General Electric PSB2200NBB User Manual

Advantium

®
Oven
MFL39991101 49-40577-1 01-08 JR
PSB2200 PSB2201
Owner’s Manual
ge.com
Advantium
Oven features . . . . . . . . . . . . . . . . . . . . .9
Getting to know the Advantium . . . . . .8

Speedcooking

Favorite recipes . . . . . . . . . . . . . . .16, 17
Power level . . . . . . . . . . . . . . . . . . . . . .13
Speedcook cookware . . . . . . . . . . . . .12
Speedcook-safe cookware . . . . . . . . .5
Things that are normal . . . . . . . . . . .11
Using the pre-set

Other Cooking Functions

Broiling and toasting . . . . . . . . . . . . .19
Convection baking . . . . . . . . . . . . . . .18
Warming and proofing . . . . . . . . . . .20

Microwaving

Defrost by food type . . . . . . . . . . . . .24
Favorite Recipes . . . . . . . . . . . . . . . . . .23
Microwave power level(s) . . . . . . . . .22
Microwave-safe cookware . . . . . . . . .6
Precautions to avoid possible exposure to excessive
microwave energy . . . . . . . . . . . . . . . . .2
Sensor cooking . . . . . . . . . . . . . . .25, 26
Things that are normal . . . . . . . . . . .21
Using pre-set
microwave selections . . . . . . . . . . . . .22

Other Features

Auto recipe convert . . . . . . . . . . . . . . .27
Beeper volume . . . . . . . . . . . . . . . . . . .27
Control lockout . . . . . . . . . . . . . . . . . . .28
Cook time completed . . . . . . . . . . . . .26
Delay Start . . . . . . . . . . . . . . . . . . . . . .27
Display ON/OFF . . . . . . . . . . . . . . . . . .27
Scroll speed . . . . . . . . . . . . . . . . . . . . . .27

Care and Cleaning

Cooking trays and baking sheet . . .30
Removable turntable . . . . . . . . . . . . .29

