General Electric MARS PC WORKSTATION V6.0 SERVICE MANUAL_SM_2010165-052_E MARS PC Workstation Service Manual Software Version 6 2010165-052 Revision E

MARS® PC Workstation

Service Manual

Software Version 6

2010165-052 Revision E

127(In addition to software version 6, the information in this manual also applies to MARS PC software version 5.1. Due to continuing product i nnovation, s pecificat ions in t his manual a re subje ct to cha nge without notice.

Listed below are GE Med ica l Sy stem s Information Technologies trademarks. All other trademarks contained herein are the property of their respective owners.

900 SC, ACCUSKETCH, AccuVision, APEX, AQUA-KNOT, ARCHIVIST, Autoseq, BABY MAC, C Qwik Connect, CardioServ, CardioSmart, CardioSys, CardioWindow, CASE, CD TELEMETRY, CENTRA, CHART GUARD, CINE 35, CORO, COROLAN, COROMETRICS, Corometrics Sensor Tip, CRG PLUS, DASH, Digistore, Digital DATAQ, E for M, EAGLE, Event-Link, FMS 101B, FMS 111, HELLIGE, IMAGE STORE, INTELLIMOTION, IQA, LASER SXP, MAC, MAC-LAB, MACTRODE, MANAGED USE, MARQUETTE, MARQUETTE MAC, MARQUETTE MEDICAL SYSTEMS, MARQUETTE UNITY NETWORK, MARS, MAX, MEDITEL, MEI, MEI in the circle logo, MEMOPORT, MEMOPORT C, MINISTORE, MINNOWS, Monarch 8000, MULTI-LINK, MULTISCRIPTOR, MUSE, MUSE CV, Neo-Trak, NEUROSCRIPT, OnlineABG, OXYMONITOR, Pres-R-Cuff, PRESSURE-SCRIBE, QMI, QS, Quantitative Medicine, Quantitative Sentinel, RAC RAMS, RSVP, SAM, SEER, SILVERTRACE, SOLAR, SOLARVIEW, Spectra 400, Spectra-Overview, Spectra-Tel, ST GUARD, TRAM, TRAM-NET, TRAM-RAC, TRAMSCOPE, TRIM KNOB, Trimline, UNION STATION, UNITY logo, UNITY NETWORK, Vari-X, Vari-X Cardiomatic, VariCath, VARIDEX, VAS, and Vision Care Filter are trademarks of GE Medical Systems Information Technologies registered in the United States Patent and Trademark Office.

12SL, 15SL, Access, AccuSpeak, ADVANTAGE, BAM, BODYTRODE, Cardiomatic, CardioSpeak, CD TELEMETRY Cumulus, Event-Link Nimbus, HI-RES, ICMMS, IMAGE VAULT, IMPACT.wf, INTER-LEAD, IQA, LIFEWATCH, Managed Use, MARQUETTE PRISM, MARQUETTE MicroSmart, MMS, MRT, MUSE CardioWindow, NST PRO, NAUTILUS, O

-LAN, CENTRALSCOPE, Corolation, EDIC, EK-Pro, Event-Link Cirrus, Event-Link

RESPONDER, MENTOR,

SENSOR, Octanet, OMRS, PHi-

Res, Premium, Prism, QUIK CONNECT V, QUICK CONNECT, QT Guard, SMART-PAC, SMARTLOOK, Spiral Lok, S wee the art, UNITY, Univers al , Wa te rf all , and Walk mom are tra demar ks of GE Medi cal S ystem s Information Technologies.

T-2 MARS PC Revision E

2010165-052 1 December 2004

Contents

1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

Manual Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

Revision History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3

Manual Purpose . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3

Chapter Content . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-4

Related Manuals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6

Downloading OEM Manuals From the Internet . . . . . . . . . . . . . . . . . . . . . . . . . . .1-7

Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-12

Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-13

Responsibility of the Manufacturer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-13

General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-13

Information Technology Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-14

Equipment Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-14

Warnings and Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-15

Service Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-16

Service Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-16

Product Code Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-16

Equipment Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-17

2 Equipment Overview and System Setup . . . . . . . . . . . . 2-1

System Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3

General Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-3

Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-3

Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-4

Remote System Support (RSS) Access Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-5

Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6

Network Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-6

Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-7

System Setup and Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8

Connecting the Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-8

MARS PC Interconnection Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-8

System Components and Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12

MARS PC Standalone, Client and Server System Boxes . . . . . . . . . . . . . . . . . .2-12

Tape Acquisition Unit (Optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-20

Remote System Access Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-21

Revision E MARS PC i

2010165-052

Uninterruptible Power Supply (UPS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-22

Monitors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-25

Printers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-25

3 Network Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

Network Setup for Windows 2000 Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3

Default Factory Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-3

Domain Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-3

Software Upgrade and Network Setup for Windows NT Systems . . . . . . . . . . . . 3-5

Standalone and Client Configurations Running Windows NT . . . . . . . . . . . . . . . .3-5

Ethernet Capabilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-5

Determine if Adding Network Drivers is Necessary . . . . . . . . . . . . . . . . . . . . . . . .3-5

Perform Software Upgrade to v6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-6

Begin Upgrade Here . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-7

MARS PC Typical Upgrade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-8

MARS PC Custom Software Upgrade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9

Verify Software Version . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-13

Setting Up the Network for Systems Running Windows NT . . . . . . . . . . . . . . . .3-13

Checkout Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-15

Shutdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-15

Power On . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-15

Acquiring Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-16

Printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-16

Archiving Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-16

Tape Acquisition Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-16

Remote System Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-17

Uninterruptible Power Supply (UPS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-17

Network Checkout Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-20

Operating System Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-20

4 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3

Maintenance Guides . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-3

Recommended Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-3

Required Tools and Supplies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-4

Power On Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-5

Safe Shutdown Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-6

Inspection and Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7

Visual Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-7

Check Cooling Fans . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-7

ii MARS PC Revision E

2010165-052

Cleaning Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-7

Ventilation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-7

Exterior Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-8

Cleaning the System Box Interior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-8

5 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1

Theory of Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3

Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-3

System Box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-3

General Fault Isolation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4

Assistance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-4

First Things to Ask . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-4

Visual Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-4

Workstation Box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-5

Replacing SCSI, Serial or Parallel (LPT) Boards . . . . . . . . . . . . . . . . . . . . . . . . . .5-6

Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-7

Keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-7

Mouse . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-7

Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-7

Uninterruptible Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-7

RSS Analog Modem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-8

Tape Acquisition Unit (Optional Device) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-9

Card Reader (Omni Drive) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-9

DVD-RW, CD-RW, or Floppy Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-10

6 System Rebuild and Software Reinstall . . . . . . . . . . . . . 6-1

Disk Imaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3

Reimage System for MARS PC Standalone and Client Workstations . . . . . . . . . 6-4

Before you Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-4

Begin Rebuild for MARS PC Standalone or Client . . . . . . . . . . . . . . . . . . . . . . . .6-5

Install MARS PC Standalone Application Software . . . . . . . . . . . . . . . . . . . . . . .6-11

Reinstall Activator Codes for Standalone Systems . . . . . . . . . . . . . . . . . . . . . . .6-12

Install MARS PC Client Application Software . . . . . . . . . . . . . . . . . . . . . . . . . . .6 -12

Reimage System for MARS PC Server Workstations . . . . . . . . . . . . . . . . . . . . . . 6-15

Change the Boot Order . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-15

Insert Server Rebuild CD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-16

Install MARS PC Server Application Software . . . . . . . . . . . . . . . . . . . . . . . . . . .6-21

Reinstall Activator Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-21

Setting the Operating System Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-22

Revision E MARS PC iii

2010165-052

7 Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-3

Ordering Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-3

Appendix A: Tech ni cal Descriptions . . . . . . . . . . . . . . . . .A - 1

21-inch Sony Color Monitor CPD G520P . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-5

NEC MultiSync LCD 1850X . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-5

NEC MultiSync LCD 1980SX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-6

Compaq 17-inch Color Monitor (V720) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-6

Card Reader Unit (internal) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-7

Card Reader Unit (external) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-7

Hewlett Packard 1200 LaserJet Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-9

Hewlett Packard 4200N LaserJet Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-9

Hewlett Packard 4250N LaserJet Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-10

Powerware PW5115 500 UPS, 120 volt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-10

Powerware PW5115 500i UPS, 230 volt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-11

Environmental — System-wide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-11

Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-12

Appendix B – Configuring Patient Slots . . . . . . . . . . . . . .B-1

Slot Installation/Time Consumption Report . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-3

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Index-1

iv MARS PC Revision E

2010165-052

1 Introduction

Revision E MARS PC 1-1

2010165-052

For your notes

1-2 MARS PC Revision E

2010165-052

Introduction: Manual Information

Manual Informatio n

Revision History

Each page of the document has the document part number followed by a revision letter at the bottom of the page. The revision letter identifies the document’s update level.

Table 1. Revision History 2010165-052

Revision Date Comment

A 14 May 2003 Initial release B 23 July 2003 Added uninstall modem instructions in chapter 6 for MARS PC client systems, added anti-virus

software recommendation and limiting drive share access notes in chapter 2 and 3. C 16 November 2003 Added HP EVO D530 system box information. D 29 March 2004 Changed v 6.0 to v. 6 throughout the manual to cover point releases. E 1 December 2004 Added HP dc7100 system box information.

Manual Purpose

This manual supplies techn ical information for the service representative and technical personnel so they can install and maintain the equipment. Use it as a guide for maintenance and electrical repairs considered field repaira ble. Where necessary the manual ident ifies additional sources of relevant information and or technical assistance.

See the operator manual for the instructions necessary to operate the equipment safely in accordance with its function and intended use.

Definitions



Items shown in Black text are keys on the keyboard, text to be entered, or hardware items such as buttons or switches on the equipment.



Items shown in Italicized text are software terms which identify menu items, buttons, or options in various windows.



To perform an operation which appears with a plus (+)sign between the names of two keys, you press and hold the first key while pressing the second key once. This is called a keystroke combination. For example, “Press Ctrl+Esc” means to press and hold down the Ctrl key while pressing the Esc key.



When instructions are given for typing a precise text string with one or more spaces, the point where the spacebar must be pressed is indicated as: <Space>. Th e purpose of the < > brackets is to ensure you press the spacebar when required.



Enter means to press the “Enter” or “Return” key on the keyboard. Do not type “enter”.

Revision E MARS PC 1-3

2010165-052

Chapter Content

1 Introduction

Introduction: Manual Information

This manual is organized into chapters and app endices:

127(

This manual primarily co vers the MARS PC Workstations running the Windows 2000 operating system. These systems run on a Compaq Evo D510, a Hewlett Packard (HP) D530 CM T, or an HP dc7100 system box.

The MARS PC Workstations running the Windows NT operating system are only discussed in two chapters, the “Network

Installation” on page 3-1, and the “System Rebuild and Software Reinstall” on page 6-1. For any additional information on the MARS

PC systems running Windows NT, please see the original Service Manual that shipped with that particular unit.

Describes the service manual and chapter contents. Provides general information on safety, service requirements, equipment symbols, and serial number identification.

2 Equipment Overview

3 Network Installation

4 Maintenance

5 Troubleshooting

Describes the equipment and its technical characteristics, preparation for use, and connector locations. An interconnect table is provided for setting up and connecting the system.

Describes the network installation for the Windows NT and Windows 2000 systems, and the process of adding new users to the workgroup. The software upgrade procedu re for MARS PC s ystems runni ng Window s NT is also explained.

In addition, this section explains how to change from a workgroup to a domain.

Contains a preventive maintenance sc hedule, cleaning guidelines and checkout procedures.

Provides overall and specific troubleshooting help.

1-4 MARS PC Revision E

2010165-052

Introduction: Manual Information

5 System Rebuild and Software Reinstall

Provides instructions on rebuilding the MARS PC Workstation with an image disk. Also provides information on the reinstallation of MARS PC application software.

6 Parts Lists

Provides a list of GE Medical Systems Information Technologies and original equipment manufacturer (OEM) part numbers for field replaceable units (FRUs).

Appendix

The appendix includes technical specifications and slot configuration information.

Revision E MARS PC 1-5

2010165-052

Introduction: Related Manuals

Related Manuals

See the documents listed below if you need additional information.

