General Procurement HT1004X16 Users manual

TABLETS

USER

MANUAL

FCC ID:2AIOHHT1004X16

KORAL10X2

Thank you for choosing the HYUNDAI® tablets. This device is designed to
provide distinct and different experiences for both study and entertainment.

This manual will introduce the main function, operation method and other
information. please read this manual carefully before using the device. this
user guide describes features that are common to most models.

Acknowledgement

Thanks for your purchase of our product KORAL 10X2，is a 7 inches high
clear board computer. Its CPU is RK3126C, it is based on Android 8.1

operation system, and easy to expand the third application procedure.

The manual systemically introduces the functions, use techniques and
announcements, please read this manual carefully before your operation.

A

nnouncements

Preventive maintenance

Please always keep the MID dry. To avoid the device short trouble,
corrosion fault and electric short, please prevent the device, battery and
charger from water and moisture, and don’t operate the device or charger
by wet hand.

To avoid failure of device, battery and charger, please prevent the device,
battery, charger from violent shock or shake.

To avoid failure of device, battery and charger, please prevent the device,
battery, charger of all over heating or too cold circumstance

Never shock, throw, prod the MID, or drop, extrude, bend the MID.

Never disassemble the device and accessories arbitrarily, otherwise the
device and accessories are not in our company warranty scope.

Safety Instruction

Before the operation of the MID, please read this chapter and teach your
kids about these information. For further details, please refer to the safety
instructions and announcement.
Never use the MID when driving car, in order to ensure safe driving.

In the medical area, please abide by related rules and regulations. Please
shut down the MID when it is near to the medical area.

To avoid the wireless signal to interrupt the plane- controlled signal, please
shut down the MID or using airplane mode when you are boarding a flight,

To avoid electronic equipment failure, please shut down the MID in the
vicinage of high-accuracy electronic equipments.

Please don’t disassemble the MID and accessories. Only authorized agent
has access to service the MID.

Please keep the MID far away from magnetic equipments, the radiation of
MID may erase the data stored in the magnetic equipments.

Never use the MID in the vicinage of high temperature, inflammable gas
( gas station).

Protect the MID and accessories from kids reach scope, and avoid the kids
to use the MID without parents’ supervision.

Please comply with related rules and regulations, and respect others’
privacy and legal rights while using the MID.

Please strictly adhere to related instructions in the manual when using USB
cable to ensure the safety of the MID or PC.

Never use the MID in bathroom or other humid environment, and please
protect the MID from liquid wash or wet.

Abbreviation/Terminology

Abbreviation/Terminology Full Name Description

MID Mobile Internet Device Mobile Internet Terminal

WIFI Wireless Fidelity

T F TransFlash

Base on IEEE 802.11b\g\n

standard wireless LAN

Alternative name Micro SD,

super miniature memory card

MID Introduction

Battery Charging

If this navigator is first used, please use AV adaptor to fully charge it.

1. Apply the power adaptor to charge for MID.

MID Status and Reminder

Reminder icons

When some remind message appears in your reminder window, please
click column and slip the screen to open the reminder list. Choose the
menu you need, and confirm the information. Then you can close the
reminder window through clicking the column to slide up. Please refer to
below status icons:

New email

Airplane Mode on

USB connected

Return button

Display recently-used applic ation

Current electric volume

USB debugging connected

Downloading

Home button

WIFI connected, internet is avail able

Reminder board

y

Reminder icons will work while receiving emails, WIFI is open, you can
open the reminder board to view the detailed information.

Open the reminder board

When the reminder column shows new reminder icon, please hold the
column and slip down your finger, then the reminder board is opened.

Quick Start Guide

Ke

s Function

Keys Function Description：

Power button

Volu me +（up）

Volu me （-down）

HOME button（home）

Back button（back）

Menu button

Setting button

Short press to sleep/wake up, long pr ess to
startup and shutdown.

increase the volume

decrease the volume

Click it in any interface will ret urn to main interface.

click it in any interface will retur n to previous menu

This button will display in menu interf ace.

display recently browsed histo ry; double click this button,
you can switch between the last two appli cations

Startup

Long press POWER key for three seconds, you can enter into startup
picture. The system enters into screen lock status, please unlock it.

Shutdown

deth

pti

1．Long press POWER, it will popup shutdown window.
2．Shutdown window contains reboot mode, airplane mode and power off

ree o

mo

ons.

3. Click power off is the last step.

Open and Close of the Screen

Screen will be closed on its own when no operation happens.

1. Screen will be closed on its own if no operation happens for some time to

save battery power

2. When screen is open, press POWER key, the screen will be closed

immediately.

Open the screen when it is closed.

If the screen is closed, short press POWER to open the screen. The
screen will be locked open it, it will show the picture as below picture, left
slide to unlock and enter into camera, right slide the unlock icon and enter
into Voice Search , upward slide unlock the screen.

