Owner’s
Manual
Side-by-Side
36″,42″,48″
Built-In Refrigerators
02-08 JR
monogram.com
49-60559
224D1893P005
Consumer Information
Built-In Refrigerators
2
Contents
Consumer Services
Important Phone Numbers . . . . . . . . . . . . . . . . . .29
Model and Serial Numbers . . . . . . . . . . . . . . . . . . .3
Problem Solver . . . . . . . . . . . . . . . . . . . . . . . . .24–26
Product Registration . . . . . . . . . . . . . . . . . . . . . . . . .3
Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . 4–7
Smartwater Filter Performance
Data Sheet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
State of California
Water Treatment Device Certificate . . . . . . . . .28
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . Back Cover
Care and Cleaning
Cleaning—Outside and Inside . . . . . . . . . . . . . . .19
Light Bulb Replacement . . . . . . . . . . . . . . . . 20–21
Moving and Vacation . . . . . . . . . . . . . . . . . . . . . . .22
Master Light Switch . . . . . . . . . . . . . . . . . . . . . . . .21
Operating Instructions
Automatic Icemaker . . . . . . . . . . . . . . . . . . . . . . . .12
Climate Control Drawer . . . . . . . . . . . . . .13, 14, 16
Control Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Ice and Water Dispenser . . . . . . . . . . . . . . . .10, 11
Shelves and Bins . . . . . . . . . . . . . . . . . . . . . . . .17, 18
Storage Pans . . . . . . . . . . . . . . . . . . . . . . . . . . .15, 16
Temperature Controls . . . . . . . . . . . . . . . . . . . . . . . .8
Water Filter Cartridge . . . . . . . . . . . . . . . . . . . . . . . .9
Sabbath Mode Product Kit, ZSAB1 . . . . . . . . . . .18
3
If you
received a
damaged
refrigerator
Immediately contact the dealer (or builder) that
sold you the refrigerator.
Save time
& money
Before you request service, check the
Problem Solver in the back of this manual.
It lists causes of minor operating problems that
you can correct yourself.
If you
need
service
To obtain service, see the Consumer Services
page in the back of this manual.
We’re proud of our service and want you to be
pleased. If for some reason you are not happy
with the service you receive, here are steps to
follow for further help.
For customers in the USA:
FIRST, contact the people who serviced your
appliance. Explain why you are not pleased.
In most cases, this will solve the problem.
NEXT, if you are still not pleased, write all the
details—including your phone number—to:
Manager, Customer Relations
GE Appliances
Appliance Park
Louisville, KY 40225
For customers in Canada:
FIRST, contact the people who serviced your
appliance. Explain why you are not pleased.
In most cases, this will solve the problem.
NEXT, if you are still not pleased, write all
the details–including your phone number to:
Manager, Consumer Relations
Mabe Canada Inc.
1 Factory Lane, Suite 310
Moncton, N.B. E1C 9M3
Consumer Information
Built-In Refrigerators
Before
using your
refrigerator
Read this manual carefully. It is intended
to help you operate and maintain your new
refrigerator properly.
Keep it handy for answers to your questions.
If you don’t understand something or need more
help, there is a list of toll-free consumer service
numbers included in the back section of this
manual.
OR
Visit our website at: monogram.com
Write
down the
model &
serial
numbers
You’ll see them on a label in the lower right hand
side of the fresh food compartment beneath
the climate control drawer.
These numbers are also on the Consumer
Product Ownership Registration Card
included with this manual.
Before sending in this card, please write these
numbers here:
Model Number
Serial Number
Use these numbers in any correspondence or
service calls concerning your refrigerator.
4
IMPORTANT SAFETY INSTRUCTIONS
REFRIGERANTS
All refrigeration products contain refrigerants,
which under federal law must be removed prior
to product disposal. If you are getting rid of
an old refrigeration product, check with the
company handling the disposal about what
to do.
w DANGER: RISK OF CHILD ENTRAPMENT
Child entrapment and suffocation are not
problems of the past. Junked or abandoned
refrigeration products are still dangerous… even
if they will sit for “just a few days.” If you are
getting rid of your old appliance, please follow
these instructions to help prevent accidents.
Before You Throw Away Your Old Refrigeration
Product:
• Take off the doors.
• Leave the shelves in place so that children
may not easily climb inside.
READ AND SAVE THESE INSTRUCTIONS
w WARNING – When using
this appliance, always exercise basic safety
precautions, including the following:
• Use this appliance only for its intended
purpose as described in this Owner’s Manual.
• This refrigerator must be properly installed
in accordance with the Installation
Instructions before it is used.
• Do not allow children to climb, stand or
hang on the shelves in the refrigerator.
They could damage the refrigerator and
seriously injure themselves.
• After your refrigerator is in operation,
do not touch the cold surfaces in the
freezer compartment, particularly when
hands are damp or wet. Skin may adhere
to these extremely cold surfaces.
• Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
• In refrigerators with an automatic icemaker,
avoid contact with the moving parts of the
ejector mechanism, or with the heating
element located on the bottom of the
icemaker. Do not place fingers or hands
on the automatic icemaking mechanism
while the refrigerator is plugged in.
• Keep fingers out of the “pinch point” areas:
clearances between the doors and between
the doors and cabinet are necessarily small.
Be careful closing doors when children are
in the area.
• Unplug your refrigerator before cleaning
and making repairs. NOTE: We strongly
recommend that any servicing be performed
by a qualified individual.
• Before replacing a burned-out light bulb,
set the Master Light switch in the OFF position
to turn off the lights in order to avoid contact
with a live wire filament. (A burned-out light
bulb may break when being replaced.)
NOTE: Setting the refrigerator temperature
controls to OFF does not remove power
to the light circuit.
• Do not refreeze frozen foods which have
thawed completely.
5
IMPORTANTES INSTRUCTIONS DE SÉCURITÉ
RÉFRIGÉRANTS
Tous les appareils de réfrigération
contiennent des réfrigérants qui, conformément
aux lois fédérales, doivent être enlevés avant
toute élimination de l’appareil. Si vous vous
débarrassez de vieux appareils de réfrigération,
vérifiez, auprès de la société qui s’occupe
de leur élimination, ce que vous devez faire.
w DANGER! RISQUES POUR LES ENFANTS
Les enfants pris au piège ou morts d’asphyxie
sont toujours d’actualité. Les appareils de
réfrigération abandonés sont toujours aussi
dangereux, même si on n’attend que “quelque
jours” pour s’en débarasser. Si vous ne gardez
pas votre ancien appareil, veuillez suivre
les directives ci-dessous afin de prévenir
les accidents.
Avant de vous débarasser de votre vieux
appareil de réfrigération :
• Démontez les portes.
• Laissez les clayettes en place afin d’empêcher
les enfants de grimper à l’intérieur.
LISEZ ET CONSERVEZ CES INSTRUCTIONS
w
AVERTISSEMENT : Lorsque
vous utilisez le réfrigérateur, observez
toujours certaines précautions de base,
notamment :
• N’utilisez le réfrigérateur que pour son usage
prévu, comme décrit dans le présent manuel.
• Installez le réfrigérateur conformément aux
directives d’installation avant de l’utiliser.
• Ne laissez pas les enfants grimper, s’asseoir,
se tenir debout ni se pendre aux clayettes
du réfrigérateur. Ils pourraient endommager
le réfrigérateur et se blesser gravement.
• Une fois le réfrigérateur en marche,
ne touchez pas les surfaces froides
du congélateur, surtout si vous avez
les mains humides ou mouillées : la peau
risque d’adhérer à ces surfaces très froides.