Table 2. MARS PC Workstation Documents

Part Number Name

2010165-053 MARS PC Pre-Installation Guide 2010165-066 MARS PC Upgrade Instructions 2010165-051 MARS PC Operators Manual 2010165-135 Adding MARS PC to MUSE communication 2010165-188 MARS PC Workstation Security Fix 2006531-006 Installation Guide (for units manufactured in Germany; catalog number 2006542-002) 2006531-007 MARS PC Service Manual (for units manufactured in Germany; catalog number 2006542-002)

1-6 MARS PC Revision E

2010165-052

Introduction: Related Manuals

Downloading OEM Manuals From the Internet

Access the original equipment manufacturer (OEM) manuals by using the URLs provided in the table that follows.

127(

The information in the fol lowing OEM we bsit e tabl e is current at the time of release. Titles, part numbers, and URL addresses are subject to change without notice.

Adobe Acrobat Reader software must be installed on your system to read or print the OEM manuals. If you do not have the software installed on your system, it can be obtained for free from the Adobe website at:

http://www.adobe.com/

Table 3. OEM Websites

Product

APC UPS http://www.apc.com http://sturgeon.apcc.com/

Compaq Deskpro EN

Small Form Factor

(SFF)

Home Page Web

Address

http:// www.compaq.com/

Manual/Data Web Address Manual Title

techref.nsf/ c2b594b2a21353f385256864006bf8 ae/ bf761bc147d2ea948525688f0069aa c3?OpenDocument

http://www5.compaq.com/support/ techpubs/maintenance_guides/ 201579-002.html

ftp://ftp.compaq.com/pub/ supportinformation/techpubs/ user_reference_guides/177620-

003.pdf

Back UPS 200/300/ 500/650 User’s Guide120v Installation and operating instructions for the 120V

Deskpro EN SFF Maintenance & Service Guide

Deskpro EN SFF Troubleshooting Guide

Manual Part number and

revision

990-2004E Rev. 7

Second Edition (September

2000) Part Number 201579-002

Third edition (Oct. 2000) 177620-003

Revision E MARS PC 1-7

2010165-052

Introduction: Related Manuals

Table 3. OEM Websites (Continued)

Product

Compaq Evo Small

Form Factor

Home Page Web

Address

http:// www.compaq.com/

Manual/Data Web Address Manual Title

http://www3.compaq.com/support/ reference_library/

Compaq Service

Reference Guide (Evo)

viewdocument.asp?countrycode=10 00&prodid=2039|Evo+Desktop+D50 0+Series+SFF&source=252312-

001.xml&dt=13 http://www3.compaq.com/support/

reference_library/ viewdocument.asp?countrycode=10 00&prodid=2039|Evo+Desktop+D50 0+Series+SFF&source=243850-

Compaq Hardware

Reference Guide

Compaq Evo Family of

Personal Computers

Desktop Model

001.xml&dt=264 http://www3.compaq.com/support/

reference_library/ viewdocument.asp?countrycode=10 00&prodid=2039|Evo+Desktop+D50 0+Series+SFF&source=243849-

001.xml&dt=264

Compaq Hardware

Reference Guide Evo

Desktop Family Evo

Workstation Family

Small Form Factor

Models - Intel Pentium

4 Version

Manual Part number and

revision

252312-001

243850-001

243849-001

Compaq Evo D510

minitower

http:// www.compaq.com/

http://www3.compaq.com/support/ reference_library/ viewdocument.asp?countrycode=10 00&prodid=2039|Evo+Desktop+D50 0+Series+SFF&source=191077-

003.xml&dt=264 http://h20000.www2.hp.com/bc/

docs/support/UCR/SupportManual/ TPM_177944_rev_us/ TPM_177944_rev_us.pdf

http://www3.compaq.com/support/ reference_library/ viewdocument.asp?countrycode=10 00&prodid=2039|Evo+Desktop+D50 0+Series+SFF&source=252312-

001.xml&dt=13

Compaq Getting

Started Evo Desktop

Family Evo

Workstation Family

Deskpro Workstations

Safety and Regulatory

Guide Evo Desktop

Family Evo

Workstation Family

Deskpro Workstations

Service Reference

Guide

191077-003

177944-004

252312-001

1-8 MARS PC Revision E

2010165-052

Introduction: Related Manuals

Table 3. OEM Websites (Continued)

Product

Compaq 18 in. Monitor

V7550

HP EVO D530

convertible minitower

Home Page Web

Address

Manual/Data Web Address Manual Title

ftp://ftp.compaq.com/pub/ supportinformation/techpubs/ user_reference_guides/177620006_rev6_us.pdf

http://h18000.www1.hp.com/ products/quickspecs/11349_na/ 11349_na.HTML

www.compaq.com/ http://h18004.www1.hp.com/

products/monitors/advantage/ v7550.html

http://www.hp.com/ http://h200007.www2.hp.com/bc/

docs/support/UCR/SupportManual/ TPM_340154_rev001_us/ TPM_340154_rev001_us.pdf

http://h200007.www2.hp.com/bc/ docs/support/UCR/SupportManual/ TPM_312969_rev2_us/ TPM_312969_rev2_us.pdf

Compaq

Troubleshooting Guide

Compaq Technical

Specifications

Product Specifications

V7550 Color Monitor

“Technical Reference

Guide hp compaq d330

and d530 Personal

Computers”

“Troubleshooting

GuideCompaq

Business

Desktopsd530, d330,

and d325 Models”

Manual Part number and

revision

177620-006

N/A

340154-001

312969-002

http://h18000.www1.hp.com/ products/quickspecs/11632_na/ 11632_na.PDF

http://h200001.www2.hp.com/bc/ docs/support/UCR/SupportManual/ TPM_335683_rev002_us/ TPM_335683_rev002_us.pdf

http://h20000.www2.hp.com/bc/ docs/support/SupportManual/ c00062755/c00062755.pdf

Quick Specs N/A

HP Compaq d530

335683-002 Series Personal Computer, CMT, Illustrated Parts Map

Business Desktop

336492-003 d500 Series Service Reference Guide

Revision E MARS PC 1-9

2010165-052

Introduction: Related Manuals

Table 3. OEM Websites (Continued)

Product

Hewlett-Packard

dc7100 system box

Home Page Web

Address

Manual/Data Web Address Manual Title

http://www.hp.com/ http://h200007.www2.hp.com/bc/

docs/support/SupportManual/ c00236571/c00236571.pdf

http://h200007.www2.hp.com/bc/ docs/support/SupportManual/ c00236571/c00236571.pdf

http://h18000.www1.hp.com/ products/quickspecs/11948_na/ 11948_na.pdf

http://h200007.www2.hp.com/bc/ docs/support/SupportManual/ c00219460/c00219460.pdf

http://h200007.www2.hp.com/bc/ docs/support/SupportManual/ c00211142/c00211142.pdf

HP Compaq dc7100

361834-001 and dx6100 Series Business Desktop Computers Technical Reference Guide

Troubleshooting Guide

361204-001 Business Desktops

Quick Specs N/A

HP Compaq Business

361292-002 Desktop dc7100 Series Personal Computer (CMT Chassis) Illustrated Parts Map

HP Compaq Business

361288-002 Desktop dc7100 Series Service Reference Guide

Manual Part number and

revision

HP 4200N LaserJet

printer

HP 1200 LaserJet

printer

MultiTech Analog

Modem

Card Reader

Acquisition Device

(Omni Drive) —

internal

http://h200007.www2.hp.com/bc/ docs/support/SupportManual/ c00189252/c00189252.pdf

http://www.hp.com/ http://h200001.www2.hp.com/bc/

docs/support/SupportManual/ bpl12546/bpl12546.pdf

http://www.hp.com/ http://h200005.www2.hp.com/bc/

docs/support/SupportManual/ bpl10395/bpl10395.pdf

http:// www.multitech.com/

http://www.multitech.com/ DOCUMENTS/Collateral/manuals/ S000286B.pdf

ftp://ftp.multitech.com/.ext/att/ ATT_Global_Modem_Configuration. pdf

http://www.csm.de/ http://www.csm.de/html/e/

produkte_komponenten/ pc_card_drives/professional_line/ frm/xomnidrive_intern_pro.htm

Hardware Reference Guide -- HP Compaq Business Desktops dc7100 Convertible Minitower

HP Laserjet 4200, and 4300 Printers User Guide

HPLaserJet 1200 Series User Guide

MultitModem Owner’s manual MT5634ZBA

MultitModem MT5634ZBA Configuration and Setup Instructions

Only technical data sheet available

360225-001

Second edition

September

2002

Second Edition

April 2001

Part number

82068600

Revision A

N/A

1-10 MARS PC Revision E

2010165-052

Introduction: Related Manuals

Table 3. OEM Websites (Continued)

Product

Card Reader

Acquisition Device

(Omni Drive) —

Home Page Web

Address

Manual/Data Web Address Manual Title

http://www.csm.de/ http://www.csmproducts.com/html/e/

produkte_komponenten/frm/ xmain.htm

external

Sony 21 in. Monitor

http://www.sony.com/ N/A Only sales data sheet

CPD-G520P

NEC MultiSync LCD

1850X

http:// www.necmitsubishi.co

http://www.necmitsubishi.com/ corpus/U/F/LCD1850X_manual.pdf

NEC MultiSync LCD

1980SX

http:// www.necmitsubishi.co m/

ttp://www.necmitsubishi.com/ corpus/5/I/ LCD1980SX_manual2.pdf

Powerware 5115 UPS www.powerware.com http://www.powerware.com/UPS/

5115_UPS.asp

Only technical data sheet available

information available MultiSync LCD1850X

User's Manual

MultiSync LCD1980SX User's Manual

Powerware 5115 User’s Guide

Manual Part number and

revision

N/A

05146640A

Revision E MARS PC 1-11

2010165-052

Conventions

Safety Messages

Introduction: Related Manuals

The following conventions are used in this manual.

DANGER safety messages indicate an imminently hazardo us situation which, if not avoided, WILL result in death or serious injury.

WARNING safety messages indicate a potentially hazardous situation which, if not avoided, COULD result in death or serious injury.

CAUTION safety messages indicate a potentially hazardous situation which, if not avoided may result in minor or moderate injury.

NOTE messages provide additional user information.

1-12 MARS PC Revision E

2010165-052

Introduction: Safety Information

Safety Information

Responsibility of the Manuf acturer

GE Medical Systems Information Technologies is responsible for the effects of safety, reliability, and performance only if:



Assembly operations, extensions, readju stments, modifications, or repairs are carrie d out by persons aut horized b y GE Medica l Systems Information Technologies.



The electrical installation of the relevant room complies with the requirements of the appropriate regulations.



The equipment is used in accordance with the instructions for use.

127(

The addition of non-approved software programs and network devices are not recommended or supported by GE Medical Systems Information Technologies. Repairs or Technical Support assistance for failures related to non-approved applications and configurations are not covered by warranty, and will be charged on a time and material basis.

General

This device is intended fo r use under the direct supervision of a licensed health care practitioner.

To ensure patient safety, use only parts and access ories manufactured or recommended by GE Medical Systems Information Technologies.

Contact GE Medical Systems Information Technologies for information before connecting any devices to this equipment that are not recommended in this manual.

If the installation of this equipment, in the USA, wi ll use 240 V rather than 120 V, the source must be a center-tapped, 240 V, single-phase circuit.

Parts and accessories used must meet t he requireme nts of t he appli cable IEC 601 series safety standards, and/or the system configuration must meet the requirements of the IEC 601-1-1 medical electrical systems standard.

The use of ACCESSORY equipment not complying with the equivalent safety requirements of this equipment may lead to a reduced level of safety of the resulting system. Consideration relating to the choice shall include:



use of the accessory in the PATIENT VICINITY; and



evidence that the safety certification of the ACCESSORY has been performed in accordance to the appropriate IEC 601-1 and/or IEC 601-1-1 harmonized national standard.

Revision E MARS PC 1-13

2010165-052

Introduction: Safety Information

Information Technology Equipment

The hardware components that make up the MARS PC Workstation are considered to be Information Technology Equipment (ITE). These individual components have been found to comply with the standard for Safety of Information Technology Equipment, Including Electrical Business Equipment EN60950 (UL 950).

