Generac Power Systems Mobile Power MMG130 Specifications

Mobile Generator – MMG130 Specifications

ENGINE

• John Deere

turbocharged, diesel engine

o Prime - 152 hp @ 1800 rpm
o Standby - 166 hp @ 1800

o 4 cylinder
o 4.5 L displacement
o Interim Tier IV emissions

• Steel, single wall fuel tank

o 342 gal. capacity
o 44 hr. run time – full load
o Fuel tank built into skid of

• Fuel consumption at prime:

o 100% - 7.4 gph (28.0 Lph)
o 75% - 5.5 gph (20.8 Lph)
o 50% - 3.7 gph (14.0 Lph)

• Cooling system capable of operating at 120°F ambient

• Low coolant shutdown

• Radiator and oil drains plumbed to exterior

• Rubber vibration dampers isolate engine/generator from frame

• Disposable air filter - paper element

• Air filter restriction indicator mounted on control panel

• 60 Hz engine/generator

• Electronic isochronous governing

• Utilizes DOC / DPF exhaust filter

• Variable Geometry Turbocharger (VGT)

®

PE4045HFG93 -

rpm

generator set

GENERATOR

• Marathon Electric

o Brushless
o 4 pole
o Class H insulation

• Voltage regulation +/- 1% with Marathon SE350 Voltage Regulator

SYSTEM OUTPUT

• 3 selector switch modes:

o Single phase – 120 / 240V Zig Zag
o Three phase – 120 / 208V Low Wye
o Three phase – 277 / 480V High Wye

Manufactured by Magnum Power Products LLC., a wholly owned subsidiary of Generac Power Systems, Inc.

®

Phone: [phone] Fax: [phone] www.m-p-llc.com

Page 1 of 5

06/12

MMG130 Specifications Continued:

• 96 kW / 96 kVA – standby, single phase

• 90 kW / 90 kVA – prime, single phase

• 107 kW / 134 kVA – standby, three phase

• 98 kW / 122 kVA – prime, three phase

SYSTEM CONTROLS

• Microprocessor-based controller

o Backlit, 128x64 pixel resolution display
o -40°F to 185°F operating

temperature range

o Thermostatically controlled LCD

heater

o Six LED indicators w/ lamp test

♦ Alarm / Fault (Red)
♦ Ready / Manual (Red)
♦ Running (Green)
♦ Warning (Yellow)
♦ Ready / Auto (Green)
♦ Supplying Load (Green)

• Push buttons for easy operation

o Manual or Auto Start
o Engine Start or Stop
o Alarm Cancel & Fault Reset
o Scrolling Arrows for Diagnostic Information

♦ System kW output display
♦ Line output & frequency display
♦ Engine diagnostic display

♦ System hours

o Alarm list – warnings / shutdowns are date & time stamped

♦ Fuel level: warning – 15%; shutdown – 5%
♦ Overspeed protection: shutdown – 115%
♦ Oil pressure: warning – 25 psi; shutdown – 20 psi
♦ Coolant temperature: warning – 220°F; shutdown – 230°F
♦ Battery voltage: over – 15VDC; under – 11VDC
♦ Generator over voltage: warning – 110%; shutdown – 111%
♦ Generator under voltage: warning – 87%; shutdown – 86%
♦ Generator over frequency: warning – 105%; shutdown – 110%
♦ Generator under frequency: warning – 95%; shutdown – 90%
♦ Over current shutdown

Manufactured by Magnum Power Products LLC., a wholly owned subsidiary of Generac Power Systems, Inc.

