Gembird KB-UMW-01 operation manual
KB-UMW-01
USER MANUAL
HANDBUCH
HANDLEIDING
INSTRUKCJA OBSŁUGI
MECHANICAL BACKLIGHT GAMING KEYBOARD
MECHANISCHE RGB MULTIMEDIA-TASTATUR
MECHANISCH BACKLIGHT GAMING TOETSENBORD
PODŚWIETLANA GAMINGOWA KLAWIATURA MECHANICZNA, USB
2
GEMBIRD EUROPE B.V. http://www.gembird.eu
All brands and logos are registered trademarks of their respective owners
KB-UMW-01
MECHANICAL BACKLIGHT GAMING KEYBOARD
Features
Full-size USB mechanical gaming keyboard with backlight
Optical switch keys with with extreme 0.2 ms key response time and
durable 100 million key strokes life span
Backlight function on all keys with 9 preset default modes, 3 special
gaming modes and 3 brightness/speed settings
3 customizable user-defined backlight modes: decide which keys light
up for use in specific games or applications
RGB LED side strips with 5 light modes and multiple color/speed
settings
Heavy-duty IP58 waterproof aluminum body with nano-coating
technology
100% anti-ghosting on all keys to ensure all key strokes are registered,
no matter how fast your play
Lock function to disable the Windows and/or Fn button during
gameplay
Practical multimedia hotkeys for Internet and music
3
GEMBIRD EUROPE B.V. http://www.gembird.eu
All brands and logos are registered trademarks of their respective owners
KB-UMW-01
MECHANICAL BACKLIGHT GAMING KEYBOARD
Specifications
Materials: aluminum + ABS plastic
Interface: USB, 1.75 m braided cable
Polling rate: 1000 Hz (fixed)
Illumination: 9 modes
100% anti-ghosting with full key rollover
Key lift: 3.8 ± 0.3 mm
Pressing force: 55 ± 15 g
Key life time: 100 000 000 strokes
Power consumption: 5 V DC up to 0.35 A
Size: 460 x 140 x 38 mm
Net weight: 1.06 kg
4
GEMBIRD EUROPE B.V. http://www.gembird.eu
All brands and logos are registered trademarks of their respective owners
KB-UMW-01
MECHANICAL BACKLIGHT GAMING KEYBOARD
1
＋
＋
My computer
Browser
Mail
Calculator
FN+ Key Combinations
Volume -
Volume +
Mute
English
5
GEMBIRD EUROPE B.V. http://www.gembird.eu
All brands and logos are registered trademarks of their respective owners
KB-UMW-01
MECHANICAL BACKLIGHT GAMING KEYBOARD
10 Kinds of Backlight Mode to Cycle: Backlight On Breath Trace
＋
2
Lock / Unlock Window Key
Enable/Disable "FN" Key
Factory resetting: Press and hold both keys for
5 seconds until the keyboard backlight blinks
Default Backlight Mode
Wave Ripple Meteor Light flow Row-by-row Bump
Backlight Off.
Levels of brightness of backlight: 30%, 60%, 100% (Default setting is
100%).
3 levels of the speed of backlight breathing (Default setting is Level 2)
6
GEMBIRD EUROPE B.V. http://www.gembird.eu
All brands and logos are registered trademarks of their respective owners
KB-UMW-01
MECHANICAL BACKLIGHT GAMING KEYBOARD
＋
3
Cycle switch (Backlight On as default setting)
Increase backlight brightness
Decrease backlight brightness
Decrease Breath speed
Increase Breath speed
Customize Backlight Mode
Please choose which key you want to light up. Follow the following steps to
customize:
1. Press FN+1 to select and activate CM1 profile.
7
GEMBIRD EUROPE B.V. http://www.gembird.eu
All brands and logos are registered trademarks of their respective owners
KB-UMW-01
MECHANICAL BACKLIGHT GAMING KEYBOARD
2. Hold FN+ ESC to enter recording mode. (All Other functions of keyboard
＋
Start / Save backlight profile
Three user-defined profiles
100% full backlight mode
RTS game backlight mode
FPS game backlight mode
Office backlight mode
are disabled).
3. Press the key or keys which you want to set backlight on. (With the
exception of Caps Lock, Num Lock, Scroll Lock and Windows four keys)
4. When finished, press “FN+ESC” to save the user-defined backlight to
CM1 profile.
8
GEMBIRD EUROPE B.V. http://www.gembird.eu
All brands and logos are registered trademarks of their respective owners
KB-UMW-01
MECHANICAL BACKLIGHT GAMING KEYBOARD
5 light modes cycle: Light On Neon Flowing Wave Breath
7
＋
Right & Left Side Light Mode
Cycle Switch (Flowing as default)
Switch to previous one
Switch to next one
Decrease RGB light speed
Increase RGB light speed
Light Off.
Backlight color sequence: White Skyblue (Default) Pink Yellow
Blue Green Red.
Apply to “Light on Wave Breath” 3 modes to switch colors.
4 level of speed adjustment, apply to “RGB color Meteor Wave
Breathing” modes.
9
GEMBIRD EUROPE B.V. http://www.gembird.eu
All brands and logos are registered trademarks of their respective owners
KB-UMW-01
MECHANICAL BACKLIGHT GAMING KEYBOARD
Remarks
8
1. The keyboard corresponds to the button with four status lights,
user-friendly real-time understanding of the keyboard status.
2. Clean the keyboard regularly to avoid dust accumulation.
3. Avoid exposing the device to liquids and humid environments. Only
use the device within the specified temperature range of 32°F to 104°F
(0°C to 40°C). Once the temperature falls below or rises above this range,
unplug and switch off the device until the temperature returns to the
appropriate range.
10
GEMBIRD EUROPE B.V. http://www.gembird.eu
All brands and logos are registered trademarks of their respective owners
KB-UMW-01
MECHANICAL BACKLIGHT GAMING KEYBOARD
1
＋
＋
Mijn computer
Browser
Mail
Rekenmachine
Volume -
Volume +
Dempen
Nederlands
