SPLIT TYPE
ROOM AIR CONDITIONER
WALL MOUNTED
type
Models Indoor unit Outdoor unit
ASG18ABA-W AOG18ANE
ASG18RBA-W AOG18RMEL
ASG24ABA-W AOG24AME
ASG24RBA-W AOG24RMEL
ASG30ABA-W AOG30AMAL
ASG30RBA-W AOG30RMAL
ASG18AGF-W A OG18AZE
ASG18RGF-W AOG18RZEL
ASG24AGF-W AOG24ABE
ASG24RGF-W AOG24RZEL
ASG30AGF-W A OG30AVAL
ASG30RGF-W AOG30R VAL
ASG24ABB-W AOG24ABE
CONTENTS
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
OUTLINE AND DIMENSIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
REFRIGERANT SYSTEM DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . 5
ERROR CONTENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
CIRCUIT DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
INDOOR PRINTED CIRCUIT BOARD CIRCUIT DIAGRAM . . . . 20
P.C. BOARD LAYOUTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
DISASSEMBLY ILLUSTRATION . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
PARTS LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Page 2
– 1 –
SPECIFICATIONS
TYPE COOL COOL & HEAT COOL COOL & HEAT COOL COOL & HEAT
INDOOR UNIT ASG18ABA-W ASG18RBA-W ASG24ABA-W ASG24RBA-W ASG30ABA-W ASG30RBA-W
OUTDOOR UNIT AOG18ANE AOG18RMEL AOG24AME AOG24RMEL AOG30AMAL AOG30RMAL
COOLING CAPACITY
(kW)
5.30 - 5.40 5.30 - 5.40 6.80 - 6.90 6.80 - 6.90 8.05 - 8.20 7.80 - 8.00
HEATING CAPACITY ----- 5.50 - 5.60 ----- 7.70 - 7.80 ----- 8.55 - 8.80
POWER SOURCE (V) 220 - 240
FREQUENCY (Hz) 50
RUNNING
(A)
COOLING 8.4 - 8.0 8.8 - 8.5 12.2 - 11.3 11.9 - 11.1 13.8 - 13.7 13.7 - 13.5
CURRENT
HEATING ----- 7.8 - 7.7 ----- 12.1 - 11.4 ----- 14.5 - 14.4
INPUT
(kW)
COOLING 1.84 - 1.89 1.89 - 1.98 2.61 - 2.65 2.60 - 2.65 2.96 - 3.08 2.93 - 3.05
WATTS
HEATING ----- 1.70 - 1.80 ----- 2.64 - 2.72 ----- 3.13 - 3.25
E.E.R. (kW/kW)
COOLING 2.88 - 2.86 2.80 - 2.73 2.61 - 2.60 2.62 - 2.60 2.72 - 2.66 2.66 - 2.62
HEATING ----- 3.24 - 3.11 ----- 2.92 - 2.87 ----- 2.73 - 2.71
MOISTURE REMOVAL ( /hr) 2.0 2.5 3.5
AIR CIRCULATION-Hi (m3/hr) 900 1,000 1,100
REFRIGERANT R-22 (g) 1,400 1,900 1,850 2,200 2,300 2,450
ELECTRICAL DATA
COMPRESSOR
FAN MOTOR
DIMENSIONS
TYPE Hermetic type, Deposit electrode condenser, 2 poles, Single phase, Induction motor
CODE 2JS318D5BA02 PH33VTTT NH44VNBT NH52VNHT
POWER SOURCE (V) 220 - 240
TYPE MFA-30HTT
INDOOR
HI-SPEED ( r.p.m. ) 1,080 1,190 1,320
UNIT
MED-SPEED ( r.p.m. ) 940 1,030 1,220
LO-SPEED ( r.p.m. ) 810 900 1,030
OUTDOOR
TYPE MFB-247FBT MFB-252TAT MFB-247FBT MFB-252TAT MFB-30DFT
UNIT
( r.p.m. ) , 735 730
INDOOR UNIT H x W x D 320 x 1,120 x 220
OUTDOOR UNIT (mm) 643 x 840 x 336 900 x 900 x 350
WEIGHT
INDOOR UNIT GROSS / NET 22 / 16
OUTDOOR UNIT (kg) 67 / 59 76 / 68 73 / 65 77 / 69 91 / 79 92 / 80
REFRIGERANT CHARGE
PIPE LENGTH 5 m 7.5 m 10 m 15 m 20 m 25 m 30 m Additional
MODELS (16 ft) (25 ft) (33 ft) (49 ft) (66 ft) (82 ft) (98 ft) refrigerant
ASG18ABA-W
1,400 g 1,450 g 1,550 g 1,650 g
-----
20 g (0.71 oz)/3.3 ft (1 m)
(49.4 oz) (51.1 oz) (54.7 oz) (58.2 oz) (over 7.5 m)
ASG18RBA-W
1,900 g 2,000 g 2,200 g 2,400 g
-----
40 g (1.41 oz)/3.3 ft (1 m)
(67.0 oz)
(70.5 oz) (77.6 oz) (84.7 oz) (over 7.5 m)
ASG24ABA-W
1,850 g 1,900 g 2,000 g 2,100 g
-----
20 g (0.71 oz)/3.3 ft (1 m)
FULL CHARGE (65.3 oz) (67.0 oz)
(70.5 oz) (74.1 oz) (over 7.5 m)
AMOUNT
ASG24RBA-W
2,200 g 2,300 g
2,500 g 2,700 g
-----
40 g (1.41 oz)/3.3 ft (1 m)
(77.6 oz) (81.1 oz) (88.2 oz) (95.2 oz) (over 7.5 m)
ASG30ABA-W
2,300 g 2,350 g 2,450 g 2,550 g 2,650 g 2,750 g 20 g (0.71 oz)/3.3 ft (1 m)
(81.1 oz) (82.9 oz) (86.4 oz) (89.9 oz)
(93.5 oz) (97.0 oz) (over 7.5 m)
ASG30RBA-W
2,450 g 2,550 g 2,750 g
2,950 g 3,150 g
-----
40 g (1.41 oz)/3.3 ft (1 m)
(86.4 oz) (89.9 oz) (97.0 oz) (104.1 oz) (111,1 oz) (over 7.5 m)
Page 3
– 2 –
TYPE COOL COOL & HEAT COOL COOL & HEAT COOL COOL & HEAT
INDOOR UNIT ASG18AGF-W ASG18RGF-W ASG24AGF-W ASG24RGF-W ASG30AGF-W ASG30RGF-W
OUTDOOR UNIT AOG18AZE AOG18RZEL AOG24ABE AOG24RZEL AOG30AVAL AOG30RVAL
COOLING CAPACITY
(kW)
5.30 - 5.40 5.30 - 5.40 6.80 - 6.90 6.80 - 6.90 8.05 - 8.20 7.80 - 8.00
HEATING CAPACITY ----- 5.50 - 5.60 ----- 7.70 - 7.80 ----- 8.55 - 8.80
POWER SOURCE (V) 220 - 240
FREQUENCY (Hz) 50
RUNNING
(A)
COOLING 9.8 - 9.4 10.6 - 10.2 12.0 - 12.3 12.6 - 12.8 14.9 - 15.5 14.6 - 15.3
CURRENT
HEATING ----- 9.2 - 9.3 ----- 12.0 - 12.3 ----- 13.7 - 14.8
INPUT
(kW)
COOLING 2.12 - 2.18 2.20 - 2.23 2.53 - 2.62 2.65 - 2.74 3.70 - 3.20 3.07 - 3.19
WATTS
HEATING ----- 1.89 - 1.94 ----- 2.51 - 2.60 ----- 2.85 - 2.96
E.E.R. (kW/kW)
COOLING 2.50 - 2.48 2.41 - 2.42 2.69 - 2.63 2.57 - 2.52 2.62 - 2.56 2.54 - 2.51
HEATING ----- 2.91 - 2.89 ----- 3.07 - 3.00 ----- 3.00 - 2.97
MOISTURE REMOVAL ( /hr) 2.0 2.5 3.0
AIR CIRCULATION-Hi (m3/hr) 900 1,000 1,100
REFRIGERANT R-22 (g) 1,300 1,900 1,950 2,050 2,350 2,450
ELECTRICAL DATA
COMPRESSOR
FAN MOTOR
DIMENSIONS
TYPE Hermetic type, Deposit electrode condenser, 2 poles, Single phase, Induction motor
CODE AWG5524EXC-4 H23B30QABKA AWG5532EXC-4 H23A42QABKA
POWER SOURCE (V) 220 - 240
TYPE MFA-30HTT
INDOOR
HI-SPEED ( r.p.m. ) 1,080 1,190 1,320
UNIT
MED-SPEED ( r.p.m. ) 940 1,030 1,220
LO-SPEED ( r.p.m. ) 810 900 1,030
OUTDOOR
TYPE MFB-247FBT MFB-252TAT MFB-247FBT MFB-252TAT MFB-30DFT
UNIT
( r.p.m. ) , 735 730
INDOOR UNIT H x W x D 320 x 1,120 x 220
OUTDOOR UNIT (mm) 643 x 840 x 336 900 x 900 x 350
WEIGHT
INDOOR UNIT GROSS / NET 22 / 16
OUTDOOR UNIT (kg) 74 / 66 76 / 68 75 / 67 76 / 68 96 / 84 97 / 85
REFRIGERANT CHARGE
PIPE LENGTH 7.5 m 10 m 15 m 20 m 25 m 30 m Additional
MODELS (25 ft) (33 ft) (49 ft) (66 ft) (82 ft) (98 ft) refrigerant
ASG18AGF-W
1,300 g 1,350 g 1,450 g 1,550 g
-----
20 g (0.71 oz)/3.3 ft (1 m)
(45.9 oz) (47.6 oz) (51.1 oz) (54.7 oz) (over 7.5 m)
ASG18RGF-W
1,900 g 2,000 g 2,200 g 2,400 g
-----
40 g (1.41 oz)/3.3 ft (1 m)
(67.0 oz)
(70.5 oz) (77.6 oz) (84.7 oz) (over 7.5 m)
ASG24AGF-W
1,950 g 2,000 g 2,100 g 2,200 g
-----
20 g (0.71 oz)/3.3 ft (1 m)
FULL CHARGE (68.8 oz) (70.5 oz)
(74.1 oz) (77.6 oz) (over 7.5 m)
AMOUNT
ASG24RGF-W
2,050 g 2,150 g
2,350 g 2,550 g
-----
40 g (1.41 oz)/3.3 ft (1 m)
(72.3 oz) (75.8 oz) (82.9 oz) (89.9 oz) (over 7.5 m)
ASG30AGF-W
2,350 g 2,400 g 2,500 g 2,600 g 2,700 g 2,800 g 20 g (0.71 oz)/3.3 ft (1 m)
(82.9 oz) (84.7 oz) (88.2 oz) (91.7 oz)
(95.2 oz) (98.8 oz) (over 7.5 m)
ASG30RGF-W
2,450 g 2,550 g 2,750 g
2,950 g 3,150 g
-----
40 g (1.41 oz)/3.3 ft (1 m)
(86.4 oz) (89.9 oz) (97.0 oz) (104.1 oz) (111.1 oz) (over 7.5 m)
Page 4
– 3 –
REFRIGERANT CHARGE
PIPE LENGTH 5 m 7.5 m 10 m 15 m 20 m Additional
MODEL (16 ft) (25 ft) (33 ft) (49 ft) (66 ft) refrigerant
FULL CHARGE
ASG24ABB-W
1,950 g 2,000 g 2,100 g 2,200 g 20 g (0.71 oz) / 3.3 ft (1 m)
AMOUNT (68.8 oz) (70.5 oz) (74.1 oz) (77.6 oz) (over 7.5 m)
TYPE COOL
INDOOR UNIT
ASG24ABB-W
OUTDOOR UNIT
AOG24ABE
COOLING CAPACITY (kW) 6.80 - 6.90
POWER SOURCE (V) 220 - 240
FREQUENCY (Hz) 50
RUNNING CURRENT (A) 12.0 - 12.3
INPUT WATTS (kW) 2.53 - 2.62
E.E.R. (kW/kW) 2.69 - 2.63
MOISTURE REMOVAL ( /hr) 2.5
AIR CIRCULATION-Hi (m3/hr) 1,000
REFRIGERANT R-22 (g) 1,950
ELECTRICAL DATA
COMPRESSOR
FAFAN MOTOR
DIMENSIONS
TYPE Hermetic type, Deposit electrode condenser, 2 poles, Single phase, Induction motor
CODE H23B30QABKA
POWER SOURCE (V) 220 - 240
TYPE MFA-30HTT
HI-SPEED (r.p.m.) 1,190
INDOOR UNIT
MED-SPEED (r.p.m.) 1,030
LO-SPEED (r.p.m.) 900
OUTDOOR UNIT
TYPE MFB-247FBT
(r.p.m.) 735
INDOOR UNIT
H x W x D (mm)
320 x 1,120 x 220
OUTDOOR UNIT 643 x 840 x 336
WEIGHT
INDOOR UNIT
GROSS / NET (kg)
22 / 16
OUTDOOR UNIT 73 / 65
Page 5
OUTLINE AND DIMENSIONS
Models : ASG18ABA-W, ASG18RBA-W ASG18AGF-W, ASG18RGF-W ASG24ABB-W
ASG24ABA-W, ASG24RBA-W ASG24AGF-W, ASG24RGF-W
ASG30ABA-W, ASG30RBA-W ASG30AGF-W, ASG30RGF-W
Unit : mm
321
Models : AOG18ANE, AOG18RMEL
AOG24AME, AOG24RMEL
AOG18AZE, AOG18RZEL
AOG24ABE, AOG24RZEL
1,120
224
626
711
626
711
Models : AOG30AMAL
AOG30RMAL
AOG30AVAL
AOG30RVAL
643
333
25
840
804
336
350
900
900
930
333
19
804
– 4 –
Page 6
Error
The OPERATION, TIMER and SWING lamps operate as follows according to the error contents.
