General Electric VIVID E9 SERVICE MANUAL_SM_GA091568_5 150-10-7 Digital Floor Level Scale Software Revision 11454 Technical Manual

GE Healthcare

VIVID E9

Service Manual

OP ER ATING DOCUMENTATION

Part Number: GA091568

Revision: 5

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVIDE9 S

Important Precautions

TRANSLATION POLICY

THIS SERVICE MANUAL IS AVAILABLE IN ENGLISH ONLY.

• IF A CUSTOMER’S SERVICE PROVIDER REQUIRES A LANGUAGE OTHER
THAN ENGLISH, IT IS THE CUSTOMER’S RESPONSIBILITY TO PROVIDE
TRANSLATION SERVICES.

WARNING

(EN)

AVERTISSEMENT

(FR)

• DO NOT ATTEMPT TO SERVICE THE EQUIPMENT UNLESS THIS SERVICE
MANUAL HAS BEEN CONSULTED AND IS UNDERSTOOD.

• FAILURE TO HEED THIS WARNING MAY RESULT IN INJURY TO THE SERVICE
PROVIDER, OPERATOR OR PATIENT FROM ELECTRIC SHOCK, MECHANICAL
OR OTHER HAZARDS.

CE MANUEL DE MAINTENANCE N’EST DISPONIBLE QU’EN ANGLAIS.

• SI LE TECHNICIEN DU CLIENT A BESOIN DE CE MANUEL DANS UNE AUTRE
LANGUE QUE L’ANGLAIS, C’EST AU CLIENT QU’IL INCOMBE DE LE FAIRE
TRADUIRE.

• NE PAS TENTER D’INTERVENTION SUR LES ÉQUIPEMENTS TANT QUE LE
MANUEL SERVICE N’A PAS ÉTÉ CONSULTÉ ET COMPRIS.

• LE NON-RESPECT DE CET AVERTISSEMENT PEUT ENTRAÎNER CHEZ LE
TECHNICIEN, L’OPÉRATEUR OU LE PATIENT DES BLESSURES DUES À DES
DANGERS ÉLECTRIQUES, MÉCANIQUES OU AUTRES.

ERVICE MANUAL

WARNUNG

(DE)

DIESES KUNDENDIENST-HANDBUCH EXISTIERT NUR IN ENGLISCHER
SPRACHE.

• FALLS EIN FREMDER KUNDENDIENST EINE ANDERE SPRACHE BENÖTIGT,
IST ES AUFGABE DES KUNDEN FÜR EINE ENTSPRECHENDE ÜBERSETZUNG
ZU SORGEN.

• VERSUCHEN SIE NICHT, DAS GERÄT ZU REPARIEREN, BEVOR DIESES
KUNDENDIENST-HANDBUCH NICHT ZU RATE GEZOGEN UND VERSTANDEN
WURDE.

• WIRD DIESE WARNUNG NICHT BEACHTET, SO KANN ES ZU VERLETZUNGEN
DES KUNDENDIENSTTECHNIKERS, DES BEDIENERS ODER DES PATIENTEN
DURCH ELEKTRISCHE SCHLÄGE, MECHANISCHE ODER SONSTIGE
GEFAHREN KOMMEN.

- i

GE H
D

IRECTION

ATENÇÃO

EALTHCARE

GA091568, R

AVISO

(ES)

(PT-Br)

EVISION

5 VIVIDE9 S

ERVICE MANUAL

ESTE MANUAL DE SERVICIO SÓLO EXISTE EN INGLÉS.

• SI ALGÚN PROVEEDOR DE SERVICIOS AJENO A GEHC SOLICITA UN IDIOMA
QUE NO SEA EL INGLÉS, ES RESPONSABILIDAD DEL CLIENTE OFRECER UN
SERVICIO DE TRADUCCIÓN.

• NO SE DEBERÁ DAR SERVICIO TÉCNICO AL EQUIPO, SIN HABER
CONSULTADO Y COMPRENDIDO ESTE MANUAL DE SERVICIO.

• LA NO OBSERVANCIA DEL PRESENTE AVISO PUEDE DAR LUGAR A QUE EL
PROVEEDOR DE SERVICIOS, EL OPERADOR O EL PACIENTE SUFRAN
LESIONES PROVOCADAS POR CAUSAS ELÉCTRICAS, MECÁNICAS O DE
OTRA NATURALEZA.

ESTE MANUAL DE ASSISTÊNCIA TÉCNICA SÓ SE ENCONTRA DISPONÍVEL EM
INGLÊS.

• SE QUALQUER OUTRO SERVIÇO DE ASSISTÊNCIA TÉCNICA, QUE NÃO A
GEHC, SOLICITAR ESTES MANUAIS NOUTRO IDIOMA, É DA
RESPONSABILIDADE DO CLIENTE FORNECER OS SERVIÇOS DE TRADUÇÃO.

• NÃO TENTE REPARAR O EQUIPAMENTO SEM TER CONSULTADO E
COMPREENDIDO ESTE MANUAL DE ASSISTÊNCIA TÉCNICA.

• O NÃO CUMPRIMENTO DESTE AVISO PODE POR EM PERIGO A SEGURANÇA
DO TÉCNICO, OPERADOR OU PACIENTE DEVIDO A‘ CHOQUES ELÉTRICOS,
MECÂNICOS OU OUTROS.

AVISO

(PT-pt)

AVVERTENZA

(IT)

ESTE MANUAL DE ASSISTÊNCIA ESTÁ DISPONÍVEL APENAS EM INGLÊS.

• SE QUALQUER OUTRO SERVIÇO DE ASSISTÊNCIA TÉCNICA, QUE NÃO A
GEHC, SOLICITAR ESTES MANUAIS NOUTRO IDIOMA, É DA
RESPONSABILIDADE DO CLIENTE FORNECER OS SERVIÇOS DE TRADUÇÃO.

• NÃO TENTE EFECTUAR REPARAÇÕES NO EQUIPAMENTO SEM TER
CONSULTADO E COMPREENDIDO PREVIAMENTE ESTE MANUAL.

• A INOBSERVÂNCIA DESTE AVISO PODE RESULTAR EM FERIMENTOS NO
TÉCNICO DE ASSISTÊNCIA, OPERADOR OU PACIENTE EM CONSEQUÊNCIA
DE CHOQUE ELÉCTRICO, PERIGOS DE ORIGEM MECÂNICA, BEM COMO DE
OUTROS TIPOS.

IL PRESENTE MANUALE DI MANUTENZIONE È DISPONIBILE SOLTANTO IN
INGLESE.

• SE UN ADDETTO ALLA MANUTENZIONE ESTERNO ALLA GEHC RICHIEDE IL
MANUALE IN UNA LINGUA DIVERSA, IL CLIENTE È TENUTO A PROVVEDERE
DIRETTAMENTE ALLA TRADUZIONE.

• SI PROCEDA ALLA MANUTENZIONE DELL’APPARECCHIATURA SOLO DOPO
AVER CONSULTATO IL PRESENTE MANUALE ED AVERNE COMPRESO IL
CONTENUTO.

• NON TENERE CONTO DELLA PRESENTE AVVERTENZA POTREBBE FAR
COMPIERE OPERAZIONI DA CUI DERIVINO LESIONI ALL’ADDETTO ALLA
MANUTENZIONE, ALL’UTILIZZATORE ED AL PAZIENTE PER FOLGORAZIONE
ELETTRICA, PER URTI MECCANICI OD ALTRI RISCHI.

ii -

GE H

EALTHCARE

D

IRECTION

HOIATUS

VAROITUS

GA091568, R

(ET)

(FI)

EVISION

5 VIVIDE9 S

ERVICE MANUAL

KÄESOLEV TEENINDUSJUHEND ON SAADAVAL AINULT INGLISE KEELES.

• KUI KLIENDITEENINDUSE OSUTAJA NÕUAB JUHENDIT INGLISE KEELEST
ERINEVAS KEELES, VASTUTAB KLIENT TÕLKETEENUSE OSUTAMISE EEST.

• ÄRGE ÜRITAGE SEADMEID TEENINDADA ENNE EELNEVALT KÄESOLEVA
TEENINDUSJUHENDIGA TUTVUMIST JA SELLEST ARU SAAMIST.

• KÄESOLEVA HOIATUSE EIRAMINE VÕIB PÕHJUSTADA TEENUSEOSUTAJA,
OPERAATORI VÕI PATSIENDI VIGASTAMIST ELEKTRILÖÖGI, MEHAANILISE
VÕI MUU OHU TAGAJÄRJEL.

TÄMÄ HUOLTO-OHJE ON SAATAVILLA VAIN ENGLANNIKSI.

• JOS ASIAKKAAN PALVELUNTARJOAJA VAATII MUUTA KUIN
ENGLANNINKIELISTÄ MATERIAALIA, TARVITTAVAN KÄÄNNÖKSEN
HANKKIMINEN ON ASIAKKAAN VASTUULLA.

• ÄLÄ YRITÄ KORJATA LAITTEISTOA ENNEN KUIN OLET VARMASTI LUKENUT
JA YMMÄRTÄNYT TÄMÄN HUOLTO-OHJEEN.

• MIKÄLI TÄTÄ VAROITUSTA EI NOUDATETA, SEURAUKSENA VOI OLLA
PALVELUNTARJOAJAN, LAITTEISTON KÄYTTÄJÄN TAI POTILAAN
VAHINGOITTUMINEN SÄHKÖISKUN, MEKAANISEN VIAN TAI MUUN
VAARATILANTEEN VUOKSI.

ΠΡΟΕΙ∆ΟΠΟΙΗΣΗ

(EL)

FIGYELMEZTETÉS

(HU)

ΤΟ ΠΑΡΟΝ ΕΓΧΕΙΡΙ∆ΙΟ ΣΕΡΒΙΣ ∆ΙΑΤΙΘΕΤΑΙ ΣΤΑ ΑΓΓΛΙΚΑ ΜΟΝΟ.

• ΕΑΝ ΤΟ ΑΤΟΜΟ ΠΑΡΟΧΗΣ ΣΕΡΒΙΣ ΕΝΟΣ ΠΕΛΑΤΗ ΑΠΑΙΤΕΙ ΤΟ ΠΑΡΟΝ

ΕΓΧΕΙΡΙ∆ΙΟ ΣΕ ΓΛΩΣΣΑ ΕΚΤΟΣ ΤΩΝ ΑΓΓΛΙΚΩΝ, ΑΠΟΤΕΛΕΙ ΕΥΘΥΝΗ ΤΟΥ
ΠΕΛΑΤΗ ΝΑ ΠΑΡΕΧΕΙ ΥΠΗΡΕΣΙΕΣ ΜΕΤΑΦΡΑΣΗΣ.

• ΜΗΝ ΕΠΙΧΕΙΡΗΣΕΤΕ ΤΗΝ ΕΚΤΕΛΕΣΗ ΕΡΓΑΣΙΩΝ ΣΕΡΒΙΣ ΣΤΟΝ ΕΞΟΠΛΙΣΜΟ
ΕΚΤΟΣ ΕΑΝ

ΕΧΕΤΕ ΣΥΜΒΟΥΛΕΥΤΕΙ ΚΑΙ ΕΧΕΤΕ ΚΑΤΑΝΟΗΣΕΙ ΤΟ ΠΑΡΟΝ

ΕΓΧΕΙΡΙ∆ΙΟ ΣΕΡΒΙΣ.

• ΕΑΝ ∆Ε ΛΑΒΕΤΕ ΥΠΟΨΗ ΤΗΝ ΠΡΟΕΙ∆ΟΠΟΙΗΣΗ ΑΥΤΗ, ΕΝ∆ΕΧΕΤΑΙ ΝΑ
ΠΡΟΚΛΗΘΕΙ ΤΡΑΥΜΑΤΙΣΜΟΣ ΣΤΟ ΑΤΟΜΟ ΠΑΡΟΧΗΣ ΣΕΡΒΙΣ, ΣΤΟ ΧΕΙΡΙΣΤΗ Ή
ΣΤΟΝ ΑΣΘΕΝΗ ΑΠΟ ΗΛΕΚΤΡΟΠΛΗΞΙΑ, ΜΗΧΑΝΙΚΟΥΣ Ή ΑΛΛΟΥΣ ΚΙΝ∆ΥΝΟΥΣ.

EZEN KARBANTARTÁSI KÉZIKÖNYV KIZÁRÓLAG ANGOL NYELVEN ÉRHETŐ EL.

• HA A VEVŐ SZOLGÁLTATÓJA ANGOLTÓL ELTÉRŐ NYELVRE TART IGÉNYT,
AKKOR A VEVŐ FELELŐSSÉGE A FORDÍTÁS ELKÉSZÍTTETÉSE.

• NE PRÓBÁLJA ELKEZDENI HASZNÁLNI A BERENDEZÉST, AMÍG A
KARBANTARTÁSI KÉZIKÖNYVBEN LEÍRTAKAT NEM ÉRTELMEZTÉK.

• EZEN FIGYELMEZTETÉS FIGYELMEN KÍVÜL HAGYÁSA A SZOLGÁLTATÓ,
MŰKÖDTETŐ VAGY A BETEG ÁRAMÜTÉS, MECHANIKAI VAGY EGYÉB
VESZÉLYHELYZET MIATTI SÉRÜLÉSÉT EREDMÉNYEZHETI.

- iii

GE H
D

IRECTION

VIÐVÖRUN

VÝSTRAHA

EALTHCARE

GA091568, R

(IS)

(CS)

EVISION

5 VIVIDE9 S

ERVICE MANUAL

ÞESSI ÞJÓNUSTUHANDBÓK ER EINGÖNGU FÁANLEG Á ENSKU.

• EF ÞJÓNUSTUAÐILI VIÐSKIPTAMANNS ÞARFNAST ANNARS TUNGUMÁLS EN
ENSKU, ER ÞAÐ Á ÁBYRGÐ VIÐSKIPTAMANNS AÐ ÚTVEGA ÞÝÐINGU.

• REYNIÐ EKKI AÐ ÞJÓNUSTA TÆKIÐ NEMA EFTIR AÐ HAFA SKOÐAÐ OG
SKILIÐ ÞESSA ÞJÓNUSTUHANDBÓK.

• EF EKKI ER FARIÐ AÐ ÞESSARI VIÐVÖRUN GETUR ÞAÐ VALDIÐ MEIÐSLUM
ÞJÓNUSTUVEITANDA, STJÓRNANDA EÐA SJÚKLINGS VEGNA RAFLOSTS,
VÉLRÆNNAR EÐA ANNARRAR HÆTTU.

TENTO SERVISNÍ NÁVOD EXISTUJE POUZE V ANGLICKÉM JAZYCE.

•VPŘÍPADĚ, ŽE POSKYTOVATEL SLUŽEB ZÁKAZNÍKŮM POTŘEBUJE NÁVOD
V JINÉM JAZYCE, JE ZAJIŠTĚNÍ PŘEKLADU DO ODPOVÍDAJÍCÍHO JAZYKA
ÚKOLEM ZÁKAZNÍKA.

• NEPROVÁDĚJTE ÚDRŽBU TOHOTO ZAŘÍZENÍ, ANIŽ BYSTE SI PŘEČETLI
TENTO SERVISNÍ NÁVOD A POCHOPILI JEHO OBSAH.

•VPŘÍPADĚ NEDODRŽOVÁNÍ TÉTO VÝSTRAHY MŮŽE DOJÍT ÚRAZU
ELEKTRICKÁM PROUDEM PRACOVNÍKA POSKYTOVATELE SLUŽEB,
OBSLUŽNÉHO PERSONÁLU NEBO PACIENTŮ VLIVEM ELEKTRICKÉHOP
PROUDU, RESPEKTIVE VLIVEM K RIZIKU MECHANICKÉHO POŠKOZENÍ NEBO
JINÉMU RIZIKU.

ADVARSEL

(DA)

WAARSCHUWING

(NL)

DENNE SERVICEMANUAL FINDES KUN PÅ ENGELSK.

• HVIS EN KUNDES TEKNIKER HAR BRUG FOR ET ANDET SPROG END
ENGELSK, ER DET KUNDENS ANSVAR AT SØRGE FOR OVERSÆTTELSE.

• FORSØG IKKE AT SERVICERE UDSTYRET MEDMINDRE
DENNE SERVICEMANUAL ER BLEVET LÆST OG FORSTÅET.

• MANGLENDE OVERHOLDELSE AF DENNE ADVARSEL KAN MEDFØRE SKADE
PÅ GRUND AF ELEKTRISK, MEKANISK ELLER ANDEN FARE FOR
TEKNIKEREN, OPERATØREN ELLER PATIENTEN.

DEZE ONDERHOUDSHANDLEIDING IS ENKEL IN HET ENGELS VERKRIJGBAAR.

• ALS HET ONDERHOUDSPERSONEEL EEN ANDERE TAAL VEREIST, DAN IS DE
KLANT VERANTWOORDELIJK VOOR DE VERTALING ERVAN.

• PROBEER DE APPARATUUR NIET TE ONDERHOUDEN VOORDAT DEZE
ONDERHOUDSHANDLEIDING WERD GERAADPLEEGD EN BEGREPEN IS.

• INDIEN DEZE WAARSCHUWING NIET WORDT OPGEVOLGD, ZOU HET
ONDERHOUDSPERSONEEL, DE OPERATOR OF EEN PATIËNT GEWOND
KUNNEN RAKEN ALS GEVOLG VAN EEN ELEKTRISCHE SCHOK,
MECHANISCHE OF ANDERE GEVAREN.

iv -

GE H

EALTHCARE

D

IRECTION

BRĪDINĀJUMS

ĮSPĖJIMAS

GA091568, R

(LV)

(LT)

EVISION

5 VIVIDE9 S

ERVICE MANUAL

ŠĪ APKALPES ROKASGRĀMATA IR PIEEJAMA TIKAI ANGĻU VALODĀ.

