SETUP & OPERATION MANUAL
FEATURES
Industrial-duty motor designed for continuous
use.
Heavy-duty steel construction, mounted on four
swivel casters for total mobility and stability.
Safety lock-out switch with removable key to
prevent unauthorized use.
Precision spin-balanced impeller for smooth
operation and minimal noise.
Reusable clear plastic collector bag.
Washable, extra-fine 5 micron filter bag.
Quick-release bags clamps with metal straps.
Hole in base allows floor sweeping use in the
shop.
¾ HP DUST COLLECTOR
SPECIFICATIONS
• Inlet diameter
(1) 4" (100 mm)
• Airflow capacity
441 cfm
• Blower wheel diameter
9" (230 mm)
• Sound rating
90 dB
• Bag opening diameter
12 5/8" (320 mm)
• Bag capacity
17 gallon (65 l)
• Static pressure (without bag)
5 ¾" of water
• Overall dimensions (l x w x h)
32 5/8" x 17 ¾" x 61" (830 x 450 x 1550 mm)
• Motor
¾ HP, 120 V, 1 Ph, 2.7 A
• Weight
48 lbs (22 Kg)
Version #1_Revision #1 - December 2014
© Copyright General International
MODEL
#
10-055
GENERAL® INTERNATIONAL
8360 Champ-d’Eau, Montreal (Quebec) Canada H1P 1Y3
Telephone (514) 326-1161 • Fax (514) 326-5555 • www.general.ca
THANK YOU
for choosing this General® International model 10-055 dust
collector. This machine has been carefully tested and inspected before shipment and if
properly used and maintained, will provide you with years of reliable service. For your safety,
as well as to ensure optimum performance and trouble-free operation, and to get the most
from your investment, please take the time to read this manual before assembling, installing
and operating the unit.
The manual’s purpose is to familiarize you with the safe operation, basic function, and features
of this dust collector as well as the set-up, maintenance and identification of its parts and
components. This manual is not intended as a substitute for formal woodworking instruction,
nor to offer the user instruction in the craft of woodworking. If you are not sure about the safety
of performing a certain operation or procedure, do not proceed until you can confirm, from
knowledgeable and qualified sources, that it is safe to do so.
Once you’ve read through these instructions, keep this manual handy for future reference.
DISCLAIMER: The information and specifications
in this manual pertain to the unit as it was supplied
from the factory at the time of printing. Because we
are committed to making constant improvements,
General® International reserves the right to make
changes to components, parts or features of this unit
as deemed necessary, without prior notice and without
obligation to install any such changes on previously
delivered units. Reasonable care is taken at the factory
to ensure that the specifications and information in this
manual corresponds with that of the unit with which it
was supplied. However, special orders and “after factory”
modifications may render some or all information in
this manual inapplicable to your machine. Further, as
several generations of this model of dust collector and
several versions of this manual may be in circulation,
if you own an earlier or later version of this unit, this
manual may not depict your unit exactly. If you have
any doubts or questions contact your retailer or our
support line with the model and serial number of your
unit for clarification.
GENERAL® INTERNATIONAL WARRANTY
All component parts of General® International and Excalibur by General International® products
are carefully inspected during all stages of production and each unit is thoroughly inspected upon
completion of assembly.
Limited Lifetime Warranty
Because of our commitment to quality and customer satisfaction, General® International agrees to
repair or replace any part or component which upon examination, proves to be defective in either
workmanship or material to the original purchaser for the life of the tool. However, the Limited Lifetime
Warranty does not cover any product used for professional or commercial production purposes nor
for industrial or educational applications. Such cases are covered by our Standard 2-year Limited
Warranty only. The Limited Lifetime Warranty is also subject to the “Conditions and Exceptions” as listed
below.
Standard 2-Year Limited Warranty
All products not covered by our lifetime warranty including products used in commercial, industrial
and educational applications are warranted for a period of 2 years (24 months) from the date of
purchase. General® International agrees to repair or replace any part or component which upon
examination, proves to be defective in either workmanship or material to the original purchaser during
this 2-year warranty period, subject to the “conditions and exceptions” as listed below.