Error display
OPERATION TIMER SWING
(RED) (GREEN) (ORANGE)
Error contents
Indoor unit circuit board error
Indoor unit room temperature sensor wire
opened
Indoor unit room temperature sensor wire
short circuited
Indoor unit piping sensor wire opened
Indoor unit piping sensor wire short circuited
Indoor unit fan error
2 times
2 times
3 times
3 times
6 times
:
Fast flashing
:
Slow flashing
:
Off
ERROR CONTENTS
– 11 –
Page 7
CIRCUIT DIAGRAM
WHITE
WHITE
WHITE
BROWN
BROWN
BLUE
BLUE
WHITE
C
R
S
BLACK
WHITE
BLACK
BLACK
RED
RED
(PIPE TEMP.)
GRAY
GRAY
WHITE
GREEN
GRAY
GRAY
GRAY
FM
(ROOM TEMP.)
(RIGHT/ LEFT)
(UP/DOWN)
BLACK
BLACK
WHITE
WHITE
WHITE
BLACK
BLUE
RED
RED
BLACK
GRAY
GRAY
GRAY
GRAY
YELLOW
PINK
GRAY
GRAY
GRAY
GRAY
GRAY
GRAY
GRAY
PURPLE
PURPLE
PURPLE
GRAY
GRAY
GRAY
GRAY
GRAY
(DIFFUSER)
GRAY
GRAY
GRAY
GRAY
RED
PINK
M
M
M
GREEN/
YELLOW
GREEN/
YELLOW
L
N
6
5
4
1
OUTDOOR UNIT
INDOOR UNIT
FAN MOTOR
FUSE 5A
TERMINAL
FAN MOTOR
CAPACITOR
COMPRESSOR
CAPACITOR
COMPRESSOR
FAN MOTOR
CAPACITOR
THERMISTOR
FAN
MOTOR
TERMINAL
THERMISTOR
STEP
MOTOR
STEP
MOTOR
STEP
MOTOR
TRANSFORMER
CONTROL BOARD
DISPLAY BOARD
CN4
CN5
CN11CN10CN7CN6
CN3
CN9CN2 CN1
CN201
THERMAL
FUSE 102
(L) (N)LN 312
THERMAL
PROTECTOR
INTERNAL
OVERLOAD
PROTECTOR
2
2
1
1
21
3
3
4
4
5
5
6
6
7
7
2
2
1
1
3
3
22113
3
221
1
776
6
221133445
5
7
7
8
8
8
8
6
6
221133445
5
22113
3
221133445
5
221
1
889910
10
776
6
221133445
5
221
1
221133445
5
221133445
5
221133445
5
(N)
123
TO POWER SOURCE
FUSE T 3. 15A 250V
MAIN RELAY
Models : ASG18ABA-W / AOG18ANE
ASG24ABA-W / AOG24AME
– 12 –
Page 8
C
R
S
WHITE
WHITE
BLACK
RED
BLACK
BLUE
BLUE
WHITE
WHITE
BLACK
SV
BLACK
RED
BLUE
BLACK
BROWN
WHITE
BROWN
(PIPE TEMP.)
GRAY
GRAY
WHITE
BROWN
GREEN
GRAY
GRAY
GRAY
FM
(ROOM TEMP.)
(RIGHT/ LEFT)
(UP/DOWN)
BLACK
BLACK
WHITE
WHITE
WHITE
BLACK
BLUE
RED
BLUE
RED
RED
BLACK
GRAY
GRAY
GRAY
GRAY
YELLOW
PINK
GRAY
GRAY
GRAY
GRAY
GRAY
GRAY
GRAY
PURPLE
PURPLE
PURPLE
GRAY
GRAY
GRAY
GRAY
GRAY
(DIFFUSER)
GRAY
GRAY
GRAY
GRAY
RED
PINK
4 5 6
M
M
M
GREEN/
YELLOW
L
N
6
5
4
1
FAN MOTOR
FUSE
5A
TERMINAL
FAN MOTOR
CAPACITOR
COMPRESSOR
CAPACITOR
COMPRESSOR
FAN MOTOR
CAPACITOR
THERMISTOR
FAN
MOTOR
TERMINAL
THERMISTOR
STEP
MOTOR
STEP
MOTOR
STEP
MOTOR
TRANSFORMER
CONTROL BOARD
DISPLAY BOARD
CN4
CN5
CN11CN10CN7CN6
CN3
CN9CN2 CN1
CN201
THERMAL
FUSE 102
(L) (N)
LN 312
THERMAL
PROTECTOR
INTERNAL
OVERLOAD
PROTECTOR
2
2
1
1
21
3
3
4
4
5
5
6
6
7
7
2
2
1
1
3
3
22113
3
221
1
776
6
221133445
5
7
7
8
8
8
8
6
6
221133445
5
22113
3
221133445
5
221
1
889910
10
776
6
221133445
5
221
1
221133445
5
221133445
5
221133445
5
(N)
123
TO POWER SOURCE
FUSE T 3. 15A 250V
4-WAY
VALVE COIL
456
OUTDOOR UNIT
INDOOR UNIT
MAIN RELAY
Models :
ASG18RBA-W / A OG18RMEL
ASG24RBA-W / A OG24RMEL
– 13 –
Page 9
(PIPE TEMP.)
GRAY
GRAY
WHITE
GREEN
GREEN/
YELLOW
GRAY
GRAY
RELAY
(ROOM TEMP.)
BLACK
BLACK
GRAY
GRAY
GRAY
GRAY
PINK
GRAY
GRAY
GRAY
GRAY
GRAY
GRAY
GRAY
GRAY
GRAY
GRAY
BLACK
BLUE
BROWN
RED
RED
PINK
N
L
(RIGHT/ LEFT)
(UP/DOWN)
(DIFFUSER)
M
M
M
OUTDOOR UNIT
INDOOR UNIT
THERMISTOR
TERMINAL
THERMISTOR
STEP
MOTOR
STEP
MOTOR
STEP
MOTOR
CONTROL BOARD
CN11CN10CN7CN6
CN 8
CN3
THERMAL
FUSE 102
22113
3
22113
3
221133445
5
221
1
889910
10
776
6
221133445
5
221
1
221133445
5
221133445
5
221133445
5
12
FUSE T 3. 15A 250V
C
R
S
(N)
RED
RED
BLACK
BLACK
WHITE
WHITE
WHITE
WHITE
1
2
FAN
MOTOR
TERMINAL
FAN MOTOR
CAPACITOR
COMPRESSOR
CAPACITOR
COMPRESSOR
INTERNAL
OVERLOAD
PROTECTOR
GREEN/
YELLOW
THERMAL
PROTECTOR
RED
GRAY
GRAY
GRAY
GRAY
GRAY
GRAY
GRAY
PURPLE
PURPLE
PURPLE
RED
TRANSFORMER
DISPLAY BOARD
CN9CN2 CN1
CN201
22113
3
221
1
776
6
221133445
5
7
7
8
8
8
8
6
6
221133445
5
FM
BLACK
WHITE
WHITE
WHITE
BLUE
RED
YELLOW
GREEN/
YELLOW
FAN MOTOR
CAPACITOR
FAN MOTOR
CN4
CN5
2
2
1
1
21
3
3
4
4
5
5
6
6
7
7
22113
3
Models : ASG18AGF-W / AOG18AZE
ASG24AGF-W / AOG24ABE
ASG24ABB-W / AOG24ABE
– 14 –
Page 10
(PIPE TEMP.)
GRAY
GRAY
WHITE
GREEN
GREEN/
YELLOW
GRAY
GRAY
RELAY
(ROOM TEMP.)
BLACK
BLACK
GRAY
GRAY
GRAY
GRAY
PINK
GRAY
GRAY
GRAY
GRAY
GRAY
GRAY
GRAY
GRAY
GRAY
GRAY
BLACK
BLUE
BROWN
RED
RED
PINK
N
L
(RIGHT/ LEFT)
(UP/DOWN)
(DIFFUSER)
M
M
M
OUTDOOR UNIT
INDOOR UNIT
THERMISTOR
THERMISTOR
STEP
MOTOR
STEP
MOTOR
STEP
MOTOR
CONTROL BOARD
CN11CN10CN7CN6
CN 8
CN3
22113
3
22113
3
221133445
5
221
1
889910
10
776
6
221133445
5
221
1
221133445
5
221133445
5
221133445
5
FUSE T 3. 15A 250V
RED
GRAY
GRAY
GRAY
GRAY
GRAY
GRAY
GRAY
PURPLE
PURPLE
PURPLE
RED
TRANSFORMER
DISPLAY BOARD
CN9CN2 CN1
CN201
22113
3
221
1
776
6
221133445
5
7
7
8
8
8
8
6
6
221133445
5
FM
BLACK
WHITE
WHITE
WHITE
BLUE
RED
YELLOW
GREEN/
YELLOW
FAN MOTOR
CAPACITOR
FAN MOTOR
CN4
CN5
2
2
1
1
21
3
3
4
4
5
5
6
6
7
7
22113
3
BLUE
BROWN
RED
TERMINAL
THERMAL
FUSE 102
1234 5
(N)
GREEN/YELLOW
C
R
S
(N)
SV
RED
RED
BLACK
BLUE
BLACK
BLACK
BLACK
WHITE
WHITE
WHITE
WHITE
1
2345
FAN
MOTOR
TERMINAL
FAN MOTOR
CAPACITOR
COMPRESSOR
INTERNAL
OVERLOAD
PROTECTOR
4-WAY VALVE
THERMAL
PROTECTOR
COMPRESSOR
CAPACITOR
Models :
ASG18RGF-W / AOG18RZEL
ASG24RGF-W / AOG24RZEL
– 15 –
Page 11
(PIPE TEMP.)
GRAY
GRAY
WHITE
GREEN
GRAY
GRAY
GRAY
FM
(ROOM TEMP.)