Troubleshooting

Problem Solver . . . . . . . . . . . . . . .33, 34

Consumer Support

Consumer Support . . . . . . .Back Cover
Warranty . . . . . . . . . . . . . . . . . . . . . . . .35
GE Profile
Write the model and serial numbers here:
Model # __________________________
Serial # __________________________
Find these numbers on a label inside the oven.
2
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY
(a) Do Not Attempt to operate this oven with
the door open since open-door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks.
(b) Do Not Place any object between the oven
front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces.
(c) Do Not Operate the oven if it is damaged.
It is particularly important that the oven door close properly and that there is no damage to the:
(1) door (bent),
(2) hinges and latches (broken or loosened),
(3) door seals and sealing surfaces.
(d) The Oven Should Not be adjusted or
repaired by anyone except properly qualified service personnel.
Advantium Oven
IMPORTANT SAFETY INSTRUCTIONS
NOTICE
Most pacemakers are shielded from interference from electronic products, including microwaves. However, patients with pacemakers may wish to consult their physicians if they have concerns.
PACEMAKERS
■ Read all instructions before using this appliance. When using electrical appliances, basic safety precautions should be followed, including the following:
■ Read and follow the specific precautions in the PRECAUTIONS TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE MICROWAVE ENERGY section on page 2.
■ Be sure your appliance is properly installed and grounded by a qualified technician in accordance with the provided installation instructions.
■ Install or locate this appliance only in accordance with the provided installation instructions.
■ Some products such as whole eggs and sealed containers—for example, closed jars—are able to explode and should not be heated in this oven. Such use of the oven could result in injury.
■ Do not mount this appliance over a sink.
■ This oven is not approved or tested for marine use.
■ This oven is UL listed for standard wall installation above 36 inches.
■ Do not operate this appliance if it has been damaged or dropped.
■ As with any appliance, close supervision is necessary when used by children.
■ Use this appliance only for its intended use as described in this manual.
■ Do not use corrosive chemicals or vapors in this appliance.
■ This oven is specifically designed to heat, dry or cook food, and is not intended for laboratory or industrial use.
■ This appliance must only be serviced by qualified service personnel. Contact nearest authorized service facility for examination, repair or adjustment.
■ Do not cover or block any openings on the appliance.
■ Do not store this appliance outdoors. Do not use this product near water— for example, in a wet basement, near a swimming pool, near a sink or in similar locations.
■ See door surface cleaning instructions in the Care and Cleaning of the Oven section of this manual.
■ To reduce the risk of fire in the oven cavity:
— Do not overcook food. Carefully attend
appliance when paper, plastic or other combustible materials are placed inside the oven while cooking.
— Remove wire twist-ties and metal handles
from paper or plastic containers before placing them in the oven.
— Do not use the oven for storage purposes. Do
not leave paper products, cooking utensils or food in the oven when not in use.
— Do not use the Sensor Features twice in
succession on the same food portion. If food is undercooked after the first countdown, use COOK BY TIME for additional cooking time.
— Do not use the oven to dry newspapers.
■ If materials inside the oven ignite, keep the oven door closed, turn the oven off and shut off power at the fuse or circuit breaker panel. If the door is opened, the fire may spread.
■ The wire oven rack should not be used for speedcook or microwave cooking to prevent arcing.
3
WARNING!
SAFETY PRECAUTIONS
To reduce the risk of burns, electric shock, fire, injury to persons, or exposure to excessive microwave energy:
Advantium Oven
IMPORTANT SAFETY INSTRUCTIONS
4
WARNING!
■ Do not operate the oven without the turntable in place. The turntable must be unrestricted so it can turn.
■ During and after use, do not touch, or let clothing or other flammable materials contact any interior area of the oven; allow sufficient time for cooling first.
■ Potentially hot surfaces include the oven door, floor, walls, oven rack and turntable.
■ Keep the oven free from grease buildup.
■ Cook meat and poultry thoroughly—
meat to at least an INTERNAL temperature of 160°F, and poultry to at least an INTERNAL temperature of 180°F. Cooking to these temperatures usually protects against foodborne illness.
SAFETY PRECAUTIONS
Arcing is the microwave term for sparks in the oven. Arcing is caused by:
■ Metal or foil touching the side of the oven.
■ Foil not molded to food (upturned edges act like antennas).
■ Use foil only as recommended in this manual.
■ Metal cookware or the wire oven rack used during either speedcook or microwave cooking (except for the pans provided with the oven).
■ Metal, such as twist-ties, poultry pins, or gold-rimmed dishes, in the oven.
■ Recycled paper towels containing small metal pieces being used in the oven.
ARCING
Arcing can occur during both speedcooking and microwave cooking. If you see arcing, press the CLEAR/OFF pad and correct the problem.
Advantium Oven
IMPORTANT SAFETY INSTRUCTIONS
■ When microwaving, place all foods and containers on the clear glass tray.
■ Do not pop popcorn in your oven unless in a special microwave popcorn accessory or unless you use popcorn labeled for use in microwave ovens.
■ Do not boil eggs in this oven. Pressure will build up inside egg yolk and will cause it to burst, possibly resulting in injury.
■ Do not operate oven without food inside. This may cause damage to the oven. It increases the heat around the magnetron and can shorten the life of the oven.
■ Foods with unbroken outer “skin” such as potatoes, hot dogs, sausages, tomatoes, apples, chicken livers and other giblets, and egg yolks should be pierced to allow steam to escape during cooking.
■ SUPERHEATED WATER
Liquids, such as water, coffee or tea, are able to be overheated beyond the boiling point without appearing to be boiling. Visible bubbling or boiling when the container is removed from the microwave oven is not always present. THIS COULD RESULT IN VERY HOT LIQUIDS SUDDENLY BOILING OVER WHEN THE CONTAINER IS DISTURBED OR A SPOON OR OTHER UTENSIL IS INSERTED INTO THE LIQUID.
To reduce the risk of injury to persons: — Do not overheat the liquid. — Stir the liquid both before and halfway
through heating it. — Do not use straight-sided containers with
narrow necks. — After heating, allow the container to stand
in the microwave oven for a short time
before removing the container. — Use extreme care when inserting a spoon
or other utensil into the container.
FOODS
5
WARNING!
■ The oven and door will get very hot when speedcooking.
■ Cookware will become hot. Oven mitts will be needed to handle the cookware.
■ Do not use coverings, containers or cooking/roasting bags made of foil, plastic, wax or paper when speedcooking.
