GemTek Technology DPH153AT User Manual

AT&T 3G MicroCell™

User Manual

ATT3GMicroCell_UserManual_1210.indd 1ATT3GMicroCell_UserManual_1210.indd 1 12/16/10 4:46 PM12/16/10 4:46 PM

ATT3GMicroCell_UserManual_1210.indd 2ATT3GMicroCell_UserManual_1210.indd 2 12/16/10 4:46 PM12/16/10 4:46 PM

AT&T 3G MicroCell™

User Manual | Table of Contents

Getting Started

Requirements 4
Getting To Know Your Device 4
Frequently Asked Questions 5
Overview 7
Step 1: Connect your device to the Internet 8
Step 2: Power on your device 10
Step 3: Activate your device online 10
Step 4: Wait while your device connects 10
Step 5: Confirm your success! 11

Troubleshooting

Help With Activating Your 3G MicroCell 12
Help After Activating Your 3G MicroCell 15
Alternate Connection 17

Other

Decoding The Lights On Your 3G MicroCell 18
Important Safety Instructions 20
Firewall Settings 23
Specifications 23
RF Exposure 24
FCC Compliance 24
Index 26
One-Year Limited Warranty Back Cover

ATT3GMicroCell_UserManual_1210.indd 3ATT3GMicroCell_UserManual_1210.indd 3 12/16/10 4:46 PM12/16/10 4:46 PM

AT&T 3G MicroCell™ User Manual | Getting Started

Requirements

To use the AT&T 3G MicroCell™, you need:

» High speed Internet service over U-verse®, DSL, or cable. For best

performance, download speeds of at least 1.5 Mbps and upload
speeds of at least 256 Kbps are recommended. There are no
restrictions on broadband service providers. Satellite Internet

service is not supported.
» Modem or optional wireless router.
» Computer with Internet access to activate your device.

Getting To Know Your Device

STATUS INDICATORS

Your MicroCell uses indicator lights on the
front of the device to show service status.

Power

Ethernet

GPS

Computer

3G

HARDWARE PORTS

Color coded connection ports are located
on the back of the device.

In the box

» AT&T 3G MicroCell™
» Yellow Ethernet

Cable
» AC Power Adapter
» Quick Start Guide
» User Manual

Computer

Ethernet

Power

4

ATT3GMicroCell_UserManual_1210.indd 4ATT3GMicroCell_UserManual_1210.indd 4 12/16/10 4:46 PM12/16/10 4:46 PM

Frequently Asked Questions

I activated my MicroCell at the
AT&T store. Do I have to do it again?

No, you can skip Step 3 and proceed to
Step 4 of the setup process.

What’s the best location for the
MicroCell?

Your MicroCell works best within three
feet of a window and not in a basement
or closet. You will improve the chances of
receiving a GPS signal when you install
your MicroCell:

» On first floor or above basement level.
» Next to a window with a clear,

unobstructed view of the sky.

» At least one foot away from other

wireless broadcasting devices.

» When the weather is clear (no clouds

or rain).

Will all cell phones work with my
MicroCell?

All 3G cell phones that receive wireless
service from AT&T will work with the
MicroCell if they are added online to the
MicroCell’s approved user list.

Do I need to change any settings on
my AT&T cell phone to make it work
with my MicroCell?

No, you don’t have to change anything on
your phone. If your AT&T cell phone number
is on your approved user list, it should work.

What is an approved user list?

The approved user list contains the phone
numbers of friends, family and associates
that you allow to use your MicroCell while
they are at your home or office. You can
only add people to this list who have an
AT&T wireless service plan. When they
make phone calls, they will use their own
minutes and service plan. To add an AT&T
3G cell phone number to your approved
user list, go to att.com/3GMicroCell and
manage your settings.

What type of Internet service does the
MicroCell need?

The MicroCell uses high speed
Internet service over U-verse, DSL, or cable.
For best performance, your service should
have download speeds of at least 1.5 Mbps
and upload speeds of at least 256 Kbps.
You can use any high speed Internet service
provider. Satellite Internet service is not
supported. Contact your Internet Service
Provider if your Internet service is slower
than minimum requirements.