• N’entreposez et n’utilisez pas d’essence
ou autres vapeurs et liquides inflammables
à proximité de cet appareil ou de tout autre
appareil électroménager.
• Pour les réfrigérateurs dotés d’une machine
à glaçons automatique, évitez le contact avec
les pièces mobiles du mécanisme éjecteur,
ou avec l’élément chauffant situé à la partie
inférieure de la machine à glaçons. Ne posez
pas les doigts ou les mains sur le mécanisme
de la machine à glaçons pendant que
le réfrigérateur est branché.
• Éloignez les doigts des parties du
réfrigérateur où l’on peut facilement
se pincer : les espaces entre les portes
et les placards sont toujours étroits. Soyez
prudent lorsque vous fermez les portes
de l’appareil en présence des enfants.
• Débranchez votre réfrigérateur avant
de le nettoyer et de le réparer. REMARQUE :
Nous vous recommandons vivement de confier
toute réparation à un technicien qualifié.
• Avant de remplacer une ampoule grillée,
mettez le commutateur de lumière principale
en position OFF (arrêt) pour éteindre la lumière
afin d’éviter tout contact avec un fil sous
tension. (Une ampoule grillée peut se briser
pendant l’opération). REMARQUE : Lorsque
vous placez les commandes de température
du réfrigérateur sur OFF (arrêt), l’alimentation
électrique de l’ampoule n’est pas coupée.
• Ne faites PAS recongeler des aliments
surgelés qui ont complètement dégelé.
6
SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
HOW TO CONNECT ELECTRICITY
Do not, under any circumstances, cut or
remove the third (ground) prong from the
power cord. For personal safety, this appliance
must be properly grounded.
The power cord of this appliance is equipped
with a 3-prong (grounding) plug which mates
with a standard 3-prong (grounding) wall outlet
to minimize the possibility of electric shock
hazard from this appliance.
Have the wall outlet and circuit checked
by a qualified electrician to make sure the outlet
is properly grounded.
Where a standard 2-prong wall outlet is
encountered, it is your personal responsibility
and obligation to have it replaced with
a properly grounded 3-prong wall outlet .
Use of a GFI (Ground Fault Interruptor) is not
recommended for the refrigerator outlet.
The appliance should always be plugged into
its own individual electrical outlet which has
a voltage rating that matches the rating plate.
This provides the best performance and also
prevents overloading house wiring circuits
which could cause a fire hazard from
overheated wires.
DO NOT USE AN ADAPTER PLUG TO CONNECT
THE REFRIGERATOR TO A 2-PRONG OUTLET.
DO NOT USE AN EXTENSION CORD WITH
THIS APPLIANCE.
Never unplug an appliance by pulling on
the power cord. Always grip the plug firmly
and pull straight out from the outlet.
Repair or replace immediately all power cords
that have become frayed or otherwise damaged.
Do not use a cord that shows cracks or abrasion
damage along its length or at either end.
When moving the appliance, be careful not to
roll over or damage the power cord.
7
CONSERVEZ CES DIRECTIVES
IMPORTANTES INSTRUCTIONS DE SÉCURITÉ
RACCORDEMENT ÉLECTRIQUE
Ne coupez ni retirez en aucun cas
la troisième broche (mise à la terre) de la fiche
du cordon d’alimentation. Pour votre sécurité,
cet appareil doit être correctement mis
à la terre.
Le cordon d’alimentation de cet appareil est
muni d’une fiche à 3 broches (mise à la terre)
qui se branche dans une prise mural ordinaire
à 3 alvéoles (mise à la terre) pour réduire
au minimum les risques du chocs électriques.
Faites examiner la prise de courant et le circuit
par un électricien qualifié pour vous assurer
que la prise est correctement mise à la terre.
Si la prise murale est du type standard
à 2 alvéoles, il vous incombe de la faire
remplacer par une prise à 3 alvéoles
correctement mise à la terre.
L’utilisation d’un interrupteur de défaut
à la terre (GFI–Ground Fault Interruptor)
nést pas recommandé pour la prise
de courant du réfrigérateur.
La machine à glaçons doit toujours être branché
dans sa propre prise de courant, dont la tension
nominale est identique à celle indiquée sur
la plaque signalétique. Cette précaution est
recommandée pour garantir un rendement
optimum et éviter une surcharge des circuits
électriques de la résidence, ce qui pourrait créer
un risque d’incendie par surschauffe des fils.
N’UTILISEZ PAS UNE FICHE D’ADAPTATION POUR
RACCORDER LE RÉFRIGÉRATEUR DANS UNE PRISE
MURALE À 2 ALVÉOLES.
N’UTILISEZ PAS DE CORDONS PROLONGATEURS
AVEC CET APPAREIL.
Ne débranchez jamais l’appareil en tirant
le cordon d’alimentation. Saisissez fermement
la fiche du cordon et tirez droit pour la retirer
de la prise.
Réparez ou remplacez immédiatement tout
cordon effiloché ou endommagé. N’utilisez
pas un cordon fendillé ou présentant des
signes d’usure.
Lorsque vous déplacez l’appareil du mur,
faites attention de ne pas la faire rouler
sur le cordon d’alimentation afin de ne pas
l’endommager.
8
Temperature Controls
Built-In Refrigerators
Temperature
controls
Changing
display
temperatures
from °F to °C
To change the temperature display
between Fahrenheit and Celsius, press
Temp Display °C/°F.
The temperature display shows the actual
temperature of the freezer and fresh food
compartments. The actual temperature will vary
from the set temperature based on factors such
as door opening, amount of food, defrost cycling
and room temperature.
NOTE: Frequent door openings or door left open
for periods of time may increase the internal
temperature of the freezer and fresh food
compartments temporarily.
To turn off the cooling system in both
the freezer and fresh food compartments, press
either pad until both displays show OFF.
To turn the cooling system on, press either
pad. The preset temperatures of 0°F and 37°F
will appear in the display.
To check the current temperature setting
for the fresh food or freezer compartment,
press the or pad once. After 5 seconds,
the display will return to the actual temperature.
To change the temperature settings, press
the or pads to desired temperature set
point for fresh food and freezer separately.
Allow 24 hours for the refrigerator to reach
the temperature you have set.
Temperature Ranges
Low High
Fresh Food
Freezer
NOTE: Setting the controls to OFF stops
cooling, but does not shut off electrical power
to the refrigerator.
34°F
1°C
–6°F
–21°C
45°F
7°C
+6°F
–14°C
Door
alarm
To turn the Door Alarm feature on, press
DOOR ALARM once. The ACTIVE light will come
on. To turn it off, press it again.
On models with a dispenser, the Door Alarm
feature is located on the dispenser panel on
the front of the freezer door.
When the DOOR ALARM
is active, the alarm will flash
and beep if you keep the door
open for more than 2 minutes.
Preset Settings:
Allow 24 hours to reach these preset temperatures.
9
Water filter cartridge
Cartridge
Holder
Slowly turn it to the right.
Do not overtighten.
Filter
Cartridge
The water filter cartridge is located in the top
machine compartment of the refrigerator.
To Replace the Filter:
The filter cartridge is designed
to filter 300 gallons of water
(lasting approximately 12 months).
There is a replacement indicator light
for the water filter cartridge on the temperature
control panel. This light will turn yellow to tell
you that you need to replace the filter soon.
The filter cartridge should be replaced when
the replacement indicator light turns red
or if the flow of water to the dispenser
or icemaker decreases.
Installing the Filter Cartridge:
1. Remove the old cartridge by slowly turning
it to the left. A small amount of water may
drip down. Do not pull down on the cartridge.