(RIGHT/ LEFT)
(UP/DOWN)
BLACK
BLACK
WHITE
WHITE
WHITE
BLACK
BLUE
RED
RED
BLACK
GRAY
GRAY
GRAY
GRAY
YELLOW
PINK
GRAY
GRAY
GRAY
GRAY
GRAY
GRAY
GRAY
PURPLE
PURPLE
PURPLE
GRAY
GRAY
GRAY
GRAY
GRAY
(DIFFUSER)
GRAY
GRAY
GRAY
GRAY
RED
PINK
M
M
M
GREEN/
YELLOW
L
N
C
RS
BLACK
BLACK
BLACK
BLUE
RED
BLACK
RED
GREEN/YELLOW
BLACK
BLACK
BROWN
BROWN
WHITE
WHITE
WHITE
WHITE
WHITE
6
5
4
1
H
L
C
FAN
MOTOR
FUSE
5A
TERMINAL
FAN MOTOR
CAPACITOR
COMPRESSOR
CAPACITOR
COMPRESSOR
MAIN RELAY
FAN MOTOR
CAPACITOR
THERMISTOR
FAN
MOTOR
TERMINAL
THERMISTOR
STEP
MOTOR
STEP
MOTOR
STEP
MOTOR
TRANSFORMER
CONTROL BOARD
DISPLAY BOARD
CN4
CN5
CN11CN10CN7CN6
CN3
CN9CN2 CN1
CN201
THERMAL
FUSE 102
(L) (N)LN 312
THERMAL
PROTECTOR
INTERNAL
OVERLOAD
PROTECTOR
2
2
1
1
21
3
3
4
4
5
5
6
6
7
7
2
2
1
1
3
3
22113
3
221
1
776
6
221133445
5
7
7
8
8
8
8
6
6
221133445
5
22113
3
221133445
5
221
1
889910
10
776
6
221133445
5
221
1
221133445
5
221133445
5
221133445
5
(N)
123
FUSE T 3. 15A 250V
CONNECTOR
OUTDOOR
THERMOSTAT
OUTDOOR UNIT
INDOOR UNIT
TO POWER SOURCE
Models :
ASG30ABA-W / A OG30AMAL
– 16 –
Page 12
(PIPE TEMP.)
GRAY
GRAY
WHITE
BROWN
GREEN
GRAY
GRAY
GRAY
FM
(ROOM TEMP.)
(RIGHT/ LEFT)
(UP/DOWN)
BLACK
BLACK
WHITE
WHITE
WHITE
BLACK
BLUE
RED
BLUE
RED
RED
BLACK
GRAY
GRAY
GRAY
GRAY
YELLOW
PINK
GRAY
GRAY
GRAY
GRAY
GRAY
GRAY
GRAY
PURPLE
PURPLE
PURPLE
GRAY
GRAY
GRAY
GRAY
GRAY
(DIFFUSER)
GRAY
GRAY
GRAY
GRAY
RED
PINK
M
M
M
GREEN/
YELLOW
L
N
C
RS
BLACK
BLACK
BLACK
BLUE
RED
SV
BLACK BLACK
RED
BLACK
BLACK
BROWN
BROWN
WHITE
WHITE
WHITE
WHITE
WHITE
6
5
4
1
FAN
MOTOR
FUSE
5A
TERMINAL
FAN MOTOR
CAPACITOR
COMPRESSOR
CAPACITOR
COMPRESSOR
MAIN
RELAY
FAN MOTOR
CAPACITOR
THERMISTOR
FAN
MOTOR
TERMINAL
THERMISTOR
STEP
MOTOR
STEP
MOTOR
STEP
MOTOR
TRANSFORMER
CONTROL BOARD
DISPLAY BOARD
CN4
CN5
CN11CN10CN7CN6
CN3
CN9CN2 CN1
CN201
THERMAL
FUSE 102
(L) (N)
LN 312
THERMAL
PROTECTOR
INTERNAL
OVERLOAD
PROTECTOR
2
2
1
1
21
3
3
4
4
5
5
6
6
7
7
2
2
1
1
3
3
22113
3
221
1
776
6
221133445
5
7
7
8
8
8
8
6
6
221133445
5
22113
3
221133445
5
221
1
889910
10
776
6
221133445
5
221
1
221133445
5
221133445
5
221133445
5
(N)
123
FUSE T 3. 15A 250V
4-WAY
VALVE COIL
456
456
CONNECTOR
OUTDOOR UNIT
INDOOR UNIT
TO POWER SOURCE
Models :
ASG30RBA-W / A OG30RMAL
– 17 –
Page 13
(PIPE TEMP.)
GRAY
GRAY
WHITE
GREEN
GRAY
GRAY
GRAY
FM
(ROOM TEMP.)
(RIGHT/ LEFT)
(UP/DOWN)
BLACK
BLACK
WHITE
WHITE
WHITE
BLACK
BLUE
RED
RED
BLACK
GRAY
GRAY
GRAY
GRAY
YELLOW
PINK
GRAY
GRAY
GRAY
GRAY
GRAY
GRAY
GRAY
PURPLE
PURPLE
PURPLE
GRAY
GRAY
GRAY
GRAY
GRAY
(DIFFUSER)
GRAY
GRAY
GRAY
GRAY
RED
PINK
M
M
M
GREEN/
YELLOW
L
N
FAN MOTOR
CAPACITOR
THERMISTOR
FAN
MOTOR
TERMINAL
THERMISTOR
STEP
MOTOR
STEP
MOTOR
STEP
MOTOR
TRANSFORMER
CONTROL BOARD
DISPLAY BOARD
CN4
CN5
CN11CN10CN7CN6
CN3
CN9CN2 CN1
CN201
THERMAL
FUSE 102
2
2
1
1
21
3
3
4
4
5
5
6
6
7
7
2
2
1
1
3
3
22113
3
221
1
776
6
221133445
5
7
7
8
8
8
8
6
6
221133445
5
22113
3
221133445
5
221
1
889910
10
776
6
221133445
5
221
1
221133445
5
221133445
5
221133445
5
(N)
123
FUSE T 3. 15A 250V
OUTDOOR UNIT
INDOOR UNIT
C
RS
BLACK
BLACK
BLACK
BLUE
RED
BLACK
RED
GREEN/YELLOW
BLACK
BLACK
BROWN
BROWN
WHITE
WHITE
WHITE
WHITE
WHITE
6
5
4
1
H
L
C
FAN MOTOR
FUSE
5A
TERMINAL
FAN MOTOR
CAPACITOR
COMPRESSOR
CAPACITOR
COMPRESSOR
MAIN RELAY
(L) (N)
LN 312
THERMAL
PROTECTOR
INTERNAL
OVERLOAD
PROTECTOR
CONNECTOR
OUTDOOR
THERMOSTAT
TO POWER SOURCE
Models :
ASG30AGF-W / AOG30A VAL
– 18 –
Page 14
(PIPE TEMP.)
GRAY
GRAY
WHITE
BROWN
GREEN
GRAY
GRAY
GRAY
FM
(ROOM TEMP.)
(RIGHT/ LEFT)
(UP/DOWN)
BLACK
BLACK
WHITE
WHITE
WHITE
BLACK
BLUE
RED
BLUE
RED
RED
BLACK
GRAY
GRAY
GRAY
GRAY
YELLOW
PINK
GRAY
GRAY
GRAY
GRAY
GRAY
GRAY
GRAY
PURPLE
PURPLE
PURPLE
GRAY
GRAY
GRAY
GRAY
GRAY
(DIFFUSER)
GRAY
GRAY
GRAY
GRAY
RED
PINK
M
M
M
GREEN/
YELLOW
L
N
FAN MOTOR
CAPACITOR
THERMISTOR
FAN
MOTOR
TERMINAL
THERMISTOR
STEP
MOTOR
STEP
MOTOR
STEP
MOTOR
TRANSFORMER
CONTROL BOARD
DISPLAY BOARD
CN4
CN5
CN11CN10CN7CN6
CN3
CN9CN2 CN1
CN201
THERMAL
FUSE 102
THERMAL
PROTECTOR
INTERNAL
OVERLOAD
PROTECTOR
2
2
1
1
21
3
3
4
4
5
5
6
6
7
7
2
2
1
1
3
3
22113
3
221
1
776
6
221133445
5
7
7
8
8
8
8
6
6
221133445
5
22113
3
221133445
5
221
1
889910
10
776
6
221133445
5
221
1
221133445
5
221133445
5
221133445
5
(N)
123
FUSE T 3. 15A 250V
456
OUTDOOR UNIT
INDOOR UNIT
TO POWER SOURCE
CONNECTOR
BELT
HEATER
C
RS
BLACK
BLACK
BLUE
BLUE
RED
SV
BLACK
RED
BLACK
BLACK
BLACK
BLUE
BLUE
BROWN
BLUE
BROWN
BROWN
WHITE
WHITE
WHITE
WHITE
WHITE
WHITE
6
5
58
4
1
17
4-WAY VALVE
FAN
MOTOR
FUSE
5A
TERMINAL
FAN MOTOR
CAPACITOR
COMPRESSOR
CAPACITOR
COMPRESSOR
MAIN RELAY
(L) (N)
LN 312
CONNECTOR
456
RELAY
Models :
ASG30RGF-W / AOG30RV AL
– 19 –
Page 15
C12
0.1
<F>
R3
1.0K <1/10W>
CN4
B4P7S-VH-B
D4 D1F60
+
C8
10/25V
R1 10K
<1/2W>
D2
MTZJ15C
14V
R2 10K
<1/4W>
Q1
2SD1191
D3
D1F60
+
C9
10/
25V
+
C10
1000
/25V
5V
5V
IC2
7805
C11
0.1
<F>
C14
100
/25V
+
C15
0.1
<F>
IO
G
C13
1000P
<R>
14V
NC
NC
R4 4.7K
<1/10W>
Q2
DTC124EUA
R5
10K
<1/10W>
10K x 2
<1/10W>
R45
R46
IC5 (5/7)
uPA2003
SSR1
G3MC
201PL-VD
+
-
K 1
K1
JQ1-12V
14V
K 5
VA3
470V <TNR>
CN1
B2P3-VH-B
W6
COMP
K5
G5NB-1A
E1
W2
C2
0.22 <RE>
C5
C6
0.022 x 2
<YE>
N
L
W1
FH1
FH2
F1
3.15A
<BET>
SA1
RA-362M
VA2
470V
<TNR>
VA1
470V <TNR>
C1
0.22 <RE>
5V
5V
C22
0.1
<F>
R12
10K <1/10W>
IC3
BR93LC46
5V
LF1
ELF17N015A
10K x 3
<1/10W>
R22
R24
R23
JM3
JM2
JM1
R21
R20
R19
1.0K x 3
<1/10W>
C27
C28
C26
0.01 x 3
<B>
1.0K x 3
<1/10W>
R17
R18
R16
JM6
JM5
JM4
1.0K x 3
<1/10W>
R15
R14
R13
C24
C23
C25
0.01 x 3
<B>
X1
5.00MHz
<CSTS>
69
70
61
33
67
4
55
54
53
58
57
56
13
12
11
10
20
19
23
22
52
51
9
8
64
80
78
73
7
75
68
74
59
63
49
47
46
45
76
77
27
28
29
30
31
32
34
35
40
41
42
43
71
65
17
16
15
14
50
60
VCC
NC
NC
GND
D0
D1
SK
CS
4
3
2
1
8
7
6
5
C21
RC4
RC3
RC2
1000P x 4
<R>
Q3
2SC982
D6
DA226U
R6
10K
<1/10W>
R7
10K
<1/10W>
15
16
13
14
12
3
5
4
1
2
CN3 B3B-XASK-1-A
D1
D2SB20
C7
2200
/50V
+
CN2
B2B-XARK-1-A
SECONDARY
PRIMARY
POWER
TRANSFORMER
EZ-0018HSE-T
IC6 (7/7)
uPA2003
C34
1000P
<R>
C33
1000P
<R>
R27
1.0K <1/10W>
R28
1.0K <1/10W>
R25
10K
<1/10W>
(1%)
R26
49.9K
<1/10W>
(1%)
C30
0.1
<F>
C29
0.1
<F>
5V
DTC124EUA x 3
Q7
Q6
Q5
Q4
DTA143
C35
1000P <R>
R42 47 <1/10W>
C36
0.01 <B>
R41 1.0K <1/10W>
5V
10K x 2
<1/10W>
R40
R39
+
C42
10/
25V
C41
0.01
<F>
CN9
S08B-PASK-2
CN10
B2B-XASK-1-A
CN11
B2B-XAKK-1-A
14V
CN6
S10B-PASK-2
14V
IC7 (4/7)
uPA2003
CN7
S05B-PASK-2
5V
10K x 4
<1/10W>
CN13
BS5P-SHF-1AA
