Gembird USER MANUAL, SIS-PMS User Manual
PROGRAMMABLE SURGE P
ROTECTOR
PROGRAMMIERBARE STECKDOSENLEISTE
PROGRAMMEERBARE STEKKERDOOS
PARASURTENSEUR PROGRAMMABLE
ПРОГРАММИРУЕМЫЙ СЕТЕВОЙ ФИЛЬТР
ПРОГРАМОВАНИЙ СЕТЕВОЙ ФІЛЬТР
USER MANUAL
HANDBUCH
HANDLEIDING
MANUEL DESCRIPTIF
РУКОВОДСТВО ПОЛЬЗОВАТЕЛЯ
КЕРІВНИЦТВО КОРИСТУВАЧА
SIS-PMS
2
GEMBIRD EUROPE B.V. http://www.gembird.eu
SIS
-
PMS
PROGRAMMABLE SURGE PROTECTOR
Contents
1. Introduction 3
1.1. Features 3
1.2. Specifications 4
1.3. Hardware requirements 5
1.4. Package contents 5
2. Indicators and controls of SIS-PMS 6
2.1. Side panel 7
2.2. Indicators 8
2.3. Audible signals 8
3. Installation 9
3.1. Getting started 9
3.2. Power Manager installation 10
4. Power Manager software 11
4.1. Managing SIS-PMS 11
4.2. Setting up the hardware schedule 15
4.3. Setting up the software schedule 20
4.4. Setting up application events 23
5. Power Manager advanced features 29
5.1. Processing the alarms 30
5.2. Managing SIS-PMS via your own software 31
6. Troubleshooting 39
3
GEMBIRD EUROPE B.V. http://www.gembird.eu
SIS
-
PMS
PROGRAMMABLE SURGE PROTECTOR
1. Introduction
Congratulations with your purchase of this Silver shield Power
Manager. Your SIS-PMS is an advanced surge protector with power
management features. Four sockets are individually manageable by the
computer via USB interface.
The sockets can be switched on/off by a timer schedule, by user or
different events. It is also possible to pre-program the unit event timer
schedule (hardware schedule) and then disconnect SIS-PMS from the
managing computer. The device can be used as an advanced standbykiller.
1.1. Features
• The main rocker switch enables switching all the sockets on and off
• In addition to it every manageable socket can be switched on and off
via the software control window
• The unit can be pre-programmed via hardware-based schedule. The
hardware schedule will work even when the managing computer is
switched off
• The unit will keep performing the programmed hardware time
schedule even after SIS-PMS is disconnected from the power for
some time
4
GEMBIRD EUROPE B.V. http://www.gembird.eu
SIS
-
PMS
PROGRAMMABLE SURGE PROTECTOR
• The manageable sockets can then be switched on and off by the
schedule, simple typical applications could be: “switch my
peripherals on every working day at 8:50 AM” etc.
• The manageable sockets can also be programmed with Power
Manager software to react whenever a certain event occurs
(Windows or other programs start-up/shutdown), simple typical
applications could be: “switch my scanner on when I want to scan”
or “switch my printer off whenever I exit Windows”
• Real time Voltage monitor provides information about the actual
status of each manageable socket (on or off). This information can
be further utilized in various ways (e.g. to check the proper
execution of the switching commands)
• The unit can be assigned a network name as a shared LAN
resource and can be afterwards accessed and managed from
anywhere within the local area network or Internet (provided the
managing computer is switched on)
1.2. Specifications
• Input voltage: 220 – 230 VAC, 50 – 60 Hz
• Maximum load: 10 A
• Maximum power consumed by SIS-PMS: 2.5 W
• Built-in power supply
• Hardware schedule features:
5
GEMBIRD EUROPE B.V. http://www.gembird.eu
SIS
-
PMS
PROGRAMMABLE SURGE PROTECTOR
• Maximum number of independent hardware schedule events –
16 per socket
• Time interval between the events – from 1 minute to 180 days
• Timer accuracy: no more than 2 seconds error per day
providing power is always present. Otherwise there can be an
additional (up to 2 seconds) error per each power off.