■ Do not cover the turntable, metal trays or any part of the oven with metal foil. This will cause arcing in the oven.
■ Use the metal tray in the same way you would use a shallow baking pan or baking tray.
■ Do not use the wire oven rack for speedcook.
■ Place food directly on the metal trays when cooking unless prompted by the oven to do otherwise.
■ Any non-metal oven-safe dish can be used in your oven. Recipes in the Advantium Cookbook were tested in Pyrex
®
glass cookware and Corningware
®
ceramic casseroles. Cook times and results may vary when using other types of oven-safe dishes. Place them directly on the trays.
■ Use of the clear glass tray when speedcooking will result in inferior cooking performance and possible cracking of the glass tray.
■ Use only the metal trays specified for use with this oven. Other metal trays are not designed for use with this oven and will result in inferior cooking performance.
Oven-safe cookware for Speedcooking
The turntable must
always be in place
when using the oven.
Put food directly on
the metal grill tray to
speedcook.
Advantium Oven
IMPORTANT SAFETY INSTRUCTIONS
■ The oven and door will get very hot when convection baking, broiling, warming or toasting.
■ Cookware will become hot. Oven mitts will be needed to handle the cookware.
■ Do not cover dishes or use plastic containers, plastic cooking/roasting bags, plastic wrap, wax paper or paper when broiling or toasting.
■ Do not cover the turntable, wire oven rack, trays or any part of the oven with metal foil. This will cause arcing in the oven if microwave or speedcook modes are used.
■ Use the metal tray in the same way you would use a shallow baking pan or baking tray.
■ Use the wire oven rack when convection baking or warming on two levels.
■ Place food directly on the metal trays when cooking unless the recipe requires a dish.
■ Any oven-safe dish can be used in your oven. Recipes in the Advantium Cookbook were tested in Pyrex
®
glass
cookware and Corningware
®
ceramic casseroles. Cook times and results may vary when using other types of oven-safe dishes. Place them directly on the trays.
■ Use of the clear glass tray when convection baking, broiling, warming or toasting will result in inferior cooking performance.
Oven-safe cookware for Convection Baking, Broiling, Warming, Proofing & Toasting
The turntable must
always be in place when
using the oven.
Put food or oven-safe
cookware directly on the
metal tray to convection
bake, warm or toast.
Put food directly on the metal tray or in the
appropriate dish and place on wire oven
rack when baking or warming on two levels.
Put food directly on the
metal grill tray as
required to broil.
Put food directly on the
metal tray to convection
bake, warm or toast.
6
WARNING!
■ Do not use the wire oven rack for microwave.
■ Place food or microwavable container directly on the clear glass tray to cook your food.
■ Use of a metal tray during microwave cooking will result in inferior cooking performance.
■ If you are not sure if a dish is microwave­safe, use this test: Place both the dish you are testing and a glass measuring cup filled with 1 cup of water in the oven. Set the measuring cup either in or next to the dish. Microwave 30-45 seconds at high. If the dish heats, it should not be used for microwaving.
If the dish remains cool and only the water in the cup heats, then the dish is microwave-safe.
■ Cookware may become hot because of heat transferred from the heated food. Oven mitts may be needed to handle the cookware.
■ Use foil only as directed in this manual. When using foil in the oven, keep the foil at least 1″ away from the sides of the oven.
■ If you use a meat thermometer while cooking, make sure it is safe for use in microwave ovens.
■ Some foam trays (like those that meat is packaged on) have a thin strip of metal embedded in the bottom. When microwaved, the metal can burn the floor of the oven or ignite a paper towel.
■ Do not use recycled paper products. Recycled paper towels, napkins and waxed paper can contain metal flecks which may cause arcing or ignite. Paper products containing nylon or nylon filaments should be avoided, as they may also ignite.
■ Paper towels, waxed paper and plastic wrap can be used to cover dishes in order to retain moisture and prevent spattering. Be sure to vent plastic wrap so steam can escape.
■ Not all plastic wrap is suitable for use in microwave ovens. Check the package for proper use.
■ “Boilable” cooking pouches and tightly closed plastic bags should be slit, pierced or vented as directed by package instructions. If they are not, plastic could burst during or immediately after cooking, possibly resulting in injury. Also, plastic storage containers should be at least partially uncovered because they form a tight seal. When cooking with containers tightly covered with plastic wrap, remove covering carefully and direct steam away from hands and face.
■ Plastic cookware—Plastic cookware designed for microwave cooking is very useful, but should be used carefully. Even microwave-safe plastic may not be as tolerant of overcooking conditions as are glass or ceramic materials. Plastic may soften or char if subjected to short periods of overcooking. In longer exposures to overcooking, the food and cookware could ignite.
Follow these guidelines:
1. Use microwave-safe plastics only, and use them in strict compliance with the cookware manufacturer’s recommendations.
2. Do not microwave empty containers.
3. Do not permit children to use plastic cookware without adult supervision.
Microwave
-safe cookware
The turntable must
always be in place when
using the oven.
The clear glass tray
should always be in place
when microwaving.
Make sure to use suitable cookware during microwave cooking. Most glass casseroles, cooking dishes, measuring cups, custard cups, pottery or china dinnerware which does not have metallic trim or glaze with a metallic sheen can be used. Some cookware is labeled “suitable for microwaving.”
Advantium Oven
IMPORTANT SAFETY INSTRUCTIONS
How to test for a
microwave-safe dish.
7
WARNING!
■ Don’t defrost frozen beverages in narrow-necked bottles (especially carbonated beverages). Even if the container is open, pressure can build up. This can cause the container to burst, possibly resulting in injury.
■ Foods cooked in liquids (such as pasta) may tend to boil more rapidly than foods containing less moisture. Should this occur, refer to the Care and Cleaning of the oven section for instructions on how to clean the inside of the oven.
■ Hot foods and steam can cause burns. Be careful when opening any containers of hot food, including popcorn bags, cooking pouches and boxes. To prevent possible injury, direct steam away from hands and face.
■ Do not overcook potatoes. They could dehydrate and catch fire, causing damage to your oven.
■ Avoid heating baby food in glass jars, even with the lid off. Make sure all infant food is thoroughly cooked. Stir food to distribute the heat evenly. Be careful to prevent scalding when warming formula. The container may feel cooler than the formula really is. Always test the formula before feeding the baby.
■ Do not attempt to deep fry in the oven.
■ Do not use the oven to dry newspapers.
SAFETY PRECAUTIONS
SAVE THESE INSTRUCTIONS
Advantium Oven
IMPORTANT SAFETY INSTRUCTIONS