R37
R38
R36
R35
R31
R32
R33
R34
1.0K x 4
<1/10W>
14V
11
14
13
12
6
5
4
3
14
15
16
10
13
12
10
11
1
6
5
4
3
2
7
7
IC7 (1/7)
uPA2003
R11
RC1
10K
<1/10W>
C37
C38
C39
C40
0.01 x 4
<B>
5V
C17
0.1 <F>
IC4
PST600C
5V
R8 10K
<1/10W>
C16
0.1 <F>
IC7-1
uPA2003
O
I
G
R44 1.0K
<1/10W>
R43 1.0K
<1/10W>
116
BZ1
PKM13EPY-4000-TF01
B Z
TEST
1-1
1-3
GRAY
UL1015 AWG22
UL1015
AWG16
GREEN
WHITE
BLACK
UL1015
AWG14
UL1015
AWG14
TERMINAL
BOARD
1
2
3
OUTDOOR UNIT
JM1 : FAN SWITCHING
JM2 : CUSTOM CODE SWITCHING-1
JM3 : CUSTOM CODE SWITCHING-2
JM4 : AUTO RESTART SWITCHING
JM5 : ROOM TEMPERATURE CORRECTION
( HEATING OPERATION )
JM6 : ROOM TEMPERATURE CORRECTION
( HEATING OPERATION )
13-1
13-2
13-3
13-4
13-5
7-1
7-2
7-3
7-4
7-5
6-1
6-2
6-3
6-4
6-5
6-6
6-7
6-8
6-9
6-10
11-1
11-2
10-2
10-1
9-1
9-2
9-3
9-4
9-5
9-6
9-7
9-8
UL1430
AWG26
GRAY
GRAY
GRAY
GRAY
GRAY
GRAY
GRAY
PURPLE
BLACK
BLACK
GRAY
GRAY
PINK
UL1061
AWG26
GRAY
GRAY
GRAY
GRAY
GRAY
GRAY
GRAY
GRAY
GRAY
UL1061
AWG26
PINK
GRAY
GRAY
GRAY
GRAY
CN201 S08B-PASK-2
C201
0.1
<F>
5V
C202
10/
25V
+
SLR-325 x 3
C203
0.01
<F>
5V
R204
R203
R201
D202
SLR-325
<RED>
R202
330 x 4 <1/4W>
D204
<ORG>
D201 <ORG>
D203 <GRN>
PHA201
SBX1810
VCC
OUT
GND1
GND2
SW201
EVQ-PAG-04K
201-1
201-2
201-3
201-4
201-5
201-6
201-7
201-8
ROOM TEMPERATURE THERMISTOR
PIPE TEMPERATURE THERMISTOR
INDICATOR PCB
EZ-0018HSE-D
I C 1
uPD780058
(uPD78F0058)
-A14-9EU
CONTROLLER PCB ASSEMBLY ( MAIN PCB )
ASG24ABA-W : EZ-001CWSE-C
ASG18ABA-W : EZ-001TWSE-C
ASG30ABA-W : EZ-001SWSE-C
ASG30AGF-W : EZ-001SWSE-C
UL1015
AWG20
RED
BLUE
RED
WHITE
GRAY
GRAY
RED
RED
3-3
3-1
2-1
2-2
YELLOW
BLACK
WHITE
WHITE
FAN CAPACITOR
1.3 uF
UL1015 AWG22
PURPLE
UL1015 AWG22 PURPLE
UL1015
AWG20
31
UL1430 AWG22
UL1430 AWG22
THRMAL FUSE
FAN
MOTOR
4-1
4-2
4-3
4-4
DIFFUSER
FLAP
U - D
LOUVER
L - R
Models : ASG18ABA-W
ASG24ABA-W
ASG30ABA-W
ASG30AGF-W
INDOOR PRINTED CIRCUIT BOARD
CIRCUIT DIAGRAM
– 20 –
Page 16
C12
0.1
<F>
R3
1.0K <1/10W>
CN4
B4P7S-VH-B
D4 D1F60
+
C8
10/25V
R1 10K
<1/2W>
D2
MTZJ15C
14V
R2 10K
<1/4W>
Q1
2SD1191
D3
D1F60
+
C9
10/
25V
+
C10
1000
/25V
5V
5V
IC2
7805
C11
0.1
<F>
C14
100
/25V
+
C15
0.1
<F>
IO
G
C13
1000P
<R>
14V
NC
NC
R4 4.7K
<1/10W>
Q2
DTC124EUA
R5
10K
<1/10W>
10K x 2
<1/10W>
R45
R46
IC5 (5/7)
uPA2003
SSR1
G3MC
201PL-VD
+
-
K 1
K1
JQ1-12V
14V
K 5
K 4
K 3
K 2
VA3
470V <TNR>
CN1
B2P3-VH-B
W6
COMP
K5
G5NB-1A
E1
W2
C2
0.22 <RE>
C5
C6
0.022 x 2
<YE>
N
L
W1
FH1
FH2
F1
3.15A
<BET>
SA1
RA-362M
VA2
470V
<TNR>
VA1
470V <TNR>
C1
0.22 <RE>
5V
W5
W3
4WV
H I
LO
W4
K4
G5NB-1A
CR2
120/0.2
CR2
120/0.2
K2
G5NB-1A
K3
JQ1-12V
5V
C22
0.1
<F>
R12
10K <1/10W>
IC3
BR93LC46
5V
LF1
ELF17N015A
10K x 3
<1/10W>
R22
R24
R23
JM3
JM2
JM1
R21
R20
R19
1.0K x 3
<1/10W>
C27
C28
C26
0.01 x 3
<B>
1.0K x 3
<1/10W>
R17
R18
R16
JM6
JM5
JM4
1.0K x 3
<1/10W>
R15
R14
R13
C24
C23
C25
0.01 x 3
<B>
X1
5.00MHz
<CSTS>
69
70
61
33
67
4
55
54
53
58
57
56
13
12
11
10
20
19
23
22
52
51
9
8
64
80
78
73
7
75
68
74
59
63
49
47
46
45
76
77
27
28
29
30
31
32
34
35
40
41
42
43
71
65
17
16
15
14
50
60
VCC
NC
NC
GND
D0
D1
SK
CS
4
3
2
1
8
7
6
5
C21
RC4
RC3
RC2
1000P x 4
<R>
Q3
2SC982
D6
DA226U
R6
10K
<1/10W>
R7
10K
<1/10W>
15
16
13
14
12
3
5
4
1
2
CN3 B3B-XASK-1-A
D1
D2SB20
C7
2200
/50V
+
CN2
B2B-XARK-1-A
SECONDARY
PRIMARY
POWER
TRANSFORMER
EZ-0018HSE-T
IC6 (7/7)
uPA2003
C34
1000P
<R>
C33
1000P
<R>
R27
1.0K <1/10W>
R28
1.0K <1/10W>
R25
10K
<1/10W>
(1%)
R26
49.9K
<1/10W>
(1%)
C30
0.1
<F>
C29
0.1
<F>
5V
DTC124EUA x 3
Q7
Q6
Q5
Q4
DTA143
C35
1000P <R>
R42 47 <1/10W>
C36
0.01 <B>
R41 1.0K <1/10W>
5V
10K x 2
<1/10W>
R40
R39
+
C42
10/
25V
C41
0.01
<F>
CN9
S08B-PASK-2
CN10
B2B-XASK-1-A
CN11
B2B-XAKK-1-A
14V
CN6
S10B-PASK-2
14V
IC7 (4/7)
uPA2003
CN7
S05B-PASK-2
5V
10K x 4
<1/10W>
CN13
BS5P-SHF-1AA
R37
R38
R36
R35
R31
R32
R33
R34
1.0K x 4
<1/10W>
14V
11
14
13
12
6
5
4
3
14
15
16
10
13
12
10
11
1
6
5
4
3
2
7
7
IC7 (1/7)
uPA2003
R11
RC1
10K
<1/10W>
C37
C38
C39
C40
0.01 x 4
<B>
5V
C17
0.1 <F>
IC4
PST600C
5V
R8 10K
<1/10W>
C16
0.1 <F>
IC7-1
uPA2003
O
I
G
R44 1.0K
<1/10W>
R43 1.0K
<1/10W>
116
BZ1
PKM13EPY-4000-TF01
B Z
TEST
1-1
1-3
GRAY
UL1015 AWG22
UL1015
AWG16
GREEN
WHITE
BLACK
UL1015
AWG14
UL1015
AWG14
RED
BLUE
BROWN
UL1015
AWG22
UL1015
AWG22
UL1015
AWG22
TERMINAL
BOARD
1
2
3
4
5
6
OUTDOOR UNIT
JM1 : FAN SWITCHING
JM2 : CUSTOM CODE SWITCHING-1
JM3 : CUSTOM CODE SWITCHING-2
JM4 : AUTO RESTART SWITCHING
JM5 : ROOM TEMPERATURE CORRECTION
( HEATING OPERATION )
JM6 : ROOM TEMPERATURE CORRECTION
( HEATING OPERATION )
13-1
13-2
13-3
13-4
13-5
7-1
7-2
7-3
7-4
7-5
6-1
6-2
6-3
6-4
6-5
6-6
6-7
6-8
6-9
6-10
11-1
11-2
10-2
10-1
9-1
9-2
9-3
9-4
9-5
9-6
9-7
9-8
UL1430
AWG26
GRAY
GRAY
GRAY
GRAY
GRAY
GRAY
GRAY
PURPLE
BLACK
BLACK
GRAY
GRAY
PINK
UL1061
AWG26
GRAY
GRAY
GRAY
GRAY
GRAY
GRAY
GRAY
GRAY
GRAY
UL1061
AWG26
PINK
GRAY
GRAY
GRAY
GRAY
CN201 S08B-PASK-2
C201
0.1
<F>
5V
C202
10/
25V
+
SLR-325 x 3
C203
0.01
<F>
5V
R204
R203
R201
D202
SLR-325
<RED>
R202
330 x 4 <1/4W>
D204
<ORG>
D201 <ORG>
D203 <GRN>
PHA201
SBX1810
VCC
OUT
GND1
GND2
SW201
EVQ-PAG-04K
201-1
201-2
201-3
201-4
201-5
201-6
201-7
201-8
ROOM TEMPERATURE THERMISTOR
PIPE TEMPERATURE THERMISTOR
INDICATOR PCB
EZ-0018HSE-D
I C 1
uPD780058
(uPD78F0058)
-A14-9EU
CONTROLLER PCB ASSEMBLY ( MAIN PCB )
ASG24RBA-W : EZ-0018HSE-C
ASG18RBA-W : EZ-0010DHSE-C
ASG30RBA-W : EZ-0010CHSE-C
ASG30RGF-W : EZ-0010CHSE-C
UL1015
AWG20
RED
BLUE
RED
WHITE
GRAY
GRAY
RED
RED
3-3
3-1
2-1
2-2
YELLOW
BLACK
WHITE
WHITE
FAN CAPACITOR
1.3 uF
UL1015 AWG22
PURPLE
UL1015 AWG22 PURPLE
UL1015
AWG20
31
UL1430 AWG22
UL1430 AWG22
THRMAL FUSE
FAN
MOTOR
4-1
4-2
4-3
4-4
DIFFUSER
FLAP
U - D
LOUVER
L - R
Models : ASG18RBA-W
ASG24RBA-W
ASG30RBA-W
ASG30RGF-W
– 21 –
Page 17
R31
R34
R33
R32
1.0 x 4
<1/10W>
10 x 4
<1/10W>
R38
R37
R36
R35
5V
R11
RC1 10K
<1/10W>
0.01 x 4
<B>
C39
C40
C38
C37
5V
14V
5V
C17
0.1
<F>
IC4
PST600C
R8
10K <1/10W>
C16
0.1
<F>
X1
5.00MHz
<CSTS>
IO
G
BZ1
PKM13EPY-4000-TF01
R44 1.0K
<1/10W>
R43 1.0K
<1/10W>
IC7-1
uPA2003
1
16
14
13
12
11
3
4
5
6
7
10
16
15
14
13
12
11
107
6
5
4
3
2
1
+
2
15
16
1
4
5
3
13
12
14
27
28
29
30
31
32
34
35
40
41
42
43
71
65
17
16
15
14
50
60
70
69
61
33
67
4
55
54
53
58
57
56
13
12
11
10
20
19
23
22
52
51
77
76
9
8
64
45
46
47
80
78
73
7
75
68
74
49
63
59
I C 1
uPD780058
(uPD78F0058)
-A14-9EU
5V
C35
1000P <R>
R42 47 <1/10W>
C36
0.01 <B>
R41 1.0K <1/10W>
R39
R40
10K x 2
<1/10W>