The software used in the MARS PC Wo rkstation is consid ered as medical software. The software has been designed and manufactured to the appropriate medical regulations and controls.

The MARS PC Workstation, which consists of the hardware and software components together, is considered a medical device. However, the appropriateness of applying the ITE requirements to evaluate the hardware portions of the workstation can be justified by the fact that the MARS PC Workstation does no t h ave a ny a pplied pa rts nor is the M ARS PC Workstation intended for use in the “patient environment”.

Equipment Symbols

The following symbol s app ear on th e equi pment. For e quipme nt s ymb ols not shown refer to the original manufacturer’s equipment manuals.

Monitor Controls

Sets Monitor contrast

Sets Monitor brightness

Power button

Disk Drive LEDs

Indicates disk activity (flashing green)

Indicates disk is on-line (green)

Indicates a disk failure (amber)

UPS

Identifies the row of LEDs that show AC input level

Identifies the row of LEDs that indicate battery charge Level

1-14 MARS PC Revision E

2010165-052

Warnings and Cautions

Introduction: Safety Information

Monitor Controls

Sets Monitor contrast

Identifies the row of LEDs that indicate load devices

Power ON button

'$1*(5

Do NOT use in the presence of flammable anesthetics.

:$51,1*6

Replace only with the same type and rating of fuse. This is Class I equipment. The mains plug must be

connected to an appropriate power supply. Turn off power and disconnect power cord from AC power

source before removing the cover.

&$87,216

To reduce the risk of electric shock, do NOT remove cover (or back). Refer servicing to qualified personnel.

This equipment contains no user servi ceab le pa rts. Refer servicing to qualified service personnel.

DO NOT load any software other than that specified by GE Medical Systems Information Technologies onto the MARS PC. Installation of software not specified by Information Technologies may cause damage to the equipment or loss or corruption of data.

U.S. Federal law restricts this device to sale by or on the order of a physician.

Revision E MARS PC 1-15

2010165-052

Service Information

Service Requirements

Refer equipment servicing to GE Medical Systems Information Technologies authorized service personnel only. Any unauthorized

attempt to repair equipment under warranty voi ds that warranty. It is the user’s responsibility to report the need for service to GE Medical

Systems Information Technologies or to one of their authorized agents. Failure on the part of the responsible individual, hospital, or institution

using this equipment to implement a satisfactory maintenance schedule may cause undue equipment failure and possible health hazards.

Regular maintenance, irrespective of usage, is essential to ensure that the MARS PC Standalone, Client and Server will always be functional when required.

Introduction: Service Information

Product Code Identification

The Product Code is used to ident ify specif ic system platf orms. Using the Product Code Table below and before servicing the MARS PC Workstation, identify the correct product code of the system.

The product code can be identified using the serial number listed on the product label attached to the base of each system. See “Equipment

Identification” on page 1-17.

127(

This manual primarily co vers the MARS PC Workstations running the Windows 2000 operating system. These systems run on either a Compaq Evo D510, HP EVO D530 CMT, or an HP dc7100 system box.

The MARS PC running on the Windows NT operating syste m is only discussed in “Network Installation” on page 3-1, and “System

Rebuild and Software Reinstall” on page 6-1. For any additional

information on the MARS PC systems running Windows NT, please

1-16 MARS PC Revision E

2010165-052

Introduction: Service Information

see the original Service Manual that shipped with the uni

Table 4. Product Codes

Product Code

or catalog

MARS Model Operating System

number

HY MARS PC Standalone and Client

workstation (Compaq Model Evo

Microsoft Windows 2000 Professional Service Pack 3

D510) MARS PC Standalone and Client

workstation (HP Model EVO D530)

HY MARS PC Server (Compaq Model

D510) MARS PC Server (HP Model EVO

D530)

SAT MARS PC Standalone and Client

workstation (HP Model dc7100) MARS PC Server (HP Model

dc7100)

Microsoft Windows 2000 Professional Service Pack 4

Microsoft Windows 2000 Server Service Pack 3

Microsoft Windows 2000 Server Service Pack 4

PU MARS PC Standalone and Client

2006542-002 MARS PC Standalone and Client

Equipment Identification

Every GE Medical Systems Information Technologies device has a unique serial number for identification. The serial number appears on the device label and may appear in one of two formats, A or B as follows.

Format A is shown below.

workstation

Microsoft Windows NT (manufactured in United States)

Microsoft Windows NT (unit manufactured in Germany)

MD1113-022

Revision E MARS PC 1-17

2010165-052

Introduction: Service Information

Table 5. Equipment Identification

Item Name Description

A name of device MARS PC Workstation B manufacturer GE Medical Systems Information Technologies C serial number Unique identifier D device characteristics One or two letters that further describe the unit, for example: P = prototype not conforming

to marketing specification; R = refurbished equipment; S = special product documented

under Specials part numbers; U = upgraded unit E division F = Cardiology G = Monitoring N = Freiburg Hellige F product sequence number Manufacturing number (of total units manufactured) G product code Two-character product descriptor

PU = MARS PC Workstation H year manufactured 0 = 2000, 1 = 2001, 2 = 2002, (and so on)

I month manufactured A = January, B = February, C = March, D = April, E = May, F = June, G = July,

H = August, J = September, K = October, L = November, M = December

Format B is shown below.

### ## ## #### # #

ABCDEF

A Product Code B Year Manufactured (00-99)

00 = 2000 01 = 2001 02 = 2002

(and so on) C Fiscal Week Manufactured D Production Sequence Number E Manufacturing Site F Miscellaneous Characteristic

1-18 MARS PC Revision E

2010165-052

2 Equipment Overview

and System Setup

Revision E MARS PC 2-1

2010165-052

For your notes

2-2 MARS PC Revision E

2010165-052

Equipment Overview and System Setup: System Characteristics

System Characteristics

General Description

MARS PC Workstation is a multi parameter analysis and review system PC on a platform that supports MARS Holter analysis and editing system software.

127(

The picture shows a representative sy stem. The configurat ion of your system may vary slightly. The print er, modem, and power supply ar e not pictured.

Hardware

The MARS PC standalone, client, and server workstation use an Intel PC platform with the Microsoft Windows

It uses a multi-tasking environment, which provides the ability to acquire, analyze, edit and print simultaneously.

Peripherals include the monitor, keyboard, mouse, card reader acquisition unit, printer, uninterruptible power supply (UPS), and CDRW. The system also includes an analog modem for remote system support (RSS). A Tape acquisition unit is optional.

Standalone and Client Platform

The client platform and stand-alone platform both require 25 Gig of storage (approximatel y 300 slots) for patient data and 10 Gig of storage for patient reports.

03A

 operating system.

Revision E MARS PC 2-3

2010165-052

Equipment Overview and System Setup: System Characteristics

Server Platform

The server platform requires 60 Gig of storage (approximately 750 slots) for patient data and 15 Gig of storage for patient reports.

Software

MARS Holter Analysis and Editing System Software

The MARS Holter analysis and editing system software acquires ECG data from electronic ECG recorders. The software provides:



multiple techniques of scanning for complex editing



algorithm enhancement for more precise beat and noise detection



up to 12 high-resolution trends simultaneously on one screen



pre-configured standard final reports



dual channel superimposition displayed at up to 240 times real-time

MARS PC Client Software

MARS PC Server Software

CardioSoft Client Software

Software Activators

MARS PC software can be loaded on MARS P C clients run ning W indows NT 4.0 service pack 6A or Windows 2000 Professional with the multi-language package operating system.

MARS PC software can be loaded on a MARS PC server running the Windows 2000 Server opera ting system with the multi-language package.

CardioSoft client software will operate on a MARS PC client, server or standalone system.

There are various software applications and features that reside in a single software application. Depending on what software applications or features were purchased, you may need to use a MARS PC Workstation specific s oft wa r e a ct iv at or to be gi n, or t o c on t in ue t o u se tha t ap p lic a t io n or feature.

See the MARS PC Workstation operator’s manual for additional information on using software activators.

2-4 MARS PC Revision E

2010165-052

Equipment Overview and System Setup: System Characteristics

Remote System Support (RSS) Access Unit

Each MARS PC Workstation uses a non-networked analog modem for Remote System Support (RSS). The RSS a ccess unit allows GE Medical Systems Information Technologies to maintain, and if necessary, diagnose and repair the software.

Revision E MARS PC 2-5

2010165-052

Configurations

Equipment Overview and System Setup: Configurations

127(

The addition of non-approved software programs is not recommended or supported by GE Me d ica l Sy st em s Information Technologies.

The MARS PC Work station c an be con figured in to a stand alone, a server, or a client system. The configurations are described below:

1. Standalone



The patient data is stored locally and saved patient reports can be sent to a MUSE server across a network. There is no access to patient data from other MARS systems. The standal one runs with Windows NT or Windows 2000 professional software.

2. Server



All patient data will be stored on the MARS PC server and can be accessed by MARS PC clients. However, in the event of server failure or availability, patient data acquired at the client will be stored locally on the client. The server may have a card re ader o r tape acquisition devices on it if 5 or less clients are attached. The patient reports can also be sent to a MUSE server. The server runs with Windows 2000 server software.

3. Client

Network Functions



The client automatically sends patient data to the MARS PC server, and has access to all patient data stored on the server. It has data acquisition devices attached. The patient reports can also be sen t t o a MU S E se r ver . Th e cl ie nt m ust h ave a M A RS P C server to operate. The client runs with Windows NT or Windows 2000 Professional software.

The individual configurations can create three different MARS PC network configurations using a standard ethernet TCP/IP network.

The network configurations are:

1. MARS PC standalone configuration



This configuration can communicate with a network printer and/or a MUSE server. It can also have a parallel printer.

2. MARS PC client-server configuration.



This configuration allows the MARS PC client to access and send patient data to a MAR S PC serv er. Pati e n t data is aut oma ti ca l ly sent from the client to the MARS PC server. Patient reports can also be sent to a MUSE server. The client can print to a network or parallel pri nter.

3. MARS PC server configuration



All patient data will be stored on the MARS PC server and can be accessed by MARS PC clients. It may have card reader or tape acquisition devices if five or less clients are attached. The server

2-6 MARS PC Revision E

2010165-052

Block Diagram

Equipment Overview and System Setup: Configurations

can support a maximum of 25 MARS PC clients. The patient reports can also be sent to a MUSE server.

127(

To enable the MARS PC to communicate with the MUSE, GE Medical Systems Information Technologies Service personnel must setup the MUSE.

Please keep in mind that the block diagram is only a representative sample, as there are too many possible configurations to show them all.

MARS

Monitor

SCSI devices

Tape Acquisition

(optional)

phone

line

UPS

External SCSI bus

Analog

Modem

Power

Supply

CPU

Local

Printer

(optional)

CAT 5 network

(optional)

Hard

Drive

Floppy

Drive

CDRW

Card

Reader

MARS to

MUSE

Network

Printer

Client/

Server

Mouse

Keyboard

Revision E MARS PC 2-7

2010165-052

Equipment Overview and System Setup: System Setup and Installation

System Setup and Installation

The following interconnection table (Table 6, “Configuration

Interconnections,” on page 2-10) instructs how the client-server and

standalone workstation should be set up. Please refer to the supplied OEM manuals and the “System Components and L ocations” on page 2-12 for additional information.

:$51,1*6

Keep leakage current within acceptable limits when connecting auxiliary equipment to this device.

This is Class 1 equipment. The mains plug must be connected to an appropriate power supply.

Connecting the Equipment

Connecting the equipment consists of:



Connecting the applicable perip he ral devi ces



Booting MARS PC Workstation for the first time



Setting up the network



Complete the c hec k out pr oc e du r e

To connect the equipment, foll ow th e conf ig urati on tabl e prov ided on t he following pages.

MARS PC Interconnection Guide

Table 6, “Configuration Interconnections,” on page 2-10 provides the physical connections necessary for the MARS PC standalone and clientserver configurations. Once the physi cal connections are completed go to

“Network Installation” on page 3-1 for setting up the network.

Before You Begin

,03257$17

Confirm the MARS PC Workstation box is configured to receive the correct source voltage (115V or 230 V) for your geographical area.