2. Fill the new cartridge with water from the tap
to allow for better flow immediately after
installation.
3. Line up the arrow on the cartridge with
the center of the holder. Do not push it up
into the holder.
4. Slowly turn it to the right until the cartridge
stops. It will rotate about 1/4 turn. DO NOT
OVERTIGHTEN.
To Reset the Filter Status Light:
Press and hold the RESET pad for 3 seconds.
Filter Bypass Plug:
You must use the filter bypass plug:
a) if you have a household
reverse osmosis water system
and/or another form of home
water filtration system
b) if a replacement filter is not
available.
The bypass plug and the mini-manual are located
in the top machine compartment.
The icemaker and dispenser will not operate
without the filter or filter bypass plug installed.
Replacement filters:
To order additional filter cartridges in the United
States, visit our Website at monogram.com, or
call GE Parts and Accessories, 800.626.2002.
Customers in Canada should consult the yellow
pages for the nearest Mabe Service Center.
Filter
Bypass
Plug
Water Filter Cartridge
Built-In Refrigerators
IMPORTANT NOTE: Remove the water filter to
immediately stop any water leak from the
Icemaker/Dispenser system. The water filter
cartridge holder (bracket) acts as a cut-off valve
when the filter is removed and will prevent
further leaking.
Call 1.800.844.1845 to schedule a service call
to repair the leak.
10
Dispenser
with
glass-touch
controls
How it Works
The electronic controls on the dispenser are
truly interactive. The control panel is equipped
with a proximity sensor that causes the panel to
light up as you approach the dispenser (approx.
2 inches). To make a selection, simply touch
the graphic for the feature you want, and the
halo for that feature will light up. When you walk
away from the refrigerator, the lighted graphics
switch off automatically.
Spill Shelf
Ice & Water Dispenser (on some models)
Built-In Refrigerators
How to Use
To dispense water or ice: select WATER , CUBED
ICE or CRUSHED ICE . Then press the glass
gently against the top of the dispenser cradle.
The spill shelf is not self-draining. To reduce
water spotting, the shelf and its grille should be
cleaned regularly.
If no water is dispensed when the refrigerator
is first installed, there may be air in the water
line system. Press the dispenser cradle for at
least two minutes to remove trapped air from
the water line and to fill the water system.
To flush out impurities in the water line,
throw away the first gallon of water.
CAUTION:Never put fingers
or any other objects into the ice crusher
discharge opening.
Locking the Dispenser:
Touch CONTROL LOCK for
3 seconds to lock the dispenser
and control pad. To unlock, touch
it again for 3 seconds.
Dispenser Light:
This feature turns the night light
on and off. The light also comes
on when the dispenser cradle is
pressed. If this light burns out, it
should be replaced with a 6 watt
12V maximum bulb. The bulb is available
through GE Parts and Accessories, 800.626.2002.
Order part number WR02X10675.
Door Alarm:
To turn the Door Alarm feature on,
touch DOOR ALARM once. To turn
it off, press it again.
When the DOOR ALARM
is active, the alarm will flash and beep if you
keep the door open for more than 2 minutes.
11
Ice storage
bin
To remove:
Lift up the access door to reach the icemaker.
Set the icemaker power switch to the OFF
position. With the access door closed, support
the storage bin at the bottom while slightly
lifting. Pull bin straight out.
To replace:
Slide the bin back until the tab on the bin locks
into the slot on the shelf. If the bin does not go
all the way back, remove it and rotate the drive
mechanism 1/4 turn. Then push the bin back
again.
Important
facts about
your ice
& water
dispenser
• Do not add ice from trays or bags to
the storage bin. It may not crush or
dispense well.
• Avoid overfilling glass with ice and use
of narrow or extra-tall glasses. Backed-up
ice can jam the chute or cause the door in
the chute to freeze shut. If ice is blocking
the chute, poke it through with a wooden
spoon.
• Beverages and foods should not be
quick-chilled in the ice storage bin. Cans,
bottles or food packages in the storage bin
may cause the icemaker or auger to jam.
• To keep dispensed ice from missing
the glass, put the glass close to, but not
touching, the dispenser opening.
• Some crushed ice may be dispensed even
though you selected CUBES. This happens
occasionally when a few cubes accidentally
get directed to the crusher.
• After crushed ice is dispensed, some water
may drip from the chute.
• Sometimes a mound of ice chips will form
on the door in the ice chute. This condition
is normal and usually occurs when you have
dispensed crushed ice repeatedly. The ice
chips will eventually evaporate.
• Dispensed water is not ice cold. For colder
water, simply add crushed ice or cubes before
dispensing water.
• The first glass of water dispensed may
be warmer than the following ones.
This is normal.
• To eliminate drips on the spill shelf, tilt
the glass in slightly when dispensing water.
Rotate
Drive
Mechanism
Ice Storage Bin
Access Door
Ice & Water Dispenser (on some models)
Built-In Refrigerators
12
Automatic icemaker
A newly-installed refrigerator may take
12–24 hours to begin making ice.
The icemaker will produce seven cubes per
cycle—approximately 15 cycles in a 24-hour
period, depending on freezer compartment
temperature, room temperature, number of
door openings and other use conditions.
If the refrigerator is operated before the water
connection is made to the icemaker, set the
power switch to OFF.
When the refrigerator has been connected
to the water supply, set the power switch to ON.
Throw away the first full bucket of ice.
Be sure nothing interferes with the sweep
of the feeler arm.
When the bin fills to the level of the feeler arm,
the icemaker will stop producing ice.
It is normal for several cubes to be joined
together.
If ice is not used frequently, old ice cubes
will become cloudy, taste stale and shrink.
After the icemaker has been turned on again,
there will be a delay of about 45 minutes before
the icemaker resumes operations.
NOTE: In homes with lower-than-average
water pressure, you may hear the icemaker
water valve cycle on several times when
making one batch of ice.
NOTE: Icemaker works best between
40 and 120 PSI home water pressure.
Automatic Icemaker
Built-In Refrigerators
Icemaker
Feeler Arm
Power
Switch
13
Climate Control drawer
How it Works
The Climate Control feature is a system of
dampers, a fan, a temperature thermistor, and a
heater. The Climate Control drawer can be used to
chill items quickly, thaw foods quickly or store items
at their optimum temperatures.
The drawer is tightly sealed to prevent the drawer’s
temperature from causing temperature fluctuations
in the rest of the refrigerator.
SELECT TEMP—Use this feature to store items at
their optimum temperatures. The CITRUS setting
will maintain a drawer temperature of 39–47°F
by cycling a small heater off and on as needed.
The PRODUCE setting will maintain the drawer
temperature at 31–38°F by drawing in additional
cold air as needed. The MEAT setting will
maintain the drawer temperature at 27–37°F
by drawing in additional cold air as needed.
EXPRESS CHILL—This feature can be used
to cool items in minutes, rather than hours.
Extra cool air is circulated throughout the
drawer. Once the cycle is complete, the drawer
will revert to the pre-set fresh food temperature.
EXPRESS THAW—This feature thaws items
in hours rather than days. Food is gently
thawed in a cool environment by circulating
air throughout the drawer. Temperature is
maintained in the drawer by cycling a small
heater off and on as needed. Once the thaw
cycle is complete, the pan will automatically
adjust to a temperature of 27–37°F to store
the food at its optimum temperature.
NOTE: By turning the controls on the Climate
Control drawer off, the drawer can be used as
a standard sealed produce pan.
How to Use
1 Empty the drawer. Place the items in
the drawer.