To file a Claim
To file a claim under our Standard 2-year Limited Warranty or under our Limited Lifetime Warranty,
all defective parts, components or machinery must be returned freight or postage prepaid to
General® International, or to a nearby distributor, repair center or other location designated by
General® International. For further details call our service department at 1-888-949-1161 or your local
distributor for assistance when filing your claim.
Along with the return of the product being claimed for warranty, a copy of the original proof of purchase
and a “letter of claim” must be included (a warranty claim form can also be used and can be obtained,
upon request, from General® International or an authorized distributor) clearly stating the model and
serial number of the unit (if applicable) and including an explanation of the complaint or presumed
defect in material or workmanship.
CONDITIONS AND EXCEPTIONS:
This coverage is extended to the original purchaser only. Prior warranty registration is not required but
documented proof of purchase i.e. a copy of original sales invoice or receipt showing the date and
location of the purchase as well as the purchase price paid, must be provided at the time of claim.
Warranty does not include failures, breakage or defects deemed after inspection by
General® International to have been directly or indirectly caused by or resulting from; improper use,
or lack of or improper maintenance, misuse or abuse, negligence, accidents, damage in handling or
transport, or normal wear and tear of any generally considered consumable parts or components.
Repairs made without the written consent of General® International will void all warranty.
TABLE OF CONTENTS
Rules for safe operation ..................................................................................................... 5
Electrical requirements ...................................................................................................... 6
Identification of main parts and components .................................................................. 7
Unpacking .......................................................................................................................... 8
Laying out a plan for the piping ........................................................................................ 9
Assembly instructions ................................................................................................. 9 - 13
Assembling the frame ........................................................................................................................................ 9
Installing the casters ......................................................................................................................................... 10
Installing the impeller/separator assembly .................................................................................................. 11
Installing the hose ............................................................................................................................................. 11
Installing the filter bag ...................................................................................................................................... 12
Installing the collector bag ............................................................................................................................. 13
Basic adjustments and controls ...................................................................................... 13
Connecting to a power source .......................................................................................................................13
On/Off power switch .........................................................................................................................................13
Operating Instructions ..................................................................................................... 14
Using the machine in floor sweep mode ...................................................................................................... 14
Checklist before starting .................................................................................................................................. 14
Maintenance .................................................................................................................... 14
Periodic maintenance ..................................................................................................................................... 14
Cleaning or replacing the filter bag .............................................................................................................. 15
Recommended optional accessories ............................................................................. 15
Parts list & diagram .................................................................................................. 16 - 17
Contact information ........................................................................................................ 20
RULES FOR SAFE OPERATION
To help ensure safe operation, please take a moment to learn the machine’s applications and limitations,
as well as potential hazards. General
harmless for any injury that may result from the improper use of it’s equipment.
1. Do not operate the dust collector when tired,
distracted, or under the effects of drugs, alcohol or
any medication that impairs reflexes or alertness.
2. The work area should be well lit, clean and free
of debris.
3. Keep children and visitors at a safe distance when
the machine is in operation; do not permit them to
operate the dust collector .
4. Childproof and tamper proof your shop and all
machinery with locks, master electrical switches
and switch keys, to prevent unauthorized or unsu pervised use.
5. STAY ALERT! Give your work your undivided attention.
Even a momentary distraction can lead to serious
injury.
6. Fine particulate dust is a carcinogen that can be
hazardous to health. Work in a well-ventilated
area and whenever possible use a dust collector
and wear eye, ear and respiratory protection
devices.
7. Do not wear loose clothing, gloves, bracelets, neck laces or other jewelry while the dust collector is in
operation. Wear protective hair covering to contain
long hair and wear non-slip footwear.
8. Do not insert hands, fingers or any foreign objects
into ventilation inlet and outlet openings.
9. Do not operate this machine without either a filter
bag or filter cartridge properly installed on the unit.
10. Clean filters (bags on standard model or cartridges
on “CF” model) on a regular basis and replace as
needed.
