AC 2483 Rev. 08 - 06/14
5079T
12/24V
INSTALLATION AND
USE MANUAL
UK
Made in Italy
1.0 - CONTENTS
1.0 - CONTENTS
2.0 - INTRODUCTION
3.0 - SYSTEM DESCRIPTION
4.0 - SYSTEM ARMING
5.0 - SYSTEM DISARMING
6.0 -
7.0 - ELECTRICAL CONNECTIONS
8.0
WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT (WEEE)
DIRECTIVE
HOW TO PROGRAM A NEW KEY
- WIRING DIAGRAM
9.0 - WARRANTY CONDITIONS
10.0 - TECHNICAL DATA
11.0 -
2.0 - INTRODUCTION
3.0 - SYSTEM DESCRIPTION
The Gemini 5079T immobilizer is designed to be installed on vehicles
with a 12 or 24V battery supply.
!
!
!
!
!
Automatically adapts to 12 or 24 Volt vehicles.
Double engine immobilizer with 30Amp relay.
Automatic arming.
Disarming via electronic override key.
The unit is supplied with 2 random rolling code electronic override keys
(art. CDE2).
UK
Homologation number 5079T Cat 2: TQA427
6.0 - HOW TO PROGRAM A NEW KEY
1. Switch the system OFF.
2. Connect the BLACK wire marked HW to the vehicle ground.
3. Turn ignition key “ON” and then “OFF”.
4. Insert the new electronic key in its receptacle. The LED will flash once to
confirm learning.
5. Repeat steps 3 and 4 for each new key to be learned.
If the immobilizer is connected to an alarm system, repeat procedure from step
3 and press the remote control button; the LED will flash to confirm learning.
NB: The unit can learn up to 12 electronic keys when in disarm mode.
7.0 - ELECTRICAL CONNECTIONS
.
Disconnect the negative battery terminal and only re-connect after the
installation is completed
GROUND
BATTERY POSITIVE TERMINAL
IMMOBILISATION RELAY 1
IGNITION
DOOR SWITCH
NEGATIVE OUTPUT WITH SYSTEM
ARMED AND +15/54 ACTIVATED
IMMOBILISATION RELAY 2
WIRE TO PROGRAM NEW KEY
BLACK marked
BLACK marked “R”
2x BLACK marked “B”
2x BLACK marked “B1”
2x BLACK markned “H”
2x BLACK marked “H1”
BLACK marked “G”
BLACK marked “VM”
BLACK marked “HW”
BLACK marked “SN”
“M”
4.0 - ARMING
5.0 - DISARMING
The 5079T immobilizer passively arms:
5 minutes after the engine is switched OFF and no door is opened.
Approx. 30 seconds after the engine is switched OFF and a door is opened.
Approx. 30 seconds after disarming the system via electronic key.
A flashing LED indicates an armed condition; the vehicle can no longer be started.
To disarm the system, touch the electronic key to its receptacle; the LED will
stop flashing to indicate the system has been disarmed.
!
!
!
BLACK marked “G”
Ignition
Electronic key
programming
Negative with system armed
and ignition (+15/54)
BLACK marked “M”
BLACK
marked “VM”
GROUND
BLACK marked “R”
Black
Black
Black
Black
5079
BLACK marked “SN”
BLACK marked “HW”
LED
Electronic key
Elec onic key
receptacle
with built-in
LED
tr
8.0 - WIRING DIAGRAM
+30
+
Battery
Immobilisation relay Nr.2
Immobilisation relay Nr.1
30A
MAX !
BLACK marked “H”
BLACK marked “H1”
BLACK marked “H”
BLACK marked “H1”
BLACK marked “B”
BLACK marked “B”
BLACK marked “B1”
BLACK marked “B1”
30A
MAX !
+12/54
STARTER
Power supply
Current absorption
Operating temperature
Relay max current capacity
Enclosure - Degree of protection
Storing memory
12/24 Vdc
-30°C +85°C
30A
Up to 12 codes
2mA
IP40
10.0 - TECHNICAL SPECIFICATIONS
9.0 - WARRANTY CONDITIONS
This product is guaranteed to be free from manufacturing defects for a period
of 24 months from the installation date shown on this warranty, in compliance
with Warranty Directive 1999/44/CE.
Please fill-in entirely the guarantee certificate included in this booklet and DO
NOT REMOVE the guarantee label from the device.
The warranty will become void if labels are missing or torn, if the installation
certificate is not fully compiled or if the enclosed sale document is missing.
The warranty is valid exclusively at Authorized Gemini Technologies service
centers.
The manufacturer declines any responsibility for eventual malfunctions of the
device or any damage to the vehicle electrical system due to improper
installation, use or tampering.
The 5079T immobilizer is solely intended to be a theft-deterrent device.
11.0 - WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT
(WEEE) DIRECTIVE
The present device does not fall within the scope of Directive 2002/96/EC on
Waste Electrical and Electronic Equipment (WEEE) as specified in art. 2.1 of
L.D. no. 151 of 25/07/2005.
7 Dudley Court , Jessop Close, Clacton-on-Sea, Essex, CO15 4LY
TEL: +44 (0) 1255 434353
Email: sales@avsgemini.com | Web: www.avsgemini.com
UK Distributors of the Gemini Alarm Systems