2 Select the Express Thaw,™ Express Chill™
or Select Temp™ pad. The display will come
on. Press the pad until the light appears next
to the desired setting. Use the chart on
the next page to determine the best setting.
• To stop a feature before it is finished,
press that feature’s pad until no options
are selected and the display is off.
• During Express Thaw™ and Express Chill,™
the display on the controls will count down
the time remaining in the cycle.
• After the Express Thaw™ cycle is
complete, the drawer will reset to the MEAT
setting (27–37°F) to help preserve thawed
items until they are used.
• The displayed actual temperature of
the Climate Control drawer may vary slightly
from the SET temperature based on usage
and operation environment.
NOTE: For food safety reasons, it is
recommended that foods be wrapped in
plastic wrap when using Express Thaw.™
This will help contain meat juices and
improve thawing performance.
Express Thaw™
Express Chill™
Climate Control Drawer
Built-In Refrigerators
14
Citrus Setting (39–47
°F)
• Oranges, Lemons, Limes,
Pineapple, Cantaloupe
• Beans, Cucumbers, Tomatoes,
Peppers, Eggplant, Squash
Pr
oduce Setting (31–38°F)
• Strawberries, Raspberries,
Kiwifruit, Pears, Cherries,
Blackberries, Grapes, Plums,
Nectarines, Apples
• Asparagus, Broccoli, Corn,
Mushrooms, Spinach,
Cauliflower, Kale, Green
Onions, Beets, Onions
Meat Setting (27–37
°F)
• Raw Meat, Fish and Poultry
15 Minutes
• 1 Beverage Can (12 oz)
• 2 Small Juice Boxes
(6–8 oz each)
30 Minutes
• Wine (750 ml bottle)
• 2 to 6 Beverage Cans
(12 oz each)
• 2 Plastic 20 oz Bottles
of Beverage
• 4 to 6 Small Juice Boxes
(6–8 oz each)
• 3 Foil Juice Packets
45 Minutes
• 2 Liter of Beverage
• 1/2 Gallon of Juice
• Gelatin—1 package
0.5 Lbs. (4 hours)
• Individually Wrapped
Filet Mignon (0.5 lb)
• Hamburger Patties (0.5 lb)
1.5 Lbs. (8 hours)
• Chicken Breasts (1.5 lbs)
• Ground Beef (1.5 lbs)
• Steak (1.5 lbs)
3.0 Lbs. (12 hour
s)
• Chicken Breasts (3.0 lbs)
• Ground Beef (3.0 lbs)
• Steak (3.0 lbs)
Climate
Control
chart
NOTE: Results may vary depending on packaging, starting temperature and other food traits.
Climate Control Drawer
Built-In Refrigerators
Control lock
Control Lock
Press and hold this pad for 3 seconds to lock
the settings for the Climate Control drawer.
To unlock, press and hold for another 3 seconds.
15
Sealed
deli pan
Use the Sealed Deli Pan for the convenient
storage of lunch meats and cheese, hors
d’oeuvres, spreads and snacks. The pan and
shelf to which it is attached can be adjusted
to any height.
Storage Pans
Built-In Refrigerators
Sealed
produce
pans
The top pan is designed to provide constant high
humidity levels.
Make sure the drawers are closed completely
to maintain the correct humidity level.
16
Drawer
and pan
removal
To remove a drawer or pan:
1. Pull the pan out to the stop position.
2. Lift the front of the pan up and out of
the wire holder.
3. Lift the back of the pan up and out.
To replace a pan:
1. Place the back of the pan in the wire
holder, making sure the wire holder fits
into the grooves on the back of the pan.
2. Lower the front of the pan into the wire holder.
3. Press firmly on the top of the pan to snap it
into the wire holder.
Climate Control Drawer and Storage Pans
Built-In Refrigerators
Drop down
shelf
The drop-down shelf gives you the use
of another full-size shelf when you need extra
storage. It conveniently folds back out
of the way when not in use, giving you room
for storage of larger items.
To use drop down shelf:
1. Pull forward and down to drop the shelf
into place.
2. Pull forward while lifting up to place the shelf
out of the way.
Lighted
vegetable
drawer
cover
The lighted vegetable drawer cover provides
lighting for the lower compartments. The lights
are recessed into the cover to illuminate
the drawers below.
To remove cover:
1. Remove the top drawer (see Drawer and pan
removal section).
2. Remove the thumb screw located inside
the front left corner under the cover.
This screw is in place so the cover cannot
be accidentally dislocated while in use.
3. Lift the cover and carefully pull forward
to expose the plug.
4. Unplug the cover and carefully remove it from
the refrigerator.
To replace cover:
1. Carefully set cover onto the side rails, leaving
the plug exposed.
2. Plug the cover into the refrigerator.
3. Carefully slide the cover into place.
4. Replace the thumb screw under the front edge
of the cover.
5. Replace the drawer (see Drawer and pan
removal section).
17
How to
rearrange
your shelves
Tempered glass shelves in the fresh food
compartment and wire shelves in the freezer
compartment are adjustable, enabling you to
make efficient shelf arrangements to fit your
family’s food storage needs.
To remove shelves:
Tilt shelf up at front, then lift it up and out
of tracks on rear wall of refrigerator.
To replace shelves:
Select desired shelf height. With shelf front
raised slightly, engage top lugs in tracks at rear
of cabinet. Then lower front of shelf until it locks
into position.
Shelves and Bins
Built-In Refrigerators
Door bins
All door bins, except for the deep gallon door bin,
are adjustable using one of 2 tabs on each end
of the bin. They can be moved up and down to
many different positions to meet your storage
needs. The deep gallon door bin can be removed
for cleaning.
To remove any bin:
Lift the bin up and slide it toward you.
Removable
wine rack
The rack can be attached to the left or
right side of any shelf. It is designed to hold
a bottle, including a 2 liter bottle, on its side.
Adjustable
Door Bin
Gallon
Door Bin
18
Freezer
baskets
Wire slide-out freezer baskets can be pulled out
for easy access to frozen foods.
To remove:
Pull basket out. Lift the front of the basket up
and then take it out.
Shelves and Bins
Built-In Refrigerators
Sabbath
Mode
Product Kit
(available at
extra cost)
The Sabbath Mode Product Kit was designed
for use on the Jewish Sabbath and Holidays.
The Sabbath Mode feature makes it possible
for observant Jews to refrigerate and freeze
food during the duration of the holiday.
The Sabbath Mode feature can be set to override
typical reactions to actions in your refrigerator.
While in the Sabbath Mode, your refrigerator will
still operate normally. However, the refrigerator
will not respond to your actions.
While in the Sabbath Mode, you may notice
the fan running when the door is opened;
however, this is not a result of your actions.
The fan will operate at random times.
The defrost heater will continue to defrost
the refrigerator and freezer and will be activated
on a timer. The defrost heater will not defrost
as a result of door openings or any consumer
actions.
ON/OFF—To activate, raise the top grille
panel and set the Sabbath Mode switch to
the ON position. A green LED light will be visible
below the Sabbath Mode Kit switch. The light will
be visible when the grille is closed between the
grille door and compartment doors.
DISPLAYS, ALARMS and LIGHTS—The main
temperature control and Express Chill displays
will be deactivated; therefore they will not be lit,
sound a tone or operate when touched. Door
alarms and lights will be disabled.
ICE and WATER DISPENSER—The proximity
sensor and dispenser touch sensor icons will
not operate. Ice or water cannot be retrieved
from the dispenser.
ICEMAKER—The icemaker will continue
to operate. The icemaker can be disabled by
opening the freezer, opening the ice storage bin
door and setting the icemaker power switch to
the OFF position (see Automatic Icemaker).
