Getting Started

Congratulations on your purchase of the Itronix GoBook II computer! Your new GoBook II features the most innovative advances in portable computing technology. It combines state-of-the-art ergonomics with a rugged, durable architecture to provide you with a notebook computer that is compact, powerful, rugged and easy to use. Designed for a wide range of business and personal productivity applications, the GoBook II is an ideal choice for use in applications that require durability and performance.

For maximum expandability without compromising portability, the GoBook II has a USB interface and a PC card The high capacity hard disk

The GoBook II features a standard 87-key Nitevue® keyboard (89-key international). The high-resolution 12.1-inch touch screen LCD panel provides clear and crisp viewing with the convenience of a touch screen.

This online document, GoBook II Help, contains all the information you need to set up and use your new GoBook II. It describes all the features of the GoBook II in an easy-to-read yet thorough manner. For information on printing, navigating or otherwise using GoBook II Help see How to Use This Help System

drive provides you with plenty of storage space for multimedia files and applications.

slot.

GoBook II™ Help

Checklists

7/21/2003file://C:\Documents%20and%20Settings\harwoodm.ITRXNT1\Local%20Settings\Temp\~hh20C9.ht

Page 2 of 73GoBook II Hel

After opening the package, carefully inspect the contents. Contact your dealer if any items are missing or appear damaged. The shipping carton should contain the following:

STANDARD



The Itronix GoBook II computer



Battery



ADP-90AB or ADP-75FB AC adapter with power cord



12.1 inch XGA display



Stylus



Shoulder Strap



GoBook II Quick Start Guide

OPTIONS

The following items are normally optional, but some vendors may include them in the standard package. Some items may not be available in some countries, or some vendors may choose not to carry all the items.



Floppy disk drive



CD-ROM drive



CD-RW Drive



DVD-ROM drive



SVGA display



Soft Handle



Media Bay Li-Ion battery pack (3000 mAhr)



Hard Disk Drive Heater



LCD Heater

CAUTION

When purchasing any of the accessories listed above, purchase only those accessories that are approved for use with your computer. The above accessories are proprietary items. Your system vendor can obtain these approved accessories. If you use items that are not approved for use with this computer, you may cause your computer to malfunction, or to emit or receive electromagnetic radiation in excess of local regulations. For non-proprietary accessories such as PC Cards or printers, ensure that the accessory functions properly in your computer before making

urchase. Your system vendor maybe able to recommend reliable brands and models.

the

7/21/2003file://C:\Documents%20and%20Settings\harwoodm.ITRXNT1\Local%20Settings\Temp\~hh20C9.ht

Page 3 of 73GoBook II Hel

Features

High Capacity Hard Disk Drive

The computer has a high capacity hard disk drive, enabling you to install your favorite programs and store large multimedia files.

Full Array of Ports and Connectors

Your computer includes standard ports for connecting to peripherals such as USB devices and monitors. USB ports allow you to add many types of peripherals.

Large SVGA or XGA LCD

Your computer has a large, easy to view SVGA or XGA LCD panel.

Built-in Microphone and Stereo Speakers

The stereo speakers and internal microphone enable you to run a variety of multimedia applications.

Function Keys

Function keys allow you to suspend your computer, shut the LCDs off, and give you easy control of audio and your monitor.

Where to Look For Information

About Your Computer

This Help System describes the key elements of your computer. New users can find a simple step-by-step orientation in this chapter.

About Windows

For more extensive information and help about Windows go to Help and Support Start, Programs, Accessories to open , an online orientation of Windows XP.

, found on the Start Menu. Go to

72_0103_003 10 December 2002

GoBook II™ Help

7/21/2003file://C:\Documents%20and%20Settings\harwoodm.ITRXNT1\Local%20Settings\Temp\~hh20C9.ht

Page 4 of 73GoBook II Hel

Precautions

You can use your computer under a wide range of environmental conditions. However, to ensure long use and continued high performance, consider the following factors when setting up your computer:



Follow all warnings and instructions noted in this documentation and in the Windows Help and Support, found on the Start Menu.