Q7
Q6
Q5
DTC124EUA x 3
Q4
DTA143
C33
1000P
<R>
R27 1.0K <1/10W>
R28 1.0K <1/10W>
C34
1000P
<R>
C29
0.1
<F>
C30
0.1
<F>
5V
R25 10K
<1/10W>
(1%)
R26 49.9K
<1/10W>
(1%)
IC6 (7/7)
uPA2003
14V
IC7 (4/7)
uPA2003
IC7 (1/7)
uPA2003
14V
CN6
S10B-PASK-2
CN7
S05B-PASK-2
CN13
BS5P-SHF-1AA
B Z
LOUVER
L - R
FLAP
U - D
DIFFUSER
TEST
CN11
B2B-XAKK-1-A
CN10
B2B-XASK-1-A
CN9
S08B-PASK-2
C42
10/
25V
C41
0.01
<F>
10-1
10-2
11-2
11-1
9-2
9-1
9-7
9-8
9-6
9-5
9-4
9-3
GRAY
GRAY
GRAY
GRAY
GRAY
GRAY
201-8
201-7
201-6
201-5
BLACK
GRAY
GRAY
GRAY
GRAY
GRAY
GRAY
GRAY
GRAY
GRAY
GRAY
GRAY
GRAY
13-1
13-5
13-4
13-3
13-2
7-1
7-5
7-4
7-3
7-2
6-1
6-9
6-8
6-7
6-6
6-5
6-4
6-3
6-2
6-10
UL1061
AWG26
UL1061
AWG26
+
CN201 S08B-PASK-2
EVQ-PAG-04K
D202
R202
D204
D201
D203
R201
R203
R204
SBX1810
VCC
OUT
GND1
GND2
PIPE TEMPERATURE THERMISTOR
ROOM TEMPERATURE THERMISTOR
INDICATOR PCB
EZ-0018HSE-D
UL1430
5V
+
R45
R46
10K x 2
<1/10W>
C13
1000P
<R>
R5
10K
<1/10W>
Q2
DTC124EUA
C12
0.1
<F>
14V
R4
4.7K
<1/10W>
SSR1
G3MC
+
-
201PL-VD
NC
NC
IC5 (5/7)
uPA2003
K 1
14V
D6
DA226U
Q3
2SC982
R6 10K
<1/10W>
R7 10K
<1/10W>
5V
R12
10K <1/10W>
C22
0.1
<F>
RC2
R22
RC4
RC3
C21
1000P x 4
<R>
IC3
BR93LC46
R23
R24
5V
10K x 3
<1/10W>
JM1
JM2
JM3
5V
R21
R19
R20
1.0K x 3
<1/10W>
R18
R17
R16
10K x 3
<1/10W>
JM4
JM5
JM6
1.0K x 3
<1/10W>
R15
R14
R13
5V
14V
IC2
7805
D3
D1F60
C15
0.1
<F>
C14
100/
25V
+
C11
0.1
<F>
C9
10/
25V
+
C10
1000
/25V
Q1
2SD1191
R2 10K
<1/4W>
+
C8
10/25V
R1
10K
<1/2W>
D1
D2SB20
C7
2200
/50V
+
D4 D1F60
D2
MTZJ15C
R3
1.0K <1/10W>
VA3
470V <TNR>
K1
JQ1-12V
CN4
B4P7S-VH-B
CN1
B2P3-VH-B
CN8
B2P3-XARK-1-A
E1
W2
SA1
RA-362M
VA2
470V
<TNR>
FH1 FH2
F1
3.15A
<BET>
W1
TM2
TM1
N
L
C2
0.22 <RE>
C5 C6
0.022 x 2
<YE>
LF1
ELF17N015A
C1
0.22 <RE>
VA1
470V <TNR>
COMP
POWER RELAY
VF12HU-UL
POWER
TRANSFORMER
EZ-0018HSE-T
SECONDARY
PRIMARY
CN2
B2B-XARK-1-A
THERMAL FUSE
CN3
B3B-XASK-1-A
VCC
NC
NC
GND
D0
D1
SK
CS
1
2
3
4
5
6
7
8
8-3
8-1
1-1
1-3
UL1430 AWG24 RED
UL1430 AWG24 RED
UL1015 AWG22 PURPLE
UL1015 AWG22 PURPLE
UL1015
AWG16
UL1015
AWG14
GREEN
GRAY
13
FAN CAPACITOR
2.5 uF
WHITE
WHITE
UL1015
AWG20
BLACK
YELLOW
UL1015
AWG20
BLUE
RED
WHITE
FAN
MOTOR
RED
RED
GRAY
GRAY
2-1
2-2
3-1
3-3
UL1430 AWG22
UL1430 AWG22
POWER SOURCE
220 / 240V
OUTDOOR UNIT
1
2
TERMINAL
BOARD
JM1 : FAN SWITCHING
JM2 : CUSTOM CODE SWITCHING-1
JM3 : CUSTOM CODE SWITCHING-2
JM4 : AUTO RESTART SWITCHING
JM5 : ROOM TEMPERATURE CORRECTION
( HEATING OPERATION )
JM6 : ROOM TEMPERATURE CORRECTION
( HEATING OPERATION )
C25
C23
C24
0.01 x 3
<B>
0.01 x 3
<B>
C28
C26
C27
O
G
I
CONTROLLER PCB ASSEMBLY ( MAIN PCB )
ASG24ABB-W : EZ-001RWSE-C
ASG24AGF-W : EZ-001RWSE-C
ASG18AGF-W : EZ-001YWSE-C
4-4
4-3
4-2
4-1
WHITE
BLACK
UL1015
AWG14
UL1015
AWG14
Models : ASG18AGF-W
ASG24AGF-W
ASG24ABB-W
– 22 –
Page 18
JM1 : FAN SWITCHING
JM2 : CUSTOM CODE SWITCHING-1
JM3 : CUSTOM CODE SWITCHING-2
JM4 : AUTO RESTART SWITCHING
JM5 : ROOM TEMPERATURE CORRECTION
( HEATING OPERATION )
JM6 : ROOM TEMPERATURE CORRECTION
( HEATING OPERATION )
INDICATOR PCB
EZ-0018HSE-D
IC3
BR93LC46
CONTROLLER PCB ASSEMBLY ( MAIN PCB )
ASG24RGF-W : EZ-0010BHSE-C
ASG18RGF-W : EZ-0010FHSE-C
Models : ASG18RGF-W
ASG24RGF-W
– 23 –
Page 19
Page 20
Page 21
Page 22
Page 23
Page 24
Page 25
Page 26
Page 27
Page 28
Page 29
Page 30
Page 31
Page 32
Page 33
Page 34
Page 35
Page 36
Page 37
Page 38
Page 39
Page 40
Page 41
Page 42
Page 43
Page 44
Page 45
Page 46
Page 47
Page 48
Page 49
INDOOR UNIT
ASG18ABA-W, ASG18RBA-W
ASG24ABA-W, ASG24RBA-W
ASG30ABA-W, ASG30RBA-W
PARTS LIST
When you order parts, please make a photocopy of this page
and fill the number of the parts in the "Order" column.
Ref.
No.
34 Capacitor (Fan Motor) 9704305060 9704305060 9704305060 9704305060 9704305060 9704305060
40 Water Seal Plate 9369684005 9369684005 9369684005 9369684005 9369684005 9369684005
45 Bracket (Eva. ) 9369372001 9369372001 9369372001 9369372001 9369372001 9369372001
61 Decoration Plate-G 9368756017 9368756017 9368756017 9368756017 9368756017 9368756017
63 Front Panel 9368540012 9368540012 9368540012 9368540012 9368540012 9368540012
69 Louver 9368560010 9368560010 9368560010 9368560010 9368560010 9368560010
69-1 Louver Base-A 9368558017 9368558017 9368558017 9368558017 9368558017 9368558017
69-2 Louver Base-B 9368559014 9368559014 9368559014 9368559014 9368559014 9368559014
74 Air Filter 9368552008 9368552008 9368552008 9368552008 9368552008 9368552008
92 Link Holder 9368563004 9368563004 9368563004 9368563004 9368563004 9368563004
108 Base 9369209017 9369209017 9369209017 9369209017 9369209017 9369209017
122 Bearing Assy 9368574000 9368574000 9368574000 9368574000 9368574000 9368574000
127 Drain Hose 9367695003 9367695003 9367695003 9367695003 9367695003 9367695003
146 Evaporator Assy 9369220005 9369220005 9369220005 9369220005 --------- --------146-1 Evaporator-A Assy --------- --------- --------- --------- 9369366000 9369366000
146-2 Evaporator-B Assy --------- --------- --------- --------- 9369373008 9369373008
158 Joint Pipe Assy 9369242007 9369242007 9369242007 9369242007 9369371004 9369371004
160 Front Drain Pan Assy 9369200014 9369200014 9369200014 9369200014 9369200014 9369200014
160-1 Rear Drain Pan Assy 9369201011 9369201011 9369201011 9369201011 9369201011 9369201011
163-2 Thermistor Spring-A 313728262708 313728262708 313728262708 313728262708 313728262708 313728262708
164 Fan Motor Assy-IN 9601388012 9601388012 9601388012 9601388012 9601388012 9601388012
169 Cross Flow Fan Assy 9368586003 9368586003 9368586003 9368586003 9368586003 9368586003
178-1 Rubber (Motor) 9368575007 9368575007 9368575007 9368575007 9368575007 9368575007
199 Step Motor 9900020019 9900020019 9900020019 9900020019 9900020019 9900020019
220 Water Plate --------- --------- --------- --------- 9368569006 9368569006
233 Power Transformer 9900069018 9900069018 9900069018 9900069018 9900069018 9900069018
236 Controller PCB Assy 9703335068 9703335051 9703335020 9703395013 9703335105 9703335099
240 Remote Control Unit 9368374020 9368374013 9368374020 9368374013 9368374020 9368374013
321 Flap 9368544010 9368544010 9368544010 9368544010 9368544010 9368544010
329 Coupling Pipe Assy 9369241000 9369241000 9369241000 9369241000 9369370007 9369370007
Description
ASG18ABA-W
Part No.
ASG30RBA-WASG18RBA-W ASG24ABA-W ASG24RBA-W ASG30ABA-W
Ord.
