Gemalto M2M PHS8 US User Manual
PHS8-US
Version: 01.000
DocId: PHS8-US_HIO_v01.000
Hardware Interface Overview
PHS8-US Hardware Interface Overview
2
Document Name:
Version:
Date:
DocId:
Status
PHS8-US Hardware Interface Overview
01.000
2012-01-06
PHS8-US_HIO_v01.000
Confidential / Released
GENERAL NOTE
THE USE OF THE PRODUCT INCLUDING THE SOFTWARE AND DOCUMENTATION (THE "PRODUCT") IS SUBJECT TO THE RELEASE NOTE PROVIDED TOGETHER WITH PRODUCT. IN ANY
EVENT THE PROVISIONS OF THE RELEASE NOTE SHALL PREVAIL. THIS DOCUMENT CONTAINS INFORMATION ON CINTERION PRODUCTS. THE SPECIFICATIONS IN THIS DOCUMENT
ARE SUBJECT TO CHANGE AT CINTERION'S DISCRETION. CINTERION WIRELESS MODULES
GMBH GRANTS A NON-EXCLUSIVE RIGHT TO USE THE PRODUCT. THE RECIPIENT SHALL NOT
TRANSFER, COPY, MODIFY, TRANSLATE, REVERSE ENGINEER, CREATE DERIVATIVE WORKS;
DISASSEMBLE OR DECOMPILE THE PRODUCT OR OTHERWISE USE THE PRODUCT EXCEPT
AS SPECIFICALLY AUTHORIZED. THE PRODUCT AND THIS DOCUMENT ARE PROVIDED ON AN
"AS IS" BASIS ONLY AND MAY CONTAIN DEFICIENCIES OR INADEQUACIES. TO THE MAXIMUM
EXTENT PERMITTED BY APPLICABLE LAW, CINTERION WIRELESS MODULES GMBH DISCLAIMS ALL WARRANTIES AND LIABILITIES. THE RECIPIENT UNDERTAKES FOR AN UNLIMITED
PERIOD OF TIME TO OBSERVE SECRECY REGARDING ANY INFORMATION AND DATA PROVIDED TO HIM IN THE CONTEXT OF THE DELIVERY OF THE PRODUCT. THIS GENERAL NOTE
SHALL BE GOVERNED AND CONSTRUED ACCORDING TO GERMAN LAW.
Copyright
Transmittal, reproduction, dissemination and/or editing of this document as well as utilization of its contents and communication thereof to others without express authorization are prohibited. Offenders will
be held liable for payment of damages. All rights created by patent grant or registration of a utility model
or design patent are reserved.
Copyright © 2012, Cinterion Wireless Modules GmbH
Trademark Notice
Microsoft and Windows are either registered trademarks or trademarks of Microsoft Corporation in the
United States and/or other countries. All other registered trademarks or trademarks mentioned in this
document are property of their respective owners.