• JA KLIENTA APKALPES SNIEDZĒJAM NEPIECIEŠAMA INFORMĀCIJA CITĀ
VALODĀ, NEVIS ANGĻU, KLIENTA PIENĀKUMS IR NODROŠINĀT TULKOŠANU.

• NEVEICIET APRĪKOJUMA APKALPI BEZ APKALPES ROKASGRĀMATAS
IZLASĪŠANAS UN SAPRAŠANAS.

•ŠĪ BRĪDINĀJUMA NEIEVĒROŠANA VAR RADĪT ELEKTRISKĀS STRĀVAS
TRIECIENA, MEHĀNISKU VAI CITU RISKU IZRAISĪTU TRAUMU APKALPES
SNIEDZĒJAM, OPERATORAM VAI PACIENTAM.

ŠIS EKSPLOATAVIMO VADOVAS YRA IŠLEISTAS TIK ANGLŲ KALBA.

• JEI KLIENTO PASLAUGŲ TEIKĖJUI REIKIA VADOVO KITA KALBA – NE ANGLŲ,
VERTIMU PASIRŪPINTI TURI KLIENTAS.

•NEMĖGINKITE ATLIKTI ĮRANGOS TECHNINĖS PRIEŽIŪROS DARBŲ, NEBENT
VADOVAUTUMĖTĖS ŠIUO EKSPLOATAVIMO VADOVU IR JĮ SUPRASTUMĖTE

• NEPAISANT ŠIO PERSPĖJIMO, PASLAUGŲ TEIKĖJAS, OPERATORIUS AR
PACIENTAS GALI BŪTI SUŽEISTAS DĖL ELEKTROS SM

ŪGIO, MECHANINIŲ AR

KITŲ PAVOJŲ.

ADVARSEL

(NO)

OSTRZEŻENIE

(PL)

DENNE SERVICEHÅNDBOKEN FINNES BARE PÅ ENGELSK.

• HVIS KUNDENS SERVICELEVERANDØR TRENGER ET ANNET SPRÅK, ER DET
KUNDENS ANSVAR Å SØRGE FOR OVERSETTELSE.

• IKKE FORSØK Å REPARERE UTSTYRET UTEN AT DENNE
SERVICEHÅNDBOKEN ER LEST OG FORSTÅTT.

• MANGLENDE HENSYN TIL DENNE ADVARSELEN KAN FØRE TIL AT
SERVICELEVERANDØREN, OPERATØREN ELLER PASIENTEN SKADES PÅ
GRUNN AV ELEKTRISK STØT, MEKANISKE ELLER ANDRE FARER.

NINIEJSZY PODRĘCZNIK SERWISOWY DOSTĘPNY JEST JEDYNIE W JĘZYKU
ANGIELSKIM.

•JEŚLI FIRMA ŚWIADCZĄCA KLIENTOWI USłUGI SERWISOWE WYMAGA
UDOSTĘPNIENIA PODRĘCZNIKA W JĘZYKU INNYM NIŻ ANGIELSKI,
OBOWIĄZEK ZAPEWNIENIA STOSOWNEGO TłUMACZENIA SPOCZYWA NA
KLIENCIE.

• NIE PRÓBOWAĆ SERWISOWAĆ NINIEJSZEGO SPRZĘTU BEZ UPRZEDNIEGO
ZAPOZNANIA SIĘ Z PODRĘCZNIKIEM SERWISOWYM.

• NIEZASTOSOWANIE SIĘ DO TEGO OSTRZEŻENIA MOżE GROZIĆ
OBRAŻENIAMI CIAłA SERWISANTA, OPERATORA LUB PACJENTA W WYNIKU
PORAŻENIA PRĄDEM, URAZU MECHANICZNEGO LUB INNEGO RODZAJU
ZAGROŻEŃ.

- v

GE H

EALTHCARE

D

IRECTION

ATE NŢIE

ОСТОРОЖНО!

GA091568, R

(RO)

(RU)

EVISION

5 VIVIDE9 S

ERVICE MANUAL

ACEST MANUAL DE SERVICE ESTE DISPONIBIL NUMAI ÎN LIMBA ENGLEZĂ.

• DACĂ UN FURNIZOR DE SERVICII PENTRU CLIENŢI NECESITĂ O ALTĂ LIMBĂ
DECÂT CEA ENGLEZĂ, ESTE DE DATORIA CLIENTULUI SĂ FURNIZEZE O
TRADUCERE.

• NU ÎNCERCAŢI SĂ REPARAŢI ECHIPAMENTUL DECÂT ULTERIOR
CONSULTĂRII ŞI ÎNŢELEGERII ACESTUI MANUAL DE SERVICE.

• IGNORAREA ACESTUI AVERTISMENT AR PUTEA DUCE LA RĂNIREA
DEPANATORULUI, OPERATORULUI SAU PACIENTULUI ÎN URMA
PERICOLELOR DE ELECTROCUTARE, MECANICE SAU DE ALTĂ NATURĂ.

ДАННОЕ РУКОВОДСТВО ПО ОБСЛУЖИВАНИЮ ПРЕДОСТАВЛЯЕТСЯ ТОЛЬКО
НА АНГЛИЙСКОМ ЯЗЫКЕ.

• ЕСЛИ СЕРВИСНОМУ ПЕРСОНАЛУ КЛИЕНТА НЕОБХОДИМО РУКОВОДСТВО
НЕ НА АНГЛИЙСКОМ ЯЗЫКЕ, КЛИЕНТУ СЛЕДУЕТ САМОСТОЯТЕЛЬНО
ОБЕСПЕЧИТЬ ПЕРЕВОД.

• ПЕРЕД ОБСЛУЖИВАНИЕМ ОБОРУДОВАНИЯ ОБЯЗАТЕЛЬНО

ОБРАТИТЕСЬ

К ДАННОМУ РУКОВОДСТВУ И ПОЙМИТЕ ИЗЛОЖЕННЫЕ В НЕМ СВЕДЕНИЯ.

• НЕСОБЛЮДЕНИЕ УКАЗАННЫХ ТРЕБОВАНИЙ МОЖЕТ ПРИВЕСТИ К ТОМУ,

ЧТО СПЕЦИАЛИСТ ПО ТЕХОБСЛУЖИВАНИЮ, ОПЕРАТОР ИЛИ ПАЦИЕНТ
ПОЛУЧАТ УДАР ЗЛЕКТРИЧЕСКИМ ТОКОМ, МЕХАНИЧЕСКУЮ ТРАВМУ ИЛИ
ДРУГОЕ ПОВРЕЖДЕНИЕ.

ПРЕДУПРЕЖДЕНИЕ

(BG)

UPOZORENJE

(SR)

ТОВА СЕРВИЗНО РЪКОВОДСТВО Е НАЛИЧНО САМО НА АНГЛИЙСКИ ЕЗИК.

• АКО ДОСТАВЧИКЪТ НА СЕРВИЗНИ УСЛУГИ НА КЛИЕНТ

СЕ НУЖДАЕ ОТ
ЕЗИК, РАЗЛИЧЕН ОТ АНГЛИЙСКИ, ЗАДЪЛЖЕНИЕ НА КЛИЕНТА Е ДА
ПРЕДОСТАВИ ПРЕВОДАЧЕСКА УСЛУГА.

• НЕ СЕ ОПИТВАЙТЕ ДА ИЗВЪРШВАТЕ СЕРВИЗНО ОБСЛУЖВАНЕ НА ТОВА
ОБОРУДВАНЕ, ОСВЕН ВСЛУЧАЙ, ЧЕ СЕРВИЗНОТО РЪКОВОДСТВО Е
ПРОЧЕТЕНО И СЕ РАЗБИРА.

• НЕСПАЗВАНЕТО НА ТОВА ПРЕДУПРЕЖДЕНИЕ МОЖЕ ДА ДОВЕДЕ ДО
НАРАНЯВАНЕ НА ДОСТАВЧИКА НА СЕРВИЗНИ УСЛУГИ, НА

ОПЕРАТОРА
ИЛИ ПАЦИЕНТА ВСЛЕДСТВИЕНА ТОКОВ УДАР, МЕХАНИЧНИ ИЛИ ДРУГИ
РИСКОВЕ.

OVAJ PRIRUČNIK ZA SERVISIRANJE DOSTUPAN JE SAMO NA ENGLESKOM
JEZIKU.

• AKO KLIJENTOV SERVISER ZAHTEVA JEZIK KOJI NIJE ENGLESKI,

ODGOVORNOST JE NA KLIJENTU DA PRUŽI USLUGE PREVOĐENJA.

• NEMOJTE POKUŠAVATI DA SERVISIRATE OPREMU AKO NISTE PROČITALI I
RAZUMELI PRIRUČNIK ZA SERVISIRANJE.

• AKO NE POŠTUJETE OVO UPOZORENJE, MOŽE DOĆI DO POVREĐIVANJA
SERVISERA, OPERATERA ILI PACIJENTA UZROKOVANOG ELEKTRIČNIM
UDAROM, MEHANIČKIM I DRUGIM OPASNOSTIMA.

vi -

GE H

EALTHCARE

D

IRECTION

OPOZORILO

UPOZORENJE

GA091568, R

(SL)

(HR)

EVISION

5 VIVIDE9 S

ERVICE MANUAL

TA SERVISNI PRIROČNIK JE NA VOLJO SAMO V ANGLEŠČINI.

• ČE PONUDNIK SERVISNIH STORITEV ZA STRANKO POTREBUJE NAVODILA V

DRUGEM JEZIKU, JE ZA PREVOD ODGOVORNA STRANKA SAMA.

• NE POSKUŠAJTE SERVISIRATI OPREME, NE DA BI PREJ PREBRALI IN

RAZUMELI SERVISNI PRIROČNIK.

• ČE TEGA OPOZORILA NE UPOŠTEVATE, OBSTAJA NEVARNOST
ELEKTRIČNEGA UDARA, MEHANSKIH ALI DRUGIH NEVARNOSTI IN
POSLEDIČNIH POŠKODB PONUDNIKA SERVISNIH STORITEV, UPORABNIKA
OPREME ALI PACIENTA.

OVAJ SERVISNI PRIRUČNIK DOSTUPAN JE SAMO NA ENGLESKOM JEZIKU.

• AKO KLIJENTOV SERVISER ZAHTIJEVA JEZIK KOJI NIJE ENGLESKI,
ODGOVORNOST KLIJENTA JE PRUŽITI USLUGE PREVOĐENJA.

• NEMOJTE POKUŠAVATI SERVISIRATI OPREMU AKO NISTE PROČITALI I
RAZUMJELI SERVISNI PRIRUČNIK.

• AKO NE POŠTUJETE OVO UPOZORENJE, MOŽE DOĆI DO OZLJEDE
SERVISERA, OPERATERA ILI PACIJENTA PROUZROČENE STRUJNIM
UDAROM, MEHANIČKIM I DRUGIM OPASNOSTIMA.

UPOZORNENIE

(SK)

VARNING

(SV)

TÁTO SERVISNÁ PRÍRUČKA JE K DISPOZÍCII LEN V ANGLIČTINE.

• AK ZÁKAZNÍKOV POSKYTOVATEĽ SLUŽIEB VYŽADUJE INÝ JAZYK AKO
ANGLIČTINU, POSKYTNUTIE PREKLADATEĽSKÝCH SLUŽIEB JE
ZODPOVEDNOSŤOU ZÁKAZNÍKA.

• NEPOKÚŠAJTE SA VYKONÁVAŤ SERVIS ZARIADENIA SKÔR, AKO SI
NEPREČÍTATE SERVISNÚ PRÍRUČKU A NEPOROZUMIETE JEJ.

• ZANEDBANIE TOHTO UPOZORNENIA MÔŽE VYÚSTIŤ DO ZRANENIA
POSKYTOVATEĽA SLUŽIEB, OBSLUHUJÚCEJ OSOBY ALEBO PACIENTA
ELEKTRICKÝM PRÚDOM, PRÍPADNE DO MECHANICKÉHO ALEBO INÉHO
NEBEZPEČENSTVA.

DEN HÄR SERVICEHANDBOKEN FINNS BARA TILLGÄNGLIG PÅ ENGELSKA.

• OM EN KUNDS SERVICETEKNIKER HAR BEHOV AV ETT ANNAT SPRÅK ÄN
ENGELSKA ANSVARAR KUNDEN FÖR ATT TILLHANDAHÅLLA
ÖVERSÄTTNINGSTJÄNSTER.

• FÖRSÖK INTE UTFÖRA SERVICE PÅ UTRUSTNINGEN OM DU INTE HAR LÄST
OCH FÖRSTÅR DEN HÄR SERVICEHANDBOKEN.

• OM DU INTE TAR HÄNSYN TILL DEN HÄR VARNINGEN KAN DET RESULTERA I
SKADOR PÅ SERVICETEKNIKERN, OPERATÖREN ELLER PATIENTEN TILL
FÖLJD AV ELEKTRISKA STÖTAR, MEKANISKA FAROR ELLER ANDRA FAROR.

- vii

GE H
D

IRECTION

EALTHCARE

GA091568, R

DİKKAT

(TR)

(JA)

EVISION

5 VIVIDE9 S

ERVICE MANUAL

BU SERVİS KILAVUZU YALNIZCA İNGİLİZCE OLARAK SAĞLANMIŞTIR.

•EĞER MÜŞTERİ TEKNİSYENİ KILAVUZUN İNGİLİZCE DIŞINDAKİ BİR DİLDE
OLMASINI İSTERSE, KILAVUZU TERCÜME ETTİRMEK MÜŞTERİNİN
SORUMLULUĞUNDADIR.

•SERVİS KILAVUZUNU OKUYUP ANLAMADAN EKİPMANLARA MÜDAHALE
ETMEYİNİZ.

• BU UYARININ GÖZ ARDI EDİLMESİ, ELEKTRİK ÇARPMASI YA DA MEKANİK
VEYA DİĞER TÜRDEN KAZALAR SONUCUNDA TEKNİSYENİN, OPERATÖRÜN
YA DA HASTANIN YARALANMASINA YOL AÇABİLİR.

Traditional

Chinese

viii -

GE H
D

IRECTION

EALTHCARE

GA091568, R

(ZH-CN)

EVISION

5 VIVIDE9 S

ERVICE MANUAL

(KO)

- ix

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVIDE9 S

DAMAGE IN TRANSPORTATION

All packages should be closely examined at time of delivery. If damage is apparent write “Damage In
Shipment” on ALL copies of the freight or express bill BEFORE delivery is accepted or “signed for” by
a GE representative or hospital receiving agent. Whether noted or concealed, damage MUST be
reported to the carrier immediately upon discovery, or in any event, within 14 days after receipt, and the
contents and containers held for inspection by the carrier. A transportation company will not pay a claim
for damage if an inspection is not requested within this 14 day period.

CERTIFIED ELECTRICAL CONTRACTOR STATEMENT - FOR USA ONLY

All electrical Installations that are preliminary to positioning of the equipment at the site prepared for the
equipment shall be performed by licensed electrical contractors. Other connections between pieces of
electrical equipment, calibrations and testing shall be performed by qualified GE Healthcare personnel.
In performing all electrical work on these products, GE will use its own specially trained field engineers.
All of GE’s electrical work on these products will comply with the requirements of the applicable
electrical codes.

The purchaser of GE equipment shall only utilize qualified personnel (i.e., GE’s field engineers,
personnel of third-party service companies with equivalent training, or licensed electricians) to perform
electrical servicing on the equipment.

ERVICE MANUAL

OMISSIONS & ERRORS

If there are any omissions, errors or suggestions for improving this documentation, please contact the
GE Healthcare Global Documentation Group with specific information listing the system type, manual
title, part number, revision number, page number and suggestion details.

Mail the information to:

Service Documentation,
GE Vingmed Ultrasound AS
P.O.Box: 141
NO 3191 HORTEN
NORWAY

GE Healthcare employees should use TrackWise to report service documentation issues. These issues
will then be in the internal problem reporting tool and communicated to the writer.

SERVICE SAFETY CONSIDERATIONS

DANGER

DANGEROUS VOLTAGES, CAPABLE OF CAUSING DEATH, ARE PRESENT IN
THIS EQUIPMENT. USE EXTREME CAUTION WHEN HANDLING, TESTING AND
ADJUSTING.

WARNINGWARNING

USE ALL PERSONAL PROTECTION EQUIPMENT (PPE) SUCH AS GLOVES, SAFETY
SHOES, SAFETY GLASSES, AND KNEELING PAD, TO REDUCE THE RISK OF INJURY.

For a complete review of all safety requirements, see Section 1-4 "Safety considerations" on page 1-11.

x -

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVIDE9 S

LEGAL NOTES

The contents of this publication may not be copied or duplicated in any form, in whole or in part, without
prior written permission of GE Healthcare.

GE Healthcare may revise this publication from time to time without written notice.

TRADEMARKS

All products and their name brands are trademarks of their respective holders.

COPYRIGHTS

All Material Copyright© 2008, 2010 - 2012 by General Electric Company Inc. All Rights Reserved.

ERVICE MANUAL

- xi

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVIDE9 S

Revision History

REVISION DATE REASON FOR CHANGE

1 2008-NOV-14

2 2010-APR-30

3 2011-MAR-01

4 2011-SEP-19

5 2012-DEC-10

Initial release of manual.

