2 PACK
INDOOR/OUTDOOR
BLUETOOTH®
SPEAKER
Model: BWA15AV 107
PRODUCT GUIDE
TM
FEATURES AND CONTROLS
Rear SideFront
SPEAKERS
PAIRVOLUME CONNECT
ON/OFF
DC IN 5V
Bluetooth
Pairing LED
Speaker
Connection LED
Battery LED
Power
Slide the power
switch to turn
Volume
Press to adjust
the volume.
Pair
DC Power
Input
Press to begin
pairing the speakers.
Connect Speakers
Press to connect the speakers.
Battery LED Indicators (RED)
Status Indicator
No Light
Charging Battery Solid Red Light
Low Battery Flashing Red Light
Charging Complete No Light
Speaker Pairing LED Indicators (WHITE)
Status Indicator
Speakers Pairing Flashing White Light
Speakers Paired Solid White Light
Bluetooth Connection LED Indicators (BLUE)
Status Indicator
Pairing to Device Flashing Blue Light
Devices Paired Solid Blue Light
POWER & CHARGING
DC Power Input
Requires an AC/DC power adapter (included).
Each speaker must be charged independently.
Battery life when not in use is roughly 6 months. The battery
must then be fully recharged. Charge each speaker for at
least 2.5 hours before use.
1. Connect one end of the included AC/DC power
adaptor to
to recharge the battery.
the unit and one end to an AC power outlet
WIRELESS CONNECTIONS
ON/OFF
DC IN 5V
Pairing the Speakers
This process should be done FIRST before pairing to a
Bluetooth device. This should only need to be done upon
beginning the pairing process.
1. Power on the speakers by sliding the power switch to
the ON position on both units.
2. The Bluetooth Indicator and Speaker Connection
Indicator If the Speaker
both speakers your speakers are already paired. You can
skip to the Pairing a Bluetooth Device section.
3. Press the Connect Speakers button on both speakers
simultaneously.
4.
5. Wait until both Speaker Connection Indicators are
solid white. This indicates that the speakers have
successfully paired. Please note that this process can take
up to 1 minute.
For all future uses please turn on both speakers and wait for
them to connect. Note that it may take up to 1 minute for
them to pair automatically even after initial use, but here
should be no need to press Connect Speaker button again.
If any pairing issues should occur, repeat the above steps.
Pairing to a Bluetooth Device
Pairing the Speakers. When pairing, the device should
remain within 3 feet of the speakers.
1. Press the Pair button on ONLY ONE of the speakers.
2. Using the native controls on your Bluetooth device,
select BWA15AV107 in your Bluetooth settings to pair.
If your device requests a password, enter the default
password 0 0 0 0 .
instructions on pairing and connecting Bluetooth devices.
3. When successfully paired, the pairing indicator will
4. After initial pairing, the unit will stay paired unless
unpaired manually by the user or erased due to a reset
of the device.
If your device should become unpaired for any reason,
repeat the above steps.
If any pairing issues should occur, un-pair the unit on your
Bluetooth device and repeat the above steps.
Note : If two speakers with the BWA15AV107 name appear
on the pairing list of your device, please erase one of
BWA15AV107 listed in your Bluetooth device and repeat the
above steps.
Playing Audio Wirelessly
Follow the instructions for Pairing a Bluetooth Device.
1. Use the native controls on the connected Bluetooth
Device to select and play, pause or skip media.
2. Any audio played through the connected Bluetooth
device will now be heard through the speakers.
SAFETY WARNINGS & INSTRUCTIONS
Important Safety Instructions
• Read these Instructions.
• Keep these Instructions.
• Heed all Warnings.
• Follow all instructions.
• Do not use this apparatus near water.
• Clean only with a dry cloth.
• Do not block any ventilation openings. Install in accordance with
the manufacturer’s instructions.
• Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including ampliers) that
produce heat.
• Do not defeat the safety purpose of the polarized or grounding type plug. A polarized plug has two blades with one
wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or
the third prong are provided for your safety. When the
provided plug does not t into your outlet, consult an
electrician for replacement of the obsolete outlet.
• Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point where
they exit from the apparatus.
• Only use attachments/accessories specied by the manufacturer.
• Unplug this apparatus during lightning storms or when unused for
long periods of time.
• Refer all servicing to qualied service personnel. Servicing is
required when the apparatus has been damaged in any way, such
as power-supply cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has
been dropped.
• Use only with a cart, stand, tripod, bracket, or table specied by
the manufacturer, or sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus combination to avoid
injury from tip-over.
FCC Warnings
Warning: Changes or modications to this unit not expressly approved
by the party responsible for compliance could void the user’s authority
to operate the equipment.
NOTE: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Additional Warnings and Precautions
• CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE
BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
• WARNING: To reduce the risk of re or electric shock, do not
expose this apparatus to rain, moisture, dripping, or splashing.
Avis: Pour réduire le risque d’incendie ou de choc électrique, ne
pas exposer cet appareil sous la pluie et l’humidité.
• CAUTION: Use of controls or adjustments or performance of
procedures other than those specied may result in hazardous
radiation exposure.
