PP9830sJ
Cut-out Dimensions (in inches)
*UL Requirement.
9
Cabinet Dimensions (in inches)
SS)
SS)
GE Profile
Dimensions anD installation information
™
Series 30" Downdraft Electric Cooktop
KW RATI NG
240V 9.1
208V 6.9
Wall I n stallatI o n: Wa l l
installations require 25" countertop
depth. When cabinet is f lush against
the wall, the fan housing can be rotated
to the horizontal position for direct
rear wall. Make a countertop
cutout in the range cabinet
venting through
according to unit dimensions and installation type.
Duct hole is positioned in back of cabinet for throughthe-wall ducting.
PenInsula or Island InstallatIon: For
peninsula/islands a minimum 26"
countertop
depth is
suggested. Blower should be in vertical position. Island
or peninsula cabinets may require adjustment in cutout
depth and/or location within the width dimensions.
Duct hole is positioned in bottom of cabinet for island
or peninsula installation.
slab InstallatIon: For peninsula or island
installation and rear wall ducting, 6" PVC duct or locally
approved piping should be used if installing under a
poured concrete slab.
rece Ptac le locatIon : Install an approved junction
box within shaded area shown in diagram. Junction box
must be at least 10-1/2" below top of cabinet.
Insta l l atIon I n form at I on: Before installing,
consult installation
for current dimensional data.
instructions, packed with product,
note: Electrical cable is not supplied with unit.
Order part number JXCK89 from your Ge Appliances
Dealer
These cooktops are approved for indoor use only
25
20-5/8
1-7/8"
MIN. Required*
227⁄16ʺ
227⁄16ʺ
9
9
(22
(22
⁄16ʺ SS)
⁄16ʺ SS)
22ʺ
22ʺ
201⁄2ʺ
201⁄2ʺ
28-7/8
16
*Note: A 6" minimum spacing to adjacent side wall is required
Dimension and installation information are shown in inches.
297⁄8ʺ
297⁄8ʺ
(30ʺ SS)
(30ʺ SS)
283⁄4ʺ
283⁄4ʺ
C
L
20
4
(2
(2
10-1/2
23⁄16ʺ
23⁄16ʺ
1
1
⁄4ʺ
⁄4ʺ
For answers to your Monogram® or GE® appliance
questions, visit our website at geappliances.com
or call GE Answer Center® service, 800.626.2000.
Listed by
Underwriters
Laboratories
Specification Created 2/15
PP9830sJ
Venting Options
Through Cabinet Toe Space
Inside Wall to Roof Direct to Outside
Between Floor Joist
GE Profile™ Series 30" Downdraft Electric Cooktop
Dimensions anD installation information
InstallIng the ductWork: Use
galvanized or aluminum duct in 6" round
or 3-1/4" x 10" size, or combination of both.
PVC duct or locally approved piping
should be used if installing under a
poured concrete slab. Local building code
must be followed in specifying type and
schedule of all duct used.
note: Ductwork must be vented to
outside. Do not vent into a wall, ceiling,
crawlspace, attic or any concealed space.
Always use an appropriate roof or wall cap
with damper.
Laundry-type wall caps should never
be used. For maximum efficiency use the
shortest and straightest duct run possible,
with as few fittings as possible.
For satisfactory performance the duct
run should not exceed 100 feet equivalent
length.
Refer to the table of equivalent lengths
(shown in installation instructions) for
various duct configurations.
10-1/8
6-1/8
9-1/8
18-3/4
For answers to your Monogram® or GE® appliance
questions, visit our website at geappliances.com
or call GE Answer Center® service, 800.626.2000.
rear Wall VentIngdoWnWard VentIng
Dimension and installation information are shown in inches.
Listed by
Underwriters
Laboratories
Specification Created 2/15