Updated per BT10 release.

Updated per BT’11-M4 release of product.

Updated per BT’12 release.

Updated with changes since Rev. 4.

List of Effected Pages

ERVICE MANUAL

Pages Revision Pages Revision Pages Revision

Title Page 5 4-1 to 4-54 5 9-1 to 9-106 5

i to xii 5 5-1 to 5-102 5 10-1 to 10-32 5

1-1 to 1-36 5 6-1 to 6-18 5 Back Cover N/A

2-1 to 2-14 5 7-1 to 7-24 5

3-1 to 3-52 5 8-1 to 8-316 5

xii -

GE H

EALTHCARE

D

IRECTION

GA091568, R

CHAPTER 1

Introduction

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 - 1

Purpose of this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 - 1

Contents in this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 - 1

Service manual overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 - 2

Contents in this service manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 - 2

Typical users of the Service Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 - 2

VIVID E9 models covered by this manual . . . . . . . . . . . . . . . . . . . . . . . . . .1 - 3

Product description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 - 5

EVISION

5 VIVIDE9 S

Table of Contents

ERVICE MANUAL

Important conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 - 6

Conventions used in this book . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 - 6

Standard hazard icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 - 7

Product icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 - 8

Safety considerations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 - 11

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 - 11

Human safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 - 11

Mechanical safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 - 13

Electrical safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 - 15

Labels locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 - 16

Label on Front of LCD Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 - 16

Label on Rear of LCD Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 - 16

Label on Upper OP Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 - 17

Labels on Front Handle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 - 17

Labels on top of Console . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 - 17

Labels near Connectors on Front . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 - 18

Labels on DVD Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 - 19

Label on External I/O . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 - 19

Labels at AC Mains Inlet and Circuit Breaker . . . . . . . . . . . . . . . . . . . . . . .1 - 20

Label on Rear Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 - 21

Label on Rear Cover - detailed descriptions . . . . . . . . . . . . . . . . . . . . . . . .1 - 26

Label on the BEP6’s door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 - 29

Label on the BEP5’s door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 - 30

Label, Disassembly Nester . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 - 31

Table of Contents xiii

GE H
D

IRECTION

EALTHCARE

GA091568, R

EVISION

5 VIVIDE9 S

ERVICE MANUAL

Dangerous procedure warnings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 - 32

Lockout/Tagout (LOTO) requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 - 33

Returning/Shipping Probes and Repair Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 - 33

Electromagnetic compatibility (EMC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 - 34

What is EMC? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 - 34

Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 - 34

Electrostatic discharge (ESD) prevention . . . . . . . . . . . . . . . . . . . . . . . . . .1 - 34

Customer assistance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 - 35

Contact information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 - 35

System manufacturer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 - 36

xiv -

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

CHAPTER 2

Site preparations

Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 1

Purpose of this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 1

Contents in this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 1

General console requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 2

Console environmental requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 2

Electrical requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 4

EMI limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 7

Probes environmental requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 8

Time and manpower requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 8

Facility needs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 9

Purchaser responsibilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 9

Required facility needs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 10

Desirable features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 11

Minimal floor plan suggestion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 11

Suggested Floor Plan, VIVID E9 and EchoPAC PC in Same Room . . . . . 2 - 11

Networking setup requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 12

5 VIVID E9 S

ERVICE MANUAL

- xv

GE H

EALTHCARE

D

IRECTION

GA091568, R

CHAPTER 3

System setup

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 - 1

Purpose of this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 - 1

Contents in this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 - 1

Setup reminders. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 - 2

Average setup time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 - 2

Setup warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 - 2

Receiving and unpacking the equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 - 3

Purpose of this section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 - 3

Receiving and unpacking warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 - 3

The Tilt & Shock indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 - 4

Receiving the VIVID E9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 - 5

Unpacking VIVID E9 from the Wooden Box . . . . . . . . . . . . . . . . . . . . . . . . .3 - 10

Unpacking VIVID E9 from the Carton Box . . . . . . . . . . . . . . . . . . . . . . . . . .3 - 12

EVISION

5 VIVIDE9 S

ERVICE MANUAL

Packing materials for the Wooden Box - recycling information . . . . . . . . . . . . . . . .3 - 16

Packing materials for the Carton Box - recycling information . . . . . . . . . . . . . . . . .3 - 17

Preparing for setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 - 19

Verify Customer Order . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 - 19

Physical inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 - 19

EMI protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 - 19

Completing the setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 - 20

Purpose of this section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 - 20

System specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 - 20

Electrical specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 - 21

Connections on the External IO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 - 22

Connections on the Patient I/O panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 - 23

Connecting Probes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 - 24

Power On/Boot Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 - 26

Power shut down . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 - 26

Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 - 27

Purpose of this section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 - 27

VIVID E9 configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 - 27

Service Screen setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 - 32

Optional Peripherals/Peripheral Connection . . . . . . . . . . . . . . . . . . . . . . . .3 - 36

xvi -

GE H
D

IRECTION

EALTHCARE

GA091568, R

EVISION

5 VIVID E9 S

ERVICE MANUAL

Software Options Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 - 38

Connectivity overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 - 40

Physical connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 - 40

Connectivity setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 - 41

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 - 41

Compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 - 41

Select TCP/IP Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 - 42

Changing the AE Title and/or Port Number (Port No.) . . . . . . . . . . . . . . . . 3 - 43

DHCP setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 - 44

Set the Remote Archive’s Network Information . . . . . . . . . . . . . . . . . . . . . 3 - 47

Save the New Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 - 48

Options Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 - 49

Software options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 - 49

Color Video Printer (optional) installation . . . . . . . . . . . . . . . . . . . . . . . . . . 3 - 49

Setup paperwork . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 - 50

User’s Manual(s) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 - 50

Product Locator Installation Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 - 51

- xvii

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVIDE9 S

CHAPTER 4

General procedures and Functional checks

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 1

Purpose of this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 1

Contents in this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 1

Special Equipment required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 2

General procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 3

Power ON/Boot Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 4

Power shut down . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 8

Top Console position adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 11

LCD Monitor position adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 14

Logging on to VIVID E9 as ‘ADM’ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 15

Moving and Transporting the VIVID E9 . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 17

Recording important settings and parameters . . . . . . . . . . . . . . . . . . . . . . .4 - 19

Cleaning the Trackball from the outside (OP-5) . . . . . . . . . . . . . . . . . . . . . .4 - 31

Cleaning the Trackball (OP-1 to OP-4) . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 32

ERVICE MANUAL

Functional checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 37

Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 37

2D Mode (B mode) Checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 37

M Mode Checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 39

Color Mode Checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 40

PW/CW Doppler Mode Checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 42

Tissue Velocity Imaging (TVI) Checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 43

Probe/Connectors Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 44

ECG Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 45

Cineloop Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 46

Back End Processor checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 47

Operator Panel Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 47

Peripheral checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 47

Mechanical Functions Checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 51

Site Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 52

xviii -

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

CHAPTER 5

Components and functions (theory)

Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 1

Purpose of this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 1

Contents in this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 1

InSite ExC. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 4

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 4

InSite ExC Icon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 4

InSite ExC Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 5

Initiating a Request for Service (RFS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 6

Automatic Request for Service (ARFS) . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 7

InSite ExC Definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 8

Exiting InSite ExC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 8

VIVID E9 overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 9

Purpose of this section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 9

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 9

VIVID E9 general description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 10

VIVID E9 block diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 10

Signal flow overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 11

System configuration and software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 12

The electronics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 12

VIVID E9 interconnection diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 13

VIVID E9’s Operating Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 15

ERVICE MANUAL

Top Console with LCD monitor and Operator Panel . . . . . . . . . . . . . . . . . . . . . . . 5 - 17

Top Console description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 17

Operator Panel (Control Panel) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 21

Main Console . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 24

Main Console description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 24

Air Flow control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 25

General description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 25

Casters and Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 26

Front End Processor (FEP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 27

Front End Card Rack description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 27

Transmitter and Receiver subsystem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 29

Transmitter Board (GTX) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 32

- xix

GE H
D

IRECTION

EALTHCARE

GA091568, R

EVISION

5 VIVIDE9 S

ERVICE MANUAL

Relay Board (RLY) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 38

Receiver Board (GRX) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 41

Front Plane boards (XD BUS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 43

Digital Receiver board (DRX) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 44

Front End Interface Board (GFI) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 47

FEP Backplane . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 50

Back End Processor (BEP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 52

Purpose of this section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 52

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 52

Signal Flow and Processing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 52

Location of the Back End Processor (BEP) . . . . . . . . . . . . . . . . . . . . . . . . .5 - 53

CPU/Back End Processor (BEP) - block diagram . . . . . . . . . . . . . . . . . . . .5 - 54

BEP description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 55

BEP6 Face, Top and Rear connections . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 56

BEP5 Face and Top connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 58

Input DC Voltages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 63

Input Signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 64

Bi-directional signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 65

Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 65

LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 66

BEP Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 69

IO Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 74

Graphics Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 76

Internal Storage Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 76

Power distribution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 77

Purpose of this section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 77

Main Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 77

Power Up Sequence Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 82

Power Down Sequence description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 86

Input and Output (I/O) modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 88

Purpose of this section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 88

Patient I/O (Physio) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 88

BEP6 I/O Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 92

BEP5 I/O Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 94

Probe Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 95

Peripherals overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 96

Internal peripherals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 96

External peripherals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 97

xx -

GE H
D

IRECTION

EALTHCARE

GA091568, R

EVISION

5 VIVID E9 S

ERVICE MANUAL

Product manuals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 99

User documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 99

Service documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 99

Common Service Desktop overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 100

Purpose of this section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 100

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 100

iLinq Interactive Platform Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 100

Global Service User Interface (GSUI) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 101

Restart VIVID E9 after diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 102

- xxi

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVIDE9 S

CHAPTER 6

Service adjustments

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 - 1

Purpose of this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 - 1

Contents in this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 - 1

LCD Monitor adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 - 2

Purpose of this section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 - 2

Cautions and Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 - 2

Access to Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 - 2

LCD Adjustment Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 - 2

Advanced LCD adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 - 3

Test the LCD Arm and LCD Monitor range of motion . . . . . . . . . . . . . . . . . . . . . . .6 - 4

Backlight adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 - 5

Purpose of this section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 - 5

Cautions and Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 - 5

Accessing the Main LCD and Touch Screen Backlight Adjustments . . . . . .6 - 5

Backlight and Blue Tint Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 - 6

Adjust LCD Brightness and Contrast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 - 6

Test Images . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 - 7

ERVICE MANUAL

Touch Screen Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 - 10

DC Offset Calibration (Front End Alignment). . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 - 11

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 - 11

When to do a Front End Alignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 - 11

Front End Alignment Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 - 11

Adjusting the XYZ Mechanism. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 - 12

Operator Panel XY movement - principle of operation . . . . . . . . . . . . . . . . .6 - 12

Adjusting the XY Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 - 13

XY Manual Release for Lock and Brake Mechanism and Adjustment . . . . .6 - 14

Using the Park Lock Properly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 - 17

Adjusting the Z mechanism . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 - 17

Adjust time-out for DICOM servers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 - 17

xxii -

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

CHAPTER 7

Diagnostics / troubleshooting

Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 1

Purpose of this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 1

Contents in this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 1

Service Safety Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 2

FAQ - Frequently Asked Questions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 2

High System Temperature Error . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 2

Reset the BEP from a Hang . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 2

How to Release the Top Console when power is unavailable . . . . . . . . . . 7 - 3

Troubleshooting Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 4

Shortcut Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 4

Image Artifacts Caused by Front End Boards . . . . . . . . . . . . . . . . . . . . . . 7 - 5

Back End Processor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 6

Operator Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 7

Probes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 7

Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 7

ERVICE MANUAL

Network Connectivity Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 8

First Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 8

Cannot connect to anything via the network . . . . . . . . . . . . . . . . . . . . . . . . 7 - 8

No Verify . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 9

System Pings and Verifies OK, but does NOT Send . . . . . . . . . . . . . . . . . 7 - 9

Gathering Troubleshooting Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 10

Collect Vital System Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 10

Collect a Trouble Image with Logs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 11

Screen Captures. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 12

Purpose of this Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 12

Ctrl+PrintScreen shortcut . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 12

To Capture a Screen Image Using the Shortcut . . . . . . . . . . . . . . . . . . . . . 7 - 12

Restart VIVID E9 After Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 12

Motor Controller Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 13

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 15

No Response from VIVID E9 - It’s “Locked” . . . . . . . . . . . . . . . . . . . . . . . . 7 - 15

Unable to scan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 16

- xxiii

GE H
D

IRECTION

EALTHCARE

GA091568, R

EVISION

5 VIVIDE9 S

ERVICE MANUAL

XY Lock is not working . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 - 17

XY Brake Motors Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 - 17

Z Movement fails . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 - 17

Difficult to lock and release the alphanumeric keyboard . . . . . . . . . . . . . . .7 - 18

USB Footswitch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 - 19

USB Device(s) stopped working . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 - 19

System Temperature Too High . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 - 20

Noise troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 - 21

General Recommendations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 - 21

EMI Prevention/abatement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 - 22

xxiv -

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

CHAPTER 8

Replacement procedures

Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 1

Purpose of this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 1

Contents in this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 1

Warnings and important information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 2

Purpose of this section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 2

Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 2

Returning/Shipping probes and Repair Parts . . . . . . . . . . . . . . . . . . . . . . . 8 - 3

Manpower - When two persons are needed . . . . . . . . . . . . . . . . . . . . . . . . 8 - 3

Tools needed for servicing VIVID E9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 4

Definitions of Left, Right, Front and Back . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 5

Reloading the software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 6

Purpose of this section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 6

VIVID E9 models versus software requirement . . . . . . . . . . . . . . . . . . . . . 8 - 7

Customer provided prerequisite . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 9

Tools provided with the VIVID E9 at delivery or after an upgrade . . . . . . . 8 - 9

Data Management - moving all images . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 10

Backing up the Patient Archive and System Configurations . . . . . . . . . . . . 8 - 10

Recording important settings and parameters . . . . . . . . . . . . . . . . . . . . . . 8 - 11

When to load or reload the software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 12

Reloading the Software from Repository . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 13

Loading the Software - from DVD/CD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 16

Setup after Software loading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 37

Verifications after the software has been re-loaded . . . . . . . . . . . . . . . . . . 8 - 37

ERVICE MANUAL

Replacing Covers and Bumpers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 38

Purpose of this section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 38

Side Covers replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 38

Top Cover replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 41

Side Bumpers Replacement Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 44

Foot Rest Bumper replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 45

Front Cover replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 47

Plate Connectors w/Guide replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 49

Filter Cover replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 51

Rear Cover replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 52

Door, I/O Panel replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 54

Cable Hooks replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 56

- xxv

GE H
D

IRECTION

EALTHCARE

GA091568, R

EVISION

5 VIVIDE9 S

ERVICE MANUAL

Rear Bumper replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 59

Rear Handle replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 60

Column Cover Assembly replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 62

Main Cable Cover replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 65

Covers under XY / Frogleg motors replacement . . . . . . . . . . . . . . . . . . . . .8 - 67

Bulkhead Cover replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 70

Top Console Parts Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 73

Purpose of this section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 73

Replacing the 17” LCD Monitor assembly . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 73

Replacing the 19” LCD Monitor assembly . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 79

Replacing the LCD Arm assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 85

Replacing the LCD Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 89

LCD Mount Lock replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 96

Replacing the Upper Operator Panel/Touch Panel Assembly . . . . . . . . . .8 - 98

Replacing the Frame w/LCD and Touch Screen . . . . . . . . . . . . . . . . . . . . .8 - 104

Replacing the Main Controller Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 108

USB Connector Board replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 113

High Voltage Inverter Board with Cable replacement . . . . . . . . . . . . . . . . .8 - 116

Upper Bezel replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 118

Frame UI Upper replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 119

Options Holder / Left or Right Support replacement . . . . . . . . . . . . . . . . . .8 - 121

Knobs for Encoders and Slidepots replacement . . . . . . . . . . . . . . . . . . . . .8 - 122

Replacing the Operator Panel, Lower . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 124

Replacing the Trackball . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 128

Encoder Board replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 130

Lower Switch Board with Elastomer replacement . . . . . . . . . . . . . . . . . . . .8 - 132

Lower Bezel replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 135

Lower Frame Assembly replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 138

Operator Panel Cable Kit Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 141

Replacing the Alpha-Numeric Keyboard Assembly . . . . . . . . . . . . . . . . . . .8 - 144

Replacing the A/N Keyboard or the A/N Keyboard Enclosure . . . . . . . . . . .8 - 147

Wagon AN Drawer Sheet Met. Assembly replacement . . . . . . . . . . . . . . .8 - 151

J-Rail Assy replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 153

Replacing the Speaker Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 155

Replacing the Bulkhead Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 157

Bulkhead, Plate, Extended replacement . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 160

Probe Cable Hook Twin replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 162

Non-Magnetic Touch Latch replacement . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 163

Handle, Left Top / Handle Right Top, replacement . . . . . . . . . . . . . . . . . . .8 - 164

Palm Rest ASSY replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 166

Replacing the Probe Holder Inserts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 168

xxvi -

GE H
D

IRECTION

EALTHCARE

GA091568, R

EVISION

5 VIVID E9 S

ERVICE MANUAL

Replacing the Gel Cup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 169

Up-Down Button Board (Buttons Frame UI Assy) replacement . . . . . . . . . 8 - 170