PHS8-US_HIO_v01.000 Page 2 of 40 2012-01-06
Confidential / Released
PHS8-US Hardware Interface Overview
Contents
40
Contents
1 Introduction.................................................................................................................6
1.1 Related Documents ........................................................................................... 6
1.2 Terms and Abbreviations ................................................................................... 6
1.3 Regulatory and Type Approval Information ..................................................... 10
1.3.1 Directives and Standards.................................................................... 10
1.3.2 SAR requirements specific to portable mobiles .................................. 12
1.3.3 SELV Requirements ........................................................................... 13
1.3.4 Safety Precautions.............................................................................. 13
2 Product Concept.......................................................................................................15
2.1 Key Features at a Glance ................................................................................ 15
2.2 PHS8-US System Overview ............................................................................ 18
3 Application Interface.................................................................................................19
3.1 Operating Modes ............................................................................................. 20
3.2 Power Supply................................................................................................... 21
3.3 USB Interface................................................................................................... 22
3.4 Serial Interface ASC0 ...................................................................................... 23
3.5 UICC/SIM/USIM Interface................................................................................ 25
3.6 Analog Audio Interface..................................................................................... 27
3.7 Digital Audio Interface...................................................................................... 27
4 GPS Receiver.............................................................................................................28
5 Antenna Interfaces....................................................................................................29
5.1 GSM/UMTS Antenna Interface ........................................................................ 29
5.1.1 Antenna Installation ............................................................................ 30
5.2 GPS Antenna Interface .................................................................................... 31
6 Mechanics..................................................................................................................33
6.1 Mechanical Dimensions of PHS8-US .............................................................. 33
7 Sample Application...................................................................................................35
8 Reference Approval..................................................................................................37
8.1 Reference Equipment for Type Approval......................................................... 37
8.2 Compliance with FCC and IC Rules and Regulations ..................................... 38
9 Appendix....................................................................................................................39
9.1 List of Parts and Accessories........................................................................... 39
PHS8-US_HIO_v01.000 Page 3 of 40 2012-01-06
Confidential / Released
PHS8-US Hardware Interface Overview
Tab les
40
Tables
Table 1: Directives ....................................................................................................... 10
Table 2: Standards of North American type approval .................................................. 10
Table 3: Requirements of quality ................................................................................. 10
Table 4: Standards of the Ministry of Information Industry of the
People’s Republic of China............................................................................ 11
Table 5: Toxic or hazardous substances or elements with defined concentration
limits............................................................................................................... 11
Table 6: Overview of operating modes ........................................................................ 20
Table 7: DCE-DTE wiring of ASC0 .............................................................................. 24
Table 8: Signals of the SIM interface (SMT application interface) ............................... 25
Table 9: Return loss in the active band........................................................................ 29
Table 10: List of parts and accessories.......................................................................... 39
Table 11: Molex sales contacts (subject to change) ...................................................... 40
Table 12: Hirose sales contacts (subject to change) ..................................................... 40
PHS8-US_HIO_v01.000 Page 4 of 40 2012-01-06
Confidential / Released
PHS8-US Hardware Interface Overview
Figures
40
Figures
Figure 1: PHS8-US system overview............................................................................ 18
Figure 2: Decoupling capacitor(s) for BATT+................................................................ 21
Figure 3: USB circuit ..................................................................................................... 22
Figure 4: Serial interface ASC0..................................................................................... 23
Figure 5: UICC/SIM/USIM interface .............................................................................. 26
Figure 6: Supply voltage for active GPS antenna ......................................................... 31
Figure 7: ESD protection for passive GPS antenna...................................................... 32
Figure 8: PHS8-US – top view ...................................................................................... 33
Figure 9: Dimensions of PHS8-US (all dimensions in mm)........................................... 34
Figure 10: PHS8-US sample application......................................................................... 36
Figure 11: Reference equipment for type approval......................................................... 37
PHS8-US_HIO_v01.000 Page 5 of 40 2012-01-06
Confidential / Released
PHS8-US Hardware Interface Overview
1 Introduction
14
1 Introduction
The document1 describes the hardware of the PHS8-US module, designed to connect to a cellular device application and the air interface. It helps you quickly retrieve interface specifications, electrical and mechanical details and information on the requirements to be considered
for integrating further components.
1.1 Related Documents
[1] PHS8-US AT Command Set
[2] PHS8-US Release Notes
[3] DSB75 Support Box - Evaluation Kit for Cinterion Wireless Modules
[4] Application Note 48: SMT Module Integration
1.2 Terms and Abbreviations
Abbreviation Description
AGPS Assisted GPS
ANSI American National Standards Institute
AMR Adaptive Multirate
ARP Antenna Reference Point
BB Baseband
BEP Bit Error Probability
BTS Base Transceiver Station
CB or CBM Cell Broadcast Message
CE Conformité Européene (European Conformity)
CS Coding Scheme
CS Circuit Switched
CSD Circuit Switched Data
CTM Cellular Text Modem
DAC Digital-to-Analog Converter
DCS Digital Cellular System
DL Download
DRX Discontinuous Reception
DSB Development Support Board
DSP Digital Signal Processor
DTMF Dual Tone Multi Frequency
1.