Q'ty
338 Motor Holder-A 9368550004 9368550004 9368550004 9368550004 9368550004 9368550004
338-1 Motor Holder-B 9368551001 9368551001 9368551001 9368551001 9368551001 9368551001
338-2 Motor Holder-C 9368769000 9368769000 9368769000 9368769000 9368769000 9368769000
385 Indicator PCB Assy 9702307011 9702307011 9702307011 9702307011 9702307011 9702307011
401 Wall Hook Bracket 9368579005 9368579005 9368579005 9368579005 9368579005 9368579005
408 Louver Link 9368562007 9368562007 9368562007 9368562007 9368562007 9368562007
425 Earth Plate 9368580001 9368580001 9368580001 9368580001 9368580001 9368580001
428 Screw Cover 9368576011 9368576011 9368576011 9368576011 9368576011 9368576011
435 Louver Spring 9368613006 9368613006 9368613006 9368613006 9368613006 9368613006
473 Pipe Holder 9368565008 9368565008 9368565008 9368565008 9368565008 9368565008
473-1 Cord Holder 9368566005 9368566005 9368566005 9368566005 9368566005 9368566005
506 Louver Rod 9368561017 9368561017 9368561017 9368561017 9368561017 9368561017
514 Control Box 9368543006 9368543006 9368543006 9368543006 9368543006 9368543006
522-1 Sector Gear 9368556006 9368556006 9368556006 9368556006 9368556006 9368556006
522-2 Pinion Gear 9368557003 9368557003 9368557003 9368557003 9368557003 9368557003
522-3 Flap Spring 9368612009 9368612009 9368612009 9368612009 9368612009 9368612009
557 Diffuser Spring 9368587000 9368587000 9368587000 9368587000 9368587000 9368587000
564 Bypass Pipe-A Assy --------- --------- --------- --------- 9369551000 9369551000
564-2 Bypass Pipe-C Assy 9369479007 9369479007 9369479007 9369479007 --------- --------574-1 Evaporator Support-R 9368549008 9368549008 9368549008 9368549008 9368549008 9368549008
574-2 Evaporator Support-L 9368548001 9368548001 9368548001 9368548001 9368548001 9368548001
588 Evaporator Holder --------- --------- --------- --------- 9368775001 9368775001
684 Motor Base 9368555009 9368555009 9368555009 9368555009 9368555009 9368555009
707 Display Cover 9368564001 9368564001 9368564001 9368564001 9368564001 9368564001
735 Distributor 9369240003 9369240003 9369240003 9369240003 9369369001 9369369001
743 Remote Control Unit Holder Case 9305642014 9305642014 9305642014 9305642014 9305642014 9305642014
759 Intake Grill-G 9368542016 9368542016 9368542016 9368542016 9368542016 9368542016
764 Drain Cap 9367677009 9367677009 9367677009 9367677009 9367677009 9367677009
815 Terminal 9306489106 9900016029 9306489106 9900016029 9306489106 9900016029
846 Relay G5NB-1A 9900007010 9900007010 9900007010 9900007010 9900007010 9900007010
– 54 –
Page 50
ASG18ABA-W, ASG18RBA-W
ASG24ABA-W, ASG24RBA-W
ASG30ABA-W, ASG30RBA-W
INDOOR UNIT (Continued)
Ref.
No.
855 Cover Display 9369264016 9369264016 9369264016 9369264016 9369264016 9369264016
855-1 Cover Display-B 9369594014 9369594014 9369594014 9369594014 9369594014 9369594014
855-2 Cover Display-C 9369683015 9369683015 9369683015 9369683015 9369683015 9369683015
938 Control Box Cover-R 9368570002 9368570002 9368570002 9368570002 9368570002 9368570002
942 Control Box Cover 9368611002 9368611002 9368611002 9368611002 9368611002 9368611002
960 Diffuser Assy 9369346019 9369346019 9369346019 9369346019 9369346019 9369346019
963 Fan Guard 9368588007 9368588007 9368588007 9368588007 9368588007 9368588007
963-1 Fan Guard Holder 9368554002 9368554002 9368554002 9368554002 9368554002 9368554002
998 Bypass Pipe-A 9369238000 9369238000 9369238000 9369238000 --------- --------999 Bypass Pipe-B 9369239007 9369239007 9369239007 9369239007 9369368004 9369368004
Description
ASG18ABA-W
When you order parts, please make a photocopy of this page
and fill the number of the parts in the "Order" column.
Part No.
ASG30RBA-WASG18RBA-W ASG24ABA-W ASG24RBA-W ASG30ABA-W
Ord.
Q'ty
– 55 –
Page 51
ASG18AGF-W, ASG18RGF-W
ASG24AGF-W, ASG24RGF-W
ASG30AGF-W, ASG30RGF-W
INDOOR UNIT
Ref.
No.
34 Capacitor (Fan Motor) 9704305060 9704305060 9704305060 9704305060 9704305060 9704305060
40 Water Seal Plate 9369684005 9369684005 9369684005 9369684005 9369684005 9369684005
45 Bracket (Eva. ) 9369372001 9369372001 9369372001 9369372001 9369372001 9369372001
61 Decoration Plate-G 9368756017 9368756017 9368756017 9368756017 9368756017 9368756017
63 Front Panel 9368540012 9368540012 9368540012 9368540012 9368540012 9368540012
69 Louver 9368560010 9368560010 9368560010 9368560010 9368560010 9368560010
69-1 Louver Base-A 9368558017 9368558017 9368558017 9368558017 9368558017 9368558017
69-2 Louver Base-B 9368559014 9368559014 9368559014 9368559014 9368559014 9368559014
74 Air Filter 9368552008 9368552008 9368552008 9368552008 9368552008 9368552008
92 Link Holder 9368563004 9368563004 9368563004 9368563004 9368563004 9368563004
108 Base Assy 9369209017 9369209017 9369209017 9369209017 9369209017 9369209017
122 Bearing Assy 9368574000 9368574000 9368574000 9368574000 9368574000 9368574000
127 Drain Hose 9367695003 9367695003 9367695003 9367695003 9367695003 9367695003
146 Evaporator Assy 9369220005 9369220005 9369220005 9369220005 --------- --------146-1 Evaporator-A Assy --------- --------- --------- --------- 9369366000 9369366000
146-2 Evaporator-B Assy --------- --------- --------- --------- 9369373008 9369373008
158 Joint Pipe Assy 9369242007 9369242007 9369242007 9369242007 9369371004 9369371004
160 Front Drain Pan Assy 9369200014 9369200014 9369200014 9369200014 9369200014 9369200014
160-1 Rear Drain Pan Assy 9369201011 9369201011 9369201011 9369201011 9369201011 9369201011
163-2 Thermistor Spring-A 313728262708 313728262708 313728262708 313728262708 313728262708 313728262708
164 Fan Motor Assy-IN 9601388012 9601388012 9601388012 9601388012 9601388012 9601388012
169 Cross Flow Fan Assy 9368586003 9368586003 9368586003 9368586003 9368586003 9368586003
178-1 Rubber (Motor) 9368575007 9368575007 9368575007 9368575007 9368575007 9368575007
199 Step Motor 9900020019 9900020019 9900020019 9900020019 9900020019 9900020019
220 Water Plate --------- --------- --------- --------- 9368569006 9368569006
233 Power Transformer 9900069018 9900069018 9900069018 9900069018 9900069018 9900069018
236 Controller PCB Assy 9703335082 9703335075 9703335037 9703395044 9703335105 9703335099
240 Remote Control Unit 9359913023 9359913016 9359913023 9359913016 9359913023 9359913016
321 Flap 9368544010 9368544010 9368544010 9368544010 9368544010 9368544010
329 Coupling Pipe Assy 9369241000 9369241000 9369241000 9369241000 9369370007 9369370007
Description
ASG18AGF-W
When you order parts, please make a photocopy of this page
and fill the number of the parts in the "Order" column.
Part No.
ASG30RGF-WASG18RGF-W ASG24AGF-W ASG24RGF-W ASG30AGF-W
Ord.
Q'ty
338 Motor Holder-A 9368550004 9368550004 9368550004 9368550004 9368550004 9368550004
338-1 Motor Holder-B 9368551001 9368551001 9368551001 9368551001 9368551001 9368551001
338-2 Motor Holder-C 9368769000 9368769000 9368769000 9368769000 9368769000 9368769000
385 Indicator PCB Assy 9702307011 9702307011 9702307011 9702307011 9702307011 9702307011
401 Wall Hook Bracket 9368579005 9368579005 9368579005 9368579005 9368579005 9368579005
408 Louver Link 9368562007 9368562007 9368562007 9368562007 9368562007 9368562007
425 Earth Plate 9368580001 9368580001 9368580001 9368580001 9368580001 9368580001
428 Screw Cover 9368576011 9368576011 9368576011 9368576011 9368576011 9368576011
435 Louver Spring 9368613006 9368613006 9368613006 9368613006 9368613006 9368613006
473 Pipe Holder 9368565008 9368565008 9368565008 9368565008 9368565008 9368565008
473-1 Cord Holder 9368566005 9368566005 9368566005 9368566005 9368566005 9368566005
506 Louver Rod 9368561017 9368561017 9368561017 9368561017 9368561017 9368561017
514 Control Box 9368543006 9368543006 9368543006 9368543006 9368543006 9368543006
522-1 Sector Gear 9368556006 9368556006 9368556006 9368556006 9368556006 9368556006
522-2 Pinion Gear 9368557003 9368557003 9368557003 9368557003 9368557003 9368557003
522-3 Flap Spring 9368612009 9368612009 9368612009 9368612009 9368612009 9368612009
557 Diffuser Spring 9368587000 9368587000 9368587000 9368587000 9368587000 9368587000
564 Bypass Pipe-A Assy --------- --------- --------- --------- 9369551000 9369551000
564-2 Bypass Pipe-C Assy 9369479007 9369479007 9369479007 9369479007 --------- --------574-1 Evaporator Support-R 9368549008 9368549008 9368549008 9368549008 9368549008 9368549008
574-2 Evaporator Support-L 9368548001 9368548001 9368548001 9368548001 9368548001 9368548001
588 Evaporator Holder --------- --------- --------- --------- 9368775001 9368775001
684 Motor Base 9368555009 9368555009 9368555009 9368555009 9368555009 9368555009
707 Display Cover 9368564001 9368564001 9368564001 9368564001 9368564001 9368564001
735 Distributor 9369240003 9369240003 9369240003 9369240003 9369369001 9369369001
743 Remote Control Unit Holder Case 9359955016 9359955016 9359955016 9359955016 9359955016 9359955016
759 Intake Grill-G 9368542016 9368542016 9368542016 9368542016 9368542016 9368542016
764 Drain Cap 9367677009 9367677009 9367677009 9367677009 9367677009 9367677009
815 Terminal 9306489106 9900016029 9306489106 9900016029 9306489106 9900016029
846 Relay G5NB-1A --------- 9900007010 --------- 9900007010 9900007010 9900007010
– 56 –
Page 52
ASG18AGF-W, ASG18RGF-W
ASG24AGF-W, ASG24RGF-W
ASG30AGF-W, ASG30RGF-W
INDOOR UNIT (Continued)
When you order parts, please make a photocopy of this page
and fill the number of the parts in the "Order" column.
Ref.
No.
855 Cover Display 9369264016 9369264016 9369264016 9369264016 9369264016 9369264016
855-1 Cover Display-B 9369594014 9369594014 9369594014 9369594014 9369594014 9369594014
855-2 Cover Display-C 9369683015 9369683015 9369683015 9369683015 9369683015 9369683015
938 Control Box Cover-R 9368570002 9368570002 9368570002 9368570002 9368570002 9368570002
942 Control Box Cover 9368611002 9368611002 9368611002 9368611002 9368611002 9368611002
960 Diffuser Assy 9369346019 9369346019 9369346019 9369346019 9369346019 9369346019
963 Fan Guard 9368588007 9368588007 9368588007 9368588007 9368588007 9368588007
963-1 Fan Guard Holder 9368554002 9368554002 9368554002 9368554002 9368554002 9368554002
998 Bypass Pipe-A 9369238000 9369238000 9369238000 9369238000 --------- --------999 Bypass Pipe-B 9369239007 9369239007 9369239007 9369239007 9369368004 9369368004
Description
ASG18AGF-W
Part No.
ASG30RGF-WASG18RGF-W ASG24AGF-W ASG24RGF-W ASG30AGF-W
Ord.
Q'ty
– 57 –
Page 53
INDOOR UNIT
Ref.
No.
34 Capacitor (Fan Motor) 9704305060
40 Water Seal Plate 9369684005
45 Bracket (Evaporator) 9369372001
61 Decoration Plate-G 9368756017
63 Front Panel 9368540012
69 Louver 9368560010
69-1 Louver Base-A 9368558017
69-2 Louver Base-B 9368559014
74 Air Filter 9368552008
92 Link Holder 9368563004
108 Base Assy 9369209017
122 Bearing Assy 9368574000
127 Drain Hose 9367695003
146 Evaporator Assy 9369220005
158 Joint Pipe Assy 9369242007
160 Front Drain Pan Assy 9369200014
160-1 Rear Drain Pan Assy 9900069018
163-2 Thermistor Spring-A 313728262708
164 Fan Motor Assy-IN 9601388012
169 Cross Flow Fan Assy 9368586003
Description
Part No.
ASG24ABB-W
When you order parts, please make a photocopy of this page
and fill the number of the parts in the "order" column.
Ord.
Ref.
Q'ty
No.
