General Tools DAF2005MDL User Manual
Air velocity, Air flow, Type K/J thermometer
Real time data logger, 16000 Data logger no., RS232
ANEMOMETER
Model : DAF2005MDL
TABLE OF CONTENTS
.
.
.
.
.
.
.
.
1. FEATURES................................................................ 1
2. SPECIFICATIONS...................................................... 2
3. FRONT PANEL DESCRIPTION.....................................6
4. GENERAL MEASURING PROCEDURE........................... 8
4-1 Air velocity/Air temperature measurement............
4-2 Air flow ( CMM, CFM ) measurement.....................9
4-3 Thermocouple ( Type K/J ) Thermometer
measurement.....................................................
4-4 Data Hold...........................................................
4-5 Data Record (Max., Min. reading)......................... 11
4-6 Data Logger........................................................ 12
8
10
11
5. ADVANCED ADJUSTMENT PROCEDURE......................
5-1 Check Memory Space...........................................15
5-2 Clear Memory......................................................15
5-3 Date/Time Setting...............................................
5-4 Sample Time Setting............................................16
5-5 Auto Power Off Default Setting.............................16
5-6 Temp. Unit Default Setting...................................16
5-7 Air Velocity Unit Default Setting............................17
5-8 Air Flow Unit Default Setting................................
5-9 Area Size ( Air Flow ) Default Setting.................... 17
5-10 Escape from the SETTING function..................... 18
6. HOW TO SEND THE DATA OUT FROM THE METER.....
7. RS232 PC SERIAL INTERFACE...................................
8. BATTERY REPLACEMENT........................................... 23
9. SYSTEM RESET.........................................................23
10. OPTIONAL ACCESSORIES........................................ 24
14
15
17
18
21
1. FEATURES
* Air velocity : m/S, Ft/min, Km/h, Knots, Mile/h,
* Air flow : CMM ( m^3/min. ) and CFM ( ft^3/min. ).
* Air temperature ( , )℃℉
* Type K/ Type J thermocouple thermometer.
* Real time data logger, build in clock ( hour-min.-sec.,
year-month-date ).
* Auto or manual data record, 16,000 Data logger no.
* Wide sampling time adjustment range from two
seconds to 8 hours 59 minutes 59 seconds.
* RS232 computer interface.
* Can default auto power off or manual power off.
* Can default the air velocity, air flow, Temp. unit.
* Air flow measurement can set the area dimension.
* Multi function with easy operation
* Low-friction ball vane wheels make sure high accuracy
in high & low velocities.
* Metal vane, high reliability.
* Large LCD with multiple display.
* Data hold, record max. and min. reading.
* Microcomputer circuit provides special function & offer
high accuracy.
* Air Temp. used thermistor sensor, fast response time.
* Power by UM3 ( 1.5 V ) x 4 batteries or DC 9V adapter.
* RS232 PC serial interface.
* Separate probe, easy for operation of different
measurement environment.
* Wide applications: use this anemometer to check air
conditioning & heating systems, measure air velocities,
wind temperature...etc.
1
2. SPECIFICATIONS
@
2-1 General Specifications
Circuit Custom one-chip of microprocessor LSI
circuit.
Display LCD size : 58 mm x 34 mm.
Measurement
Unit m/S (meters per second)
Sampling Time Manual Push the data logger button
of Data Logger once will save data one time.
Sensor
Structure Conventional twisted van arm and low
Air velocity:
Km/h ( kilometers per hour )
Ft/min ( feet per minute )
Knots ( nautical miles per hour )
Mile/h ( miles per hour )
Air flow:
CMM ( m^3/min., cube meter per min. )
CFM ( m^3/min., cube feet per min. )
Air temperature:
, ℃℉
Type K/ Type J thermometer.
, ℃℉
Set the sampling time to
0 second
Auto 2 sec to 8 hour 59 min. 59 sec.
Air velocity & Air flow :
friction ball bearing design, vane use
metal material.
Air temperature :
Thermistor.
Type K/ Type J thermometer.
Thermocouple
2
Temperature Automatic temp. compensation for the
A
.
.
Compensation Type K/J thermometer.
Data Hold Freeze the display reading.
Memory Recall Maximum & Minimum value.