Configure the dip switches on the UPS to receive the correct source voltage for your geographical area. Use the “User’s Guide” that shipped with the UPS for the correct dip switch configuration.

,03257$17

2-8 MARS PC Revision E

2010165-052

Equipment Overview and System Setup: System Setup and Installation

definitions current to avoid virus infections. Please discuss virus protection with the hospital Information Systems (IS) department before proceeding with the network installation of this equipment.

In addition to installing anti-virus software, it is recommended that the customer limit drive share access for additional virus protection. This can be accomplished by changing the share permissions for the gemsit folder. It is recommended that permissions be set for individual users, rather than the entire MARSWORKGROUP or an entire domain. This will change the default factory setup.

Revision E MARS PC 2-9

2010165-052

Equipment Overview and System Setup: System Setup and Installation

Standalone, Server, and Client Hardware Configur ati on (Compaq EVO D510 and HP EVO D530 CMT) Interconnect Table

127(

Use the pictures, “Compaq EVO D510 (Rear View)” on page 2-13,

“HP EVO D530 (Rear view)” on page 2-16, or “HP dc7100 (Rear view)” on page 2-19, for locating and identifying the connectors on

the back of the MARS PC Workstation.

Table 6. Configuration Interconnections

Connect From Connect To Comments/Instructions

Uninterruptible Power Supply (UPS)

NOTE: DO NOT plug the printer into the UPS!

RSS MultiModem MARS PC Workstation Box Connect the 9 pin, serial 2 workstation

MARS PC Workstation Box Connect the RS232 9 Pin cable from the

UPS computer interface port to the Serial-1 connector on the MARS PC Workstation Box.

AC Power Outlet Plug the UPS power cord into the AC

power wall outlet. Confirm that the “Site Wiring Fault” LED located on the rear top left corner of the UPS is off.

RSS MultiModem Connect the MultiModem LINE connector

to the UPS IN connector (via RJ11 cable).

Wall Phone line Connect the wall phone line connector to

the UPS OUT connector (via RJ11 cable).

connector to the modem D connector.

AC Power wall outlet Ensure the RSS MultiModem is “OFF”.

Plug the AC/ DC Power supply into the modem, and then to the AC power wall outlet.

Telephone RSS MutiModem Phone connector plugs

into the base of the telephone (via RJ11 cable).

Tape Acquisition Unit MARS PC Workstation Box Note: This is an optional device.

Connect to the MARS PC SCSI connector then plug the terminator connector into the top connector on the Tape Acquisition unit. See “Tape Acquisition Unit (Optional)” on page 2-20 for additional information.

Keyboard MARS PC Workstation Box Connect to top left corner USB connector.

(Looking at the rear of the workstation)

Mouse MARS PC Workstation Box Connect to green connector

2-10 MARS PC Revision E

2010165-052

Equipment Overview and System Setup: System Setup and Installation

Table 6. Configuration Interconnections (Continued)

Connect From Connect To Comments/Instructions (Continued)

Printer MARS PC Workstation Box Connect to the Parallel 2 connector.

NOTE: DO NOT plug the printer into the UPS!

AC Power wall outlet Ensure the printer is configured for the

main power (i.e. 115VAC or 220 VAC). Ensure the printer is “OFF” before plugging the power cord into the AC wall outlet.

Monitor MARS PC Workstation Box Connect via 15 pin D video connector.

AC Power wall outlet Ensure the monitor is configured for the

main power (i.e. 115VAC or 220 VAC). Ensure the monitor is “OFF” before plugging the power cord into the AC Power wall outlet.

MARS PC Workstation Box UPS AC receptacle Plug the power cord from the workstation

box into the UPS AC receptacle.

Network connector (ethernet) Connect via the network cable.

NOTE: The network is optional on Standalone units.

127(

After the physical connections are completed go to “Network

Installation” on page 3-1 for setting up the network.

Revision E MARS PC 2-11

2010165-052

Equipment Overview and System Setup: System Components and Locations

System Components and Locations

MARS PC Standalone, Client and Server System Boxes

Compaq EVO D510 (Front view)

Table 7. MARS PC System Box (Compaq EVO D510, Front View)

Item Name Description

A Internal card reader Reads holter data from data cards (This will be black in color, not white as pictured) B CD-RW Drive Reads and writes to CD-RW C Floppy Drive Reads floppy disks D Power Button Turns system on or off.

035AD035A

2-12 MARS PC Revision E

2010165-052

Equipment Overview and System Setup: System Components and Locations

Compaq EVO D510 (Rear View)

Table 8. MARS PC System Box (Compaq EVO D510, Rear View)

Item Name Description

A Mouse Connector Connects the mouse.

D E

025A

B Parallel 1 Connector Extra parallel connector (not currently used) C Ethernet Connector Connects to network D SCSI Connector Connects to the Tape Acquisition unit (optional device) E Parallel 2 Connector Connects to the printer F Serial 2 Connector Connects to RSS Modem G Serial 3 Connector Extra serial connection (not currently used) H Serial 4 Connector Extra serial connection (not currently used) J USB Connectors Connects to the USB keyboard (use top left USB port for keyboard) K Audio Connector Connects devices that supply sound

L Video Connector Connects to the monitor M Serial 1 Connector Connects to the UPS N Keyboard Connector Connects to the keyboard

Revision E MARS PC 2-13

2010165-052

Equipment Overview and System Setup: System Components and Locations

Table 8. MARS PC System Box (Compaq EVO D510, Rear View) (Continued)

Item Name Description

P Power Adapter Connects unit to power outlet Q Voltage Select Switch Switches voltage from 115V to 230V

2-14 MARS PC Revision E

2010165-052

Equipment Overview and System Setup: System Components and Locations

HP EVO D530 (Front view)

A B

E F

Table 9. MARS PC System Box (HP EVO D530, Front View)

Item Name Description

A Internal card reader Reads holter data from data cards B CD-RW Drive Reads and writes to CD-RW C Power Button Turns system on or off.

54A

D Universal Serial Bus Connectors 2.0 Front USB connectors. E Headphone Out Jack Provides sound for headphones. F Microphone In Jack Not Used

G Floppy Drive Reads floppy disks

Revision E MARS PC 2-15

2010165-052

Equipment Overview and System Setup: System Components and Locations

HP EVO D530 (Rear view)

A B

Table 10. MARS PC System Box (HP EVO D530, Rear View)

Item Name Description

A Mouse Connector Connects the mouse.

B Parallel 1 Connector Extra parallel connector (not currently used) C Ethernet Connector Connects to network D SCSI Connector Connects to the Tape Acquisition unit (optional device)

E Parallel 2 Connector Connects to the printer

D E

55A

F Serial 3 Connector Extra serial connection (not currently used) G Serial 4Connector Extra serial connection (not currently used) H Audio Connector Connects devices that supply sound

J USB Connector Connects to the USB keyboard (use top left USB port for keyboard)

K Video Connector Connects to the monitor

L Serial 1 Connector Connects to the UPS M Keyboard Connector Connects to the keyboard N Serial Connector 2 Connects to RSS Modem

2-16 MARS PC Revision E

2010165-052

Equipment Overview and System Setup: System Components and Locations

Table 10. MARS PC System Box (HP EVO D530, Rear View) (Continued)

Item Name Description

P Power Adapter Connects unit to power outlet Q Voltage Select Switch Switches voltage from 115V to 230V

Revision E MARS PC 2-17

2010165-052

Equipment Overview and System Setup: System Components and Locations

HP dc7100 (Front view)

D E

Table 11. MARS PC System Box (HP dc7100, Front View)

Item Name Description

A DVD-RW Drive Reads and writes to DVD-RW and CD-RW B Power Button Turns system on or off C Universal Serial Bus Connectors 2.0 Front USB connectors

56A

D Headphone Out Jack Provides sound for headphones E Microphone In Jack Not used

F Floppy Drive Reads floppy disks

2-18 MARS PC Revision E

2010165-052

Equipment Overview and System Setup: System Components and Locations

HP dc7100 (Rear view)

Table 12. MARS PC System Box (HP DC7100, Rear View)

55A

Item Name Description

A Serial 1 connector Connects to the UPS

B Audio out connector Headphone/Speaker audio out C Audio in connector Line audio in D Keyboard connector Connects to the keyboard

E Mouse connector Connects the mouse

F Video connector Connects to the monitor G USB ports 1, 2 Connects to the USB keyboard (use leftmost USB port for keyboard) H Ethernet connector Connects to network

I USB ports 3 – 6 Other USB devices can be connected to these ports J Parallel port Connects to parallel printer K AC input connector Connects unit to power outlet

Revision E MARS PC 2-19

2010165-052

Equipment Overview and System Setup: System Components and Locations

Tape Acquisition Unit (Optional)

Front View

md1144-316b

Table 13. Tape Acquisition Unit

Item Name Description

A power LED Indicates the operating status of the tape acquisition unit. It glows green when

power is applied.

B tape drive opening Allows tapes to be inserted into the tape acquisition unit.

md1144-322b

C tape motion indicator LED Indicates the motion of the tape drive. It glows green when the tape moves faster

than 100 mm/sec. It glows red when the tape speed drops below 100 mm/sec.

D release lever Depressing ejects the tape from the tape drive opening. Lever must be closed to

start rewind.

E mains AC power port Connects the tape acquisition unit to an external mains AC power source. The tape

acquisition unit contains a 120v/240v autosensing power supply.

F power (On/Off) switch Controls the power to the tape acquisition unit.

G SCSI ID switch Selects the SCSI target ID number. SCSI target ID for connecting to workstation =

H cooling fan intake Moves air in to cool tape acquisition unit components.

J SCSI port Connects to the terminator connector K SCSI port Connects to SCSI port on the back on the MARS PC Workstation

2-20 MARS PC Revision E

2010165-052

Equipment Overview and System Setup: System Components and Locations

Remote System Access Unit

MultiTech MultiModem Analog Modem (MT5634ZBA)

Front View

AB C D E F GH I J

Back View

MD1144-403A

MD1144-404A

NMLK

Table 14. MultiTech MultiModem Analog Modem (MT5634ZBA)

Item Name Description

A TD LED Transmit Data: Blinks when transmitting data. B RD LED Receive Data: Blinks when receiving data.

C CD LED Carrier Detect: indicates that the modem has established a connection with another modem.

During a retrain, this light blinks.

D 56 LED Lights when connected to an ISP-type K56flex server

E 28 LED Lights when the modem is connected in V.34 mode.

F 14 LED Lights when the modem is connected in V.32bis mode. G OH LED Off Hook: indicates that the modem is using the telephone line to dial, be online or answer. H TR LED Terminal Ready: Glows when modem can answer an incoming call.

I EC LED Error Control: Glows to indicate aV.42 error-controlled (TurboPEP, PEP, V.42 or MNP)

connection has been established. Blinks to indicate data compression enabled. J FX LED FAX Mode: Glows to indicate modem in Fax mode. K line port Connects the modem to an external telephone line (via the UPS). L phone port Connects the modem to a telephone.

M RS-232 port Connects to the Comm 2 (serial) connector on MARS PC. N power port Provides power to the modem via the UPS.

Revision E MARS PC 2-21

2010165-052

Equipment Overview and System Setup: System Components and Locations

Uninterruptible Power Supply (UPS)

Powerware 5115 (Front View)



Powerware Power Supply (Front view) 5115

Item Name Description

A Power On/Off Button Controls power to the UPS. B Test/Alarm Reset Button Lit whenever normal utility voltages are present at the power sockets.

C Power On Indicator This indicator is green when power is on. D On Battery Indicator This indicator is yellow when the UPS is running on battery.

E Overload Indicator This indicator is red when the UPS is overloaded. F Service Indicator This indicator is red when the UPS requires servicing.

