WLTFSM-136ACN
Quick installation Guide
1
LED Indicators
LED Indication
Status
Description
1
Power
ON
Power ON
OFF
Power OFF
2
WiFi status
ON
Wi-Fi ON
OFF
Wi-Fi OFF
Flashing
Transmitting data
3
VoIP Status
ON
VoIP ON
OFF
VoIP OFF
2
4
Signal
Strength
ON
Display signal strength
1 LED: 5dB < CINR < 10dB
2 LED: 10dB < CINR < 18dB
3 LED: 18dB < SINR
OFF
SINR < 5dB
Flashing
Scanning Base Station
5
Firmware
Upgrade
All LED
Flashing
3
Connectors
Connector
Description
1
Power
(DC-12V Port)
The power port is where you connect the
enclosed power adapter.
Power On/Off
Switch
The on/off switch support to turn off device
2
WPS
Holds down the button for 5 seconds to WPS
enable
3
Reset
Holds down the button for 5-seconds to
factory defaults.
4
LAN – RJ -45
The LAN port allows you to connect Modem to
your PC or Hub using a Cat.5/6 Ethernet
4
network cable.
5
USB Type A Host
Support USB 2.0 Host
6
Voice– RJ-11
The voice port allows you to connect your
Phone to this Modem
7
Antenna
Connector
Support external Antenna with SMA
Connectors
8
USIM Slot
Support 2FF size ; 1.8V/3.3V USIM for LTE
Mode
5
Installation
Please follow the steps below to install the device:
Step1: Connect the device LAN port to your PC with a RJ-45 Ethernet
cable that is supplied.
Step2: Insert SIM card into the device with right direction.
Step3: Insert the power cord into the LTE Indoor CPE's DC-12V
power jack; and insert the plug into power outlet.
Step4: Switch ON the power. The device will start the booting
process. After a few seconds, the LED lights will start blinking.
6
Easy Setup
Please follow the steps below to configure your device through the
web interface:
Step1: Open the Web browser (Internet Explorer) and enter the
default IP address of the IDU CPE :
Step2: Enter username/password to access the web management
interface.
http://192.168.15.1
Username : administrator
Password : administrator
The page displays in your browser after login; you can simply
configure the device settings.
http://192.168.15.1
7
Europe – EU Declaration of Conformity