To obtain ice, open the freezer door and remove
the cubed ice from the ice bin.
This Sabbath Mode Product Kit can be purchased
from your local appliance dealer. The ZSAB1 Kit
is designed for use with all Monogram Built-In
Refrigerators manufactured after 2008.
To locate your nearest dealer, visit our web site
monogram.com or call 1.800.626.2000. In Canada,
call 1.800.561.3344. Order Kit # ZSAB1.
NOTE: The Sabbath Mode Product Kit must
be installed by a qualified service technician.
19
Cleaning
outside
The dispenser spill shelf
and the area beneath it
should be cleaned
periodically with a mild liquid dish detergent.
Dispenser cradle—Before cleaning, lock
the dispenser by touching CONTROL LOCK for
3 seconds to prevent activating the dispenser.
Clean with warm water and a mild liquid dish
detergent. Rinse thoroughly and wipe dry.
Unlock the dispenser by touching CONTROL
LOCK for 3 seconds.
Do not use chemical cleaners to clean
the dispenser or any part of the dispenser.
Door handles and trim—Clean with a cloth
dampened with soapy water. Dry with a soft
cloth.
Keep the outside clean. Wipe with a clean
cloth lightly dampened with mild liquid dish
detergent. Dry with a clean, soft cloth.
Do not wipe the refrigerator with a soiled
dish cloth or wet towel. These may leave
a residue that can damage the finish. Do not
use scouring pads, powdered cleaners, bleach
or cleaners containing bleach because these
products can scratch and damage the finish.
Stainless steel—Regularly clean and polish
the stainless steel door panels and handles
(on some models) with a commercially available
stainless steel cleaner such as Stainless Steel
Magic™ to preserve and protect the fine finish.
Stainless Steel Magic and the Monogram
polishing cloth are available through GE Parts
and Accessories, 800.626.2002, or monogram.com.
For Stainless Steel Magic, order part number
WX10X15. For Monogram polishing cloth,
order part number WX72X10001.
Do not use appliance wax or polish on
the stainless steel.
Care and Cleaning
Built-In Refrigerators
Cleaning
inside
Turn off power at the circuit breaker or fuse
box before cleaning. If this is not practical, wring
excess moisture out of sponge or cloth when
cleaning around switches, lights or controls.
Use warm water and baking soda solution—
about a tablespoon (15 ml) of baking soda
to a quart (1 liter) of water. This both cleans
and neutralizes odors. Thoroughly rinse
and wipe dry.
Other parts of the refrigerator—including
door gaskets, meat and vegetable drawers,
ice storage bin and all plastic parts—can be
cleaned the same way.
Do not wash any plastic refrigerator parts
in the dishwasher.
Avoid cleaning cold glass shelves with hot
water because the extreme temperature
difference may cause them to break. Handle
glass shelves carefully. Rough handling of
tempered glass can cause it to shatter.
NOTE: Interior lights may get too hot and turn
off automatically if the refrigerator door is left
open too long. This is normal and they will turn
back on when they cool down.
WARNING –Halogen lights generate
intense heat. Be certain power is off and lamps
have sufficient time to cool before attempting
to replace.
Power to the lamps can be turned off at
the Master Light switch located behind
the grille panel at the top of the refrigerator.
There is a switch for the freezer and a switch
for the fresh food compartment.
Turning the temperature control to OFF
does NOT remove power to the light circuits.
AVERTISSEMENT :
Les ampoules halogènes produisent une chaleur
intense. Assurez-vous de bien couper le courant
et de laisser suffisamment de temps aux
ampoules pour leur permettre de se refroidir
avant d’essayer de les remplacer.
Vous pouvez couper le courant en utilisant
le commutateur de lumière principale situé
derrière le panneau grillagé en haut du
réfrigérateur. Il y a un commutateur pour le
compartiment congélateur et un commutateur
pour le compartiment réfrigérateur.
Vous NE COUPEZ PAS l’alimentation électrique
du réfrigérateur des circuits de lumières en
mettant le bouton de contrôle de température
en position OFF (arrêt).
The refrigerator uses a halogen bulb:
The columns along the back wall
of the fresh food and freezer compartments
are lit up by lamps located behind the top pan
in the fresh food compartment and the bottom
basket in the freezer compartment.
These bulbs have a life expectancy of
about 2000 hours. However, if the bulbs
do need to be replaced, they can be
purchased at hardware, general retail
and home improvement stores or through
GE Parts and Accessories, 800.626.2002.
20
Light bulb replacement
Care and Cleaning
Built-In Refrigerators
Bulbs
This is a 35 watt, 12 volt,
Type MR11 bulb.
If ordering through
GE Parts and Accessories,
order part WR02X11183.
Light
Columns
21
Using
the Master
Light switches
This feature turns off the lights in the fresh food
and freezer compartments.
The switches are located behind the grille panel
at the top of the refrigerator. Lift up the panel
to access the switches.
Fresh Food and Freezer
Master Light Switches
Halogen bulb
replacement
NOTE: Before replacing the bulbs, review
the light bulb information and WARNING.
Replacing bulbs located in lamps behind
the top pan in the fresh food compartment
and the bottom freezer basket in the freezer
compartment:
1. Set the Master Light switches to the OFF
position (see Using the Master Light switches)
and allow the lamps to cool.
2. To access the lamps in the fresh food
compartment, remove the high humidity
drawer. See Drawer and Pan Removal section.
Raise the lid of the pan up to expose
the light cover.
2. To access the lamps in the freezer
compartment, remove the bottom freezer
basket. See Freezer Baskets section.
3. The lamps are hidden by a metal clip.
Grasp the clip and pull toward you to expose
the bulbs.
NOTE: Always follow bulb manufacturer’s
directions for handling and replacing bulbs.
4. Remove the bulb by holding the base and
pulling straight up. Replace with a new bulb.
5. Replace the metal clip by inserting the clip
behind the front smaller tabs, with the larger
tabs behind the clip. Press down gently on
the shield until the tops of the larger tabs slip
into the slots on the shield.
6. Reset the Master Light switches to the ON
position.
WARNING –The metal clip must
be replaced or the heat from the bulb could
damage the refrigerator.
AVERTISSEMENT :
Vous devez remettre en place le collier de métal
pour ne pas endommager votre réfrigérateur
avec la chaleur produite par l’ampoule.
Care and Cleaning
Built-In Refrigerators
Grille
Panel
Metal Clip
22
Care and Cleaning
Built-In Refrigerators
Preparing
for vacation
For long vacations or absences, remove food
and shut off power to the refrigerator at the fuse
box or circuit breaker. Clean the interior (see
Cleaning Inside). Leave doors open.
For shorter vacations, remove perishable foods
and leave controls at regular settings. However, if
the room temperature is expected to drop below
60°F (16°C), follow the same instructions as for
long vacations.
Set the icemaker power switch to the OFF
position and be sure to shut off the water supply
to the refrigerator.
23
Questions?
Use this
problem
solver!
The Problem Solver
Built-In Refrigerators
PROBLEM POSSIBLE CAUSE
REFRIGERATOR • May be in defrost cycle when compressor does not operate for about
DOES NOT OPERATE 30 minutes.
• Temperature control set at OFF.
• If interior light is not on, refrigerator may not be plugged in at
wall outlet.
• The fuse is blown/circuit breaker is tripped. Replace fuse or reset
the breaker.
MOTOR OPERATES • Normal when refrigerator is first plugged in. Wait 24 hours for
FOR LONG PERIODS the refrigerator to completely cool down.