Sampling Time Approx. 1 second.
of display
Power off Auto shut off saves battery life or
manual off by push button.
Data Output RS 232 PC serial interface.
Operating 0 to 50 .℃
Temperature
Operating Less than 80% R.H.
Humidity
Power Supply DC 1,5 V battery ( UM3 ) x 4 PCs,
* main instrument
( Heavy duty type ).
DC 9V adapter input.
@ AC/DC power adapter is optional.
Power Supply DC 3V silver battery.
* clock module
Power Current Approx. DC 21.5 mA
Type : CR2032.
@ Main instrument.
DC 27.5 mA.
@ Main instrument. + Anemometer probe.
Weight 515 g/ 1.13 LB.
Dimension
Main instrument :
203 x 76 x 38 mm
@ Battery is included.
Anemometer sensor head :
Round, 72 mm Dia.
Accessories Instruction manual......................1 PC
Included
nemometer probe.....................1 PC
DC 3V silver battery, CR2032......
Carrying case.............................
1 PC
1 PC
3
Optional Type K thermocouple probe.
Accessories AC to DC 9V adapter.
RS232 cable, UPCB-02.
Data Acquisition software,SW-U801-WIN.
Data Logger software, SW-DL2005.
2-2 Electrical Specifications (23± 5 )℃
Air velocity
Measurement Range Resolution Accuracy
m/S 0.4 - 30.0 m/S 0.1 m/S ± ( 2%+0.2 m/S)
Km/h 1.4 - 108.0 Km/h 0.1 Km/h ± ( 2%+0.8 Km/h)
Mile/h 0.9 - 67.0 Mile/h 0.1 Mile/h ± ( 2%+0.4 Mile/h)
Knots 0.8 - 58.3 Knots 0.1 Knots ± ( 2%+0.4 Knots)
Ft/min 80 - 5910 Ft/min 1 Ft/min ± ( 2%+40 Ft/min)
Air flow
Measurement Range Resolution Area
CMM (m^3/min.) 0 to 54,000 m^3/min. 0.001-1 0.001-30.0 m^3/min.
CFM (ft^3min.). 0 to 1,908,300 ft^3/min. 0.01-100 0.01-322.91 ft^3/min.
Air temperature
Measuring Range 0 to 50 /32 to 122 ℃℃℉ ℉
Resolution 0.1 /0.1 ℃℉
Accuracy ± 0.8 /1.5 ℃℉
4
Type K/J thermometer
@
Sensor Reso- Range Accuracy
Type lution
Type K 0.1 ℃ -50.0 to 1300.0 ℃ ± ( 0.2 % + 0.5 )℃
-50.1 to -100.0 ℃ ± ( 0.2 % + 1 )℃
0.1 ℉ -58.0 to 2372.0 ℉ ± ( 0.2 % + 1 )℉
-58.1 to -148.0 ℉ ± ( 0.2 % + 1.8 )℉
Type J 0.1 ℃ -100.0 to 1100.0 ℃ ± ( 0.2 % + 0.5 )℃
-50.1 to -100.0 ℃ ± ( 0.2 % + 1 )℃
0.1 ℉ -58.0 to 2012.0 ℉ ± ( 0.2 % + 1 )℉
-58.1 to -148.0 ℉ ± ( 0.2 % + 1.8 )℉
Above specification tests under the environment RF
Field Strength less than 3 V/M & frequency less than
30 MHz only.
5
3. FRONT PANEL DESCRIPTION
6
3-1 Display
3-2 Power Button
3-3 HOLD Button ( ESC Button )
3-4 REC Button ( Enter Button )
3-5 Up Button ▲
3-6 Function Button ( Down Button )▼
3-7 Send Button ( Clock Button )
3-8 SET Button ( Logger Button )
3-9 Stand
3-10 Battery Compartment/Cover
3-11 Tripod Fix Nut
3-12 LCD Brightness Adjust VR
3-13 System Reset Switch
3-14 RS-232 Output Terminal
3-15 DC 9V Power Adapter Input Socket
3-16 Type K/J Probe Input Socket
3-17 Probe Input Socket
3-18 Probe Lock Switch ( System On/Off Switch )
3-19 Probe Plug
3-20 Probe head ( Anemometer vane & Temperature )
3-21 Probe handle
7