The first time you use your computer, we recommend that you carefully read the section on Power Management to familiarize yourself with some basic battery information and to ensure optimum performance



There is danger of explosion if the battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions.



Do not open the RAM door by yourself.



Unplug the computer from the power outlet before cleaning. Use a damp cloth for cleaning. Do not use aerosols, solvents, or strong detergents



Slots and openings in the computer case are for ventilation purposes. Do not block or cover these openings or the system could overheat



On the bottom of the GoBook II, there is a label with information on the power requirements of this system. These requirements must be followed. If you are unsure of your local power supply, consult your dealer or local Power Company



Do not step on or place anything on the power cord



If you use the computer with an extension cord, ensure that the total ampere ratings of all the devices sharing the extension do not exceed the rating of the extension cord or the rating of the wall outlet



Unless instructed, never push foreign objects into the computer through any of the slots or openings. Dangerous voltages are present, which could cause electric shock, fire, or damage sensitive components



For best results, use a power strip with a built-in surge protector. Do not use inferior extension cords as this may result in damage to your computer

72_0103_003 10 December 2002

GoBook II™ Help

7/21/2003file://C:\Documents%20and%20Settings\harwoodm.ITRXNT1\Local%20Settings\Temp\~hh20C9.ht

Page 5 of 73GoBook II Hel

The First Time. . .

Using your computer for the first time involves:



Installing the battery



Connecting the AC adapter to the computer



Turning the Computer On and Off



Adjusting the Volume

Installing the Battery

Make sure the computer is sheltered when you install the Lithium Ion battery; the computer is not weather sealed until the battery is properly installed. The battery should be fully charged before you operate the unit on battery power. To get the most from your battery, follow the guidelines in the Power Management section.

To install the battery

1. Remove the battery door.

2. Align the battery connectors and place the battery in the computer.

3. Replace the battery door and rotate the door latches to secure the door.

NOTE

When the battery is installed and the computer is connected to AC power, see Connecting the AC Adapter below, it starts charging automatically. At moderate temperatures, approximately 70° Fahrenheit (21°C), the battery will be fully charged in four to six hours. In warmer or cooler temperatures, the battery can take much longer to fully charge. Refer to the Power Management

section for additional information.

Connecting the AC Adapter

To connect the ADP-90AB or ADP-75FB AC adapter

1. Connect the AC adapter power cord to the AC adapter.

2. Connect the AC adapter to the power jack at the rear of your computer.

3. Connect the AC adapter power cord to an AC outlet.

4. Lift the display to open the LCD.

5. Open the LCD panel to a comfortable viewing angle.

6. Press the

Power Button

to turn ON the power.

Turningthe Computer On and Off

7/21/2003file://C:\Documents%20and%20Settings\harwoodm.ITRXNT1\Local%20Settings\Temp\~hh20C9.ht

Page 6 of 73GoBook II Hel

You can operate the computer while the battery is charging, while on external power , or on battery power only.

To turn on the computer



Press the

Power Button

button once, and then give the system time to respond.

To turn off the computer

1. From the Start menu, tap Shut Down.

2. Then, from the Shut Down Windows screen select Shut Down and tap OK.

If you need to leave the system for a short time, or if you want to conserve battery power, you can suspend the computer by pressingFN+F3.SeePower Management

for additional information.

Suspend to RAM

In a suspend to RAM, the contents of your computer's memory are held intact, while almost all the components in your computer either turn off completely, or reduce power consumption to a minimum. In a suspend to RAM, your computer remains active, but with a minimum possible power consumption. Return the computer to full power by pressing any key. A fully-charged battery can maintain a Suspend to RAM for many hours.

SuspendtoDisk(Hibernate)

the computer is copied to the hard disk computer returns from suspend mode

Suspend to Disk is similar to turning off the computer, except that the current state of

as a special file. In a Suspend to Disk there is no power consumption. When the

, the desktop appears with the same files and programs open as when the computer was suspended. Suspend to Disk is very useful when you don’t want to take the time to shut down all open programs one by one to shut off the computer. This mode is also called hibernation mode.