• WARNING: Changes or modications to this unit not expressly
approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
• WARNING: Do not place this unit directly onto furniture surfaces
with any type of soft, porous, or sensitive nish. As with any
rubber compound made with oils, the feet could cause marks or
staining where the feet reside. We recommend using a protective
barrier such as a cloth or a piece of glass between the unit and the
surface to reduce the risk of damage and/or staining.
• WARNING: Use of this unit near uorescent lighting may cause
interference regarding use of the remote. If the unit is displaying
erratic behavior move away from any uorescent lighting, as it
may be the cause.
• CAUTION: Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
AVIS: Danger d’explosion si les piles sont remplacées de façon
incorrect. Remplacer les piles seulement par le même type de
pile ou l’équivalent.
• WARNING: There is a danger of explosion if you attempt
to charge standard Alkaline batteries in the unit. Only use
rechargeable NiMH batteries.
• WARNING: The remote control’s button cell battery contains
mercury. Do not put in the trash, instead recycle or dispose of
as hazardous waste
• WARNING: Lithium batteries, like all rechargeable batteries,
are recyclable and should be recycled or disposed of in normal
household waste. Contact your local government for disposal or
recycling practices in your area. They should never be incinerated
since they might explode.
• WARNING: Shock hazard - Do Not Open.
AVIS: Risque de choc électrique - ne pas ouvrir
• Caution and marking information is located at the rear or bottom
of the apparatus.
Attention et de marquage des informations est situé sur le paneau
arrière ou inférieur de l’unité.
• Objects lled with liquids, such as vases, shall not be placed
on the apparatus.
Objets remplis de liquides, comme des vases, ne doivent pas être
placés sur l’appareil.
• Mains plug is used as disconnect device and it should remain
readily operable during intended use. In order to disconnect the
apparatus from the mains completely, the mains plug should be
disconnected form the mains socket outlet completely.
La prise du secteur est utilisé pour déconnecter le système. La
prise du secteur ne doit pas être obstruée ou doit être facilement
accessible pendant son utilisation. Pour être complètement
déconnecté de l’alimentation d’entrée, la prise doit être
débranchée du secteur.
• Battery shall not be exposed to excessive heat such as sunshine,
re or the like.
Les piles ne doivent pas être exposées à de forte chaleur, tel qu’à
la lumière du soleil, au feu ou autres choses de semblable.
• Keep new and used batteries away from children. If the battery
compartment does
not close securely, stop using the product and keep it away
from children.
Gardez les piles neuves et d’occasion à partir des enfants. Si le
compartiment de la batterie ne
• pas fermer correctement, cesser d’utiliser le produit et garder
loin des enfants.
• If you think batteries might have been swallowed or placed inside
any part of the body, seek immediate medical attention.
Si vous pensez que les batteries peuvent avoir été avalé ou placé
à l’intérieur d’une partie du corps, consulter immédiatement
un médecin.
• Do not mix old and new batteries.
Ne pas mélanger vieilles et nouvelles batteries.
• Completely replace all old batteries with new ones.
Remplacer complètement toutes les piles par des neuves.
• Do not mix alkaline, standard (carbon-zinc), or rechargeable
(ni-cad, ni-mh, etc) batteries.
Ne mélangez pas des piles alcalines, standard (carbone-zinc)
ou rechargeables
(Ni-Cd, Ni-MH, etc) batteries.
• Batteries should be recycled or disposed of as per state and
local guidelines.
Piles doivent être recyclées ou éliminées selon les directives
étatiques et locales.
WArNINg: To reduce the risk of electric shock, do not remove cover
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
(or back). No user-serviceable parts inside. Refer servicing to qualied
service personnel.
ATTENTION
RISQUE D' ÉLECTROCUTION
NE PAS OUVRIR
The exclamation point within an equilateral triangle is intended to alert the
user to the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.
The lightning ash with arrowhead symbol, within an equilateral triangle, is
intended to alert the user to the presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be of sufcient magnitude to constitute
a risk of electric shock to persons.
This symbol indicates that this product incorporates double insulation between
hazardous mains voltage and user accessible parts.
INTERNATIONAL SUPPORT
To download this User’s Guide in English, Spanish, or French, or to get answers to
frequently asked questions, visit the support section at: www.iLiveElectronics.com
Para descargar este Manual del Usuario en inglés, español y francés, o para obtener
respuestas a preguntas frecuentes, visite la sección de apoyo en:
www.iLiveElectronics.com
Pour télécharger ce guide de l’utilisateur en anglais, espagnol ou français, ou pour
obtenir des réponses à des questions fréquemment posées, consultez la rubrique
d’assistance sur: www.iLiveElectronics.com
For Warranty Information and the most of this User’s Guide, go to: www.iLiveElectronics.com
Customer Service: 1-888-999-4215 | Email Support: prodinfo@dpiinc.com | Email Parts: partsinfo@dpiinc.com
Copyright © 2013 Digital Products International (DPI, Inc.) All other trademarks appearing herein are the property of their
respective owners. Specications are subject to change without notice.
Made
Green
Protect for Today
Sustain for Tomorrow
Loading...