425 Earth Plate 9368580001
428 Screw Cover 9368576011
435 Louver Spring 9368613006
473 Pipe Holder 9368565008
473-1 Cord Holder 9368566005
506 Louver Rod 9368561017
514 Control Box 9368543006
522-1 Sector Gear 9368556006
522-2 Pinion Gear 9368557003
522-3 Flap Spring 9368612009
557 Diffuser Spring 9368587000
564-2 Bypass Pipe-C Assy 9369479007
574-1 Evaporator Support-R 9368549008
574-2 Evaporator Support-L 9368548001
684 Motor Base 9368555009
707 Display Cover 9368564001
735 Distributor 9369240003
743 Remote Control Unit Holder Case 9305642014
759 Intake Grill-G 9368542016
764 Drain Cap 9367677009
Description
Part No.
ASG24ABB-W
ASG24ABB-W
Ord.
Q'ty
178-1 Rubber (Motor) 9368575007
199 Step Motor 9900020019
233 Power Transformer 9900069018
236 Controller PCB Assy 9703335037
240 Remote Control Unit 9368374020
321 Flap 9368544010
329 Coupling Pipe Assy 9369241000
338 Motor Holder-A 9368550004
338-1 Motor Holder-B 9368551001
338-2 Motor Holder-C 9368769000
385 Indicator PCB Assy 9702307011
401 Wall Hook Bracket 9368579005
408 Louver Link 9368562007
815 Terminal 9306489106
846 Relay G5NB-1A 9900007010
855 Cover Display 9369264016
855-1 Cover Display-B 9369594014
855-2 Cover Display-C 9369683015
938 Control Box Cover-R 9368570002
942 Control Box Cover 9368611002
960 Diffuser Assy 9369346019
963 Fan Guard 9368588007
963-1 Fan Guard Holder 9368554002
998 Bypass Pipe-A 9369238000
999 Bypass Pipe-B 9369239007
– 58 –
Page 54
AOG18ANE, AOG18RMEL
AOG24AME, AOG24RMEL
AOG30AMAL, AOG30RMAL
OUTDOOR UNIT
Ref.
Description
No.
2 Fan Cover 9350214020 9350214020 9350214020 9350214020 --------- --------2 Fan Cover (Guard) --------- --------- --------- --------- 9359808015 9359808015
4 Emblem-Rear "GENERAL" 313791088308 313791088308 313791088308 313791088308 313791088308 313791088308
5 Cabinet-A, Painted 9303876015 9303876015 9303876015 9303876015 9359797029 9359797029
6 Cabinet-C, Painted 9353549013 9353549013 9353549013 9353549013 --------- --------7 Connector Cover 9358011010 9358011010 9358011010 9358011010 --------- --------8 Wire Assy (Shield)-D 9359904076 --------- --------- --------- --------- --------8 Shield Tube Assy-D --------- 9359904052 9359904052 9359904052 --------- --------9 Cabinet-B, Painted 9303874011 9303874011 9303874011 9303874011 9359798026 9359798026
12 Base Assy, Painted 9353452054 9353452054 9353452061 9353452061 9359813019 9359813019
13 3-Way Valve Assy 9364523002 9364523002 9357963013 9364523002 --------- --------13-2 3-Way Valve Assy (3/8) --------- --------- --------- --------- 9360150004 9369150004
13-3 3-Way Valve Assy (5/8) --------- --------- --------- --------- 9360157003 9360157003
14 2-Way Valve Assy 9365021002 9365021002 9357964010 9365021002 --------- --------15 Dryer 9368111014 9368111014 9368111014 9368111014 9368111014 9368111014
16 Condenser Assy 9353455055 9353455048 9356015010 9369005015 9360280015 9360280015
17 U Pipe-Y --------- 313728127102 --------- 9305523009 --------- --------18 Suction Pipe 9369000003 --------- --------- --------- --------- --------18 Inlet Pipe (Condenser) --------- --------- --------- --------- 9369048005 9369068003
18-1 Outlet Pipe (Condenser) --------- --------- --------- --------- 9369054006 ---------
18-4 Suction Pipe --------- --------- --------- --------- 9369046001 --------19 Capillary Tube 9364270005 --------- --------- --------- --------- --------19-3 Capillary (Cool) --------- 9365395073 9364327006 --------- --------- --------20 Discharge Pipe Assy 9368999001 --------- --------- --------- --------- --------20 Discharge Pipe --------- 9367136001 9368491000 --------- 9369047008 9369067006
26 Compressor Cover-A 9363020007 9367296002 9368504007 9367134007 --------- --------26 Comp. Cover --------- --------- --------- --------- 9369093005 9369093005
26-1 Compressor Cover-B --------- --------- 9368505004 --------- --------- --------29 Separate Wall 313986033213 313986033213 313986033213 313986033213 9359804017 9359804017
32 Control Box Metal-A --------- 9365672020 --------- 9365672020 --------- ---------
When you order parts, please make a photocopy of this page
and fill the number of the parts in the "Order" column.
Part No.
AOG30RMALAOG18ANE AOG18RMEL AOG24AME AOG24RMEL AOG30AMAL
Ord.
Q'ty
32 Control Box Metal --------- --------- --------- --------- 9359839019 9359839019
32-1 Control Box Metal-A 9365672013 --------- 9365672013 --------- --------- --------34 Capacitor (Fan Motor) 9357965017 9357965024 9357965017 9357965024 9357965024 9357965024
36 Cord Holder Metal 9356934007 9356934007 9356934007 9356934007 --------- --------37 Running Capacitor 9704436023 9703107122 9703107153 9703107153 9703107023 9703107023
38 Capacitor Clamp 9351770013 9351770013 9351770013 9351770013 9360610010 9360610010
39 Propeller Fan 9300855013 9300855013 9300855013 9300855013 9359837015 9359837015
41 Fan Motor Assy-Out 9600738023 9600738023 9600738023 9600738023 9600832011 9600832011
45 Motor Fixing Table Assy 313029311100 313029311100 313029311100 313029311100 --------- --------45-1 Motor Bracket --------- --------- --------- --------- 9359801016 9359801016
45-2 Motor Bracket-Top --------- --------- --------- --------- 9359803010 9359803010
46 Compressor Assy 9368175009 9366777007 9367112005 9367112005 9368913007 9368913007
51 Special Nut M5 9300301015 --------- --------- --------- --------- --------54 Condensing Pipe --------- --------- --------- --------- 9369061004 --------54-1 Condensing Pipe-A --------- --------- --------- --------- --------- 9369085000
54-2 Outlet Pipe-B --------- --------- --------- 9365391068 --------- --------55 Special Nut M8 9355091008 9355091008 9355091008 9355091008 9355091008 9355091008
58 Suction Pipe Assy --------- --------- 9368492007 --------- --------- 9369064005
64 Cabinet-Left, Painted --------- --------- --------- --------- 9359840022 9359840022
67 Rubber (Vibration Proof) 313659068604 313659068604 313659068604 313659068604 --------- ---------
81 Strap --------- 9362371001 9362371001 9362371001 9362371001 9362371001
82-1 Check Joint --------- --------- --------- --------- 9360162007 9360162007
83 Check Joint Bracket --------- --------- --------- --------- 9359807018 9359807018
84 Valve Cover --------- --------- --------- --------- 9359817017 9359817017
85 Valve Fixing Plate --------- --------- --------- --------- 9359806011 9359806011
107 Rubber Seat-A 9351049010 --------- --------- --------- --------- --------107 Rubber Mount --------- 9362368001 9362368001 9362368001 9362368001 9362368001
109 Terminal Cover 9351048013 9362369008 9362369008 9362369008 9362369008 9362369008
117-3 Hex. Nut w/Sp. Washer 301720080114 301720080114 301720080114 301720080114 301720080114 301720080114
139 Wire Assy (Compressor) --------- --------- --------- --------- 9369094002 9369094002
– 59 –
Page 55
AOG18ANE, AOG18RMEL
AOG24AME, AOG24RMEL
AOG30AMAL, AOG30RMAL
OUTDOOR UNIT (Continued)
Ref.
Description
No.
187 Clamp No. 1219 313361271706 313361271706 313361271706 313361271706 313361271706 313361271706
218-3 Power Relay 9900074012 9900074012 9900074012 9900074012 9900074012 9900074012
263 Accumulator --------- --------- --------- --------- --------- 9385005006
271 4-Way Valve Rubber --------- 313728251908 --------- 313728251908 --------- --------300 Suction Pipe-C --------- 9367138005 --------- 9367125005 --------- --------328 Comp. Plate Assy 9363049015 9367128020 9367128037 9367128013 9362273015 9362273046
330 Inlet Pipe-A Assy --------- 9366859017 --------- --------- --------- --------330-2 Inlet Pipe (Condenser)-B Assy --------- --------- --------- --------- --------- 9369074004
332-1 Suction Pipe-D --------- 9367135004 --------- 9367126002 --------- --------332-2 Suction Pipe-E --------- 9369004001 --------- 9369004001 --------- ---------
333 Accumulator --------- 9350363018 --------- 313986117201 --------- --------334 Suction Pipe-B --------- 9367137008 --------- 9367124008 --------- --------338 Motor Fixture 313029297108 313029297108 313029297108 313029297108 --------- --------343 Solenoid Coil --------- 9359616092 --------- 9359616092 --------- --------343 Solenoid --------- --------- --------- --------- --------- 9900003029
344 4-Way Valve --------- 313943302804 --------- 9300604017 --------- 9307556012
348 Outlet Pipe 9364266008 --------- --------- --------- --------- --------348 Outlet Pipe (Cond. ) Assy --------- --------- 9363041019 --------- --------- --------348 Outlet Pipe (Cond. )-A --------- --------- --------- 9365391051 --------- --------348-1 Outlet Pipe-B --------- 9365391020 --------- --------- --------- ---------
348-2 Outlet Pipe-A --------- 9365391075 --------- --------- --------- --------353 Valve-A Assy 9364268002 --------- 9364325002 --------- --------- --------360 4-Way Valve Band --------- 313986251802 --------- 313986251802 --------- --------373 Grip --------- --------- --------- --------- 9352157004 9352157004
407 Clamp (Cable) No. 1259 --------- --------- --------- --------- 313739340109 313739340109
412 Terminal Gasket 9351051013 9362370004 9362370004 9362370004 9362370004 9362370004
420 Capillary Assy --------- --------- --------- --------- 9369062001 9369095009
477 Bell-Mouth --------- --------- --------- --------- 9359809012 9359809012
527 Protection Net --------- --------- --------- --------- 9359844013 9359844013
549 Thermostat-Outdoor --------- --------- --------- --------- 9352553004 ---------
When you order parts, please make a photocopy of this page
and fill the number of the parts in the "Order" column.
Part No.
AOG30RMALAOG18ANE AOG18RMEL AOG24AME AOG24RMEL AOG30AMAL
Ord.
Q'ty
620 Inlet Pipe Assy --------- --------- --------- 9367298006 --------- --------646 Compressor Cover-B 9363021004 313986355101 --------- 9367293001 --------- --------653-1 Bolt (Fan Motor Fixing) --------- --------- --------- --------- 0700156014 0700156014
662 Inlet Pipe-D --------- --------- --------- 9367301003 --------- --------702 Restrector Valve Assy --------- 9365392058 --------- 9365392065 --------- --------717 Center Plate 9350216017 9350216017 9350216017 9350216017 --------- --------718 Discharge Pipe-C --------- --------- --------- 9367123001 --------- --------734 Cabinet Top Plate, Painted --------- --------- --------- --------- 9359799023 9359799023
735 Distributor Assy --------- --------- --------- --------- --------- 9369076008
744 Clamp (Condenser) --------- --------- --------- --------- 313166374106 313166374106
754 Terminal Gasket Washer 9351053017 --------- --------- --------- --------- --------772 Joint Pipe-A --------- --------- --------- --------- 9369060007 9369084003
772-3 Joint Pipe (Valve) --------- --------- --------- --------- --------- 9369082009
772-4 Joint Pipe (Valve)-B --------- --------- --------- --------- --------- 9369083006
808 Inlet Pipe (Accumulator) --------- --------- --------- --------- --------- 9369081002
815 Terminal-5P 9356497021 --------- 9356497021 --------- --------- --------815-3 Terminal-8P --------- 9358660119 --------- 9358660119 9358660119 9358660119
817 Thermostat Fixture --------- --------- --------- --------- 9352164019 --------823-2 Fuse Holder 0500063024 0500063024 0500063024 0500063024 0500063024 0500063024
824-4 Fuse 0600222529 0600222529 0600222529 0600222529 0600222529 0600222529
867 Accumulator Holder Rubber --------- 9354022027 --------- 9354022010 --------- 9354022010
909 Strainer-A --------- --------- --------- 9365112014 --------- --------910 Strainer-B --------- 9365099018 --------- --------- --------- 9365099018
983 Thermostat Cover --------- --------- --------- --------- 9358274002 --------989-1 Cord Clamp-A --------- --------- --------- --------- 9359822011 9359822011
989-2 Cord Clamp-B --------- --------- --------- --------- 9359823018 9359823018
– 60 –
Page 56
AOG18AZE, AOG18RZEL
AOG24ABE, AOG24RZEL
AOG30AVAL, AOG30RVAL
OUTDOOR UNIT
Ref.