Getting to Know the Advantium

Advantium Oven
The Advantium oven uses breakthrough Speedcook technology to harness the power of light. The Advantium oven cooks the outside of foods much like conventional radiant heat, while also penetrating the surface so the inside cooks simultaneously.
While halogen light is the primary source of power, a convection system and ceramic heater assist in the cooking, with a “microwave boost” added in some cooking algorithms. Food cooks evenly and fast, retaining its natural moisture.
Getting to know the Advantium
8
The Advantium oven is capable of speedcooking, convection baking, broiling, toasting, warming, proofing and microwaving. The Speedcook feature is the biggest benefit of the Advantium oven.
No preheating is required to speedcook. Place the food in the oven and start cooking immediately. You see timesaving because there is no preheat and because speedcook cooks faster.

Oven Features

Advantium Oven
Oven features
Throughout this manual, features and appearance may vary from your model.
Turntable
The turntable must always be in place, on the oven floor, for all cooking. Be sure the turntable is seated securely over the spindle in the center of the oven with the marked side facing up.
Metal Tray or Metal Grill Tray
Put food directly on the metal tray or metal grill tray and place on the turntable when using the speedcook, broil, toast, warm and convection bake features.
Wire Oven Rack
Put food directly on the metal tray or in an oven-safe dish on the wire oven rack only when convection baking on two levels.
Clear Glass Tray
Place on turntable when using microwave features. Place food or microwave-safe cookware directly on tray.
Upper Halogen Lamps
Two 1200W halogen lamps cook food from above in speedcook, broil and toast.
Window
Allows cooking to be viewed while keeping microwaves confined in the oven.
Door Handle
Pull to open the door.
Door Latches
The door must be securely latched for the oven to operate.
Lower Ceramic Heater
One 500W ceramic heater cooks food from the bottom in speedcook, broil and toast.
Control Panel
The pads used to operate the oven are located on the control panel.
Rear Convection System
One 1500W heating element cooks food with a convection fan circulating the hot air throughout the cavity in speedcook, broil, convection bake, toast and warm.
9
10
Controls
Advantium Oven