CAUTION

Shutting down the computer improperly could result in lost or corrupted data.

Adjusting the Volume

Volume for the computer is adjusted by using function key combinations.



FN+F8



FN+F9



FN+F10

decreases the volume

increases the volume

toggles the volume mute on or off

You can also adjust the volume with the Windows volume control applet, which is located on the taskbar and looks like

this .

NOTE

Adjusting the volume using the function keys produces only a slight change with each press. It may take

several presses to increase or decrease the volume to a level that you desire.

7/21/2003file://C:\Documents%20and%20Settings\harwoodm.ITRXNT1\Local%20Settings\Temp\~hh20C9.ht

Page 7 of 73GoBook II Hel

72_0103_001 10 December 2002

GoBook II™ Help

Calibrating the Touch Screen

Your GoBook II computer has a touch screen display. Follow the guidelines below to calibrate the touch screen for optimum use.

CAUTION



Always use an approved stylus or your finger.



Never use sharp, hard, or abrasive implements on the touch screen such as ball point pens, pencils, or keys.

They could damage the screen.



To clean the touch screen panel, apply a household glass cleaner to a soft, clean, dry cloth and wipe the screen.

Calibrating the touch screen

To calibrate the touch screen, open the Calibration Applet by selecting Start, Programs, Mobile Computer Tools, Touch Screen Calibrator. You can also open the Calibration Applet by selecting Start, Settings, Control Panel, Touch Screen Calibrator.

After the Calibration Applet starts, click on the Calibrate button

After you have completed calibration by touching the four highlighted points with an approved stylus, select OK to have the new settin

stakeeffect.

7/21/2003file://C:\Documents%20and%20Settings\harwoodm.ITRXNT1\Local%20Settings\Temp\~hh20C9.ht

Page 8 of 73GoBook II Hel

NOTE

be accomplished by revisiting the procedure above.

Adjusting the Screen

You can adjust the display brightness for better viewing.

Use the following keys to make adjustments:

Setting the Date and Time

To set the date and time

If you cannot select objects accurately with the stylus you may need to re-calibrate the touch screen. This can

To Do This... Press

Lighten the display

Darken the display

1. Tap the Start button, Settings, Control Panel, and double-tap the Date / Time icon.

FN+F7

FN+F6

2. From the Date / Time Properties menu, make changes to the Time and Date, and then close this screen by selecting OK.

7/21/2003file://C:\Documents%20and%20Settings\harwoodm.ITRXNT1\Local%20Settings\Temp\~hh20C9.ht

72_0103_003

pPag

10 December 2002

GoBook II™ Help

Startup Problems?

If your computer does not operate, try these solutions.



Connect the AC adapter to charge the battery if it is not charged.

e 9 of 73GoBook II Hel

NOTE

The Power LED on the AC adapter should be lit as well as the External Power Indicator on the GoBook II if the AC adapter is connected and functioning properly. Additionally, one of the power icons should appear in the task tray.



If the AC adapter is connected, make sure the electrical outlet you are using works.



Check to make sure the battery is installed and charged properly.



If the battery doesn’t begin charging, remove the battery, connect the AC adapter, and turn on the computer by pressingOn. Reinstall the battery. The Battery Power Indicator LED is solid while the battery is charging.

The

Troubleshooting

section lists additional solutions you can try.

72_0103_003 10 December 2002

Getting Familiar with Your Computer

The GoBook II computer is a ruggedized

, weather-sealed laptop computer system built for the demanding environment of the mobile worker. Designed for use by mobile workforces, this computer is a superior work tool for collecting, managing, and communicating information in the field.

The following pages describe the external and internal features of your GoBook II computer.

GoBook II™ Hel

7/21/2003file://C:\Documents%20and%20Settings\harwoodm.ITRXNT1\Local%20Settings\Temp\~hh20C9.ht

Individual Parts

The following diagrams and descriptions provide an overview of your GoBook II computer.

Hover the mouse over each number on the picture to see a description.