Button IF Board Assy replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 172

Replacing XYZ Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 174

XY Mechanism replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 174

XY Brake Assy replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 177

XY Park Lock replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 181

Z-Mechanism replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 182

Drive Gear Assembly replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 185

XYZ Control Assembly replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 188

Main Console parts replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 190

Purpose of this section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 190

Rear Filter and “handle type” Bottom Filter replacement . . . . . . . . . . . . . . 8 - 190

Rear Air Filter replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 194

Bottom “nylon strip” Air Filter replacement . . . . . . . . . . . . . . . . . . . . . . . . 8 - 196

Fan Assembly replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 198

Replacing Fan Screen and Fan Screen Frame . . . . . . . . . . . . . . . . . . . . . 8 - 200

Main Cable replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 202

Subwoofer replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 205

Casters and Brakes replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 208

Rear Casters replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 208

Front Casters replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 211

Pedal Mechanism replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 214

Brake Pedal replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 216

Pedal Release replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 217

Pedal Dir Lock replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 217

Front End Processor (FEP) / Card Cage parts replacement . . . . . . . . . . . . . . . . . 8 - 218

Front End parts overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 219

Front End (FEP) Cover replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 221

Front Plane / XD BUS replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 224

Relay Board (RLY) replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 229

Receiver Board (GRX) replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 232

Transmitter Board (GTX) replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 235

Digital Receiver Board (DRX) replacement . . . . . . . . . . . . . . . . . . . . . . . . 8 - 239

GFI Board replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 241

Back End Processor (BEP) parts replacement. . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 244

Back End Processor (BEP) replacement . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 244

Back End Processor Power Supply replacement . . . . . . . . . . . . . . . . . . . 8 - 251

- xxvii

GE H
D

IRECTION

EALTHCARE

GA091568, R

EVISION

5 VIVIDE9 S

ERVICE MANUAL

Hard Disk Drive (HDD) replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 256

Graphics Adapter replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 262

BEP Front Module replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 273

BEP6 Fan replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 276

BEP Power In Cable replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 279

SATA Jumper replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 281

Patient I/O Interface Cable replacement . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 282

Video Jumper (Flex) replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 284

DVI to Samtec Jumper (Flex) replacement . . . . . . . . . . . . . . . . . . . . . . . . .8 - 285

SATA Cable - DVR to BEP6 MBD replacement . . . . . . . . . . . . . . . . . . . . . .8 - 287

DVI Flex Main Yggdrasil replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 288

DVR Audio cable replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 289

BEP6 to GFI and Card Rack Backplane Cable replacement . . . . . . . . . . . .8 - 290

Main Power Supply replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 292

Preparations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 292

I/O Modules replacement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 295

Patient I/O Assembly replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 295

Side I/O Board Assembly replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 298

Peripherals replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 303

DVD R/W drive replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 303

Digital Video Recorder (DVR) replacement . . . . . . . . . . . . . . . . . . . . . . . .8 - 305

Black & White Digital Graphic Printer replacement . . . . . . . . . . . . . . . . . . .8 - 312

USB Flash Card replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 313

Color Video Printer Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 314

GFI PCIe Cable replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 - 315

xxviii -

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

CHAPTER 9

Renewal parts

Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 - 1

Contents in this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 - 1

Definitions of Left, Right, Front and Back . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 - 2

List of Abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 - 3

VIVID E9 models and hardware/software compatibility . . . . . . . . . . . . . . . . . . . . . 9 - 4

Software for VIVID E9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 - 6

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 - 6

BT’12 Software (Application Software Version 112) . . . . . . . . . . . . . . . . . . 9 - 6

BT’11 Software (Application Software Version 110) . . . . . . . . . . . . . . . . . . 9 - 9

BT’09 Software (Application software v108.x.x) . . . . . . . . . . . . . . . . . . . . . 9 - 13

5 VIVID E9 S

ERVICE MANUAL

Covers and Bumpers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 - 15

Top Console parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 - 18

LCD Monitor parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 - 18

Operator Panel (OP) parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 - 19

Top Console PCBs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 - 30

Trackball parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 - 33

Operator Panel Cable Kit for Vivid E9 and Logiq E9 . . . . . . . . . . . . . . . . . 9 - 34

Button Kits and Knobs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 - 36

Common Top Console parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 - 43

XYZ parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 - 50

Main Console parts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 - 52

Casters (Wheels) parts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 - 54

Front End Processor (FEP) Card Rack parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 - 56

Front End Processor Card Rack - BT’11/BT’12 with 2D . . . . . . . . . . . . . . . 9 - 56

Front End Processor Card Rack - BT’11/BT’12 with 4D Expert Option . . . 9 - 58

Front End Processor Card Rack - BT’09 . . . . . . . . . . . . . . . . . . . . . . . . . . 9 - 59

Back End Processor (BEP) Spare Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 - 60

Content in this section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 - 60

BEP6 Spare Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 - 60

BEP5 Spare Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 - 62

- xxix

GE H
D

IRECTION

EALTHCARE

GA091568, R

EVISION

5 VIVIDE9 S

ERVICE MANUAL

Main Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 - 64

I/O modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 - 65

Peripherals for VIVID E9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 - 66

DVD drives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 - 66

Printer, Internal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 - 66

Printers, External - USB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 - 66

Printers, Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 - 67

Digital Video Stream Recorder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 - 69

USB Flash Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 - 69

USB Hard Drive 2TB with RAID1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 - 70

Mains Power Cables - VIVID E9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 - 71

Internal Cables - VIVID E9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 - 72

Cable Harness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 - 72

Top Console Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 - 74

XYZ Controller cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 - 76

Main Power Supply cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 - 77

Front End Processor (FEP) cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 - 78

Back End Processor (BEP) cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 - 79

Peripherals Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 - 89

ECG cables - VIVID E9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 - 91

Labels VIVID E9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 - 92

Physio TX Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 - 92

Options - VIVID E9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 - 93

Options - VIVID E9 - BT’12, application software v112.x . . . . . . . . . . . . . . .9 - 93

Options - VIVID E9 - BT’11, application software v110.x . . . . . . . . . . . . . . .9 - 95

Options - VIVID E9 - BT’09, application software v108.x . . . . . . . . . . . . . . .9 - 96

Product Manuals for VIVID E9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 - 97

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 - 97

Product manuals for BT’12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 - 97

Product manuals for BT’11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 - 99

Product manuals for BT’09 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 - 101

Probes Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 - 103

xxx -

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

CHAPTER 10

Care & maintenance

Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 - 1

Periodic maintenance inspections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 - 1

Purpose of this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 - 1

Contents in this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 - 1

Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 - 2

Why do maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 - 2

Keeping records . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 - 2

Quality assurance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 - 2

Maintenance task schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 - 3

How often should maintenance tasks be performed? . . . . . . . . . . . . . . . . . 10 - 3

Tools required. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 - 5

ERVICE MANUAL

System maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 - 6

Preliminary checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 - 6

Functional checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 - 7

Input Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 - 8

Physical inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 - 9

Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 - 10

Probe maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 - 14

Electrical Safety Tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 - 20

Safety Test Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 - 21

Leakage Current Limits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 - 22

Outlet Test - Wiring Arrangement - USA & Canada . . . . . . . . . . . . . . . . . . 10 - 24

Grounding Continuity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 - 24

Chassis Leakage Current Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 - 25

Isolated Patient Lead (Source) Leakage–Lead to Ground . . . . . . . . . . . . . 10 - 26

Isolated Patient Lead (Source) Leakage–Lead to Lead . . . . . . . . . . . . . . . 10 - 28

Probe Leakage Current Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 - 29

When there's too much leakage current « . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 - 32

Chassis Fails . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 - 32

Probe Fails . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 - 32

Peripheral Fails . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 - 32

Still Fails . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 - 32

New Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 - 32

ECG Fails . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 - 32

- xxxi

GE H
D

IRECTION

EALTHCARE

GA091568, R

EVISION

5 VIVIDE9 S

ERVICE MANUAL

xxxii -

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

Chapter 1
Introduction

Section 1-1
Overview

1-1-1 Purpose of this chapter

This chapter describes important issues related to safely servicing VIVID E9. The service provider must
read and understand all the information presented here before installing or servicing a unit.

1-1-2 Contents in this chapter

1-1 Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

1-2 Service manual overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

1-3 Important conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6

1-4 Safety considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11

1-5 Labels locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-16

1-6 Dangerous procedure warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-32

1-7 Lockout/Tagout (LOTO) requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-33

1-8 Returning/Shipping Probes and Repair Parts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-33

1-9 Electromagnetic compatibility (EMC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-34

1-10 Customer assistance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-35

ERVICE MANUAL

Chapter 1 - Introduction 1 - 1

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

Section 1-2
Service manual overview

The service manual provides installation and service information for the VIVID E9 ultrasound scanning
unit. It is divided in 10 chapters as shown below, in Table 1-1 "Contents in this service manual" on page

1-2.

1-2-1 Contents in this service manual

The service manual is divided into ten chapters.

In the beginning of the manual, before chapter 1, you will find the language policy for GE Healthcare’s
service documentation, legal information, a revision overview and the Table of Contents (TOC).

An Index has been included after chapter 10.

Table 1-1 Contents in this service manual

CHAPTER

NUMBER

1

2

3

4

5

6

7

8

9

10

N/A

Introduction Contains a content summary and warnings.

Site preparations

System setup

General procedures and Functional
checks

Components and functions (theory)

Service adjustments

Diagnostics / troubleshooting

Replacement procedures

Renewal parts

Care & maintenance

Index A quick way to the topic you’re looking for.

CHAPTER TITLE DESCRIPTION

ERVICE MANUAL

Contains pre-installation requirements for the VIVID E9.

Contains installation procedure with installation checklist.

Contains functional checks that must be performed as part of the
installation, or as required during servicing and periodic
maintenance.

Contains block diagrams and functional explanations of the
electronics.

Contains instructions on how to make any available adjustments to
the VIVID E9.

Provides procedures for running and diagnostic or related routines
for the VIVID E9.

Provides disassembly procedures and reassembly procedures for all
changeable FRU.

Contains a complete list of replacement parts for VIVID E9.

Provides periodic maintenance procedures for VIVID E9.

1-2-2 Typical users of the Service Manual

• Service Personnel (setup, maintenance, etc.)

• Hospital’s Service Personnel

• Architectural Planners/Installation Planners (some parts of Chapter 2 - Site preparations)

1 - 2 Section 1-2 - Service manual overview

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

1-2-3 VIVID E9 models covered by this manual

Table 1-2 VIVID E9 Models and Hardware/Software Compatibility sheet 1 of 2

ERVICE MANUAL

MODEL

NUMBER DESCRIPTION

GA000940

GA000950

GB000040

GB000050

GA000945

GA000955

Vivid E9 100-230V 4D Expert Option

- 17” LCD

Vivid E9 100-230V 4D Expert Option

- 19” LCD

Vivid E9 100-230V BT12 Pro
Configuration - 17” LCD

Vivid E9 100-230V BT12 Pro
Configuration - 19” LCD

Vivid E9 100-230V 2D

- 17” LCD

Vivid E9 100-230V 2D

- 19” LCD

FRONT END

PROCESSOR

CARD RACK

GA200824

VE9 Card Rack

Complete with

MLA16,
4D TEE

backplane,

192 RX channels

and one TX card

with 192 channels

GA200804

VE9 Card Rack

Complete w. MLA4

BACK END

PROCESSOR

GB200001

BEP6 w/4D

GB200003

BEP5 w/4D

Nvidia Quadro

2000D

GA200890

BEP5 w/4D

Nvidia

GB200001

BEP6 w/4D

GB200003

BEP5 w/4D

Nvidia Quadro

2000D

GA200890

BEP w/4D Nvidia

GB200002

BEP6 wo/4D

GB200002

BEP6 wo/4D

GA200900

BEP5 wo/4D

GB200002

BEP6 wo/4D

GA200900

BEP5 wo/4D

SYSTEM
SOFTWARE
VERSION(s)

v104.3.4

(or higher)

v104.3.3

(or higher)

v104.3.x v112.0.x or higher v112.1.x

v104.3.4

(or higher)

v104.3.3

(or higher)

v104.3.x v112.0.x or higher v112.1.x

v104.3.4

(or higher)

v104.3.x v112.0.6 or higher v112.1.x

v104.3.x v112.0.x or higher v112.1.x

v104.3.x v112.0.6 or higher v112.1.x

v104.3.x v112.0.x or higher v112.1.x

APPLICATION

SOFTWARE

CAN BE

UPGRADED

VERSION(S)

v112.0.7 or higher v112.1.x

v112.1.x

v112.0.x or higher

v112.0.7 or higher v112.1.x

v112.0.x or higher v112.1.x

v112.1.0 or higher

v112.1.x

v112.1.x

v112.1.x

v112.1.x

TO

Chapter 1 - Introduction 1 - 3

GE H
D

IRECTION

EALTHCARE

GA091568, R

EVISION

5 VIVID E9 S

ERVICE MANUAL

Table 1-2 VIVID E9 Models and Hardware/Software Compatibility (cont’d) sheet 2 of 2

MODEL

NUMBER DESCRIPTION

GA000810

GA000815

GA000830

GA000835

VIVID E9 100-230V 4D Expert Option

- 17” LCD

VIVID E9 100-230V 4D Expert Option

- 19” LCD

VIVID E9 100-230V 2D - 17” LCD

VIVID E9 100-230V 2D - 19” LCD

FRONT END

PROCESSOR

CARD RACK

GA200824

VE9 Card Rack

Complete with

MLA16,

4D TEE backplane

and

192 RX channels

GA200804

VE9 Card Rack

Complete w. MLA4

BACK END

PROCESSOR

GB200001

BEP6 w/4D

GA200890 or

GA200800

BEP5 w/4D

Nvidia

GA200890 or

GA200800

BEP5 w/4D

Nvidia

GB200001

BEP6 w/4D

GA200890 or

GA200800

BEP5 w/4D

Nvidia

GA200890 or

GA200800

BEP5 w/4D

Nvidia

GA200890 or

GA200800

BEP5 w/4D

Nvidia

GB200002

BEP6 wo/4D

GA200900 or

GA200805

BEP5 wo/4D

GB200002

BEP6 wo/4D

GA200900 or

GA200805

BEP5 wo/4D

SYSTEM
SOFTWARE
VERSION(s)

v104.3.x

v104.2.x
v104.1.x

v104.3.x v110.1.12

v104.3.2 v110.1.x

v104.3.2 v110.1.x

v104.2.x
v104.1.x

v104.3.x

v104.2.x
v104.1.x

v104.3.x

v104.2.x
v104.1.x

APPLICATION

SOFTWARE
VERSION(S)

v110.1.12

v110.1.x

v110.0.x

v110.0.x

v110.1.12

v110.1.x

v110.0.x

v110.1.12

v110.1.x

v110.0.x

CAN BE

UPGRADED

TO

v112.1.x

v112.1.x

v112.1.x

v112.1.x

GA200744

GA200890,

GA000100

VIVID E9, 100-230 VAC (with 4D)

GA200035

GA200800 or

5145000-10

BEP5 w/4D

v104.0.x v108.x.x

NOTE: When not otherwise specified, the contents in this manual applies to all VIVID E9 models.

1 - 4 Section 1-2 - Service manual overview

v112.1.x

v112.1.x

NOTE!
Hardware
update or box
(console) swap
required.

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

1-2-4 Product description

1-2-4-1 Overview of the VIVID E9 ultrasound scanner

The VIVID E9 ultrasound unit is a high performance digital ultrasound imaging system with total data
management.

The system provides image generation in 4D, 2D (B) Mode, Color Doppler, Power Doppler (Angio), M­Mode, Color M-Mode, PW and CW Doppler spectra, Tissue Velocity imaging, Advanced Strain and
Contrast applications. The fully digital architecture of the VIVID E9 unit allows optimal usage of all
scanning modes and probe types, throughout the full spectrum of operating frequencies.

Signal flow from the Probe Connector Panel to the Front End, and then over to the Back End Processor
and finally to the monitor and peripherals.

System configuration is stored on the hard drive in the Back End Processor.

All necessary software is loaded from the hard drive on power up.

Figure 1-1 VIVID E9 major components

ERVICE MANUAL

MAIN MONITOR

OPERATOR PANEL

ALPHANUMERIC
KEYBOARD

B/W VIDEO PRINTER

DOPPLER (PEDOF) CONNECTOR

PATIENT I/O

1-2-4-2 Purpose of the operator manual(s)

The operator manuals should be fully read and understood before operating the VIVID E9.

UPPER PANEL
WITH STEREO LOUDSPEAKERS
AND TOUCH MONITOR

DVD PLAYER

DVD RECORDER

PROBE CONNECTORS

BRAKE PEDALS

The online versions of the operator manuals are available via the Help function on VIVID E9’s operator
panel.

Chapter 1 - Introduction 1 - 5

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

Section 1-3
Important conventions

1-3-1 Conventions used in this book

1-3-1-1 Model designations

This manual covers the VIVID E9 scanners listed in 1-2-3 "VIVID E9 models covered by this manual"

on page 1-3.

1-3-1-2 Icons

Pictures, or icons, are used wherever they will reinforce the printed message. The icons, labels and
conventions used on the product and in the service information are described in this chapter.