032A

2-22 MARS PC Revision E

2010165-052

Equipment Overview and System Setup: System Components and Locations

Powerware 5115 (120 volt) Rear View)

F E

Powerware 120V Power Supply 5115,

Rear view

Item Name Description

A Network transient protector

Used for network or telecommunications equipment

(OUT)

B Network transient protector

Used for network or telecommunications equipment

(IN) C Input overcurrent protector Resettable input overcurrent protector D 6 foot Power cord Connects to power E DIP Switches Configures the input and output voltage F Communication Port Allows data communication between the UPS and the computer

034A

G Site Wiring Fault Indicator Lights up if there is no ground wire connection or if the neutral and line wires are crossed in

the line receptacle

Revision E MARS PC 2-23

2010165-052

Equipment Overview and System Setup: System Components and Locations

Powerware 5115 (220 volt) Rear View

Powerware 220V Power Supply 5115 Rear view

Item Name Description

A Network Transient Protector Used for network or telecommunications equipment B 10 Amp Receptacles Connect equipment to the UPS C Input Connector Connects the UPS to power D Input Overcurrent Protector Resettable input overcurrent protector E Dip Switch Configures the input and output voltage F Communication Port Allows data communication between the UPS and the computer

031A

2-24 MARS PC Revision E

2010165-052

Monitors

Printers

Equipment Overview and System Setup: System Components and Locations

Please refer to the Owner’s Manual that shipped with the monitor for any necessary information. The monitors currently being shipped with the MARS PC are listed in the table below.

Monitors

Size Brand Manufacturer Part number

17 inch Compaq V7550 19 inch NEC 1980SX 21 inch Sony CPD-G520P

Please refer to the Owner’s Manual that shipped with the printer for any necessary information. The printers currently being shipped with the MARS PC are listed in the table below.

Printers

Type Brand Manufacturer Part number

LaserJet Hewlett Packard HP 1200 LaserJet Hewlett Packard HP 4200N LaserJet Hewlett Packard HP 4250N

Revision E MARS PC 2-25

2010165-052

For your notes

Equipment Overview and System Setup: System Components and Locations

2-26 MARS PC Revision E

2010165-052

3 Network Installation

Revision E MARS PC 3-1

2010165-052

For your notes

3-2 MARS PC Revision E

2010165-052

Network Installation: Network Setup for Windows 2000 Systems

Network Setup for Windows 2000 Systems

Default Factory Setup

At the factory and during a rebuild, all MARS PC server, client and standalone systems (which use the Windows 2000 Operating System) are setup to use Windows workgroups by default. A new workgroup (MARSWORKGROUP) is set up automatically at the MARS PC server to provide secure client access to the drive shares.

A drive share with read/write/execute permission is set up automatically for “<server drive letter>:\gemsit” (with a drive share name of “gemsit”) to allow the client to access the reports and slots directories.

The mei user account is automatically created and added to the MARSWORKGROUP. All new users added to the MARSWORKGROUP will have access to the drive shares.

,03257$17

To protect the MARS PC Workstation from viruses, the appropriate anti-virus software should be installed before connecting the system to the network. It is recommended that the customer turn on the anti-virus software auto protect option, and keep the virus definitions current to avoid virus infections. Please discuss virus protection with the hospital Information Systems (IS) department before proceeding with the network installation of this equipment.

Adding New Users to Workgroups

To add a new user to a workgroup you must add the user to the MARS PC server and to the MARS PC client.

127(

If you would like further assistance, please contact the MARS PC Workstation Technical Support Line at 1-800-558-7044 or 1-561-575-5000 ext. 4243.

Domain Network

If a customer has its own domain controller, the MARS PC can be added to the domain. The advantage of using a domain controller over the workgroup is that is allows for centrally controlled user administration.

If you create a new user account on a domain controller, the new a ccount is automatically added as a member of that domain.

Revision E MARS PC 3-3

2010165-052

Network Installation: Network Setup for Windows 2000 Systems

Joining MARS PC to a Domain

The following are the general steps necessary to add the MARS PC to the domain:

1. The customer must provide the domain name to be used.

2. Add the user names to the domain.

3. Configure the MARS PC server and the clients to join the domain.

127(

This section is onl y needed if the customer intends to configure the MARS PC to join a domain and does not want to use the workgroup default setup.

If you would like further assistance, please contact the MARS PC Workstation Technical Support Line at 1-800-558-7044 or 1-561-575-5000 ext. 4243.

127(

Standalone units can also be added to the domain, but there is no advantage to doing this.

4. Configure the gemsit drive share on the server with full control permissions for the domain users.

5. To verify the that MARS PC Workstation is operating correctly, complete the steps given in “Checkout Procedure” on page 3-15.

3-4 MARS PC Revision E

2010165-052

Network Installation: Software Upgrade and Network Setup for Windows NT Systems

Software Upgrade and Network Setup for Windows NT Systems

Standalone and Client Configurations Running Windows NT

127(

This section is for MARS PC standalone and client systems running the Windows NT Operating System.

The following st eps are needed to complete the network configuration of the Windows NT boxes:

1. Determine if the MARS PC system has Ethernet capabilities.

2. Add network drivers if necessary.

3. Perform the software upg rade from version 5.1 (for standalone configurations).

127(

The upgrade allows the option of keeping the unit as a standalone or changing it to a client configuration.

4. Set up the network.

5. Check out the system.

Ethernet Capabilities

If the system box does not have an Ethernet card it can be upgraded to MARS PC version 6, but it cannot be attached to the network or communicate with the MUSE system. There is no network upgrade kit available for these units.

Only the MARS PC version 5.10 standalone configuration is available as an upgrade to version 6. The upgraded systems cannot support the tape acquisition unit.

Determine if Adding Network Drivers is Necessary

All MARS PC systems that have a product code of PU have network capability. The PU product code units were manufactured in the United States, and run on a Compaq or Hewlett Packard box. You must confirm that units without the PU product code contain a network card.

Looking at the seri al label on the back of the unit determine:

if the MARS PC... then go to...

has a PU product code “Perform Software Upgrade to v6” on

page 3-6

has catalog number 2006542-002 “Adding Network Drivers” on page3-6

Revision E MARS PC 3-5

2010165-052

Network Installation: Software Upgrade and Network Setup for Windows NT Systems

Adding Network Drivers

If you look at the back of the MARS PC system (catalog number 2006542-002) and see an Ethernet connector, the system has network capabilities, but the network drivers must be installed prior to upgrading the unit. Use the Installation Guide, part number 2006531-006, for instructions on adding network drivers.

After you have installed the network drivers go to “Perform Software

Upgrade to v6” on page 3-6.

Perform Software Upgrade to v6

Introduction

Before beginning this setup, consult with the hospital Information Technology (IT) department and determine if the site is planning to use workgroups or a domain. If using workgroups, gather the user name, password, and computer name. If using domain, gather the user account domain and computer domain information.

Available Configurations

127(

This section is for upgrading a MARS PC standalone workstation to a client configuration, or to a new standalone configuration that has networking capabilities. The system must be running software revision 5.10 to upgrade to version 6.

The MARS PC upgrade options available are:

1. Standalone



The patient data is stored locally and saved patient reports can be sent to a MUSE server across a network. There is no access to patient data from other MARS systems. The standalone configuration runs with Windows NT or Windows 2000 professional software. Use the standalone configuration if t h ere is no MARS PC server available.

2. Client



The client must have a MARS PC server available. The client automatically sends patient data to the MARS PC server, and has access to patient data stored on the server. It has data acquisition devices attached. The patient reports can also be sent to a MUSE server. The client runs with Windows NT or Windows 2000 Professional software.

Upgrade Options

The MARS PC allows a choice between a Custom Upgrade or a Typical Upgrade. It is important to understand the difference between the

upgrades before you continue.

3-6 MARS PC Revision E

2010165-052

Network Installation: Software Upgrade and Network Setup for Windows NT Systems

Typical Upgrade

127(

If you want to change from a standalone configuration to a client configuration, you must perform the Custom Upgrade option.

The Typical Upgrade will keep the standalone configuration and will add networking capabilities. It will not prompt the user to select be twe en a client or a standalone configuration. The Typical Upgrade does not make any changes to the MARS PC application location, number of patient slots, or startup information. The Typical Upgrade leaves all the patient data in its current location and retains the System Setup information.

Custom Upgrade

The Custom Upgrade will prompt the user to select between a client or a standalone configuration. The Custom Upgrade will prompt the user to change the MARS PC application location, number of patient slots, and startup information. The Custom Upgrade option will maintain the original patient data, even if the user changes the MARS application software from the current disk location. The System Setup information will be retained.

127(

You must have a MARS PC server to use the MARS PC client configuration.

Begin Upgrade Here

Enter the Administrator Mode

You must be logged on as the administrator before performing software upgrades.

1. Determine the manufacturer name that appears on the front of the

2. Reboot the system and log on as the administrator.

Upgraded MARS PC Workstations (the systems running Windows NT) do not support the Tape Acq uisition option.

system box.



If you have a MARS PC running on a Compaq or Hewlett Packard box:

at the user name and at the password prompt, type mei. or



If you DO NOT have a Compaq or Hewlett Packard box: at the user name prompt, type MHDAdmin and at the password

prompt, type notnagel.

Select Typical or Custom Upgrade

To perform a Typical Upgrade go to “MARS PC Typical Upgrade” on page 3-8, or to perform a Custom Upgrade g o to “MARS PC Custom

Software Upgrade” on page 3-9.

Revision E MARS PC 3-7

2010165-052

Network Installation: MARS PC Typical Upgrade

MARS PC Typical Upgrade

Insert the MARS PC application CD into the CD drive. Allow the MARS installation program to start automatically.

1. Choose the desired language at the Choose Setup Language window.

2. At the Welcome to the InstallShield Wizard for MARS window, click

3. Read the License Agreement window information, and if you agree,

4. At the MARS Setup window, se le ct the Typical Install

127(

Do not run any other applications while installing MARS PC software. Close all windows before inserting the application CD.

You must be in the administrator mode before proceeding with this upgrade.

Next.

click Yes.

(Recommended) button.

01A

127(

The MARS PC software installation will begin, and it will take approximately 5–15 minutes to install.

5. At the Installshield Wizard Complete window, select Yes, I want to

restart my computer now.

6. Select Finish. The software installation is complete.

7. Remove the CD from the drive and store it in a secure location.

8. Go to “Verify Software Version ” on page 3-13.

3-8 MARS PC Revision E

2010165-052

Network Installation: MARS PC Custom Software Upgrade

MARS PC Custom Software Upgrade

127(

Do not run any other applications while installing MARS PC software. Close all windows before ins erting the application CD.

You must be in the administrator mode before proceeding with this upgrade.

Insert the MARS PC application CD into the CD drive. Allow a few seconds for the MARS installation program to start automatically.

1. Choose the desired language at the Choose Setup Language window, and click OK.

2. At the Welcome to the InstallShield Wizard for MARS window, click Next.

3. Read the License Agreement window information, and if you agree, click Yes.

4. At the MARS Setup window, se le ct the Custom Install (Experienced Computer Users Only) button.

01A

Revision E MARS PC 3-9

2010165-052

Network Installation: MARS PC Custom Software Upgrade

5. At the MARS System Type window, select the Standalone or the Client button.

6. At the Destination Disk window, select the check box for the D drive.

127(

If you want a different drive letter as the destination drive, please select one o f the drive opt ions displa yed in t he Destination

Disk window. If a drive does not have enough spa ce avail able the “Not enough free space” message will appear next to the drive

letter.

02A



Select Next.

3-10 MARS PC Revision E

2010165-052

Network Installation: MARS PC Custom Software Upgrade

7. The Number of patient slots window will only appear for the standalone configuration. If you are upgrading a cl ient configuration, go to the next step.

At the Number of patient slots window, enter the desired number of SEER slots by clicking on the arrows.

127(

When slots are not bein g imported, the number of slots created minimum number of slots is 5. Enter the fewest number of slots you intend to use. System performance decreases as the number of slots increases. Refer to “Slot Installation/Time Consumption

Report” on page B-3 for specific information.

If slots are imported, the minimum number of slots will equal the number of imported slots. This means if only 3 patient slots are imported, the minimum number of slots will be 3.



Select Next.

07A

Revision E MARS PC 3-11

2010165-052

Network Installation: MARS PC Custom Software Upgrade

8. At the MARS Setup window: a. If running only MARS PC software, select the Start MARS

automatically at login option. or

If also running CardioSoft



, select the Do not start MARS

automatically at Login option.

b. Select Next.

127(

The MARS PC software installation will begin, and it will take approximately 5–15 minutes to install, depending on the number of slots being crea ted

08A

9. At the InstallShield Wizard Complete window, select Finish. The MARS PC will reboot. This will take several minutes.

Remove the CD from the drive and store it in a secure location.