Usage of Touch Screen

MID operating methods

There are below methods to view the main screen, menu and application
procedure in your MID.

Click

When you want to use the screen keyboard typing or choose application in
the main interface, you only need to touch it by your finger.

Press on

If you want to open some item(textbox or the link in the webpage), or
shortcut and main procedure move, you can press on this item.

Quickly slide or slide indicates

Quickly slide or slide indicates make quick vertical or horizon movement by
finger.

Pull

Before you pull, you need to hold the it with strength until you pull it into the
position you want.

Rotate

For most pictures, you only need to rotate the MID sidewise to change the
screen direction from horizon to vertical. For instance, when you are typing
words, and watching movies.

Home Page

Main interface as below picture 3.5-1, long press the blank and it will popup
windows to set wallpaper, folder, widgets, and shortcut.

Batty volume time

Notice
column

return Home display recently browsed history

The extended home page

The home page can be extended beyond the wideness of screen to
provide more space, which you can put new-added shortcuts and widgets.
Click the blank space in home page then slide right or left to extend to the
right or left of the screen. In the home page, there are two extended
pictures.

The shortcut icons management in desktop application.

Create folder icon in desktop

1. Drag the icons need to be put together on one icon(can also overlay

several icons)

2. Then click the overlaid icons, the applications can befolded.

Click the unnamed folder in the black box, it will popup the hidden
keyboard, the folder name can be renamed (this is similar with Apple IOS
system), the icons position can be changed through long press.

3. Lon

g

p

set different application icon shapes, such as square、squircle、circle、
teardrop

ress to enter the home screen settings,as Picture 3.5-5.you can

Remove the icons in desktop

1. Long press the icons need to be remove, then on the right above of the

screen, it will appear

icons.

2. Drag the icon to the above of the remove icon, till the icon become red,

C

p

k

then move your finger to delete the icon.

hangethewallpaper ofdeskto

1．In home page, long press any blank space in main screen, it will popup a
window to change the wallpaper.

2. Clic

the gallery or wallpaper gallery to select the wallpaper.

Visit Application Procedures

Click

in right top, enter into main interface as Picture 3.6-1, choose the

application procedure you want to visit.

Return to home page

PinnedShortcuts
If you press an application software, you can pop-up the sub menu, and
then you can use this way to use some functions of the application quickly

MID storage configuration

Before transmitting documents, you have to conduct storage configuration
foryourMID:

1. Connect the MID and computer by USB cable, the reminder column will
show the remind information.

2.Open the reminder board; please view the MID status and reminder to
learn how to open the board.

3.In the reminder board, click the “USB for file transfer”, it will as below,
then click “File transfers”.

4.Now the USB is connected successfully.

Copy the document into memory card

1. Connect the MID to computer with USB cable.

2. As MID storage configuration, it is connected with computer successfully.

3.Open the “My computer” in your computer, check the items in “MTP
devices”.

4.Copy the documents you need into “MTP devices”.

5.After copying finishes, unplug the USB can.

Typing words

When you start the procedure or choose the words or numbers edition, it
will show the screen keyboard. The keyboard contains below typing
options:

1.Android keyboard

Choose the typing method you want

1.Click Setting procedure application.

2.Click Language and Keyboard.

3. In the text setting area will reveal all the installed words-typing methods

in your MID.

4. Tick the typing method you want.

Use and switch of input method

1 4

2

3

1 switch the capital and small letter

2 switch the mode of words input

3

click to insert the space

4

click input to execute

delete the character in the left of cursor, click and

5

hold to delete all the characters in the left on the cursor

5

Operation Technique

Enter widgets interface

In the application interface, click widgets on the above of screen, or slide
the screen, it will switch into widgets interface. Long press any widget to
create its shortcut, then you can enter into the application through the
shortcut icon.

Create application shortcut icons in the desktop

In the application interface or widgets interface, long press any icon to
switch into desktop automatically, drag and hold the icon, you can move to
any position in the desktop.
Remind: If the target position has no space, the widget won’t be add in the
main screen.

Quick Setting

Swipe-down gesture from the top of the screen, there are nine shortcuts
icons, such as Wi-Fi, Bluetooth, Auto-rotate, and so on. In the full Quick
Settings list you can also tap the edit button at the bottom right to
rearrange the tiles or replace them with others. The optional extras list is
pretty minimal: Just Hotspot, Data saver and Invert colors. But developers
are now able to create custom Quick Settings tiles for their apps, which will
definitely make things a lot more interesting in the coming mouths.

Swipe-down gesture from the top of the screen,Long press push message
to see a switch, operate it to open and close the future of this app so all
notifications.

Network and Internet

Reset Wi-Fi、mobile&Bluetooth

Click icon in right top of Picture, select Reset Wi-Fi、mobile&Bluetooth