1-3-1-3 Safety precaution messages

Various levels of safety precaution messages may be found on the equipment and in the service
information. The different levels of concern are identified by a flag word that precedes the precautionary
message. Known or potential hazards to personal are labeled in one of three ways:

•DANGER

• WARNING

•CAUTION

When a hazard is present that can cause property damage, but has absolutely no personal injury risk,
a NOTICE is used.

ERVICE MANUAL

DANGER

DANGER IS USED TO INDICATE THE PRESENCE OF A HAZARD THAT WILL
CAUSE SEVERE PERSONAL INJURY OR DEATH IF THE INSTRUCTIONS ARE
IGNORED.

WARNINGWARNING

CAUTION

NOTICE

NOTE: Notes are used to provide important information about an item or a procedure.

NOTE: Be sure to read the notes; the information contained in a note can often save you time or effort.

WARNING IS USED TO INDICATE THE PRESENCE OF A HAZARD THAT CAN CAUSE
SEVERE PERSONAL INJURY AND PROPERTY DAMAGE IF INSTRUCTIONS ARE
IGNORED.

CAUTION IS USED TO INDICATE THE PRESENCE OF A HAZARD THAT WILL OR CAN CAUSE
MINOR PERSONAL INJURY AND PROPERTY DAMAGE IF INSTRUCTIONS ARE IGNORED.
EQUIPMENT DAMAGE POSSIBLE.

Notice is used when a hazard is present that can cause property damage but has absolutely no
personal injury risk.

Example: Disk drive may crash.

1 - 6 Section 1-3 - Important conventions

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

1-3-2 Standard hazard icons

Important information will always be preceded by the exclamation point contained within a triangle,
as seen throughout this chapter. In addition to text, several different graphical icons (symbols) may be

used to make you aware of specific types of hazards that could possibly cause harm. Even if a symbol
isn’t used in this manual, it may be included for your reference.

Table 1-3 Standard hazard icons

ELECTRICAL MECHANICAL RADIATION

LASER HEAT PINCH

LASER

LIGHT

ERVICE MANUAL

OR

Some others icons make you aware of specific procedures that should be followed.

Table 1-4 Standard Icons that indicates that a special procedure is to be used

AVOID STATIC ELECTRICITY TAG AND LOCK OUT WEAR EYE PROTECTION

TAG

&

LOCKOUT

Date

Signed

OR

HAND PROTECTION FOOT PROTECTION

Chapter 1 - Introduction 1 - 7

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

1-3-3 Product icons

The following table describes the purpose and location of safety labels and other important information
provided on the equipment.

Table 1-5 Product icons sheet 1 of 3

LABEL/SYMBOL PURPOSE/MEANING LOCATION

Identification and Rating Plate

5 VIVID E9 S

- Manufacturer's name and address

- Date of manufacture

- Model and serial numbers

- Electrical ratings

Rear of console near power inlet

ERVICE MANUAL

Type/Class Label

Device Listing/Certification Labels

“CAUTION - This unit weighs « Special

care must be used to avoid «”

Used to indicate the degree of safety or
protection.

Equipment Type BF (man in the box
symbol) IEC 878-02-03 indicates B Type
equipment having a floating applied part.

Equipment Type CF (heart in the box
symbol) IEC 878-02-05 indicates
equipment having a floating applied part
having a degree of protection suitable for
direct cardiac contact.

DEFIBRILLATOR-PROOF TYPE CF
EQUIPMENT.

Laboratory logo or labels denoting
conformance with industry safety
standards such as UL or IEC.

This precaution is intended to prevent
injury that may result if one person attempt
to move the unit considerable distances or
on an incline due to the weight of the unit.

Rear of console

Probe connectors including Doppler probe

connector

Probe connectors and ECG connector.

On newer systems also on the rear of the
system.

At the ECG connector on front of system.

Rear of console

On the console where easily seen during

transport

Do not push VIVID E9 sideways when
casters are in break position. Instability
may occur.

“DANGER - Risk of explosion used in«”

The system is not designed for use with
flammable anesthetic gases.

1 - 8 Section 1-3 - Important conventions

Both sides of Top Console

Rear of console

GE H
D

IRECTION

EALTHCARE

GA091568, R

EVISION

5 VIVID E9 S

Table 1-5 Product icons (cont’d) sheet 2 of 3

LABEL/SYMBOL PURPOSE/MEANING LOCATION

ERVICE MANUAL

VIVID E9 SCANNERS

The system is not designed for use with
flammable anesthetic gases.

VIVID E9 SCANNERS

“TESTED AND PRODUCTION
MONITORED BY TUV PRODUCT
SERVICE NRTL WITH RESPECT TO
ELECTRICAL SHOCK, FIRE AND
MECHANICAL HAZARDS ONLY IN
ACCORDANCE WITH UL2601-1 AND
CAN/CSA C22.2 NO.601.1”

This unit carries the CE mark.
The VIVID E9 unit complies with

regulatory requirements of the European
Directive 93/ 42/EEC concerning medical
devices.

It also complies with emission limits for a
Group 1, Class B Medical Device as stated
in EN 60601-1-2
(IEC 60601-1-2).

“CAUTION” The equilateral triangle is
usually used in combination with other
symbols to advise or warn the user.

Rear of console

REAR OF CONSOLE ON VIVID E9

REAR OF CONSOLE

VAR IOUS

“ATTENTION - Consult accompanying
documents”

is intended to alert the user to refer to the
operator manual or other instructions
when complete information cannot be
provided on the label.

“CAUTION - Dangerous voltage”
(the lightning flash with arrowhead in
equilateral triangle) is used to indicate
electric shock hazards.

“PINCH POINT”

Indicates moving parts that may cause
injury (such as LCD arm)

“Mains OFF”
Indicates the power off position of the
mains power switch.

REAR OF SYSTEM ADJACENT TO

VAR IOUS

VAR IOUS

VAR IOUS

MAINS SWITCH

Chapter 1 - Introduction 1 - 9

GE H
D

IRECTION

EALTHCARE

GA091568, R

EVISION

5 VIVID E9 S

Table 1-5 Product icons (cont’d) sheet 3 of 3

LABEL/SYMBOL PURPOSE/MEANING LOCATION

“Mains ON”

Indicates the Power ON position of the
mains power switch.

“ON” Indicates the power on position of the
power switch.

CAUTION
THE ON/OFF BUTTON ON THE
OPERATOR PANEL DOES NOT
ISOLATE MAINS SUPPLY

On/off button

CAUTION
SYSTEM SHUTDOWN USING
THE ON/OFF BUTTON DOES
NOT DISCONNECT
FROM MAINS VOLTAGE.

For disconnecting VIVID E9 from mains
voltage after system shutdown, please set
the circuit breaker close to the mains inlet
to OFF as described in

4-2-2 "Power shut down" on page 4-8.

VIVID E9

ERVICE MANUAL

Rear of system

Operating Panel

“Protective Earth”
Indicates the protective earth (grounding)
terminal.

“Equipotential”
Indicates the terminal to be used for
connecting equipotential conductors when
interconnecting (grounding) with other
equipment as described in IEC60601-1.

This symbol indicates that waste electrical
and electronic equipment must not be
disposed of as unsorted municipal waste
and must be collected separately. Please
contact an authorized representative of
the manufacturer for information
concerning the decommissioning of your
equipment.

This product consists of devices that may
contain mercury, which must be recycled
or disposed of in accordance with local,
state, or country laws. (Within this system,
the backlight lamps in the monitor display,
contain mercury.)

USED SEVERAL PLACES INSIDE THE

SCANNER.

REAR OF CONSOLE

REAR OF CONSOLE

REAR OF LCD Monitor

1 - 10 Section 1-3 - Important conventions

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

Section 1-4
Safety considerations

1-4-1 Introduction

The following safety precautions must be observed during all phases of operation, service and repair of
this equipment. Failure to comply with these precautions or with specific warnings elsewhere in this
manual, violates safety standards of design, manufacture and intended use of the equipment.

1-4-2 Human safety

• Operating personnel must not remove the system covers.

• Servicing should be performed by authorized personnel only.

Only personnel who have participated in a VIVID E9 Training Seminar are authorized to service the
equipment.

5 VIVID E9 S

ERVICE MANUAL

DANGER

WARNINGWARNING

WARNINGWARNING

WARNINGWARNING

WARNINGWARNING

DANGEROUS VOLTAGES, CAPABLE OF CAUSING DEATH, ARE PRESENT IN
THIS EQUIPMENT. USE EXTREME CAUTION WHEN HANDLING, TESTING AND
ADJUSTING.

IF THE COVERS ARE REMOVED FROM AN OPERATING VIVID E9, SOME METAL
SURFACES MAY BE WARM ENOUGH TO POSE A POTENTIAL HEAT HAZARD IF
TOUCHED, EVEN WHILE IN SHUT DOWN MODE.

BECAUSE OF THE LIMITED ACCESS TO CABINETS AND EQUIPMENT IN THE FIELD,
PLACING PEOPLE IN AWKWARD POSITIONS, GE HAS LIMITED THE LIFTING WEIGHT
FOR ONE PERSON IN THE FIELD TO 16 KG (35 LBS). ANYTHING OVER 16 KG (35 LBS)
REQUIRES 2 PEOPLE.

HAVE TWO PEOPLE AVAILABLE TO DELIVER AND UNPACK THE VIVID E9.
ATTEMPTS TO MOVE THE UNIT CONSIDERABLE DISTANCES OR ON AN INCLINE BY
ONE PERSON COULD RESULT IN INJURY OR DAMAGE OR BOTH.

USE ALL PERSONAL PROTECTION EQUIPMENT (PPE) SUCH AS GLOVES, SAFETY
SHOES, SAFETY GLASSES, AND KNEELING PAD, TO REDUCE THE RISK OF INJURY.

Chapter 1 - Introduction 1 - 11

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

1-4-2 Human safety (cont’d)

ERVICE MANUAL

WARNINGWARNING

WARNINGWARNING

EXPLOSION WARNING

DO NOT OPERATE THE EQUIPMENT IN AN EXPLOSIVE ATMOSPHERE. OPERATION
OF ANY ELECTRICAL EQUIPMENT IN SUCH AN ENVIRONMENT CONSTITUTES A
DEFINITE SAFETY HAZARD.

DO NOT SUBSTITUTE PARTS OR MODIFY EQUIPMENT

BECAUSE OF THE DANGER OF INTRODUCING ADDITIONAL HAZARDS, ONLY
INSTALL GE APPROVED PARTS. DO NOT

PERFORM ANY UNAUTHORIZED

MODIFICATION OF THE EQUIPMENT.

1 - 12 Section 1-4 - Safety considerations

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

1-4-3 Mechanical safety

ERVICE MANUAL

WARNINGWARNING

WARNINGWARNING

WARNINGWARNING

WARNINGWARNING

WARNINGWARNING

WARNINGWARNING

WHILE THE SOFTWARE INSTALL PROCEDURE IS DESIGNED TO PRESERVE DATA,
YOU SHOULD SAVE ANY PATIENT DATA, IMAGES, SYSTEM SETUPS TO A DVD OR
HARDCOPY BEFORE DOING A SOFTWARE UPGRADE.

PRIOR TO ELEVATING SCANNER, VERIFY THAT THE KEYBOARD IS LOCKED IN ITS
LOWEST POSITION. VERIFY THAT THE FRONT BRAKE IS LOCKED AND THE
SCANNER IS UNABLE TO SWIWEL. VERIFY THAT THE REAR BRAKES ARE IN THE
LOCKED POSITION.

WHEN THE UNIT IS RAISED FOR A REPAIR OR MOVED ALONG ANY INCLINE, USE
EXTREME CAUTION SINCE IT MAY BECOME UNSTABLE AND TIP OVER.

ULTRASOUND PROBES ARE HIGHLY SENSITIVE MEDICAL INSTRUMENTS THAT CAN
EASILY BE DAMAGED BY IMPROPER HANDLING. USE CARE WHEN HANDLING AND
PROTECT FROM DAMAGE WHEN NOT IN USE. DO NOT USE A DAMAGED OR
DEFECTIVE PROBE. FAILURE TO FOLLOW THESE PRECAUTIONS CAN RESULT IN
SERIOUS INJURY AND EQUIPMENT DAMAGE.

NEVER USE A PROBE THAT HAS FALLEN TO THE FLOOR. EVEN IF IT LOOKS OK, IT
MAY BE DAMAGED.

THE SYSTEM SHOULD NOT BE MOVED WITH THE OPERATING PANEL EXTENDED.
POSITION THE OPERATING PANEL IN ITS CENTERED AND LOCKED POSITION.
LOWER THE OPERATING PANEL AS MUCH AS POSSIBLE BEFORE MOVING THE
SYSTEM.

WARNINGWARNING

CAUTION

CAUTION

CAUTION

CAUTION

CAUTION

CAUTION

REMEMBER: IF THE FRONT CASTER SWIVEL LOCK IS ENGAGED FOR
TRANSPORTATION, PRESSING THE RELEASE PEDAL ONCE DISENGAGES THE
SWIVEL LOCK. YOU MUST DEPRESS THE RELEASE PEDAL A SECOND TIME TO
ENGAGE THE BRAKE.

BEFORE YOU MOVE OR TRANSPORT THE SYSTEM, MAKE SURE TO LOCK THE LCD MONITOR
ARM FIRMLY AND FLIP DOWN THE MONITOR TO PREVENT DAMAGE TO THE SYSTEM.

ALWAYS LOCK THE TOP CONSOLE (OPERATOR PANEL) IN ITS PARKING (LOCKED)
POSITION BEFORE MOVING THE SCANNER AROUND.

TO AVOID INJURY WHEN YOU MOVE THE LCD MONITOR AND THE MONITOR ARM, DO NOT
PUT YOUR FINGER, HAND, OR OBJECT ON THE JOINT OF THE MONITOR OR THE MONITOR
ARM.

ENSURE THAT NOBODY TOUCH THE CONSOLE ARM/FROGLEG WHEN MOVING THE
OPERATOR PANEL.

DO NOT MOVE THE UNIT IF THE OPERATOR PANEL IS IN UNLOCKED POSITION.

KEEP THE HEAT VENTING HOLES ON THE MONITOR UNOBSTRUCTED TO AVOID
OVERHEATING OF THE MONITOR.

Chapter 1 - Introduction 1 - 13

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

1-4-3 Mechanical safety (cont’d)

ERVICE MANUAL

-

CAUTION

CAUTION

CAUTION

CAUTION

CAUTION

VIVID E9 WEIGHS 128 KG (283 LB.) OR MORE, DEPENDING ON INSTALLED PERIPHERALS,
WHEN READY FOR USE. CARE MUST BE USED WHEN MOVING IT OR REPLACING ITS PARTS.
FAILURE TO FOLLOW THE PRECAUTIONS LISTED BELOW COULD RESULT IN INJURY,
UNCONTROLLED MOTION AND COSTLY DAMAGE.
ALWAYS:

- BE SURE THE PATHWAY IS CLEAR.

- USE SLOW, CAREFUL MOTIONS.

- USE TWO PEOPLE WHEN MOVING ON INCLINES OR LIFTING MORE THAN 16 KG (35 LBS).

DO NOT TRANSPORT VIVID E9 IN A VEHICLE WITHOUT LOCKING THE CASTERS (WHEELS)
AND SECURING IT.

USE PROTECTIVE GLASSES DURING DRILLING, FILING AND DURING ALL OTHER WORK
WHERE EYES NEED PROTECTION.

USE SAFETY SHOES WHEN DOING WORK WHERE THERE IS ANY CHANCE OF FOOT
DAMAGE.

USE PROTECTIVE GLOVES WHEN DRILLING AND CUTTING.

NOTICE

Be careful not to pinch any of the cables.

1 - 14 Section 1-4 - Safety considerations

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

1-4-4 Electrical safety

1-4-4-1 Safe practices

Follow these guidelines to minimize shock hazards whenever you are using the scanner;

• The equipment chassis must be connected to an electrical ground.

• The unit is equipped with a three-conductor AC power cable. This must be plugged into an approved
electrical outlet with safety ground.

• The power outlet used for this equipment should not be shared with other types of equipment.

• Both the system power cable and the power connector must meet international electrical standards.

5 VIVID E9 S

ERVICE MANUAL

WARNINGWARNING

CONNECTING A VIVID E9 SCANNER TO THE WRONG VOLTAGE LEVEL WILL MOST
LIKELY DESTROY IT.

1-4-4-2 Probes

Follow these guidelines before connecting a probe to the scanner:

• Inspect the probe prior to each use for damage or degradation to the:

-housing

- cable strain relief

-lens

- seal

- connector pins

- locking mechanism

• Do not use a damaged or defective probe.

• Never immerse the probe connector or adapter into any liquid.

• The system has more than one type of probe port. Use the appropriate probe port designed for the
probe you are connecting.

Chapter 1 - Introduction 1 - 15

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

Section 1-5
Labels locations

1-5-1 Label on Front of LCD Monitor

Table 1-6 Label on Front of LCD Monitor

DESCRIPTION ILLUSTRATION

LABEL GE LOGO

ERVICE MANUAL

1-5-2 Label on Rear of LCD Monitor

Table 1-7 Label on Rear of LCD Monitor

DESCRIPTION ILLUSTRATION

LABEL, LCD MERCURY_RATING

1 - 16 Section 1-5 - Labels locations

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

1-5-3 Label on Upper OP Panel

Table 1-8 Label on Upper OP Panel

DESCRIPTION ILLUSTRATION

VIVID E9 NAMEPLATE, GOLD, UPPER OP PANEL

(Used on VIVID E9 with 4D Expert option)

VIVID E9 NAMEPLATE, BRONZE, UPPER OP PANEL

(Used on VIVID E9 with 2D)

Vivid E9 Nameplate, Periwinkle, Upper OP Panel

(Used on VIVID E9 Pro)

VIVID E9 NAMEPLATE, UPPER OP PANEL, SILVER

(Used on VIVID E9 BT’09)

ERVICE MANUAL

1-5-4 Labels on Front Handle

None.

