General Electric PYE22KELDS Specsheet

Dimensions (in inches)

H K

I J

Dimensions (in inches)

PYE22KBL/KEL/KMK/KSK

GE Profile™ Series ENERGY STAR® 22.2 Cu. Ft. Counter-Depth French-Door Refrigerator

DIMENSIONS AND INSTALLATION INFORMATION (IN INCHES)

F E

H K

Height to top of door (in.) A

Height to top of hinge (in.) B

Height to top of case (in.) C

Case depth without door (in.) D

Case depth less door handle (in.) E

Case depth with door handle (in.) F

Depth with fresh food door open 90˚ (in.) G

Width (in.) H

Width with door open 90˚ with door handle (in.) I

Width with doors open fully (in.) J

Min distance between side of case and wall, in either direction, to allow doors to open fully (in.) K

Depth with FZ door completely open (w/o handle) (in.) X

Depth with FZ door completely open (w/ handle) (in.) Y

70-1/2

69-7/8

24-3/8

29-3/4

31-1/4

43-3/8

35-3/4

44-5/8

16-1/8

44-3/4

46-1/4

B C

For answers to your Monogram, GE Café™ Series, GE Profile™ Series or GE Appliances product questions, visit our website at geappliances.com or call GE Answer Center® Service, 800.626.2000.

Listed by Underwriters Laboratories

As an ENERGY STAR® partner, GE has determined that this product meets the ENERGY STAR guidelines for energy efficiency.

Speci fication Revised 10/17

PYE22KBL/KEL/KMK/KSK

ADA

COMPLIANT

GE Profile™ Series ENERGY STAR® 22.2 Cu. Ft. Counter-Depth French-Door Refrigerator

FEATURES AND BENEFITS

Counter-depth design – Offers a built-in look by fitting nearly flush with surrounding cabinetry

Hands-free Autofill – Lets you walk away while the dispenser automatically fills any container with filtered water

Full-width, electronic temperature-controlled drawer with colored LED lights – 3 accurate settings deliver the optimal temperature for your favorite foods, while colored lights indicate the chosen setting

Second icemaker option – Always have extra ice on hand with an optional second icemaker in the freezer (IM5D kit sold separately)

TwinChill™ evaporators – Separate climates in the fresh food and freezer sections help keep foods fresh

Showcase LED lighting – Positioned throughout the interior and under fresh food doors to spotlight foods inside the refrigerator and in the freezer

Quick Space shelf – Quickly slides out of the way to make room for tall items

Drop-down tray – Allows for extra door storage when you need it and tucks away when you don’t

Turbo Cool setting – Drops interior temperature to maintain freshness after frequent openings

Model PYE22KBLTS – Black Stainless

Model PYE22KELDS – Black Slate

Model PYE22KMKES – Slate

Model PYE22KSKSS – Stainless steel

As an ENERGY STAR® partner, GE has determined that this product meets the ENERGY STAR guidelines for energy efficiency.

Speci fication Revised 10/17
