General mobile DST12 User Manual

1
2
Table of Contents
1. For your Safety .................................................................................................. 3
2. Mobile Phone Profile ......................................................................................... 5
3. Preparation before Use ...................................................................................... 6
4. General Instructions for Mobile Phone .............................................................10
5. Basic operation .................................................................................................17
6. Use Menu Functions .........................................................................................20
7. English Editor Operation ..................................................................................48
8. Use USB ...........................................................................................................48
9. Appendix I ........................................................................................................50
10. Appendix 2 .......................................................................................................51
3
1. For your Safety
For your safety and proper use of the mobile phone, please read the following guidelines carefully:
Do not switch the mobile phone on when close to chemical factory, gas station or other explosive
objects.
During driving, please use headset for safety purpose; unless otherwise in emergency, always stop the
car on roadside to have a call conversation.
Because the use of the mobile phone can cause interference in the aircraft, never use the mobile phone
in aircraft. The use of the mobile phone is dangerous and illegal; do switch off the mobile phone before boarding.
Pay special attention to the use of the mobile phone near heart pacemaker, deaf-aid and some other
medical equipments, because the mobile phone can cause interference with them.
None-original factory’s accessories and parts will lose guarantee. Do not dismantle the mobile phone without permission. In case of failure, please contract the supplier
as soon as possible.
Do not plug the charger into the mobile phone and charge without battery. Always power off the
mobile phone when taking out the battery; otherwise the memory of the phone may be damaged.
When charging the mobile phone, always keep it in the place with good ventilation, heat sink and
away from flammable and explosive objects.
In order to avoid demagnetization, always keep the mobile phone away from magnetic objects such as
4
CD, credit card etc.
Ensure the mobile phone not to contact any liquid; once such case occurs, remove the battery and
contact the supplier immediately.
Do not use the mobile phone in the environment at too high or too low temperature, never expose the
mobile phone under strong sunshine or too wet environment. The suitable temperature for the phone and accessories is 0℃-40℃. The height to use the phone shall be less than 2,000m.
Do not use liquid or wet cloth with strong cleanser to clean the mobile phone. This mobile phone has shooting, videoing and audio recording functions, which shall be used as per
the related laws and regulations.
Always keep the mobile phone out of children’s reach. Do not throw or vibrate the mobile phone
because violent treatment to the mobile phone may damage the inner circuits and precise structures.
Please do not discard the waste battery into general household garbage. Please deal with the waste
battery according to provisions where they are definitely made.
Warning: We will not be bear any responsibility for any incompliance with the above guidelines or improper
use of the mobile phone.
Our company keeps the right to make modifications to any of the content here in this user guide without public announcement in advance. The content of this manual may vary from the actual content displayed in the mobile phone. In such case, the latter shall govern.
5
2. Mobile Phone Profile
SIM1 Dial Key
SIM2 Dial Key
Navigation Key
Recevier
Screen
OK Key
Central/Right soft key
Microphone Output
Standard Keypad
Switch-on/off/End Key
The mobile phone has 12 keys on the keypad. In addition, it is inbuilt with one vibration motor, one charger/data common transmission port. (Below is the front of the mobile phone)
6
3. Preparation before Use
Install SIM Card
When registering mobile phone number, you can apply for two different phone numbers, two different mobile phone network service providers and thus obtain two SIM (Subscriber Identification Module) cards.
With these two SIM cards, you can use all functions of your mobile phone. The SIM cards save the parameters needed for communications and personal data, including PIN (Personal Identification Number) code, phonebook, short message and other extra system services.
Warning: Do not distort or scratch the SIM card nor let it contact static, dust or moisture. If it is lost, please contact immediately your network operator for help.
Before SIM card installation, please switch off the mobile phone. The SIM card is installed on the back
of the mobile phone.
Follow the following diagram to install the SIM card. Please insert the host SIM card into the SIM1 slot
7
and the slave SIM card into the SIM2 slot. Note: If SIM card is inserted only into the SIM1 slot, then only the host works; likely, If SIM card is inserted only into the SIM2 slot, then only the slave works. When two SIM cards are inserted into the SIM1 slot and SIM2 slot respectively, you can choose work mode freely as you wish. Note: As the SIM card is small object, keep it out of children’s touch or prevent children gulping it!
Install Memory card
As the mobile phone does not have enough storage space, to use some functions, you need to install a memory card (This mobile phone use T-FLASH card.)
Install T-FLASH card: Open the back cover to take out the battery, release the T-Flash card lock, insert the T-Flash card into its slot, restore the lock and the battery before restarting the mobile phone. Note: As the T-FLASH card is small object, keep it out of children’s touch or prevent children gulping it!