The document is effective only if listed in the appropriate Release Notes as part of the technical
documentation delivered with your Cinterion Wireless Modules product.
PHS8-US_HIO_v01.000 Page 6 of 40 2012-01-06
Confidential / Released
PHS8-US Hardware Interface Overview
1.2 Terms and Abbreviations
14
Abbreviation Description
DTX Discontinuous Transmission
EDGE Enhanced Data rates for GSM Evolution
EFR Enhanced Full Rate
EGSM Extended GSM
EMC Electromagnetic Compatibility
ERP Effective Radiated Power
ESD Electrostatic Discharge
ETS European Telecommunication Standard
ETSI European Telecommunications Standards Institute
FCC Federal Communications Commission (U.S.)
FDD Frequency Division Duplex
FDMA Frequency Division Multiple Access
FR Full Rate
GPRS General Packet Radio Service
GPS Global Positioning System
GSM Global Standard for Mobile Communications
HiZ High Impedance
HSDPA High Speed Downlink Packet Access
HR Half Rate
I/O Input/Output
IF Intermediate Frequency
IMEI International Mobile Equipment Identity
ISO International Standards Organization
ITU International Telecommunications Union
kbps kbits per second
LED Light Emitting Diode
LGA Land Grid Array
MBB Moisture barrier bag
Mbps Mbits per second
MCS Modulation and Coding Scheme
MO Mobile Originated
MS Mobile Station, also referred to as TE
MSL Moisture Sensitivity Level
MT Mobile Terminated
NMEA National Marine Electronics Association
NTC Negative Temperature Coefficient
PHS8-US_HIO_v01.000 Page 7 of 40 2012-01-06
Confidential / Released
PHS8-US Hardware Interface Overview
1.2 Terms and Abbreviations
14
Abbreviation Description
PBCCH Packet Switched Broadcast Control Channel
PCB Printed Circuit Board
PCL Power Control Level
PCM Pulse Code Modulation
PCS Personal Communication System, also referred to as GSM 1900
PD Pull Down resistor (appr. 100k)
PDU Protocol Data Unit
PS Packet Switched
PSK Phase Shift Keying
PU Pull Up resistor (appr. 100k)
QAM Quadrature Amplitude Modulation
R&TTE Radio and Telecommunication Terminal Equipment
RF Radio Frequency
ROPR Radio Output Power Reduction
RTC Real Time Clock
Rx Receive Direction
SAR Specific Absorption Rate
SELV Safety Extra Low Voltage
SIM Subscriber Identification Module
SLIC Subscriber Line Interface Circuit
SMPL Sudden Momentary Power Loss
SMD Surface Mount Device
SMS Short Message Service
SMT Surface Mount Technology
SNR Signal-to-Noise Ratio
SRAM Static Random Access Memory
SRB Signalling Radio Bearer
SUPL Secure User Plane Location
TDMA Time Division Multiple Access
TE Terminal Equipment
TPC Transmit Power Control
TS Technical Specification
TTFF Time To First Fix
Tx Transmit Direction
UL Upload
UMTS Universal Mobile Telecommunications System
PHS8-US_HIO_v01.000 Page 8 of 40 2012-01-06
Confidential / Released
PHS8-US Hardware Interface Overview
1.2 Terms and Abbreviations
14
Abbreviation Description
URC Unsolicited Result Code
USB Universal Serial Bus
UICC USIM Integrated Circuit Card
USIM UMTS Subscriber Identification Module
WCDMA Wideband Code Division Multiple Access
PHS8-US_HIO_v01.000 Page 9 of 40 2012-01-06
Confidential / Released
PHS8-US Hardware Interface Overview
1.3 Regulatory and Type Approval Information
14
1.3 Regulatory and Type Approval Information
1.3.1 Directives and Standards
PHS8-US has been designed to comply with the directives and standards listed below.