10. Go to “Verify Software Version” on page 13.

09A

3-12 MARS PC Revision E

2010165-052

Network Installation: MARS PC Custom Software Upgrade

Verify Software Version

11. Start the MAR S PC applic a tio n. a. Click on Help. b. Click on About. c. Verify that the correct revision appears.

127(

If any other revision appears, please call GE Medical Systems Information Technologies technical support.

12. The upgrade is complete.

Go to “Setting Up the Network for Systems Running Windows NT” on page 3-13.

Setting Up the Network for Systems Running Windows NT

Before beginning the network setu p, consult with the hospital Information Technology (IT) department to determine if the facility will be using a domain or workgroups. If using workgroups, gather the user name, password, and computer name. If using domain, gather the user account domain, and computer domain information.

1. Right-click Network Neighborhood on the desktop.

2. Select Properties.

3. Select Protocols.

4. If TCP/IP Protocol is not listed, select Add.

5. Select TCP/IP Protocol.

6. Select OK.

7. If TCP/IP Protocol is listed, right-click on it and select Properties.

8. If you select YES at the DHCP prompt, go to step 9. or

If you select NO at the DHCP prompt, go to step 8.

127(

If any Windows NT Setup windows appear, click Continue.

9. Select TCP/IP Protocol. a. Select Properties. b. Enter the IP address, Subnet mask, and Default gateway

information. c. Select OK. d. Select Yes at the Restart your computer? window.

10. Select the Identification tab.

11. Select Change.

Revision E MARS PC 3-13

2010165-052

Network Installation: MARS PC Custom Software Upgrade

12. Enter your unique Computer Name.

13. If you select Workgroup, enter a unique workgroup name or to add MARS workgroup, type MARSWORKGROUP.

or If you select Domain, enter t he domain name g iven by the hospi tal IT

department.

14. Select OK.

15. Select Close.

16. At the Restart message, click Yes.

17. Go to “Checkout Procedure” on page 3-15.

3-14 MARS PC Revision E

2010165-052

Network Installation: Checkout Procedure

Checkout Procedure

Verify the MARS PC Workstation is operating correctly by following the system checkout procedure. Have the MARS PC Operator’s and OEM manuals available for reference.

127(

Shutdown

Not all the checkout steps will apply to each MARS PC configuration. For example, not all systems will have a tape acquisition unit, and standalone systems will not have a MARS PC server. Only run the appropriate steps for each configuration.

If you have a MARS PC system which is running the Windows NT operating system, use the checkout procedure located in the original MARS PC Service manual that shipped with that unit. Then use the “Network Checkout Procedure ” on page 3-20 of this manual to verify the network connections.

Power On

1. Power off the MARS PC Workstation using the following safe shutdown procedure:

a. Exit the MARS application by clicking System on the menu ba r. b. Click Exit on the pulldown menu. The MARS application will

close.

c. Open the Start menu located in the lower left corner of the

display. d. Select Shut Down. e. From the Shut Down menu, select Shut down the computer? f. Select Yes. g. At the message, It is now safe to turn off your computer, turn off

the MARS PC Workstation.

2. Power on the MARS PC Workstation. a. Turn on the workstation. b. Turn on the monitor power switch. Several screens appear

momentarily. Watch for error messages on the screen.

127(

If any error messages appear, contact the MARS PC Workstation technical support line.

c. If using a local parallel printer, turn it on. d. Press Crtl + Alt + Delete to access the logon window. e. Position the cursor in the User Name field and type your user

name.

Revision E MARS PC 3-15

2010165-052

Acquiring Data

Network Installation: Checkout Procedure

127(

The default User Name and Password is mei.

f. Position the cursor in th e Password field and type your password. g. Click OK. h. The application software starts and the system screen appears.

The system will automatically run a power on self test. Watch for error messages that may appear on the screen.

127(

If any error messages appear, contact the MARS PC Workstation Technical Support Line.

3. Verify that data from a patient data card can be acquired.

127(

Refer to the MARS PC Operators Manual for information on acquiring data fro m a patie n t da ta ca rd.

Printing

Archiving Data

Tape Acquisition Unit

4. Verify printing. a. Select Patient Select b. Choose a patient. c. Select Report Review. d. Select Print Page.

127(

Refer to the MARS PC Workstation Operator’s Manual for more information on printing.

5. If you have a CD-RW drive verify that you can archive to a CD.

127(

Refer to the MARS PC Workstation Operators Manual for more information on archiving data.

127(

NT systems do not support tape acquisition units.

6. Confirm that the SCSI I D s wi tch is s et to 5 on th e b a ck o f t h e uni t. I f it isn’t, correct the setting by us ing a point ed object (such as a pe n) to depress the switch. If you set the SCSI ID, you must reboot the MARS PC.

3-16 MARS PC Revision E

2010165-052

Network Installation: Checkout Procedure

7. If you have a tape acquisition unit, verify the unit can read, display, and print information from a Holter tape.

127(

Refer to the MARS PC Operator’s Manual for more information on loading the tape and acquiring data .

Remote System Support

8. Verify Remote System Support. a. No modem error messages should be seen on the screen. b. Contact MARS PC Workstation Technical Support to request a

RSS link to verify remote access. Have the analog telephone line number available.

Uninterruptible Power Supply (UPS)

9. Looking at the front of the UPS, determine the manufacturer name on the unit, and

a. If you have a Powerware b. If you have an APC

10. Verify Powerware UPS.

127(

This procedure is for the Powerware UPS only. If you have an APC UPS, go to step 11.

a. Detach the UPS serial cable from the connector on the back of the

UPS.

Serial connector



UPS proceed to step 10.



UPS proceed to step 11.

031A

b. Verify the Lansafe III Power Monitor window appears stating

Communications failure with UPS.

c. Attach the UPS serial cable.

Verify the Lansafe III Power Monitor window appears stating Communications established with UPS.

Revision E MARS PC 3-17

2010165-052

Network Installation: Checkout Procedure

d. Press and hold the test button on the front of the UPS.

Verify the Lansafe III Power Monitor window appears stating...Utility power failure... MARS PC is on

battery...shutdown in 5 minutes. Verify a message box appears stating Message from MARS PC to

WORKGROUP on...MARSPC is on battery...shutdown in 5 minutes.

e. Release the test button

Verify the Lansafe III Power Monitor window states...Utility

power failure resolved... MARS PC shutdown has been cancelled...MARS PC shutdown has been cancelled.

Verify a message box appears stating Message from MARSPC to WORKGROUP on...MARSPC shutdown has been cancelled.

f. Unplug the power cable from the wall outlet.

Verify the Lansafe III Power Monitor window appears stating...Utility power failure... MARS PC is on

battery...shutdown in 5 minutes. Verify a message box appears stating Message from MARS PC to

WORKGROUP on...MARSPC is on battery...shutdown in 5 minutes.

Verify the system shuts down in 5 minutes.

g. The checkout procedure is complete.

11. If you have an APC UPS unit look at the back of the unit, and if the model number listed on the label located near the upper left is:

BK500MC then go to step 12.

BK500MI then go to step 13.

12. Verify domestic APC UPS model number BK500MC. a. Select Start from the PC menu bar. b. Select Programs. c. Select Parachute plus. d. Select Parachute plus. e. A t th e Monitor Server window, select Attach.

3-18 MARS PC Revision E

2010165-052

Network Installation: Checkout Procedure

f. Verify the following window is displayed on the monitor:

g. Verify Monitoring is followed by the System name and Status is

On Line.

127(

In the following steps XXXXXX refers to the system name.

11A

h. Press up on the UPS Tes t butt on and hold it in for app roxima tely

3 seconds. It will beep and the status should change to On

Battery and the following message will be displayed:

XXXXXX is running on battery power. XXXXXX will shut down in xxx minutes and xxx seconds.

i. The status should return to On Line and the following message

will be displayed:

Normal utility power at XXXXXX has been restored.

j. Click OK. k. Close all windows. l. The checkout procedure is complete.

13. Verify international UPS model number BK500MI. a. Disconnect the UPS AC power inlet cord. b. An audible alarm will sound once every 5 seconds. c. Confirm the Compaq box is receiving power from the UPS by

verifying the power light is lit on the front of the Compaq box.

d. Reconnect the UPS AC power inlet cord. e. If the MARS PC has network capabilities, go to “Network

Checkout Procedure” on page 3-20

If the MARS PC does not have network capabilities, go to

“Operating System Language” on page 3-20.

Revision E MARS PC 3-19

2010165-052

Network Installation: Checkout Procedure

Network Checkout Procedure

If the MARS PC has network capabilities, perform the following tests that apply:

127(

Some of the steps listed below will not apply to all MARS PC configurations.

If necessary, refer to the MARS PC Operator’s manual for further assistance.

1. From a client system, use the DOS Command Prompt window to ping the MARS PC server to confirm the connection.



Type the following: ping [space] computer name.

127(

computer name refers to the server name.



Press Enter.



Verify that the correct IP address appears in the Reply from xxx.xxx.xxx.xxx message.

2. Click the Patient Select icon from the MARS PC client application.



If you were able to ping the MARS PC server, but can’t bring up the Patient Select option, confirm that the drive share permissions are correct.

3. Print a patient strip review from the standalone or client and server.

4. Verify that the MARS PC client can view the server patient list.

5. Verify that a patient file can be selected and edited from the MARS PC server.

6. If the MARS to MUSE option is enabled, verify that a report can be stored to MUSE from a standalone or client and server.

127(

If the Delete Report option is selected at the MARS PC the patient report will disappear from the list.

The network checkout is complete.

7. Go to “Operating System Language” on page 3-20.

Operating System Language

127(

This section is for MARS PC units running the Windows 2000 operating system. This section does not apply to MARS PC units running Windows NT.

3-20 MARS PC Revision E

2010165-052

Network Installation: Checkout Procedure

The MARS PC operating system is set to English at the factory. Additional languages supported are German, Spanish, French, Italian Swedish and Dutch.

If the desired operating system language is... then...

English the network installation is complete.

German, Spanish, French, Italian, Swedish, or Dutch go to “Setting the Language” on page 3-21.

Setting the Language

1. If necessary, reboot the system to log on as the administrator. At the user name type Administrator. Type WERIOP for the Password.

2. Select Start>Settings>Control Panel.

3. Select Regional Options.

4. Select the General tab.

5. Select the correct country for your location, and select the correct language for menus and dialogs.

6. Windows 2000 and Windows 2000 Server units complete step 6: a. Click Set Default. b. Select the correct language. c. Click OK. All other units proceed to step 7.

7. Click OK to close the Regional Options window.

8. Click Yes to confirm the change.

9. Log off as the administrator and log on again as administrator.

10. Verify the operating system is in the new language.

Revision E MARS PC 3-21

2010165-052

For your notes

Network Installation: Checkout Procedure

3-22 MARS PC Revision E

2010165-052

4 Maintenance

Revision E MARS PC 4-1

2010165-052

For your notes

4-2 MARS PC Revision E

2010165-052

Introduction

Maintenance Guides

For further information please reference the appropriate OEM manuals for the recommended maintenance of their product. To download OEM manuals please see “Downloading OEM Manuals From the Internet” on page 1-7.

If you would like further assistance, please call the MARS PC Workstation Technical Support Line at 1-800-558-7044 or 1-561-5755000 ext. 4243.

Items Requiring Maintenance

      

Maintenance: Introduction

MARC PC client system box MARS PC server system box MARS PC standalo ne system box Monitor DVD-RW or CD-RW Drive Printer UPS

Recommended Maintenance

GE Medical Systems Information Technologies recommends that you perform the tests described in this chapter:



Every 6 months as part of routine maintenance



Whenever internal assemblies are serviced



More frequently if indicated.

A regular equipment maintenance program helps prevent unnecessary equipment and power failures and also reduces possible health hazards. This chapter contains instructions for the following recommended maintenance:



Inspecting and cleaning the equipment



Domestic electrical safety tests



Workstation power supply test



Checkout procedure

127(

Unless you have an Equipment Maintenance Contract, GE Medical Systems Information Technologies does not assume the responsibility for performing the recommended maintenance procedures. The sole responsibility rests with the individual or institution using the equipment. GE Medical Systems Information Technologies service personnel may, at their discretion, follow the procedures provided in this manual as a guide during visits to the equipment site.