11. Do not handle the electrical plug with wet hands.
12. Do not use this unit outdoors, or near wet surfaces.
®
International disclaims any real or implied warranty and hold itself
14. Do not vacuum anything that is burning, smoking
or smoldering such as cigarettes, matches or hot
ashes.
15. Do not vacuum or use this dust collector near flam mable or combustible liquids, gases, gasoline or
other fuels, lighter fluid, cleaners, oil or solvent
based paints, natural gas, hydrogen or explosive
dusts like coal dust, magnesium dust, grain dust or
gun powder.
16. Do not operate the unit until a dust hose is installed
onto the hose inlet.
17. Never leave the machine unattended while it is run ning or with the power on.
18. To avoid health hazards from vapors or dusts, do
not vacuum toxic material.
19. Use only recommended accessories. Use of ac cessories NOT recommended by General
tional may result in a risk of injury or damage to
the machine.
20. Always disconnect the unit from the power source
before servicing, performing any maintenance or
repairs and when changing bags or hoses, or if the
machine will be left unattended.
21. Make sure that the switch is in the “OFF” position be fore plugging in the power cord.
22. Make sure the tool is properly grounded. If equip ped with a 3-prong plug, it should be used with
a three-pole receptacle. Never remove the third
prong.
23. Do not use this dust collector for any purpose other
than its intended use. If used for other purposes,
General
plied warranty and holds itself harmless for any
injury, which may result from that use.
®
International disclaims any real or im-
®
Interna-
13. Always turn on the dust collector before starting
the dust producing machine. Always turn off the
dust producing machine before turning off the dust
collector.
5
ELECTRICAL REQUIREMENTS
BEFORE CONNECTING THE MACHINE TO THE POWER SOURCE, VERIFY THAT THE VOLTAGE OF YOUR POWER
SUPPLY CORRESPONDS WITH THE VOLTAGE SPECIFIED ON THE MOTOR I.D. NAMEPLATE. A POWER SOURCE
WITH GREATER VOLTAGE THAN NEEDED CAN RESULT IN SERIOUS INJURY TO THE USER AS WELL AS DAMAGE
TO THE MACHINE. IF IN DOUBT, CONTACT A QUALIFIED ELECTRICIAN BEFORE CONNECTING TO THE POWER
SOURCE.
THIS TOOL IS FOR INDOOR USE ONLY. DO NOT EXPOSE TO RAIN OR USE IN WET OR DAMP LOCATIONS.
GROUNDING INSTRUCTIONS
In the event of an electrical malfunction or short circuit,
grounding reduces the risk of electric shock. The motor
of this machine is wired for 120 V single phase operation and is equipped with a 3-conductor cord and
a 3-prong grounding plug A to fit a grounded type
receptacle B. Do not remove the 3rd prong (grounding pin) to make it fit into an old 2-hole wall socket or
extension cord. If an adaptor plug is used C, it must be
attached to the metal screw of the receptacle.
Note: The use of an adaptor plug is illegal in some
areas. Check your local codes. If you have any
doubts or if the supplied plug does not correspond
to your electrical outlet, consult a qualified electrician before proceeding.
A
B
C
CIRCUIT CAPACITY
Make sure that the wires in your circuit are capable of handling the amperage draw from your machine, as well
as any other machines that could be operating on the same circuit. If you are unsure, consult a qualified electrician. If the circuit breaker trips or the fuse blows regularly, your machine may be operating on a circuit that is
close to its amperage draw capacity. However, if an unusual amperage draw does not exist and a power failure
still occurs, contact a qualified technician or our service department.
EXTENSION CORDS
If you find it necessary to use an extension cord with your machine, use only 3-wire extension cords that have
3-prong grounding plug and a matching 3-pole receptacle that accepts the tool’s plug. Repair or replace a damaged extension cord or plug immediately.
Make sure the cord rating is suitable for the amperage listed on the motor I.D. plate. An undersized cord will cause
a drop in line voltage resulting in loss of power and overheating. The accompanying chart shows the correct size
extension cord to be used based on cord length and motor I.D. plate amp rating. If in doubt, use the next heavier
gauge. The smaller the number, the heavier the gauge.