• Working temperature range: from +10 to +40 °C
• Dimensions: 378 x 98 x 55 mm
• Net weight: 1.0 kg
1.3. Hardware requirements
• Computer running Windows® 2000/XP/Vista or Windows 7 is
required for using the Power Manager software
• One free USB port
1.4. Package contents
The package contains:
• SIS-PMS
• User manual
• USB cable
• CD with Power Manager software for Windows
6
GEMBIRD EUROPE B.V. http://www.gembird.eu
SIS
-
PMS
PROGRAMMABLE SURGE PROTECTOR
2. Indicators and controls of SIS-PMS
Figure #1
Main rocker switch (Z)
Indicator Socket 3
“Silence” button to
suppress beeps
Indicator
“POWER”
Non-
manageable
socket
Indicator Socket 4
Indicator Socket 2
Indicator Socket 1
Non-manageable
socket
Socket 4
Socket 3
Socket 2
Socket 1
USB Connector
Side panel
7
GEMBIRD EUROPE B.V. http://www.gembird.eu
SIS
-
PMS
PROGRAMMABLE SURGE PROTECTOR
2.1. Side panel
Figure #2
Circuit breaker
Power cord
8
GEMBIRD EUROPE B.V. http://www.gembird.eu
SIS
-
PMS
PROGRAMMABLE SURGE PROTECTOR
2.2. Indicators
• Main rocker switch Z (see Figure #1 above) is lit – this means that
SIS-PMS is connected to the power supply and active
• Power indicator (see Figure #1 above) is lit – this means that the
non-manageable sockets (marked with the sign ) are
switched on
• The indicator Socket 1 (2,3,4) (see Figure #1 above) is lit – this
means that this particular socket is switched on
2.3. Audible signals
• Long beep – will be heard after SIS-PMS is successfully connected
to the computer USB port after the self-test
• Short beep – will be heard by switching the manageable sockets on
and off
• Continuous beeps – hardware event schedule is lost – for example if
the power supply was cut for a long time. These beeps can be
stopped by pressing the Silence button (see Figure #1 above)
• Alarm beep – will be heard if the managing command cannot be
executed. E.g. if there is a command to switch the socket on but
SIS-PMS is disconnected from the power supply. The alarm will be
heard every second during a minute, after that every 8 seconds. Let
SIS-PMS execute the command (e.g. switch SIS-PMS on) to get rid
of the alarm beeps
9
GEMBIRD EUROPE B.V. http://www.gembird.eu
SIS
-
PMS
PROGRAMMABLE SURGE PROTECTOR
3. Installation
• It is strongly recommended to avoid damp or wet places for
installation.
• SIS-PMS should be connected to the European AC wall socket of
the standard DIN 49 440.
3.1. Getting started
• Connect SIS-PMS to the wall socket first and then to the USB socket
of the manageable computer or vice versa.
• SIS-PMS can now be switched on and off by means of the Main
rocker switch (Z).
• Two (the first and the last) sockets of SIS-PMS are marked with the
symbol . These two sockets are switched on and off by
means of the Main rocker switch (Z) and cannot be managed by the
computer – so they are called non-manageable sockets in this
manual.
• If SIS-PMS is switched on then the red indicator POWER is lit. In
this case both non-manageable sockets are now live and connected
to the power supply.
• The sockets: Socket 1, Socket 2, Socket 3 and Socket 4 can be
managed or pre-programmed by computer via USB. They are called
manageable sockets in this manual.
10
GEMBIRD EUROPE B.V. http://www.gembird.eu
SIS
-
PMS
PROGRAMMABLE SURGE PROTECTOR
• The manageable sockets of SIS-PMS can be programmed to be on
or off. The current status of each manageable socket is represented
by the corresponding indicator which will be lit if socket has power to
it.
• If the Main rocker switch (Z) (see figure #1 above) is turned off then
the manageable sockets cannot be switched on by either Power
manager software or the hardware schedule.
• As soon as you turn the Main rocker switch (Z) on then the Power
manager software or the hardware schedule will be able to turn the
manageable sockets on and off.
• To protect the connected devices from possible high current and
short circuit SIS-PMS is equipped with the automatic circuit breaker.
NOTE: If the total power consumption (or peak power) of the devices,
connected to SIS-PMS exceeds 2200 Watts, the circuit breaker may
power SIS-PMS off. In this case, please, remove the excessive load first
and then press the Circuit breaker button to restore the power supply
(see figure #2 above).
3.2. Power Manager installation
• Insert the Power Manager CD into a PC CD-ROM drive.
If for any reason the automatic setup does not work, then open CD-ROM
drive in the My Computer window and launch SETUP.EXE from the CD
• Follow instructions of the installation software
11
GEMBIRD EUROPE B.V. http://www.gembird.eu
SIS
-
PMS
PROGRAMMABLE SURGE PROTECTOR
4. Power Manager software
The Power Manager software is designed to support not only SISPMS but also other products of SIS family.
After a successful installation a socket icon will appear in your
system tray.
4.1. Managing SIS-PMS
Double click on the socket icon in the system tray or select Open
from the popup menu (see Figure #3 below).
Figure #3
12
GEMBIRD EUROPE B.V. http://www.gembird.eu
SIS
-
PMS
PROGRAMMABLE SURGE PROTECTOR
You will get then the window of the main control panel shown on the
Figure #4 below.
Figure #4
Double click over each socket will switch it on and off (green color
means the socket is switched off; red color means the socket is switched
on). Click the Settings button for each socket to access the Settings
dialog box (see Figure #5 below).
13
GEMBIRD EUROPE B.V. http://www.gembird.eu
SIS
-
PMS
PROGRAMMABLE SURGE PROTECTOR
Figure #5
You can choose a different device and another socket from the
Device and Socket drop down list-boxes.
Loading...