Revision E MARS PC 4-3

2010165-052

Maintenance: Introduction

Required Tools and Supplies

In addition to a standard set of hand tools , you will need the speci al tool s and items listed below to maintain or check out the system.

DVOM N/A Leakage current tester MT-1216-01 (120V),

CD-ROM Cleaning Kits 416627-001

Table 15. Required Tools and Supplies

Item Part Number

MT-1216-02 (240V), or equivalent

Tape Cleaning and Demagnetizer kit (Used on tape acquisition unit)

Holter Installation Tape 3613-602

3613-902

4-4 MARS PC Revision E

2010165-052

Power On Procedure

Maintenance: Introduction

1. Turn on the workstation.

2. Turn on the monitor power switch. Several screens appear momentarily.

127(

Watch for error messages on the screen. Reference the OEM Troubleshooting Guide that shipped with the MARS PC Workstation. The Troubleshooting Guide is also available on the Internet. For further information please see “Downloading OEM

Manuals From the Internet” on page 1-7.

3. If using a local parallel printer, turn on the local parallel printer.

4. Press Crtl + Alt + Delete to access the logon window.

5. Position the cursor in the User Name field and type your user name.

6. Position the cursor in the Password field and type your password.*

7. Click on OK. The MARS PC application screen appears.

* The default user name is mei. The default password is mei. It is

possible to change both user name and password; contact your system administrator for more information.

Revision E MARS PC 4-5

2010165-052

Safe Shutdown Procedure

Make sure to shut down the system properly. Follow this procedure to prevent inadvertent errors from occurring during system shut down.

127(

Failure to follow the recommended method to shut down the workstation may result in the loss of data and damage to the workstation.

Exit the MARS PC Application

To exit the MARS application, follow these steps.

1. Click System on the menu bar.

2. Click Exit on the pulldown menu. The MARS application will close.

Shut Down the Workstation

Once the MARS application has closed, follow these steps to shut down the workstation.

Maintenance: Introduction

1. Open the Start menu located in the lower left corner of the screen.

2. Select Shut Down from the Start menu.

3. Select Shut Down > Select OK.

127(

If you are shutting the computer down prior to logon, hold down the following keys simultaneously:

Ctrl + Alt + Delete and select the Shut Down option.

4-6 MARS PC Revision E

2010165-052

Maintenance: Inspection and Cleaning

Inspection and Cleaning

Visual Inspection

Perform a visual inspection regularly. Turn off the unit and remove power before making an inspection or cleaning the unit.



Check the case and display screen for cracks or other damage.



Regularly inspect all cords and cables for fraying or other damage. Perform safety tests on any repaired line cords.



Inspect all plugs, cables, and connectors for bent prongs or pins.



Verify that all cords, socketed components, and connectors are securely seated.



Inspect keys and controls for proper operation.



Power switches should not stick in one position.

Check Cooling Fans

Cleaning Precautions

Ventilation

Check operation of fans in:



client workstation box



server workstation box



standalone workstation box

With the workstation operating verify that all fans contained in the unit are operating properly.

Turn off the unit and remove all power before inspecting or cleaning. Do not immerse any part of the equipment in water. Do not use organic solvents, ammonia based solutions, or abrasive

cleaning agents which may damage equipme nt surfaces.

Position the workstation box to ensure adequate ventil ation. Poor ventilation can cause overheating and damage system components.



Do not place the workstation box in a position where the ventilation holes in the front and rear are blocked or restricted.



Do not place the system box near ducts, pipes or equipment which generate heat.

Revision E MARS PC 4-7

2010165-052

Exterior Cleaning

Clean the exterior surfaces once per month, and more frequently if needed, with a clean, soft clot h and a mild dishwashing detergent dilut ed in water.



Cleaning the Monitor Screen

Wipe the screen with a soft, dry, clean cloth to remove dust. To remove fingerprints and other soil:

1. Wipe the screen with a soft cloth moistened with a solution of

Maintenance: Inspection and Cleaning

Wring the excess water from the cloth. Do not drip water or any liquid on the writer assembly, and avoid contact with open vents, plugs, or connectors.

Dry the surfaces with a clean cloth or paper towel.

127(

Never use abrasive materials to clean the screen. They can damage the anti-reflective coating.

isopropyl alcohol, water and mild detergent.

2. Rinse the screen immediately with a cloth dampened with clean water.

3. Dry the screen with a soft, clean cloth.

Cleaning the System Box Interior

The factory seals the e quipment b efore it lea ves. The re shoul d be no dust buildup on the surfaces of the interior PCB assemblies and components when you receive it.

Follow these steps to clean the system box interior.

1. Power off the workstation by following the “Safe Shutdown

Procedure” on page 4-6.

2. Detach the AC power cord before cleaning the interior of the system box.

3. Remove the system box cover to clean the interior. See the OEM’s Service Manual for detailed information.

4. Replace the cover.

:$51,1*

Turn off power and disconnect power cord from AC power source before removing the cover.

4-8 MARS PC Revision E

2010165-052

Maintenance: Inspection and Cleaning

Cleaning the CD-RW Drive or DVD-RW Drive

Follow these steps to clean the CD-RW or DVD-RW drive.

1. Open the CD-RW or DVD-RW drive.

2. Insert the cleaning disk, brushes down, into the drive.

3. Close the CD-RW or DVD-RW drive. The acti vity l ed blink s for abou t 10 seconds.

4. Remove the cleaning disk from the drive.

5. Close the CD-RW or DVD-RW drive

Cleaning the Printer

For maintenance please see th e OEM User’s manual that shipped with the printer. The manual can also be located on the Hewlett Packard website. For further information please see “Downloading OEM Manua ls

From the Internet” on page 1-7.

Cleaning the Tape Acquisition Unit

Cleaning and inspecting the tape acquisition unit involves several steps, including:



Demagnetizing and cleaning the tape acquisition unit



Cleaning the tape acquisition unit interior

127(

Demagnetize the tape acquisition unit, clean the tape drive, and check out the tape acquisition unit on a weekly basis.

Cleaning and Demagnetizing the Tape Drive Using the Cleaning and Demagnetizer Kit (PN 3613-9 02)

The cleaning and demagnetizing kit performs cleaning of the audio head and demagnetization simultanously, removing contaminants and magnetism build up.

Use the following steps to clean the tape drive using kit PN 3613-902.

127(

While running, the cleaning cass ette will e mit a buzzing soun d much louder than a normal tape. This is normal and does not indicate a problem with the unit.

1. Insert the cleaning cassette into the tape acquisition unit. Gently push the cleaning cassette into the drive opening until the clea ning cassette clicks into place.

2. Turn release lever to its up position.

3. The Tape Download/Analysis Options window appears and the cleaning tape runs briefly (less than a second) and stops.

127(

An error message may appear, if the correct slot type is not available or all slots are full. Click Cancel in the error message box. The

Revision E MARS PC 4-9

2010165-052

Maintenance: Inspection and Cleaning

message box will disappear and the cleaning cassette will run normally.

If the cleaning cassette continues to run for more than a few seconds, click Cancel in the Tape Download/Analysis Options window. This will stop the cleaning process. Contact MARS PC technical support.

4. Click Cancel in the Tape Download/Analysis Options window. The Tape Download/Analysis Options window closes.

5. Push tape lever down to eject tape.

Interior Cleaning

The factory seals the e quipment b efore it lea ves. The re shoul d be no dust buildup on the surfaces of the interior PCB assemblies and components when you receive it.

However, if dust is an environmental problem, use a commercially available dust remover (compressed air). Follow the manufacturer’s directions for its use.

:$51,1*

Only qualified personnel sh ould dissemble this unit. Turn off the power and disconnect power cord from the

AC power source before removing the cover.

Disassembly Guidelines

Follow these steps to disassemble and reassemble the tape acquisition unit.

Opening the Unit –

1. Power off the workstation.

2. Turn off the tape acqu isition unit power switch.

3. Disconnect the tape acquisition unit power cord from the back of the UPS.

4. Remove the fifteen retaining screws from the tape acquisition unit.

127(

The tape acquisition unit uses fifteen screws to secure the cover in place. To reduce EMI emissions, replace all fifteen screws securely

4-10 MARS PC Revision E

2010165-052

Maintenance: Inspection and Cleaning

when reassembl i ng th e u ni t.

MD1144-334A

5. Remove the tape acquisition unit cover. Slide the tape acquisition unit cover forward.

UPS

Checkout Procedure

Reassembling the Unit

1. Slide the tape acquisition unit cover over the front of the tape acquisition unit.

2. Install the fifteen retaining screws to secure the cover to the unit. Hand tighten all screws.

127(

The tape acquisition unit uses fifteen screws to secure the cover in place. To reduce EMI emissions, replace all fifteen screws securely when reassembl i ng th e u ni t.

3. Turn on the tape acquisition unit.

4. Power on the workstation. See “Power On Procedure” on page 4-5.

Battery replacement is recommended every 3-6 years. Please see the OEM User’s Guide for the battery replacement procedure.

Follow the “Checkout Procedure” on page 3-15.

Revision E MARS PC 4-11

2010165-052

For your notes

Maintenance: Inspection and Cleaning

4-12 MARS PC Revision E

2010165-052

5 Troubleshooting

Revision E MARS PC 5-1

2010165-052

For your notes

5-2 MARS PC Revision E

2010165-052

Troubleshooting: Theory of Operation

Theory of Operation

The theory of operati on provides a very bro ad overvie w of the s ystem box hardware and the various MARS PC configurations.

Configurations

There are three different MARS PC network configurations available using a standard Ethernet TCP/IP network. The MARS PC can be configured as a client, a server, or a standalone unit.

Standalone

The MARS PC standalone stores patient data locally, and the saved patient reports can be sent to a MUSE server across the network. The MARS PC standalone cannot receive patient data from other MARS systems.

Client

Server

System Box

The MARS PC client allows reports to be edited and printed. The MARS PC client-server configuration allows the MARS PC clients to access and automaticall y send pa tie nt dat a to the MARS PC se rver vi a the networ k. Patient reports can be sent to a MUSE server.

MARS PC servers store the patient data, and “serve” file requests from other MARS PC clients on the net work. A ll patie nt data wi ll be store d on the MARS PC server and can be accessed by MARS PC clients. The server can support a maximum of 25 MARS PC clients. The patient reports can also be sent to a MUSE server.

The system box contains a motherb oa rd, C PU proc essor( s), hard dri ve or drives, physical RAM, an internal CD-RW drive, floppy diskette drive, two separate Ethernet network ada pters, and a power supply. It also contains four audio ports, an internal speaker, two parallel ports and four serial ports. PCI expansion slots connect directly to the system bus and allow for additional network interface cards and other devices.

The motherboard contains the main ethernet interface for connecting to the network. MARS non-realtime devices such as printers or RSS access units have independent ports.

Revision E MARS PC 5-3

2010165-052

Troubleshooting: General Fault Isolation

General Fault Isolation

Assistance

If any assistance i s ne eded d uring the trou bleshoo ting pro cess please call the Technical Support Line at 1-800-558-7044 or 1-561-575-5000 ext. 4243.

First Things to Ask

If the unit is not working prop erly, start by asking yourself these basic questions.

1. Are the unit and all peripherals turned on?

2. Have there been any changes in the use, lo cation, or environment of the equipment that could cause the failure?

3. Has the unit been modified in any way, either in software or hardware?

Visual Inspection

Area Look for the following problems

I/O Connectors and Cables

4. Is operator error the cause of the problem? Try to repeat the user’s scenario exactly and compare that to the proper operation of the equipment. Check the operator’s manual as necessary.

A thorough visual inspection of the equipment can save time. Small things — disconnected cables, foreign debris on circuit boards, missing hardware, loose components — can frequently cause symptoms and equipment failures that may appear to be unrelated and difficult to track.

Read the Disassembly Guidelines in the product’s OEM manual before you perform an internal visual inspection of the components.

Take the time to make all the recommended visual checks (refer to the following visual inspection chart) before starting any detailed troubleshooting procedures.