TABLE - MINIMUM GAUGE FOR CORD
EXTENSION CORD LENGTH
AMPERES 50 feet 100 feet 200 feet 300 feet
< 5
6 to 10
10 to 12
12 to 16
*NR = Not Recommended
18 16 16 14
18 16 14 12
16 16 14 12
14 12 *NR *NR
6
IDENTIFICATION OF MAIN PARTS AND COMPONENTS
A. SWIVEL CASTER (4)
B. FLOOR SWEEP OPENING
C. BASE
D. DUST HOSE
E. IMPELLER/SEPARATOR ASSEMBLY
F. SAFETY SWITCH
G. MOTOR
H. 5 MICRON FILTER BAG
I. QUICK-RELEASE BAG CLAMP
J. COLLECTOR BAG
G
H
D
F
I
E
J
C
B
A
7
UNPACKING
Carefully unpack and remove the unit and its components from the box and check for missing or damaged items
as per the list of contents below.
NOTE: PLEASE REPORT ANY DAMAGED OR MISSING ITEMS TO YOUR GENERAL® INTERNATIONAL DISTRIBUTOR IMMEDIATELY.
LIST OF CONTENTS QTY
A. IMPELLER/SEPARATOR ASSEMBLY ...........................................1
B. VERTICAL SUPPORT PANEL ....................................................... 2
C. CROSS PANEL........................................................................... 1
D. BAG HANGER .......................................................................... 1
E. BASE ......................................................................................... 1
F. DUST HOSE ............................................................................... 1
G. FILTER BAG ............................................................................... 1
H. HOSE FITTING ........................................................................... 1
I. COLLECTOR BAG ..................................................................... 1
J. HOSE CLAMP ........................................................................... 2
K. BAG CLAMP ............................................................................ 2
L. CARRIAGE BOLT (M8 X 12) ..................................................... 4
M. CARRIAGE BOLT (SMALL) ........................................................ 4
N. BOLT (M6 X 12) ........................................................................ 6
O. FLANGE NUT (M6) ................................................................... 6
P. NUT ........................................................................................... 4
Q. FLANGE NUT (M8) ................................................................... 4
R. SWIVEL CASTER ........................................................................ 2
S. LOCKABLE SWIVEL CASTER ..................................................... 2
T. GROUNDING CHAIN W/SCREW ............................................. 1
ADDITIONAL REQUIREMENTS FOR SET UP
A. EXTRA PERSON FOR HELP WITH LIFTING
B. 9, 13 & 17 MM WRENCHES
C. FLAT HEAD SCREWDRIVER
A B
C
H
A
R S
B
T
C
D
F
G
I
E
J
K
L
M
N
O
P
Q
8
LAYING OUT A PLAN FOR THE PIPING
LAYING OUT A PLAN FOR THE PIPING
For permanent installations, it is advisable to map out a rough layout of your planned installation starting from
the dust collector out to all the machines that you wish to connect to the system. You may vary your layout to suit
your specific shop needs and may choose to use metal or plastic ducting, or flexible hose in any combination as
suited to your needs.
Note: To avoid accidents as well as damage to ducting or hoses, plan your installation with hoses and ducting
running along walls or mounted from above wherever possible. See the accompanying examples of non-recommended
and recommended installations.
HOSES AND DUCTING RUNNING ALONG THE SHOP FLOOR BETWEEN MACHINERY CAN CAUSE USERS TO TRIP
AND LEAD TO SERIOUS INJURY.
Wherever possible avoid running hoses and ducting
along the floor.
ASSEMBLY INSTRUCTIONS
BEFORE ASSEMBLING, MAKE SURE THAT THE SWITCH IS IN THE “OFF” POSITION AND THAT THE POWER CORD IS
UNPLUGGED. DO NOT PLUG IN OR TURN ON THE MACHINE UNTIL YOU HAVE COMPLETED THE ASSEMBLY AND
INSTALLATION STEPS DESCRIBED IN THIS SECTION OF THE MANUAL.