Install Battery
The mobile phone is suitable for original battery and accessories. When the battery is idle, it is
recommended to put it into the protection box.
Follow the following diagram to install the battery.
8
Note: Do install the battery as per the diagram so as prevent the battery contact patch being damaged.
Charge Battery
The new battery cannot reach the optimal efficiency unless it has undergone several continuous complete charges and discharges.
When the battery is used up, charge it in time. Over-discharge can damage the battery.
After the battery is charged full, cut off the connection of charger with the AC power supply and then the connection with the mobile phone.
Follow the following diagram to connect the charger.
During charging, the battery capacity icon on the screen flickers from the right to the left. After the battery is charged full, the icon is full of bars. Slight heat during charging is normal. Warning: When a travel charger and its accessories are used to charge the battery, please firstly check if they are original or recognized by the original manufacturer. The use of other accessories may damage your
9
mobile phone and cause risks! Always use them indoor and dry places.
Warning Charging the mobile phone by improper means can cause to explosion. Always refer to the related regulations for the disposal of the battery.
Notices on using the battery
The performance of the battery is affected by many factors, including radio barrier network settings, signal strength, work temperature, chosen and used functions or settings as well as phone accessories, tone, data or other applications.
For optimal performances, please follow the rules below: New battery or the battery having been idle for long need charging for long. The standard voltage
scope for the battery is 3.6V-4.2V.
During charging, keep the battery at room temperature or similar temperature. With time passing by, the battery will gradually be worn and thus need longer time to charge. This is
normal. However, after normal charging, if call duration decreases but charging time increases, you need to buy another battery from the original manufacturer or authorized by the original manufacturer. The battery of interior quality can damage your mobile phone and cause danger!
If the phone is overused at low battery when charging, there might need a longer time for the charge
indicator to be shown on the screen. Note: Please dispose the battery according to the local regulations. Try to recycle the battery as possible. Do not treat the waste battery as common waste. Warning: Do not throw the battery into fire so as to prevent fire. The broken battery may cause explosion.
10
PIN Code
PIN1 Code:It is the personal identification number used to enter SIM and able to prevent others using
SIM1 without permission. If the mobile phone has activated the PIN1 code protection, when the mobile
phone is switched on, the screen will display “Input PIN”. In the process of inputting PIN1 code, the screen will use “*” to represent the input content. While obtaining SIM, you can obtain its PIN1 code.
PIN2 Code: It is the personal identification number used for some special functions such as paid call etc.
PUK Code and PUK2 Code(8-digit)
To change the locked PIN code, you need to use PUK (Personal Unblocking Key) code. To change the locked PIN2 code, you need to use PUK2 code. If these two codes are not provided together with the SIM cards, ask the local service provider for them. Warning: If the PIN code is input wrongly for successively three times, the SIM card will be locked. Please contact the network operator immediately for help. Attempt to unlock the code may make the SIM card ineffective forever!
4. General Instructions for Mobile Phone
SIM 1 Dial key
It is used to have SIM1 call (when the phone number is input or in phonebook state) and receive SIM1 incoming call. In standby state, press this key to display the latest calls (all received calls, missed calls, and dialed calls, at most 40 phone numbers). In standby state, press this key twice successively to dial out the latest call number.
Note: SIM1 Dial Key has same function as OK Key except standby state and call.
11
SIM 2 Dial key
It is used to have SIM2 call (when the phone number is input or in phonebook state) and receive SIM2 incoming call. The function is same as the SIM 1 dial key.
Switch-on/off /End key
In call state, it is used to interrupt a call; in call conversation state, it is used to end a call or exit from the current menu and back to the standby state. Hold this key for 4~5s to switch on/off the mobile phone.
OK Key
Press the OK key to have the functions indicated in the left-bottom row of the main screen of the mobile
phone.
Central/Right soft key
Press the central/right soft key to have the functions indicated in the right-bottom row of the main screen of the mobile phone.
Navigation key
This mobile phone has four navigation keys, with the left, right, up and down control functions. In some interfaces, they have special function, for example, in call state, press the up/down key to adjust volume. Similarly, these four navigation keys can be set with shortcut functions, in default state: press the up key to enter the Audio player, the down key to enter Alarm, the left key to User profiles and the right key to enter Tone setup. Shortcut keys can be active only in standby state and their function definitions can be set by yourself with the procedures as: enter the phone settings menu, choose dedicated key function to reedit the navigation keys. You can find detail information about navigation keys below table.