1-5-5 Labels on top of Console

Table 1-9 Labels on top of Console

DESCRIPTION ILLUSTRATION

LABEL WARNING

Do not push VIVID E9 sideways when casters are in

brakeage position. Instability may occur.

LABELS ON BOTH SIDES
OF SCANNER.

Chapter 1 - Introduction 1 - 17

GE H

GA314321-01

GA314385-01

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

1-5-6 Labels near Connectors on Front

Table 1-10 Labels near Connectors on Front

DESCRIPTION ILLUSTRATION

Label, Front Panel

5166825 rev2

ERVICE MANUAL

Label, Patient IO

DEFIBRILLATOR-PROOF TYPE CF

EQUIPMENT.

Label, Probe Connectors

Label, Doppler (Pedof) Connector

1 - 18 Section 1-5 - Labels locations

GE H

DVD

GA314383-01

DVR Digital Video Recorder

GA314384-01

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

1-5-7 Labels on DVD Units

Table 1-11 Labels on DVD units

DESCRIPTION ILLUSTRATION

Label, DVD

Label, DVR Digital Video Recorder

1-5-8 Label on External I/O

Table 1-12 Labels on External I/O

DESCRIPTION ILLUSTRATION

ERVICE MANUAL

Label for External Connectors, IO Board

!

RL

5180173 rev1

Chapter 1 - Introduction 1 - 19

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

1-5-9 Labels at AC Mains Inlet and Circuit Breaker

Table 1-13 Labels on AC Power Supply (Main Power Supply)

DESCRIPTION ILLUSTRATION

Label, AC Controller

ERVICE MANUAL

Label, System Part Number

and Power Rating

Label, System Serial Number and

manufacturing week/year.

1 - 20 Section 1-5 - Labels locations

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

1-5-10 Label on Rear Cover

1-5-10-1 Label, General Info - BT’12

Table 1-14 Label, General Info - BT’12

DESCRIPTION ILLUSTRATION

Label, General Info - BT’12

(International)

(Introduced JUN. 2012)

ERVICE MANUAL

Label, General Info - BT’12

(International)

Label, General Info - BT’11 and BT’12

(Importer: Alkan Medical, Egypt)

Label, General Info - BT’11 and BT’12

(Importer: GE Medical Systems, Egypt)

Chapter 1 - Introduction 1 - 21

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

1-5-10-2 Label, General Info - BT’11/BT’10

Table 1-15 Label, General Info - BT’11/BT’10 sheet 1 of 3

DESCRIPTION ILLUSTRATION

Label, General Info - BT’11

(International)

(Introduced SEP 2010)

Label, General Info - BT’11

(International)

(Introduced AUG 2010)

ERVICE MANUAL

Label, General Info - BT’11

(International)

Label, General Info - BT’11 and BT’12

(Importer: Alkan Medical, Egypt)

1 - 22 Section 1-5 - Labels locations

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

Table 1-15 Label, General Info - BT’11/BT’10 (cont’d) sheet 2 of 3

DESCRIPTION ILLUSTRATION

Label, General Info - BT’11 and BT’12

(Importer: GE Medical Systems, Egypt)

Label, General Info - BT’11

Korean

Used after

June 1, 2012

5 VIVID E9 S

ERVICE MANUAL

Label, General Info - BT’11

Korean

Used before

Label, General Info - BT’11 and BT’12

June 1, 2012.

(Egypt)

Chapter 1 - Introduction 1 - 23

GE H

EALTHCARE

D

IRECTION

GA091568, R

DESCRIPTION ILLUSTRATION

Label, General Info - BT’10

Chinese

EVISION

5 VIVID E9 S

Table 1-15 Label, General Info - BT’11/BT’10 (cont’d) sheet 3 of 3

ERVICE MANUAL

1 - 24 Section 1-5 - Labels locations

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

1-5-10-3 Label, General Info - BT’09

Table 1-16 Label on Rear Cover

DESCRIPTION ILLUSTRATION

Label, General Info - BT’09

International

Label, General Info - BT’09

Chinese

ERVICE MANUAL

Label, General Info - BT’09

Korean

Chapter 1 - Introduction 1 - 25

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

1-5-11 Label on Rear Cover - detailed descriptions

Table 1-17 Label on Rear Cover - detailed descriptions sheet 1 of 3

DESCRIPTION ILLUSTRATION

Label on Rear Cover.

Follow instructions for use.

Read and understand all instructions in the User's
Manual before attempting to use the ultrasound unit.

ERVICE MANUAL

“CAUTION - Dangerous voltage”

(the lightning flash with arrowhead in equilateral
triangle) is used to indicate electric shock hazards.

“ATTENTION - Consult accompanying
documents”

is intended to alert the user to refer to the operator
manual or other instructions when complete
information cannot be provided on the label.

The system is not designed for use with flammable
anesthetic gases.

This precaution is intended to prevent injury that
may result if one person attempt to move the unit
considerable distances or on an incline due to the
weight of the unit.

OR

“CAUTION - This unit weighs« Special care must be used to avoid«”

1 - 26 Section 1-5 - Labels locations

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

Table 1-17 Label on Rear Cover - detailed descriptions (cont’d) sheet 2 of 3

DESCRIPTION ILLUSTRATION

VIVID E9 SCANNERS

“TESTED AND PRODUCTION MONITORED BY
TUV PRODUCT SERVICE NRTL WITH RESPECT
TO ELECTRICAL SHOCK, FIRE AND
MECHANICAL HAZARDS ONLY IN
ACCORDANCE WITH UL2601-1 AND CAN/CSA
C22.2 NO.601.1”

GOST

ERVICE MANUAL

This symbol indicates that waste electrical and
electronic equipment must not be disposed of as
unsorted municipal waste and must be collected
separately. Please contact an authorized
representative of the manufacturer for information
concerning the decommissioning of your equipment.

This unit carries the CE mark.
The VIVID E9 unit complies with regulatory

requirements of the European Directive 93/ 42/EEC
concerning medical devices.

It also complies with emission limits for a Group 1,
Class B Medical Device as stated in EN 60601-1-2
(IEC 60601-1-2).

GROUP 1 Class A

(Some units produced in 2010 are Class B).

Chapter 1 - Introduction 1 - 27

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

Table 1-17 Label on Rear Cover - detailed descriptions (cont’d) sheet 3 of 3

DESCRIPTION ILLUSTRATION

CAUTION

United States law restricts this device to sale or use
by or on the order of a physician.

CLASS I

The VIVID E9 ultrasound unit is a Class I device,
type CF, according to Sub-clause 14 of IEC60601-1
(1988).

TYPE CF

Equipment Type CF (heart in the box symbol) IEC
878-02-05 indicates equipment having a floating
applied part having a degree of protection suitable
for direct cardiac contact.

ERVICE MANUAL

MANUFACTURER

1 - 28 Section 1-5 - Labels locations

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

1-5-12 Label on the BEP6’s door

Figure 1-2 Label on the BEP6’s door

ERVICE MANUAL

Chapter 1 - Introduction 1 - 29

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

1-5-13 Label on the BEP5’s door

Figure 1-3 Label on the BEP5’s door

ERVICE MANUAL

1 - 30 Section 1-5 - Labels locations

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

1-5-14 Label, Disassembly Nester

This label is located on the outside of the Front End Rack’s cover (inside unit).

Figure 1-4 Label, Disassembly Nester

ERVICE MANUAL

Chapter 1 - Introduction 1 - 31

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

Section 1-6
Dangerous procedure warnings

Warnings, such as the example below, precede potentially dangerous procedures throughout this
manual. Instructions contained in the warnings must be followed.

ERVICE MANUAL

DANGER

WARNINGWARNING

WARNINGWARNING

WARNINGWARNING

DANGEROUS VOLTAGES, CAPABLE OF CAUSING DEATH, ARE PRESENT IN
THIS EQUIPMENT. USE EXTREME CAUTION WHEN HANDLING, TESTING AND
ADJUSTING.

IF THE COVERS ARE REMOVED FROM AN OPERATING VIVID E9, SOME METAL
SURFACES MAY BE WARM ENOUGH TO POSE A POTENTIAL HEAT HAZARD IF
TOUCHED, EVEN WHILE IN SHUT DOWN MODE.

EXPLOSION WARNING
DO NOT OPERATE THE EQUIPMENT IN AN EXPLOSIVE ATMOSPHERE. OPERATION

OF ANY ELECTRICAL EQUIPMENT IN SUCH AN ENVIRONMENT CONSTITUTES A
DEFINITE SAFETY HAZARD.

DO NOT SUBSTITUTE PARTS OR MODIFY EQUIPMENT

BECAUSE OF THE DANGER OF INTRODUCING ADDITIONAL HAZARDS, ONLY
INSTALL GE APPROVED PARTS. DO NOT

PERFORM ANY UNAUTHORIZED

MODIFICATION OF THE EQUIPMENT.

1 - 32 Section 1-6 - Dangerous procedure warnings

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

Section 1-7
Lockout/Tagout (LOTO) requirements

Follow OSHA Lockout/Tagout requirements (USA) or local Lockout/Tagout requirements by ensuring
you are in total control of the AC power plug at all times during the service process.

To apply Lockout/Tagout (LOTO):

1.) Plan and prepare for shutdown.

2.) Shutdown the equipment.

3.) Isolate the equipment.

4.) Apply Lockout/Tagout Devices.

5.) Control all stored and residual energy.

6.) Verify isolation.

All potentially hazardous stored or residual energy is relieved.

ERVICE MANUAL

WARNINGWARNING

ENERGY CONTROL AND POWER LOCKOUT FOR VIVID E9.

WHEN SERVICING PARTS OF THE SYSTEM WHERE THERE IS EXPOSURE TO
VOLTAGE GREATER THAN 30 VOLTS:

TAG

&

LOCKOUT

Signed

1. FOLLOW LOCK OUT/TAG OUT PROCEDURES.

2. TURN OFF THE BREAKER.

Date

3. UNPLUG THE VIVID E9.

4. MAINTAIN CONTROL OF THE POWER PLUG.

5. WAIT FOR AT LEAST 20 SECONDS FOR CAPACITORS TO DISCHARGE, AS THERE ARE NO TEST POINTS TO
VERIFY ISOLATION. THE AMBER LIGHT ON THE OP PANEL ON/OFF BUTTON WILL TURN OFF.

BEWARE THAT THE MAIN POWER SUPPLY AND BACK END PROCESSOR MAY BE ENERGIZED EVEN IF THE POWER
IS TURNED OFF WHEN THE CORD IS STILL PLUGGED INTO THE AC OUTLET.

Section 1-8
Returning/Shipping Probes and Repair Parts

Equipment being returned must be clean and free of blood and other infectious substances.

GE Healtcare policy states that body fluids must be properly removed from any part or equipment prior
to shipment. GE Healtcare employees, as well as customers, are responsible for ensuring that parts/
equipment have been properly decontaminated prior to shipment. Under no circumstance should a part
or equipment with visible body fluids be taken or shipped from a clinic or site (for example, body coils
or an ultrasound probe).

The purpose of the regulation is to protect employees in the transportation industry, as well as the
people who will receive or open this package.

NOTE: The US Department of Transportation (DOT) has ruled that “items that were saturated and/or

dripping with human blood that are now caked with dried blood; or which were used or intended
for use in patient care” are “regulated medical waste” for transportation purposes and must be
transported as a hazardous material.

Chapter 1 - Introduction 1 - 33

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

Section 1-9
Electromagnetic compatibility (EMC)

1-9-1 What is EMC?

Electromagnetic compatibility describes a level of performance of a device within its electromagnetic
environment. This environment consists of the device itself and its surroundings including other
equipment, power sources and persons with which the device must interface. Inadequate compatibility
results when a susceptible device fails to perform as intended due interference from its environment or
when the device produces unacceptable levels of emission to its environment. This interference is often
referred to as radio–frequency or electromagnetic interference (RFI/EMI) and can be radiated through
space or conducted over interconnecting power of signal cables. In addition to electromagnetic energy,
EMC also includes possible effects from electrical fields, magnetic fields, electrostatic discharge and
disturbances in the electrical power supply.

1-9-2 Compliance

VIVID E9 conforms to all applicable conducted and radiated emission limits and to immunity from
electrostatic discharge, radiated and conducted RF fields, magnetic fields and power line transient
requirements.

Applicable standards are: 47CFR Part 18, IEC60601–1–2:2001.

ERVICE MANUAL

NOTE: For CE Compliance, it is critical that all covers, screws, shielding, gaskets, mesh, clamps, are

in good condition, installed tightly without skew or stress. Proper installation following all
comments noted in this service manual is required in order to achieve full EMC performance.

1-9-3 Electrostatic discharge (ESD) prevention

WARNINGWARNING

WARNINGWARNING

DO NOT TOUCH ANY BOARDS WITH INTEGRATED CIRCUITS PRIOR TO TAKING THE
NECESSARY ESD PRECAUTIONS.

1. ALWAYS CONNECT YOURSELF, VIA AN ARM-WRIST STRAP, TO THE ADVISED
ESD CONNECTION POINT LOCATED ON THE REAR OF THE SCANNER (NEAR THE
POWER CONNECTOR).

2. FOLLOW GENERAL GUIDELINES FOR HANDLING OF ELECTROSTATIC SENSITIVE
EQUIPMENT.

RISK OF ELECTRICAL SHOCK, SYSTEM MUST BE TURNED OFF. AVOID ALL
CONTACT WITH ELECTRICAL CONTACTS, CONDUCTORS AND COMPONENTS.
ALWAYS USE NON-CONDUCTIVE HANDLES DESIGNED FOR THE REMOVAL AND
REPLACEMENT OF ESD SENSITIVE PARTS. ALL PARTS THAT HAVE THE POTENTIAL
FOR STORING ENERGY MUST BE DISCHARGED OR ISOLATED BEFORE MAKING
CONTACT.

1 - 34 Section 1-9 - Electromagnetic compatibility (EMC)

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

Section 1-10
Customer assistance

1-10-1 Contact information

If this equipment does not work as indicated in this service manual or in the user manual, or if you
require additional assistance, please contact the local distributor or appropriate support resource, as
listed below.

Before you call, identify the following information, and acquire image (Alt+D) to send to the Customer
Care team:

1.) System ID serial number.

2.) Software version.

3.) Date and time of occurrence.

4.) Sequence of events leading to issue.

5.) Is the issue repeatable?

6.) Imaging mode, probe, preset/application.

7.) Media brand, speed, capacity, type.

8.) Save secondary image capture, cine loop, 4D multi-volume loop.

ERVICE MANUAL

NOTE: Restart the application before resuming clinical scanning.

Table 1-18 Phone numbers for Customer Assistance

LOCATION PHONE NUMBER

USA

GE Medical Systems

Ultrasound Service Engineering

9900 Innovation Drive

Wauwatosa, WI 53226

Canada 1-800-668-0732

Latin America

Europe (OLC- EMEA)

GE Ultraschall Deutschland GmbH

Beethovenstraße 239

Postfach 11 05 60, D-42655 Solingen

Germany

Online Services Ultrasound Asia

Australia

China

India

Japan

Korea

Singapore

Service: On-site

Service Parts

Application Support

Service

Application Support

OLC - EMEA

Phone: [phone] - 652

[phone]

Fax: [phone] - 431

Phone: +(61) 1-800-647-855

+(86) 800-810-8188

+(91) 1800-425-8025

+(81) 42-648-2940

+(82) 2620 13585

+(95) 6277-3444

1-800-437-1171

1-800-558-2040

1-800-682-5327 or 1-262-524-5698

1-800-321-7937

1-262-524-5698

Chapter 1 - Introduction 1 - 35

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

1-10-2 System manufacturer

Table 1-19 System manufacturer

MANUFACTURER PHONE NUMBER FAX NUMBER

GE VINGMED ULTRASOUND A/S

STRANDPROMENADEN 45

P.O. BOX 141

NO-3191 HORTEN

NORWAY

[phone] [phone]

ERVICE MANUAL

1 - 36 Section 1-10 - Customer assistance

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

Chapter 2
Site preparations

Section 2-1
Overview

2-1-1 Purpose of this chapter

This chapter provides the information required to plan and prepare for the setup of a VIVID E9. Included
are descriptions of the facility and electrical needs to be met by the purchaser of the unit.

2-1-2 Contents in this chapter

2-1 Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

2-2 General console requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2

2-3 Facility needs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9

ERVICE MANUAL

Chapter 2 - Site preparations 2 - 1

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

Section 2-2
General console requirements

2-2-1 Console environmental requirements

2-2-1-1 If the unit is very cold or hot

ERVICE MANUAL

CAUTION

IF THE UNIT IS VERY COLD OR HOT, DO NOT TURN ON ITS POWER UNTIL IT HAS HAD A
CHANCE TO ACCLIMATE TO ITS OPERATING ENVIRONMENT.

