Gembird DCAM-001 User Manual

USER MANUAL

HANDBUCH

HANDLEIDING

MANUEL DESCRIPTIF

РУКОВОДСТВО ПОЛЬЗОВАТЕЛЯ

КЕРІВНИЦТВО КОРИСТУВАЧА

DASH CAM

KAMERA FÜR DAS ARMATURENBRETT

DASHBOARD CAM

APPAREIL PHOTO POUR LE TABLEAU DE BORD

АВТОМОБИЛЬНЫЙ ВИДЕОРЕГИСТРАТОР

АВТОМОБІЛЬНИЙ ВІДЕОРЕЄСТРАТОР

DCAM-001

2

GEMBIRD EUROPE B.V. http://www.gembird.eu

All brands and logos are registered trademarks of their respective owners

DCAM-001 DASH CAM

Features

 In-car HD camera with built-in microphone
 120 degrees wide angle lens
 Automatic brightness adjustment
 Automatically starts recording when the car is started
 Stores hours of video material on removable SD/SDHC card (not

included)

 Built-in pivoting LCD screen
 Suction cup window mount

Specifications

 Interface: USB 2.0
 Image sensor: 1/4 color CMOS WXGA HD Sensor
 Video Resolution: 640 x 480 / 720 x 480 / 1280 x 960
 Video file format: MPEG4
 Memory: Supports SDHC/MMC Cards (Max. 32 GB)
 Battery: internal rechargeable battery
 Power consumption: 5 V DC up to 0.25 A
 Dimensions: 100 mm x 62 mm x 23 mm (L x W x H)
 Length of USB cable: 96 mm
 Length of car charging cable: 345 mm
 Net weight: 99 g

3

GEMBIRD EUROPE B.V. http://www.gembird.eu

All brands and logos are registered trademarks of their respective owners

DCAM-001 DASH CAM

4

GEMBIRD EUROPE B.V. http://www.gembird.eu

All brands and logos are registered trademarks of their respective owners

DCAM-001 DASH CAM