Table 16. Visual Inspection List



Fraying or other damage



Bent prongs or pins



Cracked housing



Loose screws in plugs

Interface Cables

5-4 MARS PC Revision E



Excessive tension or wear



Loose connection



Strain reliefs out of place

2010165-052

Troubleshooting: General Fault Isolation

Table 16. Visual Inspection List (Continued)

Area Look for the following problems

Circuit Boards

Ground Wires/Wiring

Mounting Hardware

Power Source

Workstation Box



Moisture, dust, or debris (top and bottom)



Loose or missing components



Burn damage or smell of over-heated components



Socketed components not firmly seated



PCB not seated properly in edge connectors



Solder problems: cracks, splashes on board, incomplete feedthrough, prior modifications or repairs



Loose wires or ground strap connections



Faulty wiring



Wires pinched or in vulnerable position



Loose or missing screws or other hardware, especially fasteners used as connections to ground panes on PCBs



Faulty wiring, especially AC outlet



Circuit not dedicated to system



(Power source problems can cause static discharge, resetting problems, and noise.)

Please refer to the OEM Service manual and Troubleshooting Guide for troubleshooting the MARS PC Workstation box. The OEM Troubleshooting Guide is shipped with the unit, and is also available on the OEM website. For further information please see “Downloading OE M

Manuals From the Internet” on page 1-7.

For further assistance, call the MARS PC Workstation Technical Support Line at 1-800-558-7044 or 1-561-575-5000 ext. 4243.

Error Codes

For a list of Power-On-Self-Test (POST) messages please reference the OEM Troubleshooting Guide that shipped with the MARS PC Workstation. The Troubleshooting Guide is also available on the OEM website. For further information please see “Downloading OEM Manua ls

From the Internet” on page 1-7.

Replacing Workstation Box Items

Fault Detection

Use the troubleshooting process located in the OEM Service Manual for the additional SCSI, serial, and parallel boards. See “Replacing SCSI,

Serial or Parallel (LPT) Boards” on page 5-6 for additional board

locations. See the OEM Service Manual for additional detailed instructions. If you

have a question that is not answered in the OEM Service manual or if you would like further assistance, call the MARS PC Workstation Technical Support Line at 1-800-558-7044 or 1-561-575-5000 ext. 4243.

Revision E MARS PC 5-5

2010165-052

Troubleshooting: General Fault Isolation

C c t

L c t

C c t

Replacing SCSI, Serial or Parallel (LPT) Boards

Confirm you have the correct location before removing and replacing any circuit boards.

127(

The image will not work if the mother board configuration below is not followed.

The parallel (LPT) board has an additional connector (referred to as LPT 2) on it, which the card reader plugs into. The parallel (LPT) board plugs into the PCI 2 mother board slot. See the Mother Board Slots table below for more information.

EVO D510 Mother

Board

OM 1

onnected

o UPS

PCI 1

PCI 3

PCI 4

PCI 5

PCI 2

PCI 3

PCI 4

PCI 5

PT2 onnected

o printer

OM 2

onnected

o modem

COM 2 connected to modem

COM 1 connected to UPS

LPT2 connected to printer

EVO D530 Mother

Board

PCI 1

PCI 2

PCI 3

PCI 4

PCI 5

COM 1 connected to UPS

LPT2 connected to printer

COM 2 connected to modem

HP dc7100 Mother

Board

PCI 1

PCI 2

PCI 3

PCI 4

Table 17. Mother Board Slots

PCI Slot Number Description

1 This slot holds the SCSI board. The SCSI board is required if there is a Tape Acquisition unit attached to

the MARS PC Workstation. The Tape Acquisition unit is an optional device.

2 This slot holds the LPT (parallel) board. There is an extra connector on the LPT board, referred to as LPT 3,

5-6 MARS PC Revision E

3 This slot is empty.

which connects to the 26 pin ribbon connector on the card reader.

2010165-052

Troubleshooting: General Fault Isolation

Table 17. Mother Board Slots (Continued)

PCI Slot Number Description

4 This slot holds the serial board. 5 This slot is empty.

Monitor

The monitor is a field replaceable unit.

Fault Detection

If the monitor is not working correctly, try the following:

1. Verify the power and video connections.

2. If necessary follow the proper shut down procedures in th e MARS PC Operator’s manual to cycle the power.

Keyboard

Mouse

Printer

3. Reference the manual that came with the monitor.

4. Contact tech support for further assistance.

The keyboard is a field replaceable unit.

The mouse is a field replaceable unit.

The printer is a field replaceable unit. For troubleshooting please see the OEM User’s manual that shipped

with the printe r. The manua l can also be lo cated on the Hewl ett Packard website. For further information please see “Downloading OEM Manua ls

From the Internet” on page 1-7.

Please call the MARS PC Workstation Technical Support Line for further assistance.

Uninterruptible Power Supply

The UPS is a field replaceabl e unit. For troubleshooting please see the OEM manual that shipped with the

UPS. The manual can also be loca ted on the ma nufactur er’s websi te. Fo r further information please see “Downloading OEM Manuals From the

Internet” on page 1-7.

Revision E MARS PC 5-7

2010165-052

RSS Analog Modem

Troubleshooting: General Fault Isolation

127(

Only use the serial cable which was shipped with the UPS.

If the UPS is not working correctly, do the following:

1. Verify the connections.

2. Verify the wall outlet is not faulty by plugging the unit into a different outlet. Have a qualif ied electri cian repair any f aulty outlet s.

3. Press and hold the test button for three seconds. If the test LED illuminates see the “Troubl eshooting” section of the OEM manual f or further information.

4. If necessary, contact technical support for further assistance.

The RSS modem is a field replaceable unit. The MARS PC Workstation uses a non-networked analog modem for

Remote System Support (RSS). The RSS a ccess unit allows GE Medical Systems Information Technologies to maintain, and if necessary, to diagnose and to repair the work station software in a timely manner.

Fault Detection

If the modem is not working correctly, do the following:

1. Verify the connections.

2. Verify the power supply plugged into the modem is working.

3. Verify the software is running by: a. Select Control panel. b. Select Services. c. Verify pcAnywhere Host Service has a status of Started.

If necessary start the Host service and config ure it to start automatically.

4. Contact technical support to verify that they can remotely access the system.

5-8 MARS PC Revision E

2010165-052

Troubleshooting: General Fault Isolation

Tape Acquisition Unit (Optional Device)

The tape acquisition unit is a field replaceable unit. The tape acquisition is an optional device. The acquisition unit reads and

downloads 8500 tapes to the MARS PC.

Fault Detection

If the tape acquisition unit is not working correctly, do the following:

1. Verify the connections.

2. If necessary follow the proper shut down pro cedures to s hutdown and power the computer off; then power the unit on again.

Refer to the operator’s manual for the correct shut down procedures.

3. Verify data from a tape can be acquired.

127(

Reference the MARS PC operators manual for f urther assistance on acquiring data from the tape acquisition unit.

Card Reader (Omni Drive)

The card reader is a field replaceable device. Some MARS PC Workstations are shipped from the factory with an

internal card reader device. Other MARS PC Workstations are shipped from the factory with external card reader devices. The card reader reads and downloads SEER MC and SEER Light data cards to the MARS PC.

Fault Detection

If the card reader device is not working correctly, do the following:

1. Verify the connections.

2. If necessary follow the proper shut down procedures to shutdown and power the computer off, and then back on again.

3. Verify the data from a SEER MC data card can be acquired.

127(

Refer to the MARS PC operators manual for further assistance on acquiring data from a SEER MC data card.

Replacing the Internal Omni Drive Card Reader

When replacing the internal card reader:

1. Connect the ribbon cable to the LPT-3 connector. The LPT-3 connector is on the parallel port extension card, which is located inside the EVO D510 and EVO D530 system box. See “Replacing

Revision E MARS PC 5-9

2010165-052

Troubleshooting: General Fault Isolation

SCSI, Serial or Parallel (LPT) Boards” on page 5-6 for additional

information.

2. Connect the power connector on the card reader to the power supply.

Replacing the External Omni Drive Card Reader

When replacing the external card reader:

1. Remove the old USB OmniDrive unit, noting the port to which it was connected.

2. Connect the USB cable from the new USB OmniDrive to the appropriate USB port.

127(

There is no power connection; the external card reader receives power via the USB port.

3. Log in to the system.

4. After logging in, the external card reader will be installed. The Found New Hardware window will appear after login to display the drive. If the Hardware Wizard asks for OmniDrive software, insert the MARS PC Support CD. Browse to the location of the OmniDrive software.

If the card reader (Omni Drive) drive letter assigned is other than O: it will have to be changed:

a. Right-click on the My Computer icon on the desktop. Select

Manage. b. Click on Disk Mana g ement. c. Right-click on Disk 1 Removable and select Change Drive Letter. d. Select Edit. e. Select O:. f. Click OK. g. Click Yes. h. Close the Computer Management window.

DVD-RW, CD-RW, or Floppy Drive

The DVD-RW, CD-RW and floppy drives are field replaceable units. For troubleshooting please see the OEM User’s manual. The manual is

available on the website. For further information please see

“Downloading OEM Manuals From the Internet” on page 1-7.

If the device is not working properly, do the following:

5-10 MARS PC Revision E

2010165-052

Troubleshooting: General Fault Isolation

1. Verify that the device can archive data to the correct media. Reference the MARS PC operators manual for further assistance on archiving data.

2. Verify the connections.

3. If necessary follow the proper shut down pro cedures to s hutdown and power the computer off; then power the unit on again.

Refer to the operator’s manual for the correct shut down procedures.

4. If still not working, replace the unit.

Revision E MARS PC 5-11

2010165-052

For your notes

Troubleshooting: General Fault Isolation

5-12 MARS PC Revision E

2010165-052

6 System Rebuild and

Software Reinstall

Revision E MARS PC 6-1

2010165-052

For your notes

6-2 MARS PC Revision E

2010165-052

Disk Imaging

System Rebuild and Software Reinstall: Disk Imaging

A disk image is used to restore the MARS PC Workstation to its original factory state. During the proces s all exis ting data and setups will be lost . Disk imaging is only suggested when all other system recovery attempts have failed. This process can take between one to two hours to complete.

&$87,21

When a system is imaged, the hard drive is reformatted and ALL existing data will be lost. Do not proceed with this section if there is any confusion about disk imaging and its impact on the MARS PC Workstation. For further assistance, call technical support before proceeding with this section.

Revision E MARS PC 6-3

2010165-052

System Rebuild and Software Reinstall: Reimage System for MARS PC Standalone and Client Workstations

Reimage System for MARS PC Standalo ne and Client Workstations

This section explains how to reimage the MARS PC standalone and client boxes using the System Rebuild CD.

Before you Begin

Save Activator Codes

Activator codes must be saved to a floppy disk and then copied back to the system box after the rebuild is complete.

1. Select Start > Windows Explorer.

2. Select the drive letter where the MARS PC program is installed.

127(

This will be the C: drive for workstations running Windows 2000, and generally the D: drive for workstations running Windows NT.

Confirm Your System Box

3. Select gemsit > var > MarsNT > system.

4. Copy the .active file to a floppy disk.

127(

Confirm the .active file was actually copied to the floppy disk.

5. Place the floppy disk in a safe place. You will need to cop y the .active file back onto the system at the end of this rebuild procedure.

6. If you are reimaging a MARS PC server, please go to “Reimage

System for MARS PC Server Workstations” on page 6-15.

or If you are rebuilding a MARS PC standalone or client workstation, go

to “Confirm Yo ur Sy st em Box” on page 6-4.

1. Confirm which system box you have:

127(

If you would like further assistance, please call the MARS PC Workstation Technical Support Line at 1-800-558-7044 or 1-561-575-5000 ext. 4243.

There is a picture of the of the “Compaq EVO D510 (Front view)” on page 2-12, a picture of the “HP EVO D530 (Front view)” on page 2-15 of this manual, and a picture of the “HP dc7100 (Front view)” on page 2-18. As shown in the pictures, the Compaq EVO D510 and the HP EVO D530 are mini -tow ers with an in tern al Omni dr ive (i.e . card reader). The HP dc7100 is a mini-tower WITHOUT an internal card reader.

6-4 MARS PC Revision E

2010165-052
