Technical data
Model Capacities Weights Crate
Electrical
Dimensions
9/20 36 0.7 - 2.5 1.5 - 5.6 770 880 31” x 33” x 63” 220 3 60 3.0 0.55
10/25 36 0.9 - 3.3 2.0 - 7.5 770 880 31” x 33” x 63” 220 3 60 3.0 0.55
11/30 36 1.0 - 4.0 2.3 - 9.0 770 880 31” x 33” x 63” 220 3 60 3.0 0.55
4/40 30 1.4 - 4.3 2.6 - 8.1 770 880 31” x 33” x 63” 220 3 60 3.0 0.55
5/18 50 0.6 - 1.5 1.9 - 4.7 770 880 31” x 33” x 63” 220 3 60 3.0 0.55
6/150 15 5.4 - 9.5 5.1 - 8.9 770 880 31” x 33” x 63” 220 3 60 3.0 0.55
7/70 20 2.5 - 7.1 3.1 - 8.9 770 880 31” x 33” x 63” 220 3 60 3.0 0.55
Parts Weight of
individual
dough
pieces
oz.
Total
weight
range
lbs.
Net
weight
lbs.
Shipping
weight
lbs.
D x W x H
inches
volts ph Hz amps kW
Since 1972
Semi Automatic
Bun Divider/Rounder
8/250 7 9.0 - 21.0 3.9 - 9.2 770 880 31” x 33” x 63” 220 3 60 3.0 0.55
Features
• 3 sanitary rounding plates
• Oil for rounding mechanism
• Rounding plate drive is via a double bearing support
• Teflon-coated head and knives for work with sticky sough
Options
• 1-phase, 220 volts
• Prison package
In an effort to consistently upgrade our products,
we reserve the right to change specifications and
dimensions without notice