Front View

1. Touch Screen Display

2. Display Latches

3. Antenna

3a. Antenna (internal mini-WLAN)

Page10of73GoBook II Hel

4. Activity Indicators

5. Power Button

6. Touchpad

7. Scrolling Button

8. Touchpad Buttons

9. Power / Wireless Modem Indicators

10. Speakers

7/21/2003file://C:\Documents%20and%20Settings\harwoodm.ITRXNT1\Local%20Settings\Temp\~hh20C9.ht

Page11of73GoBook II Hel

Back View



Cooling Fan



Power Jack



15-Pin VGA Port



60-Pin Multi-IO Port



9-Pin Serial Port

6. PS2 Port

7. RJ-11 Modem Jack

8. RJ-45 Network Jack

9. USB Port

10. D-Rings

7/21/2003file://C:\Documents%20and%20Settings\harwoodm.ITRXNT1\Local%20Settings\Temp\~hh20C9.ht

Left Side View

1. PC Card Slot

2. Microphone Jack

Page12of73GoBook II Hel

3. Audio Jack

4. Stylus

Right Side View

1.Antenna

2. Media Bay - CDROM, DVD, Floppy Disk, CDRW, or Media Bay Battery

3. Radio Bay

4. Cooling Fan

5. Securit

Slot

7/21/2003file://C:\Documents%20and%20Settings\harwoodm.ITRXNT1\Local%20Settings\Temp\~hh20C9.ht

Display with Stylus

Page13of73GoBook II Hel

LED Activity Indicators

The activity indicators, located above the keyboard, light up when a particular function of the computer is active. Each indicator is marked with a corresponding symbol and is visible when the lid is open or closed. LED numbers are from left to right.

Icon & LED #

Function

Mini PCI

LED #1

Not Used

7/21/2003file://C:\Documents%20and%20Settings\harwoodm.ITRXNT1\Local%20Settings\Temp\~hh20C9.ht

LED #2

LED #3

LED #4

LED #5

LED #6

LED #7

Page14of73GoBook II Hel

Disk Status (HW)

Media Drive Bay

Number Lock

Caps Lock

Scroll Lock

LED Power / Wireless Modem Indicators

The case front LED’s indicate external power, unit ON/OFF, battery status, and wireless modem ON/OFF. The indicators remain active and viewable even when the LCD panel is closed.

Icon

Function LED

External Power

Power

Battery

Wireless Modem

Green LED off Green Flashing Green Green Flashing Green LED off Green Flashing Green LED off

72_0103_003 10 December 2002

7/21/2003file://C:\Documents%20and%20Settings\harwoodm.ITRXNT1\Local%20Settings\Temp\~hh20C9.ht

Page15of73GoBook II Hel

GoBook II™ Hel

Keyboard Basics

The keyboard on the GoBook II computer looks much like the keyboard of a typewriter and operates in almost the same way. While typewriter keys put characters on paper, the keys on the laptop enter characters in the computer and perform certain functions, depending on the application or program.

The GoBook II computer features:



87-key US keyboard; 89-key international keyboard



Twelve function keys,F1-



Embedded numeric keypad



Mouse keys and cursor control keys

F12

Restarting the Computer

Press…

CTRL+ALT+DEL

Primary Keys

. .

Arrow Ke

7/21/2003file://C:\Documents%20and%20Settings\harwoodm.ITRXNT1\Local%20Settings\Temp\~hh20C9.ht

The arrow keys are defined by the software application.

Page16of73GoBook II Hel

The

UP ARROW

selections from menus and scrollable list boxes.

The

DOWN ARROW

selections from menus and scrollable list boxes.

The

RIGHT ARROW

The

LEFT ARROW

key usually moves the cursor up one line. In some cases, you can use the up arrow to make

key usually moves the cursor down one line. In Windows, you can use the down arrow to make

key usually moves the cursor one character position to the right.

key usually moves the cursor one character position to the left.

Function Keys

Hold the

key while pressing the numbered function key.

Numeric Keypad

The numeric keypad is embedded in the keyboard area. The embedded keypad emulates the numeric keypad typically found on a full-size keyboard. It is arranged like a calculator for applications that require you to key many numbers or for use with the Calculator in the standard Windows Accessories.