• Oil pressure

• Engine temperature

• Fuel level

• Battery

• Running hours

• kW hours

• Time to service

Phone: [phone] Fax: [phone] www.m-p-llc.com

Page 2 of 5

06/12

MMG130 Specifications Continued:

ELECTRICAL CONTROLS

• Remote start / stop contacts located next to lug box

• Lockable control box door with diagnostics window

• Lockable lug box with safety switch

o Trips main breaker when lug door is opened
o Disables voltage regulator

• Cable entry guides to the lug box

o Restricts access of foreign objects

• Output ground connection lug inside lug box

• Convenience receptacles with individual breakers (restricted use in high wye mode)

o (2) 120V 20 Amp GFCI duplex outlets (Nema 5-20R type)
o (3) 125 / 250V 50 Amp, 3 pole, 4 wire twistlock (Non-Nema 6369)

• Panel mounted rheostat for voltage adjustment - +/- 10%

• 1000 CCA wet cell battery

ENCLOSURE

• Generac Mobile Power decals

• Aluminum, sound attenuated enclosure

o UV & fade resistant, high temperature cured, white polyester powder paint
o Insulated and baffled
o 68 dB(A) at 23 feet – prime power

• Fully lockable enclosure including doors and fuel fill

• Stainless steel hinges on doors

• Emergency stop switch located on outside of enclosure

• Central lifting point

• Multi-lingual operating/safety decals

• Document holder with operating manual including AC/DC wiring diagrams

TRAILER

• DOT approved tail, side, brake, and directional lights

o Recessed rear lights

• Transportation tie downs

• Safety chains with spring loaded safety hooks

• 3” lunette ring hitch

• (2) 6000 lb. axles with surge brakes

• 5000 lb. tongue jack with footplate

• 7.50x16E-6-W tubeless tires – 10 ply

WEIGHTS & DIMENSIONS

Skid mounted

• Dry weight: 5444 lbs (2469 kg)

• Operating weight: 7929 lbs (3596 kg)

• 144 x 50 x 77 in

(3.66 x 1.27 x 1.95 m)

Manufactured by Magnum Power Products LLC., a wholly owned subsidiary of Generac Power Systems, Inc.

Phone: [phone] Fax: [phone] www.m-p-llc.com

Page 3 of 5

06/12

MMG130 Specifications Continued:

Trailer mounted

• Dry weight: 6840 lbs (3102 kg)

• Operating weight: 9325 lbs (4230 kg)

• 210 x 86 x 93 in

(5.33 x 2.18 x 2.36 m)

WARRANTY

• Engine and generator covered under OEM warranty – consult factory for details.

CERTIFICATIONS

• CSA pending

ENGINE OPTIONS

♦ In-line engine block heater (Kim Hotstart)
♦ Fuel transfer pump

MMG130 Options

ELECTRICAL CONTROLS OPTIONS

♦ Battery disconnect
♦ Battery charger – 2A trickle

GENERATOR OPTIONS

♦ Super Start Generator - motor starting applications

VOLTAGE OUTPUT OPTIONS

♦ 4 position phase switch

 Single phase – 120 / 240V Zig Zag
 Three phase – 120 / 208V Low Wye
 Three phase – 277 / 480V High Wye
 Three phase – 120 / 240V Delta

♦ Dedicated voltage configurations
♦ Buck Transformer kit - Provides 120V at GFCI outlets when in 277/480V
♦ Cam locks

SYSTEM CONTROLS OPTIONS

♦ Auxiliary strobe/audible indication for soft & hard alarm conditions

COOLANT OPTIONS

♦ 60/40 Coolant - cold weather applications

Manufactured by Magnum Power Products LLC., a wholly owned subsidiary of Generac Power Systems, Inc.

Phone: [phone] Fax: [phone] www.m-p-llc.com

Page 4 of 5

06/12

MMG130 Specifications Continued:

ENCLOSURE OPTIONS

♦ Fire extinguisher
♦ Interior cabinet light
♦ Control panel light

FUEL TANK OPTIONS

♦ 36 hr. single wall fuel tank
♦ 23 hr. double wall fuel tank
♦ 120% Containment

TRAILER OPTIONS

♦ Tandem axle trailer w/ electric brakes
♦ 6 pin or 7 spade electrical connectors
♦ Spare tire/wheel kit

HITCH OPTIONS

♦ 2 5/16” ball