OR CYCLES ON AND
• The new variable speed compressor is designed to run for longer
OFF FREQUENTLY
periods of time to optimize efficiency and noise. You may notice
the compressor and/or fan speeds accelerate based upon door
openings and/or increased food loads.
• You may hear the fans spinning at high speeds. This happens when
the refrigerator is first plugged in, when the doors are opened
frequently or when a large amount of food is added to the
refrigerator or freezer compartments. The fans are helping to
maintain the correct temperatures.
• Door left open or package holding door open.
• If either door is open for over 3 minutes, you may hear the fans
come on in order to cool the light.
• Hot weather or frequent door openings. This is normal.
• Temperature controls set at the coldest setting. See Temperature
Controls.
OPERATING • Refrigerator is so quiet, that most of the time you will hear low or no
SOUNDS operating noise.
• Normal fan air flow—one fan blows cold air through the
fresh food and freezer compartments—another fan cools
the compressor motor.
• The fans change speeds in order to provide optimal cooling and
energy savings.
• These NORMAL sounds will also be heard from time to time:
– You may hear a whooshing or gurgling sound when the doors close.
This is due to pressure equalizing within the refrigerator.
– A water dripping noise may occur during the defrost cycle as ice
melts from the evaporator and flows into the drain pan.
– The flow of refrigerant through the freezer cooling coils may make
a gurgling noise like boiling water.
– Water dropping on the defrost heater can cause a sizzling, popping
or buzzing sound during the defrost cycle.
– You may hear cracking or popping sounds when the refrigerator
is first plugged in or during/after the defrost cycle. This happens as
the refrigerator cools to the correct temperature.
– Electronic dampers click open and closed to provide optimal cooling
and energy savings.
– The compressor may cause a clicking or chirping sound when
attempting to restart (this could take up to 5 minutes).
– The electronic control board may cause a clicking sound when
relays activate to control refrigerator components.
– Ice cubes dropping into the bin and water running in pipes
as icemaker refills.
– The icemaker water valve will buzz when the icemaker fills
with water.
(Modern refrigerators
with more storage
space and a larger
freezer require
more operating time.
They start and stop
often to maintain
even temperatures.)
24
Questions?
Use this
problem
solver!
The Problem Solver
Built-In Refrigerators
PROBLEM POSSIBLE CAUSE
DOOR NOT CLOSING • Package may be holding door open.
PROPERLY
• Check the door gasket; it may be out of position.
• Refrigerator is not level. See Installation Instructions.
ACTUAL • Refrigerator just plugged in. Allow 24 hours for system to stabilize.
TEMPERATURE
• Door open for too long. Allow 24 hours for system to stabilize.
NOT EQUAL TO SET
• Warm food added to refrigerator. Allow 24 hours for system TEMPERATURE
to stabilize.
• Defrost cycle is in process. Allow 24 hours for system to stabilize.
VIBRATION OR • Refrigerator may not be properly installed.
RATTLING
(Slight vibration
is normal.)
FRESH FOOD • Temperature controls not set cold enough. See Temperature Controls.
OR FREEZER
• Warm weather or frequent door openings.
COMPARTMENT
• Door left open for long time.TOO WARM
• Package may be holding door open.
FROST OR ICE • Door left open or package holding door open.
CRYSTALS ON
• Too frequent or too long door openings.
FROZEN FOOD
(Frost within package
is normal.)
SLOW ICE CUBE • Door may have been left open.
FREEZING
• Freezer compartment is too warm. Set the freezer to a colder
temperature.
ICE HAS • Old cubes need to be discarded.
ODOR/TASTE
• Ice storage bin needs to be emptied and washed.
• Unsealed packages in freezer compartment may be transmitting
odor/taste to ice.
• Keep open box of baking soda in refrigerator; replace every 3 months.
• Poor-tasting incoming water. Replace water filter.
AUTOMATIC • Icemaker power switch is in the OFF position.
ICEMAKER
• Water supply turned off or not connected.
DOES NOT WORK
• Freezer compartment too warm.
• Piled up cubes in storage bin may cause icemaker to shut off
too soon. Level cubes in bin.
MOISTURE FORMS • Not unusual during periods of high humidity. Wipe surface dry.
ON CABINET
• Controlling humidity and temperature in the kitchen with air
SURFACE BETWEEN
conditioning will eliminate this condition.
THE DOORS
25
PROBLEM POSSIBLE CAUSE
MOISTURE • Too frequent or long door openings.
COLLECTS INSIDE
• In humid weather, air carries moisture into refrigerator when doors
are opened.
• Controlling humidity and temperature in the kitchen with air
conditioning will eliminate this condition.
REFRIGERATOR • Foods with strong odors should be tightly covered.
HAS ODOR
• Check for spoiled food.
• Interior needs cleaning. See Care and Cleaning.
• Keep open box of baking soda in refrigerator; replace every
3 months.
INTERIOR LIGHT • No power at outlet.
DOES NOT WORK
• Light bulb needs replacing. See Care and Cleaning.
• Master Light switch is in the OFF position.
• The refrigerator is equipped with a safety feature that turns off
the refrigerator lights when the doors have been opened for an
extended period. Once the refrigerator doors are closed and the lights
have had time to cool, they will again come on automatically when
the doors are opened.
SMALL OR • Water filter clogged. Replace the filter or use the filter bypass plug.
HOLLOW CUBES
• Check for a connection to a Reverse Osmosis water system.
If an RO is connected, remove the water filter and install the
original bypass plug that came with the unit.
WATER ON • If you use an extra tall glass or pitcher, or overfill a glass or pitcher,
THE FLOOR you may be jamming the cubes in the funnel chute. They can fuse
inside the chute and drop out later, leaving water or ice on the floor.
UNEVEN SPACING
• Kitchen cabinets are not level or square. Call the installer or
OR GAPS
BETWEEN cabinetmaker.
DOORS AND
KITCHEN CABINET
POOR DOOR • Fresh food door needs adjusting. See Installation Instructions.
• Refrigerator is not level. See Attention Installer Instructions.
WATER HAS POOR • Water dispenser has not been used for a long time. Dispense water
TASTE OR ODOR until all water in system is replenished.
WATER IN FIRST • Normal when refrigerator is first installed. Wait 24 hours for the
GLASS IS WARM refrigerator to completely cool down.
• Water dispenser has not been used for a long time. Dispense water
until all water in system is replenished.
• Water system has been drained. Allow several hours for replenished
supply to chill.
ALIGNMENT OR
ONE DOOR HIGHER
THAN THE OTHER
The Problem Solver
Built-In Refrigerators
26
Questions?
Use this
problem
solver!
The Problem Solver
Built-In Refrigerators
PROBLEM POSSIBLE CAUSE
WATER DISPENSER • Water supply line turned off, restricted or not connected. Call your
DOES NOT WORK installer for proper water supply line connection.
• Water filter clogged. Replace the filter or use the filter bypass plug.
• The CONTROL LOCK on the dispenser has been activated.
To unlock the dispenser, touch CONTROL LOCK for 3 seconds.
• Air may be trapped in system. Press the dispenser arm for at least
2 minutes.
ICE DISPENSER • Ice bin improperly installed. See Ice storage bin.
DOES NOT WORK
• Icemaker turned off or water supply turned off. Turn on icemaker
or water supply.
• Ice cubes are frozen to the icemaker feeler arm. Remove cubes.
• Irregular ice clumps in storage bin. Break up with fingertip pressure
and discard remaining clumps.
• Freezer may be too warm. Adjust freezer control to a colder setting,
one position at a time, until clumps do not form.
• Water filter clogged. Replace the filter or use the filter bypass plug.
