manual carefully and
thoroughly before using the instrument.

The DAF4207SD is a general-purpose handheld instrument that can make two kinds
of measurements:

• Air (wind) speed and temperature (simultaneously)

• Surface temperature, as measured by an optional Type K or Type J
thermocouple

The meter comes with a combination air speed-temperature probe. Air speeds can
be displayed in m/s (meters/second), fpm (feet per minute), km/h (kilometers/hr),
knots (nautical miles per hour), or mph (miles per hour). Temperatures can be
displayed in ºF (Fahrenheit) or ºC (Celsius) units.

Several features and capabilities enhance the instrument’s versatility. Among them
are automatic temperature compensation for measurements made by the
combination probe or Type K or J thermocouples, the ability to hold readings and
display maximum and minimum readings, and an automatic power off function that
extends battery life.

Because it is microprocessor-based, the DAF4207SD can make full use of the
portability, reliability and large storage capacities that SD memory cards offer.
Measurements can be made automatically at any sampling rate between one second
and one hour. After storing and time-stamping the measurements on an SD card
plugged into the instrument (a process called datalogging), the user can remove the
card and plug it into to a laptop or desktop computer either directly or via a USB card
reader. The data logs are stored on the card as files with the .xls extension, which
can be opened by Microsoft’s Excel application.

The DAF4207SD has a backlit 2-1/2 in. diagonal display and is powered by six “AA”
Alkaline batteries or an optional 9-VDC AC adapter.

3

KEY FEATURES

• Includes combination air speed-temperature probe

• Displays air (wind) speed in meters/second, feet per minute, kilometers/hr,
knots (nautical miles per hour), or miles per hour

• Displays temperature in ºF or ºC

• Big (2.5 in. diagonal) front-panel green backlit LCD is easy to read

• Displays maximum and minimum readings and holds any reading

• Automatically logs measurements at sampling time settable from one second
to one hour

• Also supports manual datalogging and changing of SD card storage location

• Outputs Excel-compatible data logs

• Accepts SD memory cards of up to 16 GB capacity

• Auto power off function

• Powered by six “AA” batteries or optional 9V AC/DC adapter

OPERATING INSTRUCTIONS

WHAT’S IN THE CASE

The DAF4207SD comes fully assembled in a carrying case along with a combination
air speed-temperature probe a 2 GB SD memory card and this user’s manual.

Optional accessories available from General Tools & Instruments include:

• Type K and Type J thermocouples

• A 9VDC adapter for a 110V power supply

See the Optional Accessories section of this manual for more details.

Figure 1 shows all of the controls and indicators on the front, right side, back, top and
bottom of the DAF4207SD. It also shows the main components of the included multi­function probe. Familiarize yourself with the positions and functions of these controls,
indicators and connectors before moving on to the setup procedure.

4

Fig. 1

FRONT

TOP

BOTTOM

RIGHT

SIDE

BACK

1. The DAF4207SD’s controls and indicators and other physical features

1-1 Liquid-crystal display
1-2 POWER/ESC button
1-3 FUNC./HOLD/NEXT button
1-4 REC/ENTER button
1-5 SET ▼ button
1-6 LOGGER ▲ button
1-7 Socket for combination air speed-

temperature probe

1-8 Socket for optional Type K or J

thermocouple

1-9 SD card socket

1-10 RS-232 output jack
1-11 RESET button
1-12 Socket for 9VDC AC adapter
1-13 Battery compartment cover
1-14 Battery compartment cover

screws
1-15 Kickstand
1-16 Tripod attachment nut
1-17 Probe plug
1-18 Probe handle
1-19 Probe head

5