ASSEMBLING THE FRAME
Keep hoses and ducting safely mounted along the
walls.
A
1. Set the base on a flat and stable surface. 2. Align the three holes located on the bottom of the
left support panel A with the corresponding holes
in the base as shown.
9
BEFORE ASSEMBLING, MAKE SURE THAT THE SWITCH IS IN THE “OFF” POSITION AND THAT THE POWER CORD IS
UNPLUGGED. DO NOT PLUG IN OR TURN ON THE MACHINE UNTIL YOU HAVE COMPLETED THE ASSEMBLY AND
INSTALLATION STEPS DESCRIBED IN THIS SECTION OF THE MANUAL.
ASSEMBLING THE FRAME (CONTINUED)
C
B
C
3. Insert a bolt B into each hole and secure the sup-
port using a flange nut C and a 9 mm wrench.
Then repeat steps 2 and 3 with the second support
panel.
D
E
5. Slide the cross panel D onto the carriage bolts and
secure it in place using the flange nuts E and a 13
mm wrench.
4. Insert a carriage bolt C into each hole located in
the support panel sides.
6. Make sure the frame is assembled as shown.
INSTALLING THE CASTERS
1. Insert a wheel into the mounting holes located in
each corner of the base, and secure it by tightening a nut A using two 17 mm wrenches.
10
C
B
A
B
Note: The two swivel casters must be installed in the front
of the machine B while the two lockable swivel casters
must be installed in the back C.
BEFORE ASSEMBLING, MAKE SURE THAT THE SWITCH IS IN THE “OFF” POSITION AND THAT THE POWER CORD IS
UNPLUGGED. DO NOT PLUG IN OR TURN ON THE MACHINE UNTIL YOU HAVE COMPLETED THE ASSEMBLY AND
INSTALLATION STEPS DESCRIBED IN THIS SECTION OF THE MANUAL.
INSTALLING THE IMPELLER/SEPARATOR ASSEMBLY
D
1. Install the separator on the frame. 2. Align the mounting holes D with the correspond-
ing holes on the two sides of frame.
F
3. Insert a carriage bolt E into each mounting holes. 4. Attach the separator to the frame by tightening
four nuts F with a 8 mm wrench.
INSTALLING THE HOSE
A
1. Loosen the screw A using a flat head screwdriver
to open the hose clamp.
2. Slide the hose clamp onto the hose.
11
BEFORE ASSEMBLING, MAKE SURE THAT THE SWITCH IS IN THE “OFF” POSITION AND THAT THE POWER CORD IS
UNPLUGGED. DO NOT PLUG IN OR TURN ON THE MACHINE UNTIL YOU HAVE COMPLETED THE ASSEMBLY AND
INSTALLATION STEPS DESCRIBED IN THIS SECTION OF THE MANUAL.
INSTALLING THE HOSE (CONTINUED)
3. Slide the hose onto the inlet located under the im-
peller.
INSTALLING THE FILTER BAG
1. Fit the bag hanger support into the holes on the
separator A.
2. Slip a belt clamp through the opening in the filter
bag B, then fit the bag on the hanger C.
3. Use the belt clamp to attach the filter bag to the
separator D & E.
Note: Before tightening the clamp make sure the metal
strap is well seated on the upper portion of separator to
create an airtight seal between the fan and the bag.
A
4. Tighten the hose clamp using a flat head screw-
driver. Repeat steps 1 to 2 with the other hose
clamp, then connect to the dust producing machine.
B
C
12
D E
INSTALLING THE COLLECTOR BAG
1. Install the collector bag on the lower portion of the
separator.
2. Use the clamp to attach the bag to the lower por-
tion of the separator.
Note: Before tightening the clamp make sure the metal
strap is well seated on the upper portion of separator to
create an airtight seal between the fan and the bag.
BASIC ADJUSTMENTS & CONTROLS
TO REDUCE THE RISK OF SHOCK OR FIRE DO NOT OPERATE THE UNIT WITH A DAMAGED POWER CORD OR PLUG. REPLACE DAMAGED CORD OR PLUG IMMEDIATELY. TO AVOID UNEXPECTED OR UNINTENTIONAL START-UP, MAKE SURE
THE POWER SWITCH IS IN THE OFF POSITION BEFORE CONNECTING TO A POWER SOURCE.