• The CONTROL LOCK on the dispenser has been activated.
To unlock the dispenser, touch CONTROL LOCK for 3 seconds.
WATER SPURTING • Newly installed filter cartridge. Run water from the dispenser for
FROM DISPENSER 3 minutes (about one and a half gallons).
NO WATER OR ICE • Water supply line turned off, restricted or not connected. Call your
PRODUCTION installer for proper water supply line connection.
• Water filter clogged. Replace the filter or use the filter bypass plug.
CUBED ICE WAS • Last setting was CRUSHED ICE. A few cubes were left in the crusher
SELECTED BUT from the previous setting. This is normal.
CRUSHED ICE
• If continual crushed ice is dispensed while cubed ice is selected,
WAS DISPENSED
adjust ice bin. See Ice storage bin.
• Packaging. Increase time or re-package in plastic.
• Wrong weight selected. Select a larger weight.
• Item with high fat content. Select a larger weight.
SELECT TEMP • Fresh Food temperature control is set at warmest setting.
FEATURE ON This is normal. In order to minimize energy usage, the Select Temp
CLIMATE CONTROL feature is disabled when the Fresh Food control is set at the warmest
DRAWER IS NOT setting.
WORKING
CLIMATE CONTROL • Control Lock feature is active. Press and hold the CONTROL LOCK
DRAWER CONTROLS pad on the Climate Control drawer for 3 seconds.
DO NOT WORK
FOOD IS NOT
THAWING/CHILLING
IN CLIMATE
CONTROL DRAWER
27
Manufactured for: General Electric Company, Louisville, KY 40225
EPA EST. No. 070595-MN-001
Performance Data Sheet
SmartWater Filtration System
MWF Cartridge
This system has been tested according to NSF/ANSI 42/53 for reduction of the substances listed below.
The concentration of the indicated substances in water entering the system was reduced to a concentration
less than or equal to the permissible limit for water leaving the system, as specified in NSF/ANSI 42/53.*
(100% safety factors built in for unmetered usage)
Standard No. 42: Aesthetic Effects
USEPA Influent Influent Effluent % Reduction Min. Required
Parameter MCL Challenge Concentration Average Average Maximum Average Minimum Reduction
Chlorine — 2.0 mg/L +
10% 1.96 mg/L 0.06 mg/L 0.11 mg/L 96.77% 94.74% > 50%
T & O — — — — — — — —
Particulate** — ≥ 10,000 particles/mL 6,400,000 #/mL 58,833 #/mL 150,000 #/mL 99.14% 97.97% ≥ 85%
Standard No. 53: Health Effects
USEPA Influent Influent Effluent % Reduction Min. Required
Parameter MCL Challenge Concentration Average Average Maximum Average Minimum Reduction
Turbidity 0.5 NTU 11 +
1 NTU*** 10.5 NTU 0.14 NTU 0.28 NTU 98.54% 97.20% 0.5 NTU
Cysts ≥ 99.95% Reduction Minimum 50,000 L 118,750 #/L < 1 #/L 4 #/L > 99.99% > 99.99% ≥ 99.95%
Asbestos ≥ 99% Reduction 107to 108fibers/L; > 10µm 57 MF/L 0.996 MF/L < 1 MF/L 99.60% 99.39% ≥ 99%
Lead at pH 6.5 0.015 mg/L 0.15 mg/L + 10% 0.1567 mg/L < 0.001 mg/L < 0.001 mg/L 99.36% 99.29% 0.010 mg/L
Lead at pH 8.5 0.015 mg/L 0.15 mg/L +
10% 0.1433 mg/L < 0.001 mg/L < 0.001 mg/L 99.30% 99.29% 0.010 mg/L
Mercury at pH 6.5 0.002 mg/L 0.006 mg/L + 10% 0.0059 mg/L 0.000350 mg/L 0.0007 mg/L 94.70% 87.50% 0.002 mg/L
Mercury at pH 8.5 0.002 mg/L 0.006 mg/L + 10% 0.0057 mg/L 0.000325 mg/L 0.0006 mg/L 93.20% 89.29% 0.002 mg/L
Alachlor 0.002 mg/L 0.04 mg/L +
10% 0.0367 mg/L 0.00023 mg/L 0.0004 mg/L 99.34% 98.67% 0.002 mg/L
Lindane 0.0002 mg/L 0.002 mg/L + 10% 0.0020 mg/L < 0.00002 mg/L < 0.00002 mg/L 99.00% 98.95% 0.0002 mg/L
2,4-D 0.070 mg/L 0.210 mg/L + 10% 0.2033 mg/L 0.00337 mg/L 0.011000 mg/L 98.32% 94.50% 0.070 mg/L
Toxaphene 0.003 mg/L 0.015 mg/L +
10% 0.0160 mg/L 0.00100 mg/L 0.001000 mg/L 93.44% 91.67% 0.003 mg/L
Benzene 0.005 mg/L 0.015 mg/L + 10% 0.0145 mg/L 0.000500 mg/L 0.000500 mg/L 96.51% 95.83% 0.005 mg/L
Carbofuran 0.040 mg/L 0.080 mg/L + 10% 0.0830 mg/L 0.001000 mg/L 0.001000 mg/L 98.78% 98.65% 0.04 mg/L
1,4 dichlorobenzene
0.075 mg/L 0.225 mg/L +
10% 0.2283 mg/L 0.000500 mg/L 0.000500 mg/L 99.78% 99.77% 0.075 mg/L
Atrazine 0.003 mg/L 0.009 mg/L + 10% 0.0087 mg/L < 0.0005 mg/L < 0.0005 mg/L 94.22% 93.33% 0.003 mg/L
* Tested using a flow rate of 0.50 gpm; pressure of 60 psig; pH of 7.5 ± 0.5; temp. of 68° ± 5°F (20° ± 3°C)
** Measurement in Particles/ml. Particles used were 0.5-1 microns
*** NTU=Nephelometric Turbidity units
Operating Specifications
‡ Capacity: certified for up to 300 gallons (1135 l); up to one year
‡ Pressure requirement: 40–120 psi (2.8–8.2 bar), non-shock
‡ Temperature: 33–100ºF (0.6–38ºC)
‡ Flow rate: 0.5 gpm (1.9 lpm)
General Installation/Operation/Maintenance Requirements
‡ Flush new cartridge at full flow for 3 minutes to purge out trapped air.
‡ Replace cartridge when the indicator light flashes.
Special Notices
‡ Installation instructions, parts and service availability, and standard warranty are included with the product when shipped.
‡ This drinking water system must be maintained according to manufacturer’s instructions, including replacement of filter cartridges.
‡ Do not use with water that is microbiologically unsafe or of unknown quality without adequate disinfection before or
after the system. Systems certified for cyst reduction may be used on disinfected water that may contain filterable cysts.
‡ The contaminants or other substances removed or reduced by this water treatment system are not necessarily in your water.
‡ Check for compliance with the state and local laws and regulations.
‡ Note that while the testing was performed under standard laboratory conditions, actual performance may vary. Systems must be
installed and operated in accordance with manufacturer’s recommended procedures and guidelines.