Touchpad

The touchpad is a pointing device that provides all the features of a two-button mouse. Its primary function is to move the cursor around the screen.

Using Your Touchpad

Clicking

1. First, place your fingers on the keyboard in the normal typing position. The touchpad is easily accessible by moving either your left or right thumb off the space bar and on to the touchpad.

2. Gently move your thumb across the touchpad in the direction you want the cursor to move. The pad detects the

einpressure and moves the cursor in the correspondingdirection.

chan

7/21/2003file://C:\Documents%20and%20Settings\harwoodm.ITRXNT1\Local%20Settings\Temp\~hh20C9.ht

Page17of73GoBook II Hel

NOTE

The touchpad on your GoBook II computer is electrically sensitive to finger touch. It will not respond if

touched by anything other than your fingers, such as a stylus or pencil.

3. The touchpad offers another method of making selections in a software program. It is called double-tapping. This function corresponds to double-clicking with a mouse. Once the cursor has been moved to the object you want to select, lightly double-tap the pressure sensitive touchpad. This double-tapping on the touchpad will select the desired item and prompt the software to perform the related operation.

4. The left and right buttons located directly below the touchpad are the same in function as those on a twobuttoned mouse. Clicking these buttons makes selections, drags objects, or performs a variety of other functions depending on the software. To select an object, first move the pointer over the object you want to select, and then press the left button one time. The functions of these buttons are software specific.

Double-clicking



Double-clicking is a common technique for selecting objects or launching programs from icons. Once you have moved the pointer over the object you wish to select, rapidly press the left button two times. This action is commonly referred to as "double-clicking" an object.

Dragging



Move the pointer to the desired location then press down the left button. While still holding down the left button, move the pointer to the desired location. Release the button.



Move the pointer to the desired location. Tap the touchpad twice quickly as if you were double-clicking, however do not remove your finger after the second tap. Move the cursor to the desired location. Lift your finger to finish dragging.

Adjust the touchpad settings by selecting Settings/Control Panel/Mouse/Buttons. These settings allow you to change the orientation of the touchpad from right-handed to left-handed, and fine-tune the pointer movement and timing of clicks.

Touchpad Precautions

If not properly cared for the touchpad can be easily damaged. Please take note of the following precautions.



Do not rest heavy objects on the touchpad or the touchpad buttons.

General Guidelines

The mobile computer uses a Liquid Crystal Display (LCD), which is the type of screen used on many notebook and sub-notebook computers. One problem experienced on computers with an LCD display, especially in cold environments, is that the cursor seems to "disappear" whenever the mouse is moved quickly. To improve the visibility of the mouse cursor, you should use a slow or medium speed/sensitivity level.

You can combine a higher level of acceleration with a slow or medium speed/sensitivity level. This will allow you to move the mouse cursor quickly by increasing your finger pressure, while still providing a finer degree of control when you apply minimum pressure.

NOTE

to make ad

To change the speed of the mouse, from the Start Menu select Settings, Control Panel, and then choose Mouse

ustments.

7/21/2003file://C:\Documents%20and%20Settings\harwoodm.ITRXNT1\Local%20Settings\Temp\~hh20C9.ht

Page18of73GoBook II Hel

Scrolling Buttons

If you are scrolling through a document, you may it find the scrolling button more restful to your hand than holding down a mouse button. The scrolling button is located between the touchpad buttons. Push the top of the button to scroll up in a document or Web page; press the bottom of the button to scroll down.

Connecting an External Keyboard or Mouse

You can use your GoBook II computer with an optional external keyboard, numeric keypad, or IBM PS/2 compatible mouse. These devices are "hot swap" capable, which means you do not have to power down the GoBook II to connect them to the PS/2 connection located on the back of the unit.

72_0103_003 10 December 2002

GoBook II™ Help

Display Basics

XGA vs. SVGA Display

Your GoBook II computer has either an XGA (standard) or SVGA (optional) display.