Cooking controls

With your Advantium oven, you can cook with high-intensity halogen lights, ceramic heaters, convection heating element, and/or conventional microwave energy.
SPEEDCOOK/Repeat Last
Press this pad to access the pre-set speedcook menu. Press and hold for 3 seconds to repeat the last cooking selection.
CONVECTION BAKE/BROIL
Press this pad to convection bake, broil or toast.
CUSTOM SPEEDCOOK
Press this pad to set your own speedcook program.
WARM/PROOF
Select WARM to keep hot, cooked foods at serving temperature.
Select PROOF to create a warm environment useful for raising yeast-leavened products.
COOK (Microwave)
Press this pad to microwave food.
EXPRESS (Microwave)
Press for 30 seconds of microwave cooking time. Each time the pad is pressed an additional 30 seconds is added to the remaining cooking time. The oven starts immediately.
DEFROST (Microwave)/OVEN LIGHT
Press this pad to defrost frozen foods, soften or melt. While cooking, press this pad to light the cavity for 4 seconds.
REHEAT (Microwave)
Press this pad to reheat previously cooked foods, a plate of leftovers or beverages.
FAVORITE RECIPES
Press this pad to add, edit (change) or remove a recipe from the memory.
TIMER
Press this pad to set the minute timer.
Display
Shows and instructs the use of all features on the oven.
SELECTOR DIAL–Turn to select, press to enter First turn, then press the dial
to make option, food, power level or temperature selections. Also use the dial to increase (turn clockwise) or decrease (turn counterclockwise) cooking times.
START/PAUSE
Press this pad to start or pause any cooking function.
CLEAR/OFF
Press this pad to cancel ALL oven programs except the control lock, clock and timer.
BACK
Press this pad to step back one or more levels in the program process.
HELP
Press this pad to find out more about your oven’s features.
POWER/TEMP
During cooking, press this pad and turn/press the selector dial to change the microwave power level, the convection bake temperature or the speedcook power levels.
OPTIONS
Press this pad to set the Clock and access the Beeper Volume, Auto
Recipe Convert, Clock Display ON/OFF, Display Scroll Speed, Delay Start and Reminder features.
11
Speedcooking
Advantium Oven
Using speedcook features
CAUTION: When using speedcook programs, remember that the oven, door and dishes will be very hot!
Prior to the first use of your oven, the clock must be set. See the Clock section. Before you begin, make sure the turntable is in place with the side marked “TOP” facing up.
Use the metal tray or metal grill tray and your own glass or ceramic cookware, if needed.
The turntable must always be in
place when using the oven.
Put food directly on the metal tray or metal grill tray to speedcook.
■ If the door is opened during cooking, the oven will stop and PAUSE will appear in the display. Close the door and press the START/PAUSE pad to resume cooking.
■ At any time during cooking you can turn the selector dial to change the cooking time. You can change power levels by pressing POWER/TEMP.
■ Speedcooking meats in the oven may produce smoke.
■ To cook for additional time after a cooking cycle has been completed, use the Resume feature as instructed on the display.

Things that are normal

Cooking Times
■ When speedcooking preprogrammed foods, you may see OPTIMIZING COOK TIME in the display several seconds after you press START/PAUSE. The oven automatically senses the electrical voltage level in your home and adjusts the cooking time up or down for proper cooking.
Cooling Fans
■ The fans will be on during cooking. At the end of cooking, the fans may continue to run for a short time to cool internal components. The fans will automatically shut off when the internal parts of the oven have cooled.
■ The oven vent will emit warm air while the oven is on.
Lights
■ When the oven is on, light may be visible around the door or outer case.
■ The halogen lights will dim and cycle on and off during a speedcook cycle, sometimes even at full power levels. This is normal. The oven senses the heat level and adjusts automatically.
Oven Heat
■ No preheating time is required during Speedcook cycles. The oven begins cooking immediately.
■ The door and inside of the oven will be very hot. Use caution when opening the door and removing food. Be cautious of steam or vapor that may escape from around the door.
■ Do not use cookware or coverings made of paper, plastic, or foil when speedcooking.
■ When cooking for an extended period of time, the oven may automatically reduce the power levels to maintain the appropriate level of oven heat.
Sounds
■ Clicks and a fan blowing are normal sounds during cooking. The electronic control is turning components on and off.
Interference
■ TV/radio interference might be noticed
while using the microwave, similar to the interference caused by other small appliances. It does not indicate a problem with the microwave. Move the radio or TV as far away from the microwave as possible, or check the position of the TV/radio antenna.
Loading...
+ 25 hidden pages
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