NSF
®
System Tested and Certified by NSF International against ANSI/NSF Standard 42 & 53 for the reduction of:
Standard No. 42: Aesthetic Effects
Chemical Unit
Chlorine Taste and Odor
Mechanical Filtration Unit
Particulate Reduction, Class I
Standard No. 53: Health Effects
Chemical Reduction Unit
Alachlor and Atrazine Reduction
Benzene and Carbofuran Reduction
1,4 dichlorobenzene and 2,4-D Reduction
Lead and Lindane Reduction
Mercury and Toxaphene Reduction
Mechanical Filtration Unit
Turbidity Reduction
Cyst and Asbestos Reduction
28
State of California
Department of Health Services
Water Treatment Device
Certificate Number
169805 -
Date Issued: February 2, 2005
Trademark/Model Designation
MWF MWF
Manufacturer: General Electric Company
The water treatment device(s) listed on this certificate have met the testing requirements pursuant to Section
116830 of the Health and Safety Code for the following health related contaminants:
Microbiological Contaminants and Turbidity
Cysts
Turbidity
Organic Contaminants
Alachlor
Atrazine
Benzene
Carbofuran
Lindane
Mercury
Toxaphene
1,4-dichlorobenzene
2,4-D
Replacement Elements
Inorganic/Radiological Contaminants
Asbestos
Lead
Mercury
300 galRated Service Capacity:
Conditions of Certification:
Do not use where water is microbiologically unsafe or with water of unknown quality, except that systems certified for
cyst reduction may be used on disinfected waters that may contain filterable cysts.
Rated Service Flow:
0.5 gpm
29
With the purchase of your new Monogram appliance,
receive the assurance that if you ever need information
or assistance from GE, we will be there. All you have to
do is call!
GE Answer
Center
®
In the USA:
800.626.2000
Whatever your question about any Monogram major appliance, GE Answer Center
®
information service is available to help. Your call—and your question—will be answered
promptly and courteously. And you can call any time. GE Answer Center®service is open
24 hours a day, Monday through Saturday.
OR
Visit our Website at: monogram.com
In Canada, call 1.800.561.3344.
In-Home Repair
Service
In the USA:
800.444.1845
In Canada:
1.800.561.3344
A GE consumer service professional will provide expert repair service, scheduled at a time
that’s convenient for you. Many GE Consumer Service company-operated locations offer you
service today or tomorrow, or at your convenience (7:00 a.m. to 10:00 p.m. weekdays, 8:00 a.m.
to 6:00 p.m. Saturday and Sunday). Our factory-trained technicians know your appliance inside
and out—so most repairs can be handled in just one visit.
In Canada: Monday to Friday, 7:00 a.m. to 8:00 p.m. and Saturday, 8:00 a.m. to 5:00 p.m. EDST.
Service Contracts
In the USA:
800.626.2224
In Canada:
1.800.561.3344
You can have the secure feeling that GE Consumer Service will still be there after your
warranty expires. Purchase a GE contract while your warranty is still in effect and you’ll
receive a substantial discount. With a multiple-year contract, you’re assured of future service
at today’s prices.
Parts and
Accessories
In the USA:
800.626.2002
In Canada:
1.800.561.3344
Individuals qualified to service their own appliances can have parts or accessories sent
directly to their home. The GE parts system provides access to over 47,000 parts…and all
GE Genuine Renewal Parts are fully warranted. VISA, MasterCard and Discover cards
are accepted. Visit www.geappliances.com.
User maintenance instructions contained in this manual cover procedures intended
to be performed by any user. Other servicing generally should be referred to qualified
service personnel. Caution must be exercised, since improper servicing may cause unsafe
operation.
For Customers
With Special
Needs…
In the USA:
800.626.2000
GE offers Braille controls for a variety of GE appliances, and a brochure
to assist in planning a barrier-free kitchen for persons with limited
mobility.
Consumers with impaired hearing or speech who have access to a
TDD
or a conventional teletypewriter may call 800.TDD.GEAC (800.833.4322)
to request information or service.
Consumer Services
Built-In Refrigerators
Notes
Built-In Refrigerators
30
31
Notes
Built-In Refrigerators
Warranty
Built-In Refrigerators
YOUR MONOGRAM REFRIGERATOR WARRANTY
Staple sales slip or cancelled check here. Proof of original
purchase date is needed to obtain service under warranty.
WHAT IS
COVERED
From the Date
of the Original
Purchase
LIMITED TWO-YEAR WARRANTY
For two years from date of original purchase, we will provide, free of charge, parts and service labor in
your home to repair or replace any part of the refrigerator that fails because of a manufacturing defect.
LIMITED FIVE-YEAR WARRANTY
For five years from date of original purchase, we will provide, free of charge, parts and service labor
in your home to repair or replace any part of the sealed refrigerating system (the compressor, condenser,
evaporator and all connecting tubing) that fails because of a manufacturing defect.
LIMITED ADDITIONAL SIXTH- THROUGH TWELFTH-YEAR WARRANTY ON THE SEALED SYSTEM
For the sixth through twelfth year from the date of the original purchase, we will provide, free of charge,
replacement parts for any part of the sealed refrigerating system (the compressor, condenser, evaporator and
all connecting tubing) that fails because of a manufacturing defect . You pay for the service trip to your home
and for service labor charges.
LIMITED THIRTY-DAY WARRANTY ON WATER FILTER CARTRIDGE (Water filter, if included)
From the date of the original purchase we will provide, free of charge, replacement parts for any part of
the water filter cartridge that fails because of a manufacturing defect. During this limited thirty-day warranty,
we will also provide, free of charge, a replacement water filter cartridge.
This warranty is extended to the original purchaser and any succeeding owner for products purchased for
ordinary home use in the 48 mainland states, Hawaii, Washington, D.C. or Canada. If the product is located
in an area where service by a GE Authorized Servicer is not available, you may be responsible for a trip
charge or you may be required to bring the product to an Authorized GE Service location for service.
In Alaska the warranty is the same except that it is LIMITED because you must pay to ship the product
to the service shop or for the service technician’s travel costs to your home.
All warranty service will be provided by our Factory Service Centers or by our authorized Customer Care
®
servicers during normal working hours.
Should your appliance need service, during warranty period or beyond, in the USA call 800.444.1845.
In Canada: 800.561.3344. Please have your serial number and model number available when calling for service.
Some states/provinces do not allow the exclusion or limitation of incidental or consequential damages,
so the above limitation or exclusion may not apply to you. This warranty gives you specific legal rights, and you
may also have other rights which vary from state to state/province to province. To know what your legal rights
are in your state/province, consult your local or state/provincial consumer affairs office or your state’s Attorney
General.
Warrantor in USA: General Electric Company,
Louisville, KY 40225
Warrantor in Canada: Mabe Canada Inc.
WHAT IS NOT
COVERED
• Service trips to your home to teach you how
to use the product.
• Replacement of house fuses or resetting of circuit
breakers.
• Damage to the product caused by accident, fire,
floods or acts of God.
• Failure of the product if it is used for other than
its intended purpose or used commercially.
• Damage caused after delivery.
• Improper installation, delivery or maintenance.
If you have an installation problem, contact
your dealer or installer. You are responsible
for providing adequate electrical, plumbing
and other connecting facilities.
• Replacement of the light bulbs, if included,
or water filter cartridge, if included, other
than as noted above.
• Replacement of the water filter cartridge,
if included, due to water pressure that is outside
the specified operating range or due to excessive
sediment in the water supply.
• Loss of food due to spoilage (in the USA only).
• Incidental or consequential damage caused
by possible defects with this appliance.
• Product not accessible to provide required
service.
Printed in the United States
02-08 JR
EXCLUSION OF IMPLIED WARRANTIES—Your sole and exclusive remedy is product repair as provided in
this Limited Warranty. Any implied warranties, including the implied warranties of merchantability or
fitness for a particular purpose, are limited to one year or the shortest period allowed by law.
GE Consumer & Industrial
Appliances
General Electric Company
Louisville, KY 40225
ge.com
49-60559
224D1893P005
Loading...