It is the responsibility of the application manufacturer to ensure compliance of the final product
with all provisions of the applicable directives and standards as well as with the technical specifications provided in the "PHS8-US Hardware Interface Description".
Table 1: Directives
2002/95/EC Directive of the European Parliament and of the Council of
27 January 2003 on the restriction of the use of certain hazardous substances in electrical and electronic equipment
(RoHS)
Table 2: Standards of North American type approval
1
CFR Title 47 Code of Federal Regulations, Part 22, Part 24 and Part 27; US Equipment
Authorization FCC
OET Bulletin 65
(Edition 97-01)
UL 60 950-1 Product Safety Certification (Safety requirements)
NAPRD.03 V5.8 Overview of PCS Type certification review board Mobile Equipment Type
RSS132, RSS133,
RSS139
Table 3: Requirements of quality
IEC 60068 Environmental testing
DIN EN 60529 IP codes
Evaluating Compliance with FCC Guidelines for Human Exposure to Radiofrequency Electromagnetic Fields
Certification and IMEI control
PCS Type Certification Review board (PTCRB)
Canadian Standard
1.
Manufacturers of applications which can be used in the US shall ensure that their applications have a
PTCRB approval. For this purpose they can refer to the PTCRB approval of the respective module.
PHS8-US_HIO_v01.000 Page 10 of 40 2012-01-06
Confidential / Released
PHS8-US Hardware Interface Overview
1.3 Regulatory and Type Approval Information
14
Table 4: Standards of the Ministry of Information Industry of the People’s Republic of China
SJ/T 11363-2006 “Requirements for Concentration Limits for Certain Hazardous Substances
in Electronic Information Products” (2006-06).
SJ/T 11364-2006 “Marking for Control of Pollution Caused by Electronic
Information Products” (2006-06).
According to the “Chinese Administration on the Control of
Pollution caused by Electronic Information Products”
(ACPEIP) the EPUP, i.e., Environmental Protection Use
Period, of this product is 20 years as per the symbol
shown here, unless otherwise marked. The EPUP is valid only as long as
the product is operated within the operating limits described in the Cinterion
Hardware Interface Description.
Please see Table 5 for an overview of toxic or hazardous substances or elements that might be contained in product parts in concentrations above the
limits defined by SJ/T 11363-2006.
Table 5: Toxic or hazardous substances or elements with defined concentration limits
PHS8-US_HIO_v01.000 Page 11 of 40 2012-01-06
Confidential / Released
PHS8-US Hardware Interface Overview
1.3 Regulatory and Type Approval Information
14
1.3.2 SAR requirements specific to portable mobiles
Mobile phones, PDAs or other portable transmitters and receivers incorporating a GSM module
must be in accordance with the guidelines for human exposure to radio frequency energy. This
requires the Specific Absorption Rate (SAR) of portable PHS8-US based applications to be
evaluated and approved for compliance with national and/or international regulations.
Since the SAR value varies significantly with the individual product design manufacturers are
advised to submit their product for approval if designed for portable use. For USmarkets the
relevant directives are mentioned below. It is the responsibility of the manufacturer of the final
product to verify whether or not further standards, recommendations or directives are in force
outside these areas.
Products intended for sale on US markets
ES 59005/ANSI C95.1 Considerations for evaluation of human exposure to electromagnetic
fields (EMFs) from mobile telecommunication equipment (MTE) in the
frequency range 30MHz - 6GHz
IMPORTANT:
Manufacturers of portable applications based on PHS8-US modules are required to have their
final product certified and apply for their own FCC Grant and Industry Canada Certificate related to the specific portable mobile.
PHS8-US_HIO_v01.000 Page 12 of 40 2012-01-06
Confidential / Released
Loading...
