Gembird DCAM-007 User Manual
USER MANUAL
HANDBUCH
HANDLEIDING
MANUEL DESCRIPTIF
РУКОВОДСТВО ПОЛЬЗОВАТЕЛЯ
КЕРІВНИЦТВО КОРИСТУВАЧА
FULL HD DASHCAM
KAMERA FÜR DAS ARMATURENBRETT
DASHBOARD CAM
APPAREIL PHOTO POUR LE TABLEAU DE BORD
АВТОМОБИЛЬНЫЙ ВИДЕОРЕГИСТРАТОР
АВТОМОБІЛЬНИЙ ВІДЕОРЕЄСТРАТОР
DCAM-007
2
GEMBIRD EUROPE B.V. http://www.gembird.eu
All brands and logos are registered trademarks of their respective owners
DCAM-007
FULL HD DASHCAM
Features
Compact in-car FHD camera with built-in microphone and LED light
Real 1080p resolution without interpolation (1080P/30fps, 720P/60fps, VGA/120fps)
Supports WDR - provides high quality video in fast changing light conditions
120 degrees wide angle lens with 4X digital zoom
Automatically starts recording when the car is started
Stores hours of video material on removable Micro SD card (not included)
G-sensor – automatically saves and locks video in case of accidents
Built-in 2.0” color LCD screen
Uninterrupted seamless cycle recording
Adjustable record section time
Specifications
Interface: USB 2.0 (Micro USB)
Image sensor: CMOS HD sensor
Lens type: Fixed focus
Aperture: F3.1
Effective Focal Length: f = 2.9 mm
Video Resolutio:1920X1080 (30fps), 1280X720 (60fps), 640X480 (120fps)
Video File Format: MOV
Video output: 1X Mini HDMI
Memory: Supports TF/Micro SD Cards ( Speed class 10, max. 32 GB)
Battery: internal rechargeable battery,110 mAh
Power input: 5 V DC/ 800 mA
Dimensions: 100.7 x 46.2 x 22.4 mm (L x W x H)
Length of USB cable: 75 cm
Length of car charging cable: 350 cm
Net weight: 70 g
3
GEMBIRD EUROPE B.V. http://www.gembird.eu
All brands and logos are registered trademarks of their respective owners
DCAM-007
FULL HD DASHCAM