12
Keys
Press
Long/
Shortly
Standby State
Audio Player
FM Radio
Incoming
Call
Call State
Up
Navigati
on Key
Long
Default entering
music player
MP3 play /
pause
Radio record
on
Turn up call
volume
Short
Default entering
music player
MP3 play /
pause
Radio record
on
Turn up call
volume
Down
Navigati
on Key
Long
Default entering
alarm
MP3 stop
Radio On/ Off
Eliminate
incoming call
tone
Turn down call
volume
Short
Default entering
alarm
MP3 stop
Radio On/ Off
Eliminate
incoming call
tone
Turn down call
volume
Left
Navigati
on Key
Long
Default entering user
profiles
MP3 rewind
Backward
search
Short
Default entering user
profiles
Previous title
Backward
search
Right
Navigati
on Key
Long
Default entering tone
setup
MP3 fast
forward
Forward
search
Short
Default entering tone
setup
Next title
Forward
search
13
* Key
Short
MP3 volume
down
Radio volume
down
# Key
Short
MP3 volume up
Radio volume
up
Standard keypad
On the keypad, you can see 0-9 number keys, * key and # key, totally 12 keys. Press these keys to input phone number, password, English letters, symbols etc, or choose menus. Note: In standby state, hold “1” key long to call the voice inbox service center. The number for the voice inbox should be preset.
In different states or different functional menus, * key and # key have different functions:
Press “#” key long to start or exit from the silence mode. Continuously press shortly or press long * key to input “P”, "＋" or "W" , among which, “P” and “W”
are used for extension calls while “+” for international calls.
In music player state, * and # are used to adjust volume. Tip: The difference between “W” and “P” is that “P” will directly send DTMF after 3s pause while “W” will eject a window asking whether the user to send DTMF. FM function key
OK key: Press this key to enter FM Radio option menu. Up key: Activate radio recording. Down key: In radio state, press the key to turn on/off radio. Left/Right key: In search state, press the left/right key to search channels forward and backward until
14
you find an effective channel.
1-9 number keys: If they are pressed shortly, you can switch to the corresponding channels saved in
the channel list; if they are pressed long, you can save the current frequency to the corresponding channel.
0 key: Press this key to switch FM channel list and switch to the corresponding frequency. *, # key: Adjust volume.
Keypad lock
When in standby interface, if the mobile phone is idle for certain time, it will be locked automatically. Press the right soft key to release and press # key again to unlock. After the mobile phone is locked, the keypad cannot be activated easily; in case of incoming call, likewise, press the answer key to receive it; after that, the keypad will be locked automatically.
Icons in Standby State
Antenna; the host antenna has“1“on the icon while the slave antenna has “2“on the icon. Activate the alarm clock. SMS tip; the host SMS has“1“on the icon while the slave SMS has “2“on the icon.
Battery power capacity indication
Ring; this icon may vary with different warning modes and it may be in the three icons:
Ring after vibration Vibration and ring
Vibration Missed Calls Locked
SIM1 line 1
15
SIM2 line 1 SIM1 line 2 SIM2 line 2
MMS PUSH Inbox GPRS All calls diverted
Language and Input Mode
The mobile phone has defaulted English and Turkish input mode.
Call hint
The mobile phone is inbuilt with vibration motor and buzzer and provides several incoming call modes:
Ring Vibration Ring after vibration Vibration and ring
Services
Services are provided with SIM kit. The mobile phone support service function. The detailed menu items depend on SIM card and the network. When the network provides such function and your SIM card supports such function, the service menu will automatically be posted in the services of the mobile phone.
Caller groups
The callers group in the mobile phone includes friends, family, VIP, business and others etc. You can set different call tone and photo for different caller group.
16
Term Description Dial domestic calls
The simplest method to dial a domestic call is to input phone number via the number keypad, then
press dial key to dial call. To change phone number, press “Clear” key. During dialing, the screen will display a cartoon. If SIM card 1 call, "SIM1-" occurs; if SIM card 2 call, "SIM2-" occurs. When the other party is connected, the screen will display the corresponding information.
Press end key to end the call. To dial a domestic call, input area code + phone number and then press the dial key.
Dial international calls
If you want to make an international call, you can press * key continuously until the international
dialing prefix “+” is seen on the screen. This will allow you make an international call from any
country without knowing the dialing prefix (for example, +86 represents China).
After inputting the prefix, you need to input the Country number and complete telephone number. You
can input the Country number according to the common practice, such as, 49 for Germany, 44 for British, 46 for Sweden, etc.
Dial international telephone number as following: “+” Country number +Complete telephone number
+ Dial key.
Dial fixed-line telephone extension
Some fixed-line telephone extension may not directly get through, so you need to connect to the
switchboard at first then put through extension number. The mobile phone can automatically dial extension number if you input “P” between the switchboard and extension number. Method for input
“P” as following: hold press or continually short press three times “*” key (“P” will be shown on the
display).