No.
2 Fan Cover 9350214020 9350214020 9350214020 9350214020 9359808015 9359808015
4 Emblem-Rear "GENERAL" 313791088308 313791088308 313791088308 313791088308 313791088308 313791088308
5 Cabinet-A, Painted 9303876015 9303876015 9303876015 9303876015 9359797029 9359797029
6 Cabinet-C, Painted 9353549013 9353549013 9353549013 9353549013 --------- --------7 Connector Cover 9358011010 9358011010 9358011010 9358011010 --------- --------8 Wire Assy (Shield)-D 9350215010 9350215010 9350215041 9350215027 9359904021 9359904021
9 Cabinet-B, Painted 9303874011 9303874011 9303874011 9303874011 9359798026 9359798026
10 Nise Insulation-E 313791106305 313791106305 313790016305 313791106305 --------- --------11 Nise Insulation-B --------- --------- --------- 313791106100 --------- --------12 Base Assy, Painted 9353452016 9353452016 9353452061 9353452061 9359812029 9359812029
13 3-Way Valve 9364523002 9364523002 9357963013 9364523002 --------- --------13-1 3-Way Valve (5/8) --------- --------- --------- --------- 9360157003 9360157003
13-2 Packed Valve (3-8) --------- --------- --------- --------- 9360150004 9360150004
14 2-Way Valve Assy 9365021002 9365021002 9357964010 9365021002 --------- --------15 Dryer 313791082502 9368111014 313781082502 9368117016 9368111014 9368111014
16 Condenser Assy 9353455055 9353455048 9356015010 9363794014 9360280015 9360280015
17 U-Pipe (Y) --------- 313728127102 --------- 9305523009 --------- --------18 Suction Pipe 9360518002 9351590017 9360412003 9350598007 --------- --------18-1 Suction Pipe-A --------- --------- --------- --------- 9360487001 9360152008
19 Capillary Tube 9359017004 --------- 9355977005 --------- --------- ---------
19-2 Joint Pipe 9354268005 --------- 9354268005 --------- --------- --------20 Discharge Pipe 9360522009 9358635001 9357470009 9350601004 --------- --------21 Discharge Pipe-B --------- 9358634004 9360411006 9350602001 --------- --------26 Compressor Cover-A 9354036000 9354036000 9360639004 9354036000 9353088000 9362501002
29 Separate Wall 313986033213 313986033213 313986033213 313986033213 9359804017 9359804017
32 Control Box Metal --------- --------- --------- --------- 9359839019 9359839019
32-1 Control Box Metal-A 9365672013 9365672013 9365672013 9365672013 --------- --------34 Capacitor (Fan Motor) 9357965017 9357965024 9357965017 9357965024 9357965024 9357965024
36 Cord Holder Metal 9356824001 9356362008 9356824001 9356362008 --------- --------37 Running Capacitor 9704436023 9704436023 9704436023 9704436023 9703107078 9703107078
Description
AOG18AZE
When you order parts, please make a photocopy of this page
and fill the number of the parts in the "Order" column.
Part No.
AOG30RVALAOG18RZEL AOG24ABE AOG24RZEL AOG30AVAL
Ord.
Q'ty
38 Capacitor Clamp Metal 9351770013 9351770013 9351770013 9351770013 9360610010 9360610010
39 Propeller Fan 9300855013 9300855013 9300855013 9300855013 9359837015 9359837015
41 Fan Motor Assy-Out 9600738023 9600738047 9600738023 9600738047 9600832011 9600832011
45 Motor Fixing Table Assy 313029311100 313029311100 313029311100 313029311100 --------- --------45-1 Motor Bracket-Top --------- --------- --------- --------- 9359801016 9359801016
45-2 Motor Bracket --------- --------- --------- --------- 9359803010 9359803010
46 Compressor Assy 9360509055 9360509055 9360391001 9360509017 9360613011 9360613011
54 Outlet Pipe (Cond. )-B --------- 9365391020 --------- 9365391068 --------- --------55 Special Nut M8 313252257701 313252257701 313252257701 313252257701 313252257701 313252257701
64 Cabinet Left --------- --------- --------- --------- 9359840022 9359840022
67 Rubber (Vibration Proof) 313659068604 313659068604 313659068604 313659068604 --------- --------82 Check Joint Assy --------- --------- --------- --------- 9360762009 9360771001
83 Check Joint Bracket --------- --------- --------- --------- 9359807018 9359807018
84 Valve Cover --------- --------- --------- --------- 9359817017 9359817017
85 Valve Fixing Plate --------- --------- --------- --------- 9359806011 9359806011
88 Restrector Valve --------- --------- --------- --------- --------- 9360146007
107 Rubber Seat-A (For Comp. ) 313093081402 313093081402 313102081406 313093081402 313102081406 313102081406
108 Sleeve-A (For Comp. ) 313093081706 313093081706 313696081700 313093081706 313696081700 313696081700
109 Terminal Cover (For Comp. ) 313202059600 313202059600 9355987004 313202059600 9352456022 9352456022
110 Lock Wire (For Comp. ) 313202059706 313202059706 9355989008 313202059706 --------- ---------
111 Terminal Packing (For Comp. ) 313202059807 313202059807 9355988001 313202059807 9352456039 9352456039
128-1 Rubber (Discharge Pipe) --------- --------- --------- --------- --------- 313155086308
158 Joint Pipe 9365312018 --------- --------- --------- --------- --------178-1 Capillary Holder Rubber 313414274807 --------- 313414274807 --------- --------- --------178-2 Capillary Holder Rubber --------- --------- --------- --------- 313394274808 313394274808
187 Clamp No. 1219 313361271706 313361271706 313361271706 313361271706 313361271706 313361271706
196-1 Clamp SKB-3M --------- 312300787605 312300787605 312300787605 --------- --------218-2 Power Relay --------- --------- --------- --------- --------- 9900008017
218-3 Power Relay --------- --------- --------- --------- 9900074012 --------232 Joint Pipe --------- 9365312032 9300990028 9365312032 --------- ---------
– 61 –
Page 57
AOG18AZE, AOG18RZEL
AOG24ABE, AOG24RZEL
AOG30AVAL, AOG30RVAL
OUTDOOR UNIT (Continued)
Ref.
No.
259 Muffler --------- 313755083903 313948083902 9350605002 313755083903 313755083903
271 Rubber (4-Way Valve) --------- 313728251908 --------- 313728251908 --------- --------272 Strainer --------- --------- --------- --------- --------- 9360147011
300 Suction Pipe-C --------- 9350358014 --------- 313986157307 --------- --------324 Muffler Cushion-B --------- --------- --------- 313584295407 --------- --------330 Inlet Pipe-A Assy --------- 9366859017 --------- --------- --------- --------331 Suction Pipe-D --------- 9350359011 --------- 313986353502 --------- --------332 Suction Pipe-E --------- 9301296013 --------- 9350600007 --------- --------333 Accumulator --------- 9350363018 --------- 313986117201 --------- 9366439004
334 Suction Pipe-B --------- 9351591014 --------- 9350599004 --------- ---------
335 Insulation (Accumulator) --------- 313681188608 --------- 313681188608 --------- --------338 Motor Fixture Metal 313029297108 313029297108 313029297108 313029297108 --------- --------343 Solenoid Coil --------- 9359616092 --------- 9359616092 --------- 9360538017
344 4-Way Valve --------- 313943302804 --------- 9300604017 --------- 9360195005
348 Outlet Pipe (Cond. ) Assy --------- --------- --------- 9365391051 9360171009 9360131003
348-1 Outlet Pipe-B --------- 9365391020 --------- --------- --------- --------348-2 Outlet Pipe-A --------- 9365391075 --------- --------- --------- --------349 Outlet Pipe-E --------- --------- --------- --------- 9360174000 --------351 Outlet Pipe-F --------- --------- --------- --------- --------- 9360158000
360 4-Way Valve Band --------- 313986251802 --------- 313986251802 --------- ---------
361 Accumulator Support Assy --------- 313986353804 --------- 313986353804 --------- 9359843016
371 Process Pipe-B 313142082352 --------- 313142082352 --------- --------- --------407 Clamp (Cable) No. 1259 --------- --------- --------- --------- 313739340109 313739340109
450 Discharge Pipe-A --------- --------- --------- --------- 9360166005 9360124005
477 Bell-Mouth --------- --------- --------- --------- 9359809012 9359809012
519 Restrector Valve Assy --------- 9365392034 --------- 9365392041 --------- --------527 Protection Net --------- --------- --------- --------- 9359844013 9359844013
549 Thermostat-Outdoor --------- --------- --------- --------- 9352553004 --------620 Inlet Pipe (Cond. ) Assy --------- --------- --------- 9363796025 9360167002 9360126009
646 Compressor Cover-B 313986355101 313986355101 313986355101 313986355101 9353368003 9353368003
Description
AOG18AZE
When you order parts, please make a photocopy of this page
and fill the number of the parts in the "Order" column.
Part No.
AOG30RVALAOG18RZEL AOG24ABE AOG24RZEL AOG30AVAL
Ord.
Q'ty
652-1 Thermistor Holder Pipe --------- --------- --------- --------- --------- 313806262805
653-1 Bolt (Fan Motor Fixing) --------- --------- --------- --------- 0700156014 0700156014
717 Center Plate 9350216017 9350216017 9350216017 9350216017 --------- --------718 Discharge Pipe-C --------- --------- --------- 9350603008 --------- --------734 Cabinet Top Plate, Panel --------- --------- --------- --------- 9359799023 9359799023
744 Clamp (Condenser) --------- --------- --------- --------- 313166374106 313166374106
750 Joint Pipe-A --------- --------- 9301003017 --------- --------- --------751 Bracket (Muffler) Assy --------- --------- --------- 9350612000 --------- --------790 Belt Heater --------- --------- --------- --------- --------- 9361140035
812 Grip --------- --------- --------- --------- 9352157004 9352157004
815 Terminal-5P --------- 9356497021 --------- 9356497021 --------- --------815-1 Terminal-3P 9356488005 --------- 9356488005 --------- --------- --------815-3 Terminal-8P --------- --------- --------- --------- 9358660119 9358660119
817 Thermostat Fixture --------- --------- --------- --------- 9352164019 --------823-2 Fuse Holder --------- --------- --------- --------- 0500063024 0500063024
824-4 Fuse --------- --------- --------- --------- 0600222529 0600222529
826 Condensing Pipe-B 9353601001 --------- 9353601001 --------- --------- --------829 Joint Pipe-A 9365314012 --------- --------- --------- --------- --------867 Accumulator Holder Rubber --------- 9354022027 --------- 9354022010 --------- 9354022010
909 Strainer-A --------- --------- 9365112014 --------- --------- ---------
910 Strainer-B --------- 9365099018 --------- --------- --------- --------922 Muffler Rubber --------- --------- --------- 9354014008 --------- --------983 Thermostat Cover --------- --------- --------- --------- 9358274002 --------989-1 Cord Clamp-A --------- --------- --------- --------- 9359822011 9359822011
989-2 Cord Clamp-B --------- --------- --------- --------- 9359823018 9359823018
– 62 –
Page 58
June 2002 Printed in Japan0206J2049
Loading...
