XP6500E
1 of 2
Model 5605-0
UPC Number: 696471056051
Emissions Certification: 49/CSA
features customer connections
GENERAC OHVI ENGINE, FULL PRESSURE LUBRICATION
ALL ENGINE CONTROLS LOCATED ON OUTLET PANEL
LOW-OIL PRESSURE SHUT-DOWN
COVERED, CIRCUIT BREAKER PROTECTED OUTLETS
H-STYLE LOCKING FOLD-DOWN HANDLES
FULL-WRAP, 1¼” HARDENED STEEL TUBE CRADLE
HOUR METER WITH MAINTENANCE RESETS
STEEL FUEL TANK WITH BUILT-IN FUEL GAUGE
HEAVY-DUTY NEVER-FLAT WHEELS
ELECTRIC START INCLUDING STARTING BATTERY
Connection Outlets
4X5-20R.GFCI
1xL14-30R
A
B
Circuit Breakers
(2) 20A
(1) 27A
M
N
Hour MeterH
Off/On/Start SwitchI
ChokeJ
Fuel Cut-OffK
12VDC Battery Charger InputL
A/C Rated Output Watts: 6500
A/C Maximum Output Watts: 8125
Other Features
XP SERIES
Commercial/Residential
Portable Generators
specifications
Product Series
Model
Configuration/Emissions
A/C Rated Output Watts:
A/C Maximum Output Watts:
A/C Voltage
A/C Frequency
Rated 120/240 VAC Amperage
Max 120/240 VAC Amperage
Engine Displacement
Engine Type
Engine RPM
Recommended Oil
Lubrication Method
Choke Type
Idle Control
Starting Method
Battery
Battery Size
Low Oil Shutdown Method
XP6500E
5605-0
49/CSA
6500
8125
120/240VAC
60 Hz
27.1
33.9
410cc
OHVI
3600
SAE 30
Full Pressure
On Control Panel
Full Speed
Electric/Manual
Included
12VDC 10 Ahr
Low Pressure
Start Switch Type
Switch Location
Single-Point Lifting Eye
Fuel Gauge
Fuel Tank Capacity (Gal)
Fuel Tank Capacity (Ltrs)
Run Time at 50% (Hours)
Cord Set
Handle Style
Wheel type
Maintenance Kit
Warranty - Residential
Warranty - Commercial
3-Position
On Control Panel
Optional
Built-in Tank
9.00
34.07
14.00
20' 30A
Folding Interlocked
10.5" Semi-Solid Wheels
Included
3 Year
2 Year
dimensions and weights
Length (L)
Width (W)
Height (H)
Extended Length (EL)
Carton Length
Carton Width
Carton Height
Unit Weight (lbs)
Shipping Weight (lbs)
32.5
26.0
29.5
50.5
34.0
24.0
30.5
177.0
237.0
XP6500E
Generac Power Systems, Inc. • S45 W29290 HWY. 59, Waukesha, WI 53189 • generac.com
© 2009 Generac Power Systems, Inc. All rights reserved. All specifications are subject to change without notice. Bulletin 0180310SBY/Printed in U.S.A.9/4/2009
2 of 2
Fuel Shut Off On Control Panel
