GP5000
1 of 2
Model 5698-0
UPC Number: 696471056983
Emissions Certification: CARB
features customer connections
OHV SPLASH LUBRICATION
HIGH PERFORMANCE ALTERNATOR
STEEL FUEL TANK WITH FUEL GAUGE
LOCKING, FOLD-DOWN HANDLES
NEVER-FLAT WHEEL KIT
1.25" HARDENED STEEL TUBE CRADLE
CIRCUIT BREAKER PROTECTED OUTLETS
LOW TONE MUFFLER
Connection Outlets
(4) 5-20R 120V
L14-30R Twist-Lock 120/240V
A
B
Circuit Breakers
(2) 20A
(2) 25A
M
N
Hour MeterH
A/C Rated Output Watts: 5000
A/C Maximum Output Watts: 6250
Other Features
GP SERIES
Commercial/Residential
Portable Generators
specifications
Product Series
Model
Configuration/Emissions
A/C Rated Output Watts:
A/C Maximum Output Watts:
A/C Voltage
A/C Frequency
Rated 120/240 VAC Amperage
Max 120/240 VAC Amperage
Engine Displacement
Engine Type
Engine RPM
Recommended Oil
Lubrication Method
Choke Type
Idle Control
Starting Method
Battery
Battery Size
Low Oil Shutdown Method
GP5000
5698-0
CARB
5000
6250
120/240VAC
60 Hz
20.8
26.0
389cc
OHV
3600
SAE30
Splash Sump
Manual Lever
Full Speed
Manual
N/A
N/A
Low Level
Start Switch Type
Switch Location
Single-Point Lifting Eye
Fuel Gauge
Fuel Tank Capacity (Gal)
Fuel Tank Capacity (Ltrs)
Run Time at 50% (Hours)
Cord Set
Handle Style
Wheel type
Maintenance Kit
Warranty - Residential
Warranty - Commercial
On/Off Toggle
On Engine
N/A
Built-in Tank
6.60
24.98
10.00
N/A
Folding
9.5" Solid Wheels
Sold Separately
2 Year
1 Year
dimensions and weights
Length (L)
Width (W)
Height (H)
Extended Length (EL)
Carton Length
Carton Width
Carton Height
Unit Weight (lbs)
Shipping Weight (lbs)
33.5
26.5
27.5
47.0
35.5
26.5
27.5
167.0
180.0
GP5000
Generac Power Systems, Inc. P.O. Box 8, Waukesha, WI 53187 generac.com
©2008 Generac Power Systems, Inc. All rights reserved. All specifications are subject to change without notice. Bulletin 0182720SBY/Printed in U.S.A.6/17/2009
2 of 2
Fuel Shut Off Manual Lever
