Gemlink WA69BT User Manual

WALL MOUNTABLE 2.0-CHANNEL BLUETOOTH

SOUNDBAR SPEAKER

USER MANUAL

JSBW-210

PLEASE READ THIS USER MANUAL COMPLETELY BEFORE OPERATING THIS UNIT AND

RETAIN THIS BOOKLET FOR FUTURE REFERENCE.

DEAR JENSEN® CUSTOMER

Selecting fine audio equipment such as the unit you've just purchased is only the
start of your musical enjoyment. Now it's time to consider how you can maximize the
fun and excitement your equipment offers. This manufacturer and the Electronic
Industries Association's Consumer Electronics Group want you to get the most out of
your equipment by playing it at a safe level. One that lets the sound come through
loud and clear without annoying blaring or distortion and, most importantly, without
affecting your sensitive hearing.
Sound can be deceiving. Over time your hearing "comfort level" adapts to higher
volumes of sound. So what sounds "normal" can actually be loud and harmful to your
hearing. Guard against this by setting your equipment at a safe level BEFORE your
hearing adapts.

To establish a safe level:

• Start your volume control at a low setting.

• Slowly increase the sound until you can hear it comfortably and clearly, and

without distortion.

Once you have established a comfortable sound level:

• Set the dial and leave it there.
Taking a minute to do this now will help to prevent hearing damage or loss in the
future. After all, we want you listening for a lifetime.

We Want You Listening For a Lifetime

Used wisely, your new sound equipment will provide a lifetime of fun and enjoyment.
Since hearing damage from loud noise is often undetectable until it is too late, this
manufacturer and the Electronic Industries Association's Consumer Electronics
Group recommend you avoid prolonged exposure to excessive noise.

Customer's Record:

The serial number of this product is found on its back cover. You should note the
serial number of this unit in the space provided as a permanent record of your
purchase to aid in identification in the event of theft of loss.

Model Number: JSBW-210 Serial Number: ____________________

1

IMPORTANT SAFETY INSTRUCTIONS

When used in the directed manner, this unit has been designed and manufactured to
ensure your personal safety. However, improper use can result in potential electrical
shock or fire hazards. Please read all safety and operating instructions carefully before
installation and use, and keep these instructions handy for future reference. Take
special note of all warnings listed in these instructions and on the unit.

1. Read these instructions – All the safety and operating instructions should be read
before the appliance is operated.

2. Keep these instructions – The safety and operating instructions should be kept for
future reference.

3. Heed all warnings – All warnings on the appliance and in the operating instructions
should be adhered to.

4. Follow all instructions – All operation and use instructions should be followed.

5. Do not use this apparatus near water – The appliance should not be used near
water; for example, near a bath tub, washbowl, kitchen sink, laundry tub, in a wet
basement, or near a swimming pool.

6. Clean only with dry cloth – The appliance should be cleaned only as
recommended by the manufacturer.

7. Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions. The appliance should be situated so that its location or
position does not interfere with its proper ventilation. For example, the appliance
should not be situated on a bed, sofa, rug, or similar surface that may block the
ventilation openings; or placed in a built-in installation, such as a bookcase or
cabinet that may impede the flow of air through the ventilation openings.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that produce heat.

9. AC adaptor is used as disconnect device and it should remain readily operable
during intended use. In order to disconnect the apparatus from the mains
completely, the AC adaptor should be disconnected form the mains socket outlet
completely.

10. Only use attachments / accessories specified by the manufacturer.

11. Use only with a cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use
caution when moving the cart/apparatus combination to avoid injury
from tip-over.

12. Unplug this apparatus during lightning storms or when unused for long periods of
time.

13. Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has
been dropped.

14. This appliance shall not be exposed to dripping or splashing water and that no
object filled with liquids such as vases shall be placed on the apparatus.

15. Power Sources – The appliance should be connected to a power supply only of the
type described in the operating instructions or as marked on the appliance. Do not
overload wall outlet.

2

16. Battery shall not be exposed to excessive heat such as sunshine, fire or the like

17. Danger of explosion if battery is incorrectly replaced. Replace only with the same
or equivalent type.

18. Do not attempt to dismantle, open or repair this product yourself. If a fault occurs,
seek advice from your local qualified service technician or contact the distributor
via the telephone number at the back of this instruction manual.

19. Caution marking and nameplate are located on bottom of product.

IMPORTANT NOTE

Avoid installing the unit in locations described below:

• Places exposed to direct sunlight or close to heat radiating appliances such as

electric heaters.

• Places subject to constant vibration.

• Dusty, humid or moist places.

• Sources of electrical noise such as fluorescent lamps or motors.

• In case of malfunction due to electrostatic discharge, the apparatus has to be reset

by disconnecting it from mains supply, wait at least for 60 seconds before reconnect
the AC power cord.

COMPLIANCE WITH FCC REGULATIONS

This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:

(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that

may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the
following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

CAUTION: Changes or modifications not expressly approved by the party

responsible for compliance could void the user’s authority to operate
the equipment.

Protect Your Furniture

This product is equipped with non-skid rubber 'feet' to prevent the product from moving
when you operate the controls. These 'feet' are made from non-migrating rubber
material specially formulated to avoid leaving any marks or stains on your furniture.
However certain types of oil based furniture polishes, wood preservatives, or cleaning
sprays may cause the rubber 'feet' to soften, and leave marks or a rubber residue on
the furniture. To prevent any damage to your furniture we strongly recommend that you
purchase small self-adhesive felt pads, available at hardware stores and home
improvement centers everywhere, and apply these pads to the bottom of the rubber
'feet' before you place the product on fine wooden furniture.

3

ACCESSORIES

1 x AC Adaptor
1 x Remote Control,

1 x Stereo Audio Connection Cable with 3.5mm stereo plugs
1 x User Manual

1 x RCA Connection Cable
1 x Wall Mount Template
2 x Spaces
2 x Anchors (For Wall Mounting)
2 x 55mm Screws (For Wall Mounting)

INSTALLATIONS

Placing the JSBW-210 on a table

Ventilation
When placing the Sound Bar on an entertainment center, bookshelf, or any type of
enclosed space, be sure to allow at least 2-3 inches of space around the Sound
Bar for ventilation. If the Sound Bar is enclosed in a tight space, without ventilation,
heat generated from the Sound Bar could create potential overheating.

Mounting the JSBW-210 on a woode n wa l l

It’s important to be sure there are no electric, gas or water lines located behind the wall
where you are attaching the sound bar. We recommend having this speaker
professionally installed. Use the included wall mounting accessories and template to
attach the sound bar to the wall.

Distance Between Two Brackets

4

1. Use the supplied wall mounting template to make drill hole marks on the wall. Make

sure the marks are level before drilling.

2. Attach the Spaces to the wall by screwing the supplied flat head screws directly into

the marks that you have made on the wall as shown above.

3. Place the sound bar onto the mounting screw heads. Make sure the sound bar is

attached firmly to the wall.

Mounting the JSBW-210 on wall

Use a power drill to make pilot holes for the
plastic anchors

1. Use the supplied wall mounting template to make drill hole marks on the wall for the

anchors. Make sure the marks are level before drilling.

2. Use a 1/4” (6.35mm) bit and power drill (Not supplied) to drill holes on the marks.

3. Insert the included plastic anchors into the holes and push in until they are flush with

the wall.

4. Secure the supplied Spaces to the wall by screwing the included flat head screws

into the anchors and tighten until the screw head is 1/4” (6.35mm) away from the
surface of spaces.

5. Place the sound bar onto the mounting screw heads. Make sure the sound bar is

attached firmly to the wall.

5