XGA Display:

light from the backlight so it has excellent readability in indirect light. The XGA display is the most popular display because it is easy to read indoors and in vehicles.

SVGA Display:

superior readability in direct sunlight. It also includes a backlight to improve visibility in low light conditions such as shade, in a vehicle or indoors.

Connecting to an External Monitor

The GoBook II has a 15-Pin VGA monitor port to connect your computer to an external monitor.

Using the VGA monitor port for dual display

The XGA display is a transmissive color display designed to minimize glare and maximize transmitted

The optional SVGA display is a transflective color display designed for frequent outdoor use with

You may use an external monitor simultaneously with your GoBook II’s LCD. You may also disable the GoBook II's LCD and use the external monitor exclusivel

7/21/2003file://C:\Documents%20and%20Settings\harwoodm.ITRXNT1\Local%20Settings\Temp\~hh20C9.ht

Page19of73GoBook II Hel

1. Locate the 15-pin VGA monitor port on the back of the unit behind the IO door. Then connect the video signal cable from the external monitor to the monitor port.

2. Connect the monitor’s power cable to a power outlet and turn on the monitor.

3. If the new monitor has not automatically been detected and is not displaying what appears on your GoBook II’s LCD screen, open the Control Panel.

4. Double-tap

5. Tap the

6. Tap the

7. You can also use theFN+F2hot keys to cycle through the CRT, LCD, and CRT//LCD settings.

72_0103_003 10 December 2002

GoBook II™ Help

Display

Settings

S3DuoVue

. The Display Properties window opens.

tab. Then select the

tab and select the CRT box the enable display on an external monitor.

Advanced

button.

Disk Drives

Your computer comes with several components for reading and writing (recording) information.

TheHardDiskDrive

The hard disk provides high-capacity storage and fast access. Windows and most programs are stored here. Your GoBook II identifies the hard disk drive as drive C. For information about removing or installing the hard drive see

Hard Drive Care and Handling.

The Floppy Disk, CD-ROM, or DVD-ROM Drive

Your computer may come with a floppy disk drive. The floppy disk drive accepts 3.5-inch floppy disks and is read and write capable.

The CD-ROM drive is a read only drive. It cannot be used to write data to a recordable compact disk. The CD-ROM drive can read data from CDs, including audio or video CDs. The DVD drive can read both DVD and CD disks. Your GoBook II identifies the drive with the letter following the hard drive letter. If you hard drive is C, then the CD0-ROM drive will be D. The media ba

is located on the right side ofyour computer, asyou are facingthe display,andis

7/21/2003file://C:\Documents%20and%20Settings\harwoodm.ITRXNT1\Local%20Settings\Temp\~hh20C9.ht

accessible by sliding the two bay door latches, which release and open the door.

Inserting a CD-ROM or DVD-ROM Disk

1. Press the button on the front of the drive to open the disk tray and pull the tray open.

2. Place the disk on the tray, label side up.

3. Place the disk on the central spindle and press gently until the disk clicks into place.

4. Slide back the tray until it clicks shut.

Removing a CD-ROM or DVD-ROM Disk

1. Make sure the computer is not accessing the CD-ROM/DVD-ROM drive.

2. Press the button on the front of the drive and pull the tray all the way out.

Page20of73GoBook II Hel

3. Pick up the CD-DVD by the edges and remove the CD-ROM/DVD-ROM from the tray. Push the tray into the computer until it closes fully.

CAUTION

When the computer is reading from a CD-ROM/DVD-ROM or Floppy disk drive, the indicator light for

the drive will flash. Do not attempt to remove a disk while this light is active.

Changing your 'swappable' media bay device

1. Make sure the computer is not accessing the media bay drive.

2. Slide the door latches to release the media bay door.

3. Left click the "unplug or eject" media bay icon on the right side of the taskbar.

4. Select the media bay device and left click to stop the device.

5. Wait for the "safe to remove hardware" message.

6. Grasp the media bay device by the removal tab and pull straight out until it is clear from the slot.

7. Click OK

8. Re-insert the next media bay device by firmly pushing it back into the slot until it clicks into place.

Precautions for Handling CD-ROM/DVD-ROM Disks

theseprecautions in mind when handlingCD-ROM/DVD-ROM discs.