Table 2-1 VIVID E9 Acclimate Time

o

-40-35-30-25-20-15-10-5 0 5 10152025303540455055606570

C

o

-40 -31 -22 -13 -4 5 14 23 32 41 50 59 68 77 86 95 104 113 122 131 140 149 158

F

Hrs 2018161412108642000000024681012

2-2-1-2 Environmental specifications for VIVID E9 scanners

Temperature Limits:

•Operation:

10 to 35 ºC (50 to 95 ºF)

• Storage and Transport:

-20 to 60 ºC (-4 to 140 ºF)

Humidity Limits:

•Operation:

30 - 60% rH non-condensing

• Storage and Transport:

30 - 95% rH non-condensing

Air Pressure Limits:

•Operation:
700-1060 hPa

• Storage and Transport:
700-1060 hPa

Heat Dissipation:

• 3800 BTU/h

2 - 2 Section 2-2 - General console requirements

GE H

EALTHCARE

D

IRECTION

GA091568, R

2-2-1-3 Cooling

The cooling requirement for the VIVID E9 scanner with monitor and on board peripherals, is up to
3800 BTU/h. This figure does not include cooling needed for lights, people, or other equipment in the
room. Each person in the room places an additional 300 BTU/h demand on the cooling system.

2-2-1-4 Lighting

Bright light is needed for system installation, updates and repairs. However, operator and patient
comfort may be optimized if the room light is subdued and indirect. Therefore a combination lighting
system (dim/bright) is recommended. Keep in mind that lighting controls and dimmers can be a source
of EMI which could degrade image quality. These controls should be selected to minimize possible
interference.

EVISION

5 VIVID E9 S

ERVICE MANUAL

Chapter 2 - Site preparations 2 - 3

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

2-2-2 Electrical requirements

2-2-2-1 General requirements

NOTE: GE Healthcare requires a dedicated power and ground for the proper operation of its Ultrasound

equipment. This dedicated power shall originate at the last distribution panel before the system.

The VIVID E9 will function on voltages from 100-240 Volts and 50 or 60 Hz. However, if using 220 volt
power in North America, then a center tapped power source is required.

Sites with a mains power system with defined Neutral and Live:

The dedicated line shall consist of one phase, a neutral (not shared with any other circuit), and a full
size ground wire from the distribution panel to the Ultrasound outlet.

Sites with a mains power system without a defined Neutral:

The dedicated line shall consist of one phase (two lines), not shared with any other circuit, and a full
size ground wire from the distribution panel to the Ultrasound outlet.

NOTE: Please note that image artifacts can occur, if at any time within the facility, the ground from the

main facility's incoming power source to the Ultrasound unit is only a conduit.

ERVICE MANUAL

2 - 4 Section 2-2 - General console requirements

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

2-2-2-2 Electrical requirements for VIVID E9

In the table below, the electrical specifications for VIVID E9 includes monitor and on board peripherals.

Table 2-2 Electrical specifications for VIVID E9

PART NUMBER DESCRIPTION VOLTAGE TOLERANCES

BT’12

GA000940 Vivid E9 4D Expert Option - 17” LCD

GA000950 Vivid E9 4D Expert Option - 19” LCD

GA000945 Vivid E9 2D - 17” LCD

GA000955 Vivid E9 2D - 19” LCD

GB000040 Vivid E9 BT12 PRO Configuration 17” LCD

GB000050 Vivid E9 BT12 PRO Configuration 19” LCD

BT’11

GA000810 VIVID E9 4D Expert Option - 17” LCD

GA000815 VIVID E9 4D Expert Option - 19” LCD

GA000830 VIVID E9 2D - 17” LCD

GA000835 VIVID E9 2D - 19” LCD

100-230 VAC ±10% 1100 W 50/60 Hz

100-230 VAC ±10% 1100 W 50/60 Hz

ERVICE MANUAL

POWER

CONSUMPTION FREQUENCY

BT’09

GA000100 VIVID E9 (with 4D) - v108.x.x 100-230 VAC ±10% 1100 W 50/60 Hz

The current drain will vary depending on the mains voltage.

• At 230 VAC the current may be up to 5 A.

• At 100 VAC the current may be up to 12 A.

2-2-2-3 Site circuit breaker

CAUTION

POWER OUTAGE MAY OCCUR. THE VIVID E9 SCANNER REQUIRES A DEDICATED SINGLE
BRANCH CIRCUIT. TO AVOID CIRCUIT OVERLOAD AND POSSIBLE LOSS OF CRITICAL CARE
EQUIPMENT, MAKE SURE YOU DO NOT HAVE ANY OTHER EQUIPMENT OPERATING ON THE
SAME CIRCUIT.

It is recommended that the branch circuit breaker for the unit be readily accessible.

2-2-2-4 Site power outlets

A dedicated AC power outlet must be within reach of the unit without extension cords. Other outlets
adequate for the external peripherals, medical and test equipment needed to support this unit must also
be present within 1 m (3.2 ft.) of the unit. Electrical installation must meet all current local, state, and
national electrical codes.

2-2-2-5 Unit power plug

If the unit arrives without a power plug, or with the wrong plug, you must contact your GE dealer or the
installation engineer must supply what is locally required.

Chapter 2 - Site preparations 2 - 5

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

2-2-2-6 Power stability requirements

Voltage drop-out

Max 10 ms.

Power transients (all applications)

Less than 25% of nominal peak voltage for less than 1 millisecond for any type of transient, including
line frequency, synchronous, asynchronous, or aperiodic transients.

ERVICE MANUAL

2 - 6 Section 2-2 - General console requirements

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

2-2-3 EMI limitations

Ultrasound machines are susceptible to Electromagnetic Interference (EMI) from radio frequencies,
magnetic fields, and transients in the air or wiring. They also generate EMI. The VIVID E9 complies with
limits as stated on the EMC label. However there is no guarantee that interference will not occur in a
particular installation.

Possible EMI sources should be identified before the unit is installed.

Electrical and electronic equipment may produce EMI unintentionally as the result of a defect. These
sources include:

• medical lasers,

• scanners,

• cauterizing guns,

• computers,

•monitors,

• fans,

• gel warmers,

• microwave ovens,

• light dimmers

• portable phones.

The presence of a broadcast station or broadcast van may also cause interference.

5 VIVID E9 S

ERVICE MANUAL

See Table 2-3 on page 2-7 for EMI Prevention tips.

Table 2-3 EMI prevention/abatement sheet 1 of 2

EMI RULE DETAILS

• Keep the unit at least 5 meters (15 feet) away from other EMI sources.

Be aware of RF sources

Ground the unit

Install all screws, RF
gaskets, covers, cores

Replace broken RF
gaskets

Do not place labels where
RF gaskets touch metal

Use GE specified
harnesses and peripherals

• Special shielding may be required to eliminate interference problems caused by high
frequency, high powered radio or video broadcast signals.

• Poor grounding is the most likely reason a unit will have noisy images.

• Check grounding of the power cord and power outlet.

• After you finish repairing or updating the system, replace all covers and tighten all screws.

• Any cable with an external connection requires a magnet wrap at each end.

• Install the Card Rack Cover over the Card Rack.

Loose or missing covers or RF gaskets allow radio frequencies to interfere with the ultrasound
signals.

• If more than 20% or a pair of the fingers on an RF gasket are broken, replace the gasket.

• Do not turn on the unit until any loose metallic part is removed.

Never place a label where RF gaskets meet the unit. otherwise, the gap created will permit RF
leakage. or, if a label has been found in such a position, move the label.

• The interconnect cables are grounded and require ferrite beads and other shielding.

• Also, cable length, material, and routing are all important; do not change from what is
specified.

Take care with cellular
phones

Cellular phones may transmit a 5 V/m signal; that could cause image artifacts.

Chapter 2 - Site preparations 2 - 7

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

Table 2-3 EMI prevention/abatement (cont’d) sheet 2 of 2

EMI RULE DETAILS

• Do not allow cables to lie across the top of the Card Rack or hang out of the peripheral
Properly dress peripheral
cables

bays.

• Loop the excess length for peripheral cables inside the peripheral bays. attach the

monitor cables to the frame.

2-2-4 Probes environmental requirements

Table 2-4 Operation and storage temperatures for probes

Operation: 10 to 40 ºC (50 to 104 ºF) 5 to 42.7 ºC (41 to 108,9 ºF)

Storage: -20 to 50 ºC (-4 to 122 ºF) -20 to 60 ºC (-4 to 140 ºF)

Temperatures in degrees Celsius (oC) conversion to degrees F: (oF) = (oC * 9/5) + 32

Electronic PAM PTE

ERVICE MANUAL

CAUTION

PAMPTE probes are designed for storage temperatures of -20 to +60 degrees C
(-4 to +140 degrees F).
Electronic probes are designed for storage temperatures of -20 to +50 degrees C
(-4 to +122 degrees F).
When exposed to large temperature variations, the product should be kept at room temperature
the needed time to stabilize its temperature before use.
Refer to Table 2-1 "VIVID E9 Acclimate Time" on page 2-2 to determine the needed settlement
time.

2-2-5 Time and manpower requirements

Site preparation takes time. Begin Pre-installation checks as soon as possible, if possible, six weeks
before delivery, to allow enough time to make any changes.

WARNINGWARNING

HAVE TWO PEOPLE AVAILABLE TO DELIVER AND UNPACK THE VIVID E9.
ATTEMPTS TO MOVE THE UNIT CONSIDERABLE DISTANCES OR ON AN INCLINE BY
ONE PERSON COULD RESULT IN INJURY OR DAMAGE OR BOTH.

2 - 8 Section 2-2 - General console requirements

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

Section 2-3
Facility needs

2-3-1 Purchaser responsibilities

The work and materials needed to prepare the site is the responsibility of the purchaser. Delay,
confusion, and waste of manpower can be avoided by completing pre-installation work before delivery.
Purchaser responsibility includes:

• Procuring the materials required.

• Completing the preparations before delivery of the ultrasound system.

• Paying the costs for any alterations and modifications not specifically provided in the sales contract.

NOTE: All electrical installations that are preliminary to the positioning of the equipment at the site

prepared for the equipment must be performed by licensed electrical contractors. Other
connections between pieces of electrical equipment, calibrations, and testing must also be
performed by qualified personnel. The products involved (and the accompanying electrical
installations) are highly sophisticated and special engineering competence is required. All
electrical work on these products must comply with the requirements of applicable electrical
codes. The purchaser of GE equipment must only utilize qualified personnel to perform
electrical servicing on the equipment.

ERVICE MANUAL

The desire to use a non–listed or customer provided product or to place an approved product further
from the system than the interface kit allows, presents challenges to the installation team. To avoid
delays during installation, such variances should be made known to the individuals or group performing
the installation at the earliest possible date (preferably prior to the purchase).

The ultrasound suite must be clean prior to delivery of the machine. Carpet is not recommended
because it collects dust and creates static. Potential sources of EMI (electromagnetic interference)
should also be investigated before delivery. Dirt, static, and EMI can negatively impact system reliability.

Chapter 2 - Site preparations 2 - 9

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

2-3-2 Required facility needs

NOTE: GE Healthcare requires a dedicated power and ground for the proper operation of its Ultrasound

equipment. This dedicated power shall originate at the last distribution panel before the system.

The VIVID E9 will function on voltages from 100-240 Volts and 50 or 60 Hz. However, if using 220 volt
power in North America, then a center tapped power source is required.

Sites with a mains power system with defined Neutral and Live:

The dedicated line shall consist of one phase, a neutral (not shared with any other circuit), and a full
size ground wire from the distribution panel to the Ultrasound outlet.

Sites with a mains power system without a defined Neutral:

The dedicated line shall consist of one phase (two lines), not shared with any other circuit, and a full
size ground wire from the distribution panel to the Ultrasound outlet.

• Dedicated single branch power outlet of adequate amperage (see Table 2-2 on page 2-5) meeting
all local and national codes which is located less than 2.5 m (8 ft.) from the unit’s proposed location

• Door opening is at least 76 cm (30 in) wide

• Proposed location for unit is at least 0.3 m (1 ft.) from the wall for cooling

• Power outlet and place for any external peripheral are within 2 m (6.5 ft.) of each other with
peripheral within 1 m of the unit to connect cables.

ERVICE MANUAL

NOTE: VIVID E9 has two outlets inside the unit, one is for the B/W printer and one spare.

• Power outlets for other medical equipment

• Power outlets for test equipment within 1 m (3.2 ft.) of unit

• Clean and protected space to store probes (in their cases or on a rack)

• Material to safely clean probes (done with a plastic container, never metal)

2 - 10 Section 2-3 - Facility needs

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

2-3-3 Desirable features

• Door is at least 92 cm (3 ft.) wide

• Circuit breaker for dedicated power outlet is easily accessible

• Sink with hot and cold water

• Receptacle for bio–hazardous waste, like used probe sheaths

• Emergency oxygen supply

• Storage for linens and equipment

• Nearby waiting room, lavatory, and dressing room

• Dual level lighting (bright and dim)

• Lockable cabinet ordered by GE for its software and proprietary manuals

2-3-4 Minimal floor plan suggestion

Figure 2-1 Minimal Floor Plan, 2.5 m x 3 m (8 by 10 foot)

ERVICE MANUAL

Scale:

Each square equals one
square foot (app. 31 x 31 cm)

Ethernet Connector

Ultrasound
Unit

Power outlet

GE cabinet for
software and
manuals (optional)

2-3-5 Suggested Floor Plan, VIVID E9 and EchoPAC PC in Same Room

A dedicated Ethernet network wall outlet

3 Dedicated Power outlets

EchoPAC PC parts

243,84 cm

UPS

A dedicated Analog Telephone jack

Hot & Cold water

1.5m

A dedicated Ethernet
network wall outlet

A dedicated Power
outlet

105cm

609.6 cm

Figure 2-2 Suggested Room with EchoPAC PC and Ultrasound Scanner

Chapter 2 - Site preparations 2 - 11

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

2-3-6 Networking setup requirements

2-3-6-1 Stand alone scanner (without network connection)

None.

2-3-6-2 Scanner connected to hospital’s network

Supported networks:

10/100/1000 Mbit Ethernet/DICOM network (option)

2-3-6-3 InSite Requirements

InSite requires an Ethernet connection either via:

• 10/100 Mbit or 10/100/1000 Mbit Interface

2-3-6-4 Purpose of the DICOM network function

DICOM services provide the operator with clinically useful features for moving images and patient
information over a hospital network. Examples of DICOM services include the transfer of images to
workstations for viewing or transferring images to remote printers. As an added benefit, transferring
images in this manner frees up the on-board monitor and peripherals, enabling viewing to be done while
scanning continues. With DICOM, images can be archived, stored, and retrieved faster, easier, and at
a lower cost.

ERVICE MANUAL

2-3-6-5 DICOM option setup requirements

To configure the VIVID E9 to work with other network connections, the site’s network administrator must
provide information to complete the form in Figure 2-3 "Worksheet for DICOM Network Information" on

page 2-13. Ensure that there are no spaces in any field of the form.

Entries must include:

• A host name, local port number, AE Title, IP address and Net Mask for the VIVID E9.

• The IP addresses for the default gateway and other routers at the site for ROUTING
INFORMATION.

• The host name, IP address, port and AE Title for each device the site wants connected to the
VIVID E9

for DICOM APPLICATION INFORMATION. A field for the make (manufacturer) and the

revision of the device, is also included. This information may be useful for error solving.

2 - 12 Section 2-3 - Facility needs

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

2-3-6-5 DICOM option setup requirements (cont’d)

Figure 2-3 Worksheet for DICOM Network Information

VIVID E9

ERVICE MANUAL

Host Name

AE Title

ROUTING INFORMATION

ROUTER1
ROUTER2
ROUTER3

DICOM APPLICATION INFORMATION

NAME

Store 1

Store 2

Store 3

Local Port

Destination
IP Addresses

...

...

...

MAKE/REVISION IP ADDRESSES PORTAE TITLE

IP Address

Net Mask

Default

...

...

GATEWAY IP Addresses

...

...

...

...

...

...

...

Store 4

Store 5

Store 6

Worklist

Storage
Commit

MPPS

...

...

...

...

...

...

Chapter 2 - Site preparations 2 - 13

GE H
D

IRECTION

EALTHCARE

GA091568, R

EVISION

5 VIVID E9 S

This page left blank to facilitate double-sided printing.

ERVICE MANUAL

2 - 14 Section 2-3 - Facility needs

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

Chapter 3
System setup

Section 3-1
Overview

3-1-1 Purpose of this chapter

This chapter contains information needed to install VIVID E9. Included is a procedure that describes
how to receive and unpack the equipment and how to file a damage or loss claim.

How to prepare the facility and unit of the actual installation, and how to check and test the unit, probes,
and external peripherals for electrical safety are included in this procedure.

3-1-2 Contents in this chapter

3-1 Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

3-2 Setup reminders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2

3-3 Receiving and unpacking the equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3

3-4 Packing materials for the Wooden Box - recycling information . . . . . . . . . . . . . . . . . . . 3-16

3-5 Packing materials for the Carton Box - recycling information. . . . . . . . . . . . . . . . . . . . . 3-17

3-6 Preparing for setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-19

3-7 Completing the setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-20

3-8 Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-27

3-9 Connectivity overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-40

3-10 Connectivity setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-41

3-11 Options Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-49

3-12 Setup paperwork. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-50

ERVICE MANUAL

Chapter 3 - System setup 3 - 1

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

Section 3-2
Setup reminders

3-2-1 Average setup time

Table 3-1 Average installation time

DESCRIPTION

UNPACKING THE SCANNER 0.5 HOUR

INSTALL SCANNER WO/OPTIONS 4 HOURS DEPENDENT ON THE CONFIGURATION

DICOM NETWORK CONFIGURATION 2 HOURS OR MORE DEPENDENT ON THE CONFIGURATION

INSTALL INSITE / ILINK 0.5 HOUR

3-2-2 Setup warnings

AVERAGE

INSTALLATION

TIME

COMMENTS

ERVICE MANUAL

DANGER

WHEN USING ANY TEST INSTRUMENT THAT IS CAPABLE OF OPENING THE
AC GROUND LINE (I.E., METER’S GROUND SWITCH IS OPEN), DON’T TOUCH
THE UNIT!

