Gembird SIS-PWM User Manual

РУКОВОДСТВО ПОЛЬЗОВАТЕЛЯ

КЕРІВНИЦТВО КОРИСТУВАЧА

USER MANUAL

HANDBUCH

HANDLEIDING

MANUEL DESCRIPTIF

SIS-PWM Silver Shield(TM) advanced

surge protector with power meter

Silver Shield(TM) advanced surge protector with

power meter

Silver Shield (TM) Advanced Surge Protector

mit Leistungsmesser

Silver Shield(TM) geavanceerde surge protector

met stroom meter

Silver Shield (TM) de pointe de surtension avec

mesureur de puissance

Silver Shield (TM) Сетевой фильтр с функцией

измерения потребляемой мощности

Silver Shield (TM) Мережевий фільтр з

функцією вимірювання споживаної

потужності

All brands and logos are registered trademarks of their respective owners

2

SIS-PWM Silver Shield(TM) advanced

surge protector with power meter

Features

• USB interface power meter provides readings of voltage, current, power

and energy consumption

• Supplied with the software calculating the energy costs

• Power meter function does not require permanent connection to the

computer

• 6 socket AC power surge protector 230 VAC, 10A

• Protection from surges, spikes, radio-frequency noise (EMI/RFI filter)

• Built-in circuit breaker and overload protection

Specifications

• Power rating: 6 sockets 270 VAC max, 10A max

• USB 1.1 or 2.0 compatible interface: up to 5 m working distance

All brands and logos are registered trademarks of their respective owners

3

SIS-PWM Silver Shield(TM) advanced

surge protector with power meter

• Computer measurements: voltage and current measuring (RMS, peak

values), power measuring (true, apparent, reactive), real and full energy

consumed during a time period (kWH)

• Measurements range: up to 250 VAC, 10 A (RMS), 2500 W, 22.000 kW a

year

• Working conditions: +10...40 Celsius degrees, below 90% humidity

• Measurements accuracy: ± 1% (within 40W-2500W power range)

• Max surge voltage 6000 V, spike current 13500 A

• Automatic circuit breaker: 10 A

• Resistance to short-circuits: 1.5 KV

• Dimenstions: 460 x 140 x 65 mm

• Net weight: 1.3 Kg

1. Introduction

Congratulations on purchasing the SIS-PWM. It is an advanced

surge protector with power metering features.

All brands and logos are registered trademarks of their respective owners

4

SIS-PWM Silver Shield(TM) advanced

Measured

Non measured

surge protector with power meter

2. Indicators and controls of the SIS-PWМ

sockets

socket

Main rocker

switch

Indicator “Power”

Indicator

“Wiring OK”

Indicator

“Wiring Wrong”

Indicator

“Self-test”

Indicator

“Day/Night Mode”

All brands and logos are registered trademarks of their respective owners

USB socket

5

SIS-PWM Silver Shield(TM) advanced

2.1 Right side panel

surge protector with power meter

Circuit breaker

Power cord

All brands and logos are registered trademarks of their respective owners