5

ATT3GMicroCell_UserManual_1210.indd 5ATT3GMicroCell_UserManual_1210.indd 5 12/16/10 4:46 PM12/16/10 4:46 PM

AT&T 3G MicroCell™ User Manual | Getting Started

Frequently Asked Questions (cont.)

Why did my MicroCell lights go
off during activation?

Your MicroCell automatically checks
for software updates each time you
turn it on. If necessary, the MicroCell
downloads updated software and then
restarts.

Will my MicroCell slow down my
network?

The MicroCell takes up very little of your
bandwidth. Downloading music, videos, or
other large files may impact the bandwidth
available for your MicroCell and affect voice
quality.

How do I improve the voice quality?

Use the Alternate Connection on page
17 to ensure that you’re getting the best
possible voice quality for phone calls made
using the 3G MicroCell signal.

Should I use my MicroCell for data
instead of Wi-Fi?

The MicroCell supports data usage.
However, it is not intended to be a
replacement for your wireless network
(Wi-Fi). Data over Wi-Fi doesn’t affect
your wireless plan and provides best
performance for Wi-Fi capable cell phones
and other devices. The MicroCell is a
great supplement for data on cell phones
that aren’t Wi-Fi capable.

How do I move my MicroCell to a new
location?

Use the Quick Start Guide for setup
instructions and then update your account
online with the new address by visiting

att.com/3GMicroCell and manage your

settings.
NOTE: The new location must be in an area
where AT&T is licensed to provide service.

How do I purchase the Unlimited
MicroCell Calling feature?

Go to wireless.att.com. Log in to your
online wireless account and click “Manage
Features” and select “AT&T Unlimited
MicroCell Calling.”

I have more questions.

For more information about your MicroCell,
visit att.com/3GMicroCell.

6

ATT3GMicroCell_UserManual_1210.indd 6ATT3GMicroCell_UserManual_1210.indd 6 12/16/10 4:46 PM12/16/10 4:46 PM

Overview

This guide will take you step-by-step through
configuration, activation, and confirmation.

STEP 1

Connect your device to the Internet.

STEP 2

Power on your device.

www

STEP 3

Activate your device online.

90

MIN

STEP 4

Wait while your device connects.

STEP 5

Confirm your success!

7

ATT3GMicroCell_UserManual_1210.indd 7ATT3GMicroCell_UserManual_1210.indd 7 12/16/10 4:46 PM12/16/10 4:46 PM

AT&T 3G MicroCell™ User Manual | Getting Started

STEP 1

Connect your device to the Internet.

Select the configuration option that’s right for you to connect your device.

PLACEMENT TIPS

Your MicroCell works best within three feet of a window and not in
a basement or closet.

You will improve the chances of receiving a GPS signal when you install your MicroCell:

» On first floor or above basement level.
» Next to a window with a clear, unobstructed view of the sky.
» At least one foot away from other wireless broadcasting devices.
» When the weather is clear (no clouds or rain).

E911 SERVICE

The location address you provide during online activation is sent to local emergency
responders and must be kept up to date if you move your device. To update your
location address information, visit att.com/3GMicroCell and manage your settings.

8

ATT3GMicroCell_UserManual_1210.indd 8ATT3GMicroCell_UserManual_1210.indd 8 12/16/10 4:46 PM12/16/10 4:46 PM

I have a network.

I do not have

a network.

1. Connect the yellow Ethernet cable

from the “Ethernet” port on your
MicroCell to your router.

ATT3GMicroCell_UserManual_1210.indd 9ATT3GMicroCell_UserManual_1210.indd 9 12/16/10 4:46 PM12/16/10 4:46 PM

1. Disconnect the existing Ethernet

cable from your modem and connect
it to the “Computer” port on your
MicroCell.

2. Connect the yellow Ethernet cable

to the “Ethernet” port on your
MicroCell and the Ethernet port on
your modem.

9