CAUTION

o

-40-35-30-25-20-15-10-5 0 5 10152025303540455055606570

C

o

-40 -31 -22 -13 -4 5 14 23 32 41 50 59 68 77 86 95 104 113 122 131 140 149 158

F

Hrs 2018161412108642000000024681012

CAUTION

CAUTION

IF THE UNIT IS VERY COLD OR HOT, DO NOT TURN ON ITS POWER UNTIL IT HAS HAD A
CHANCE TO ACCLIMATE TO ITS OPERATING ENVIRONMENT.

Table 3-2 VIVID E9 Acclimate Time

TO PREVENT ELECTRICAL SHOCK, CONNECT THE UNIT TO A PROPERLY GROUNDED
POWER OUTLET. DO NOT USE A THREE TO TWO PRONG ADAPTER. THIS DEFEATS SAFETY
GROUNDING.

DO NOT WEAR THE ESD WRIST STRAP WHEN YOU WORK ON LIVE CIRCUITS AND MORE
THAN 30 V PEAK IS PRESENT.

CAUTION

DO NOT OPERATE THIS UNIT UNLESS ALL BOARD COVERS AND FRAME PANELS ARE
SECURELY IN PLACE. SYSTEM PERFORMANCE AND COOLING REQUIRE THIS.

3 - 2 Section 3-2 - Setup reminders

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

3-2-2 Setup warnings (cont’d)

ERVICE MANUAL

CAUTION

CAUTION

OPERATOR MANUAL(S)
THE USER MANUAL(S) SHOULD BE FULLY READ AND UNDERSTOOD BEFORE OPERATING

THE VIVID E9 AND KEPT NEAR THE UNIT FOR QUICK REFERENCE.

ACOUSTIC OUTPUT HAZARD
ALTHOUGH THE ULTRASOUND ENERGY TRANSMITTED FROM THE VIVID E9 PROBE IS

WITHIN AIUM/NEMA STANDARDS, AVOID UNNECESSARY EXPOSURE. ULTRASOUND
ENERGY CAN PRODUCE HEAT AND MECHANICAL DAMAGE.

Section 3-3
Receiving and unpacking the equipment

3-3-1 Purpose of this section

This section describes how to receive and unpack VIVID E9.

Two types of packages have been used; a Wooden Box and a Carton Box on a Wooden Pallet. Some
of the Receiving and Unpacking instructions are specific for only one of the boxes. This will be stated
where applicable.

3-3-2 Receiving and unpacking warnings

CAUTION

CAUTION

TWO PEOPLE ARE NEEDED TO UNPACK THE UNIT BECAUSE OF ITS WEIGHT.
ATTEMPTS TO MOVE THE UNIT CONSIDERABLE DISTANCES OR ON AN INCLINE BY ONE
PERSON COULD RESULT IN INJURY OR DAMAGE OR BOTH.

TWO PEOPLE ARE REQUIRED WHENEVER A PART WEIGHING 16 KG (35 LBS) OR MORE MUST
BE LIFTED.

REMEMBER TO USE RELEVANT PERSONAL PROTECTING EQUIPMENT (PPE) DURING
PACKING/UNPACKING. CHECK WITH YOUR LOCAL EHS REPRESENTATIVE.

Chapter 3 - System setup 3 - 3

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

3-3-3 The Tilt & Shock indicators

3-3-3-1 Overview

Improper handling during transportation may harm the equipment inside the package even if the
package itself is undamaged.

To make it easier to detection if the handling during transportation has been improper, a set of Tilt &
Shock indicators have been attached to the transportation box.

3-3-3-2 Position of the Tilt and Shock indicators

The Tilt & Shock indicators have been attached to the right side of the transportation box as illustrated
in the figure below. The wooden box is used in the illustrated below, but the Tilt and Shock indicators
are also used on the carton box.

ERVICE MANUAL

Figure 3-1 Tilt & Shock indicators’s position on right side of transportation box

3 - 4 Section 3-2 - Setup reminders

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

3-3-4 Receiving the VIVID E9

3-3-4-1 Examine all packages

Examine all packages closely at time of delivery, as described in the procedure below.

Table 3-3 Examine all packages

STEP TASK ILLUSTRATIONS

1

2 Is the Shock Indicator red colored inside the middle of the

Is damage apparent?

• If yes; continue with the instructions in subsection

3-3-4-2 - Damage in transportation.

• If no; continue with the next step.

indicator?

• If yes: The Shock Indicator has been activated.
Continue with the instructions in subsection

3-3-4-2 - Damage in transportation, then continue with

the next step.

• If no: continue with the next step.

RED COLOR

ERVICE MANUAL

3 Is the Tilt Indicator red colored inside the middle of the

indicator?

• If yes: The Tilt Indicator has been activated.
Continue with the instructions in subsection

3-3-4-2 - Damage in transportation before you continue

with the next step.

• If no: continue with the next step

4 Wooden box ONLY:

The two upper hinges on the Front Side and the Rear Side of
the wooden transportation box have been sealed with red
plastic seals, marked GE Vingmed Ultrasound and a serial
number. Verify that the four red plastic seals are intact at
arrival.

If seals are broken:

If broken, it indicates that the container may have been
opened after it left the manufacturer.
Continue with the instructions in subsection

3-3-4-2 - Damage in transportation.

Continue with the instructions in 3-3-5 - Unpacking VIVID E9

from the Wooden Box.

5 Carton Box ONLY: Continue with 3-3-6 "Unpacking

VIVID E9 from the Carton Box" on page 3-12.

RED COLOR

Chapter 3 - System setup 3 - 5

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

3-3-4-2 Damage in transportation

Follow this procedure if damage is apparent, or if the Tilt & Drop indicators show failure:

Table 3-4 Damage in transportation

STEP TASK

1

2

Write “Damage In Shipment” on ALL copies of the freight or express bill BEFORE delivery is accepted or “signed
for” by a GE representative or hospital receiving agent.

Report the damage to the carrier.

• Whether noted or concealed, damage MUST be reported to the carrier immediately upon discovery, or in
any event, within 14 days after receipt, and the contents and containers held for inspection by the carrier.

• A transportation company will not pay a claim for damage if an inspection is not requested within this 14
day period.

3-3-4-3 If Shock Indicator has triggered or is missing

Table 3-5 Shock Indicator has triggered or is missing

STEP TASK

ERVICE MANUAL

1

If the Shock Indicator is missing:

Note on the shipping papers at the time of receipt that the Shock Indicator label is
missing.

If the Shock Indicator has triggered:

Note on the shipping papers at the time of receipt that the Shock Indicator label was
activated.

2

Inspect the product for possible concealed damage.

3 - 6 Section 3-2 - Setup reminders

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

3-3-4-4 If Tilt Indicator has triggered or is missing

Table 3-6 Tilt Indicator has triggered or is missing

STEP TASK

ERVICE MANUAL

1

If the Tilt Indicator is missing:

Note on the shipping papers at the time of receipt that the Tilt Indicator label is missing.

If the Tilt Indicator has triggered:

Note on the shipping papers at the time of receipt that the Tilt Indicator label was
activated.

2

Inspect the product for possible concealed damage.

Chapter 3 - System setup 3 - 7

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

3-3-4-5 VIVID E9 Transportation Box Label for the Wooden Box

The VIVID E9 Transportation Box Label is located at the front of the Wooden Transportation Box.

Figure 3-2 VIVID E9 Transportation Box Label used on the Wooden Box

60 °C

106 kPa

70 kPa

95%

-20 °C

30%

RELATIVE HUMIDITY
BETWEEN 30 and 95%

ᖙ㢢䎵༠䇺ᯝԚ

ӗ૱〠˖
ර˖

Vivid E9

ࠪল㕆˖
⭏ӗᰕᵏ˖
ᴰབྷཆරቪረ (Max size):

116x78x133 mm (LxWxH)
128 kg

߰䟽 (Net weight):

200 kg

∋䟽 (Gross weight):
㇡(Box No.):

1/1

GE Vingmed Ultrasound AS

⭏ӗলᇦ˖

Strandpromenade 45

ൠ൰˖

N-3191 Horten

ᥚေ

䖼⯝⮹GaG㍐䞌ὤ㟝㸼㢀䑀㜵ㇵ㫸␜㣙㾌

: Vivid E9䝉⮹

㍌㢹㣄㢌

ㇵ䝬ⵃ㨰㋀: 㫴㢨䜠㏘䀴㛨䂈⫠㙸 ර

㉐㟬㐐Gᵉ⇜ẠG䚍┍⦐GZ[ZG

wvihGᵉ⇜G䇴㠀G^SG_㽩
㥐㦤㠄 : GE Vingmed Ultrasound AS O⊬⪨㠜㢨P
䖼⯝䛼ᴴⶼ䝬aG㍌䛼W`TYW`䝬
㇠㟝⯝㤵GaG㫸␜㡸G㠸䚌㜠G䞌⺴㜄G㸼㢀䑀G㜄∼㫴⪰G㤸㋕SG
ⵌ㇠G㐔䝬⪰G㍌㐔䚌㜠G㜵ㇵ㹠㜵GⵃG㐠㣙ḰG䜼Ḵ㢌G
㜵ㇵ㹠㜵㜄G㇠㟝╌⏈G㸼㢀䑀㜵ㇵ㫸␜㣙㾌
㥐㦤ⶼ䝬GⵃG㥐㦤≸㠈aG㥐㦤㠄㢌G䖐㐐ὤ㣠㇠䚡G㵬㦤
䔠㣙␜㠸:1 Set
㥉󰵾㤸㚉, 㨰䑀㍌, ㋀⽸㤸⥙:

AC: 100 ~ 230 VAC, 50 ~ 60 Hz, 1100 W

⸨䝬䝉㐑ⵃ⸨䝬㥉⓸ : 1Ἵὤὤ, CF䝉ὤὤ
⸬㥐䖼㡴㢌⨀ὤὤ㢸

Vivid E9

HANDLE WITH
CARE

ERVICE MANUAL

KEEP DRY,
PROTECT FROM MOISTURE

KEEP AIR PRESSURE
BETWEEN

GA314326-05

70 kPa and 106 kPa

RECYCLING.
RECYCLABLE WOOD

KEEP TRANSPORTATION
TEMPERATURE BETWEEN

-20°C and +60°C

MANUFACTURER

TOP UPRIGHT
TRANSPORTATION &
STORAGE

FRAGILE,
HANDLE WITH CARE

3 - 8 Section 3-2 - Setup reminders

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

3-3-4-6 VIVID E9 Transportation Box Label on the Carton Box

The VIVID E9 Transportation Box Label is printed on four sides of the Carton Box.

Figure 3-3 VIVID E9 Transportation Box Label printed on the Carton Box

ERVICE MANUAL

ICONS

and

SYMBOLS

DESCRIPTION

KEEP AIR PRESSURE
BETWEEN 70 kPa and
106 kPa

KEEP
TRANSPORTATION
TEMPERATURE
BETWEEN -20°C AND
+60°C

RELATIVE HUMIDITY
BETWEEN 30 AND 95%

ICONS

and

SYMBOLS

DESCRIPTION

DO NOT STACK

TOP UPRIGHT
TRANSPORTA-TION
AND STORAGE

HANDLE WITH CARE

MANUFACTURER

ICONS

and

SYMBOLS

DESCRIPTION

FRAGILE, HANDLE
WITH CARE

KEEP DRY, PROTECT
FROM MOISTURE

RECYCLING.
RECYCLABLE
PACKING PARTS

Chapter 3 - System setup 3 - 9

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

3-3-5 Unpacking VIVID E9 from the Wooden Box

Table 3-7 Unpacking VIVID E9 from the Wooden Box sheet 1 of 2

Step Task

1. Open the four hinges on each door and remove the doors.

One of the doors are used as ramp out off and into the transportation box.
On the first version of the Transportation Box, only the front door is meant to be used as a ramp. It has bevel cut in one end.

ERVICE MANUAL

Front door bevel cut.
This end of the door
should be used as
the lower end of the
ramp.

2.

3.

Place the front door as a ramp against the rear edge of the pallet.

“Labank”

On the second version transportation box, the ramp is placed
directly on the labank ends.

Carefully remove the accessory box, and any other items, including the wooden shelf above the scanners Operator Panel and all
the filling material, from the Transportation Box.

3 - 10 Section 3-2 - Setup reminders

GE H

EALTHCARE

D

IRECTION

Step Task

4.

GA091568, R

EVISION

5 VIVID E9 S

Table 3-7 Unpacking VIVID E9 from the Wooden Box (cont’d) sheet 2 of 2

NOTICE

Moving the unit in and out of the transportation box

The unit has brakes on all wheels, but direction lock only on the
front wheels. The wheels position when moving the system into
its transportation box are therefore vital. If the wheels are
swiveling when the system is inside the transportation box, it
may jam the system inside the box. The system must be moved
backwards

both into and out of the transportation box.

Moving the system into the transportation box

1. Align the front wheel under the front end of the system as
shown in Figure 1.

2. Push the direction lock pedal to lock the front wheels in this
direction. Check that they are locked.

3. Push the Top Console to its lowest and most backward
locked position.

4. Pull the system into the box with the rear end first.

Moving the system out of the transportation box

1. Unlock brakes but keep direction lock activated. The
direction lock keeps the front wheels in position, and secures
the direction stability when the system is rolled out of the
transportation box.

2. Pull

the system out of the box with rear end first.

Direction Lock Brake Brakes

Front Wheels Rear Wheels

Figure 1: Brakes and direction locks

ERVICE MANUAL

Transportation box

CAUTION

Have two people available to unpack the system.
Attempts to move the system considerable
distances or on an incline by one person could

Transport notice GA314329-02

result in injury or damage or both.

Figure 2: Console and Wheels position

• Press once on the Release pedal to release the brakes.

• Press once on the Direction Lock pedal to keep direction lock activated. The direction lock keeps the front wheels from swiveling
and blocking the system inside the narrow transportation box.

5. Carefully move the instrument out of the Transportation Box, down the ramp, with rear end first.

6.

7.

Remove the clear plastic (wrapped around the scanner) from the unit.

Place all the filling material inside the Transportation Box, close it and store it for possible use in the future.

Chapter 3 - System setup 3 - 11

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

3-3-6 Unpacking VIVID E9 from the Carton Box

Table 3-8 Uncrating the VIVID E9 sheet 1 of 4

Step Task Illustration

ERVICE MANUAL

1.

2.

Cut the straps around the crate.

Remove the Top Cover.

3.

Remove the Complete Column Left and
Complete Column Right.

4.

Remove the Box For Accessories.

3 - 12 Section 3-2 - Setup reminders

GE H
D

IRECTION

EALTHCARE

GA091568, R

EVISION

5 VIVID E9 S

Table 3-8 Uncrating the VIVID E9 (cont’d) sheet 2 of 4

Step Task Illustration

ERVICE MANUAL

5.

6.

Remove the two Frames (sides) and the two
Exit Ramp Bases.

Install the two Exit Ramp Base on the
Complete Exit Ramp (the rear plate).

Chapter 3 - System setup 3 - 13

GE H
D

IRECTION

EALTHCARE

GA091568, R

EVISION

5 VIVID E9 S

Table 3-8 Uncrating the VIVID E9 (cont’d) sheet 3 of 4

Step Task Illustration

ERVICE MANUAL

7.

8.

Remove the Inlay UI Top.

Remove the Support For Monitor.

9.

10.

Remove the Complete Front Protection.

Remove the clear plastic bag from the
VIVID E9.

3 - 14 Section 3-2 - Setup reminders

GE H
D

IRECTION

EALTHCARE

GA091568, R

EVISION

5 VIVID E9 S

Table 3-8 Uncrating the VIVID E9 (cont’d) sheet 4 of 4

Step Task Illustration

ERVICE MANUAL

11.

12.

13.

Fold down the assembled Exit Ramp.

Unlock the Front Brakes on the VIVID E9,
but keep direction lock activated. The
direction lock keeps the front wheels in
position, and secures the direction stability
when the system is rolled down the ramp
from the pallet.

Unlock the Rear Brakes.

1 - Direction (Dir) Lock

2 - Release Dir Lock and Front Brakes

14.

15.

3 - Front Brakes

4 - Rear Brakes

Carefully move the VIVID E9 down the ramp,
with rear end first.

Assemble the empty transportation box and
place all of the filling inside the box before
you close it.

Close the box, and store it for possible future
use.

Chapter 3 - System setup 3 - 15

GE H

EALTHCARE

D

IRECTION

GA091568, R

EVISION

5 VIVID E9 S

Section 3-4
Packing materials for the Wooden Box - recycling information

The packing materials for VIVID E9 are recyclable:

• The Transportation Box is made of spruce or similar material.
(“PHYTOSANITARY CERTIFICATE” included in all shipments to The People's Republic of China.)

• Lever lockings (hinges) are made of zinc plated steel.

• The inner reinforcements are made of Ethafoam (Polyethylene foam).

• The plastic foil is made of LDPE (Low Density Polyethylene).

ERVICE MANUAL

3 - 16 Section 3-4 - Packing materials for the Wooden Box - recycling information
