GemTek Technology M950913GN User Manual

WMIM-205GN

User’s Guide

11N mini PCI module

Federal Communication Commission Interference

Statement

This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try
to correct the interference by one of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and
receiver.

- Connect the equipment into an outlet on a circuit different

This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause
undesired operation.

FCC Caution: Any changes or modifications not expressly
approved by the party responsible for compliance could void the
user's authority to operate this equipment.

IMPORTANT NOTE:
FCC Radiation Exposure Statement:

This equipment complies with FCC radiation exposure limits set forth
for an uncontrolled environment. This equipment should be installed
and operated with minimum distance 20cm between the radiator &
your body.

This transmitter must not be co-located or operating in conjunction
with any other antenna or transmitter.

from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician
for help.

IEEE 802.11b or 802.11g operation of this product in the U.S.A.
is firmware-limited to channels 1 through 11.

This device is intended only for OEM integrators under the

End Product Labeling

following conditions:

1) The antenna must be installed such that 20 cm is maintained
between the antenna and users, and

2) The transmitter module may not be co-located with any other
transmitter or antenna, and

3) For all products market in US, OEM has to limit the operation
channels in CH1 to CH11 for 2.4G band by supplied firmware
programming tool. OEM shall not supply any tool or info to the
end-user regarding to Regulatory Domain change.

As long as 3 conditions above are met, further transmitter test will not
be required. However, the OEM integrator is still responsible for
testing their end-product for any additional compliance requirements
required with this module installed (for example, Router, Access

Point… etc.).

IMPORTANT NOTE: In the event that these conditions can not be
met (for example certain laptop configurations or co-location with

This transmitter module is authorized only for use in device where the
antenna may be installed such that 20 cm may be maintained
between the antenna and users (for example : Access point,
Router… mobile device.). The final end product must be labeled in a
visible area with the following: “Contains TX FCC ID:
MXF-M950913GN”.

Manual Information To the End User

The OEM integrator has to be aware not to provide information
to the end user regarding how to install or remove this RF
module in the user’s manual of the end product which integrates
this module.

The end user manual shall include all required regulatory
information/warning as show in this manual.

another transmitter), then the FCC authorization is no longer
considered valid and the FCC ID can not be used on the final product.
In these circumstances, the OEM integrator will be responsible for
re-evaluating the end product (including the transmitter) and obtaining
a separate FCC authorization.