CONNECTING TO A POWER SOURCE
Once the assembly steps have been completed, plug the power cord into an appropriate outlet. Refer back to
the section entitled “Electrical Requirements” and make sure all requirements and grounding instructions are followed. When operations have been completed unplug the machine
Note: Screw the chain into the base A to ground the machine.
SWITCH OFF
TO AVOID UNEXPECTED OR UNINTENTIONAL
START-UP, MAKE SURE THAT THE POWER SWITCH
IS IN THE OFF POSITION BEFORE CONNECTING
TO A POWER SOURCE.
A
from the power source.
ON/OFF POWER SWITCH
The machine is equipped with a rocker type ON/OFF switch that is equipped with a lock-out key. To prevent unwanted or unauthorized start-up remove the lock-out key D and store it in a safe place. To start the machine, insert
the lock-out key and pull up the switch B. To stop the machine, push down on the power switch C. When the machine comes to a complete stop, remove the lock-out key D by gently pulling it outward.
B
POWER ON
C
D
POWER OFF LOCK-OUT KEY
(PREVENTS START-UP WHEN REMOVED)
13
OPERATING INSTRUCTIONS
USING THE MACHINE IN FLOOR SWEEP MODE
A hole in the base allows floor sweeping use. To use the
machine in floor sweep mode proceed as follows:
1. Turn off the machine.
2. If the dust hose is connected to a machine in the
shop, disconnect the hose from the machine.
3. Insert the dust port A into the hole located in the
base as shown B.
4. Start the dust collector, then wheel the machine
around the shop to vacuum up dust on the floor.
CHECKLIST BEFORE STARTING
ALWAYS TURN ON THE DUST COLLECTOR BEFORE STARTING YOUR DUST PRODUCING MACHINE AND ALWAYS STOP THE
DUST PRODUCING MACHINE BEFORE TURNING OFF THE DUST COLLECTOR.
•
To minimize airborne dust make sure that all hoses, fittings and clamps are secure and airtight.
•
Never operate the machine without the filter bag and the collection bag properly installed.
A
B
THE SOUND LEVEL OF THIS MACHINE IS RATED AT APPROXIMATELY 90 DB DURING OPERATION. MAKE SURE THAT ADEQUATE HEARING PROTECTION IS USED AND THAT THE OVERALL SOUND LEVEL WITHIN THE WORK ENVIRONMENT IS
TAKEN INTO CONSIDERATION.
MAINTENANCE
MAKE SURE THE MACHINE HAS BEEN TURNED OFF AND UNPLUGGED FROM THE POWER SOURCE BEFORE PERFORMING ANY MAINTENANCE OR ADJUSTMENTS.
PERIODIC MAINTENANCE
• All bearings are sealed and permanently lubricated. No further lubrication is needed.
• Periodically inspect all hardware, fittings and fasteners that may have loosened due to vibration - retighten as
needed.
• Keep the outside of the unit clean and wipe off excessive dust or dirt with a dry rag.
• Clean filter bag on a regular basis and replace as needed.
• Periodically inspect inside all pipes, fittings, hoses, blast gates, and connectors for accumulated dust buildup or other obstructions and clean as needed. Remove sections and vacuum or manually remove debris as
needed.
• Check and if necessary replace all damaged parts or components.
• Do not operate with a damaged filter bag - replace damaged filter immediately.
• Periodically inspect the power cord and plug for damage. If necessary, replace the power cord and plug
at the first signs of visible damage.
• Use only recommended parts and accessories. The use of parts or accessories NOT recommended by
GENERAL® INTERNATIONAL may result in a risk of injury or damage to the machine.
14
CLEANING OR REPLACING THE FILTER BAG
Tip: To avoid potentially costly down-time, consider keeping a spare filter bag on-hand and nearby for use if needed.