Kee

7/21/2003file://C:\Documents%20and%20Settings\harwoodm.ITRXNT1\Local%20Settings\Temp\~hh20C9.ht



Always hold the disc by the edges; avoid touching the surface of the disc.



Use a clean, dry, cloth to remove dust, smudges, or fingerprints. wipe from the center outward.



Do not write on the surface of the disc.



Extremes in temperature may damage discs. Store discs in a cool dry place.



Do not use benzene, thinners, or cleaners with detergent. Only use CD0-ROM/DVD-ROM cleaning kits.



Do not bend or drop the discs.



Do not place objects on top of discs.

Page21of73GoBook II Hel

CAUTION

do not insert any foreign objects into the disc tray. Do not force the tray to open or close manually. When not in use, keep the tray closed to prevent dust or dirt from entering the drive unit. If you experience difficulty when removing a CD/DVD disc, stretch a paper clip (or use a pin or a thin metal rod) and insert it into the emergency eject hole located on the front panel.

The CD/DVD disk tray should eject immediately. This procedure can also be used to remove a CD-DVD from the drive when the GoBook II is powered off.

72_0103_003 10 December 2002

GoBook II™ Help

The PC Card Slot

The PC card slot can be used as an interface between your computer and a variety of communications devices, such as network adapters, SCSI adapters, and fax/modems. They can also be used to provide additional data storage capacity. Your com

uter’s PC Card slot supports Type I, II or III PC Cards, 32-bit CardBus cards, and Zoomed Video cards.

7/21/2003file://C:\Documents%20and%20Settings\harwoodm.ITRXNT1\Local%20Settings\Temp\~hh20C9.ht

Page22of73GoBook II Hel

Installing a Card

1. The top side of a PC Card is usually identified with a label. Insert the card into the slot with the top up and the edge with pinhole contacts going in first. You will feel some resistance as the card slides into the back of the slot.

2. PC Cards require drivers, or a program that allows the operating system are included with Windows, but if not, you will be prompted to install the driver included with your card.

NOTE

while others require that the computer be turned off.

Removing a PC Card

Please read the instructions included with individual PC Cards. Some cards may be inserted with power on,

1. If a PC Card is in use, you must shut down the PC Card before removing it.

2. Select the PC Card icon on the right side of the Windows tray taskbar

3. When the Windows message appears, telling you that it is safe to remove the card, tap OK.

4. Press the eject button on the PC Card slot to release the eject button (it is spring loaded and remains hidden until it is pressed).

5. Press the eject button again to release the PC Card.

to use a specific device. Many drivers

, then tap Stop.

72_0103_003 10 December 2002

MakingConnections

7/21/2003file://C:\Documents%20and%20Settings\harwoodm.ITRXNT1\Local%20Settings\Temp\~hh20C9.ht

Page23of73GoBook II Hel

Your computer is equipped with a full array of ports and connectors, including standard input/output (I/O) ports for quickly and easily adding peripheral devices such as printers and monitors. Refer to documentation included with individual devices for details on connecting these devices to your computer. Along with the standard ports found on most computers, your computer may also include optional modem and LAN ports for advanced communications technology.

GoBook II™ Help

Rear Connectors

Hover the mouse over each number on the picture to see a description.

1 DC-in Jack

Connect the DC power cable from the AC adapter to this jack.

2 VGA Out (External Video) Port

The 15-pin monitor can connect your computer to an external monitor.

3Multi-I/OPort

The 60-pin Multi-IO port is provided so you can connect the GoBook II to an optional cradle or office dock.

4 Serial Port

The 9-pin serial port can be used to connect your computer to serial devices such a a fax/modem or a serial mouse.

ort is identified as COM1 and is 16550A compatible.

This

7/21/2003file://C:\Documents%20and%20Settings\harwoodm.ITRXNT1\Local%20Settings\Temp\~hh20C9.ht

+ 53 hidden pages

General Dynamics Itronix IX260MPIRIM902 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