After a period of time, depending on the frequency of use, the filter bag may become clogged and affect airflow
as well the overall efficiency of the unit. Should you notice a drop in the efficiency or performance of the unit, it
may be a sign that it is time to clean the filter bag. If so, proceed as follows:
1. Turn off and unplug the machine. Unclip the belt
clamp and remove the bag from the machine.
Clean the dust from inside the filter bag using a
vacuum.
Note: For extreme cases, after the initial cleaning with a
vacuum, turn the filter bag inside out and vacuum a second time, laying the bag on a flat hard surface (such as
a table or workbench) and slowly passing the vacuum
nozzle over the entire surface area.
2. Reinstall the bag and reattach the clamp.
Note: Filter bags can also be machine washed (gentle
cycle only) in cold or warm water. Do not use hot water
or detergent. Make sure the bag has completely dried before reinstalling on the machine. Make sure to remove the
belt clamp from the bag before washing!
RECOMMENDED OPTIONAL ACCESSORIES
Here is a sampling of optional accessories available from your local General International dealer that can be
used with this product. For more information about our products, please visit our website at www.general.ca
Item #10-056
FILTER BAG
Washable, extra-fine
5 micron filter bag for
model 10-055.
Item #10-057
BAGS CLAMP
Cast-iron bag clamp for
model 10-055.
Item #10-058
CLEAR PLASTIC COLLECTOR BAG
For model 10-055.
Item #10-089
HOSE CLAMP
For 4" dust collector hose
Item #10-085
4" SPLICE
For 4" hose.
Item #10-130/410
DUST HOSES
Heavy-duty polyethylene flexible. 10-130: 4" X
50'; v10-410: 4" X 10'
15
DIAGRAM
10-055
1
32
31
30
29
28
27
22
21
20
33
23
34
35
2
26
36
2
19
18
17
16
15
24
25
3
9
4
5
6
7
8
13
16
8
10111214
PARTS LIST
10-055
IMPORTANT: When ordering replacement parts, always give the model number, serial number of the
machine and part number. Also a brief description of each item and quantity desired.
PART # REFERENCE # DESCRIPTION QTY
10055-01 FILTER BAG 5 MICRON 1
10055-02 LOWER BAG CLAMP 2
10055-03 COLLECTOR BAG 1
10055-04 LEFT SIDE PANEL 1
10055-05 NUT M5 20
10055-06 CARRIAGE BOLT M8 X 12 4
10055-07 BASE 1
10055-08 FLANGE NUT M6 7
10055-09 ENHANCE PANEL 1
10055-10 INLET 4" 1
10055-11 SWIVEL CASTER 2
10055-12 HEX HEAD BOLT M6 X 12 6
10055-13 GROUNDING CHAIN 1
10055-14 LOCKABLE SWIVEL CASTER 2
10055-15 FLANGE NUT M8 4
10055-16 HOSE 1
10055-17 HOSE CLAMP 2
10055-18 SUPPORT PLATE 1
10055-19 RIGHT SIDE PANEL 1
10055-20 IMPELLER 1
10055-21 HEX HEAD BOLT M8 X 12 4
10055-22 LOCK WASHER 4
10055-23 LARGE WASHER 1
10055-24 LOWER IMPELLER COVER 1
10055-25 CAP SCREW M6 X 1 1
10055-26 UPPER IMPELLER COVER 1
10055-27 CARRIAGE BOLT M5 X16 14
10055-28 SWITCH 1
10055-29 SELF-TAPPING SCREW ST3.5 X 9.5 6
10055-30 SWITCH COVER 1
10055-31 SELF-TAPPING SCREW ST2.9 X 9 .5 4
10055-32 SWITCH PLATE 1
10055-33 CORD 1
10055-34 MOTOR 1
10055-35 HANGER 1
10055-36 CARRIAGE BOLT M5 X 20 6
17
8360 Champ-d’Eau, Montreal (Quebec) Canada H1P 1Y3
Fax: (514) 326-5565 - Parts & Service / (514) 326-5555 - Order Desk
www.general.ca
Tel.: (514) 326-1161
orderdesk@general.ca
Follow us:
Loading...
