Product Technical Information
July 10, 2020
Data shown is for the current revision model #. Ensure your nameplate model # matches.
Model Number:
5KS513SAA258B
Catalog Number:
Q5017
Instruction Manual:
GEI-56128
Connection Diagram:
GEM2034E-FIG20
Outline Drawing:
239C6C00HE
Accessory Connection Diagrams
Bearing Thermocouple:
None
Heater:
3027JE-1C
RTD:
None
Thermistor:
None
Thermostat:
None
Winding Thermocouple:
None
Bearing RTD:
None
Table of Contents
Specification
01
Performance Characteristics
02
Outline Drawing
03
Connection Drawing(s)
04
Spare parts
05
Model Number:5KS513SAA258B
July 10, 2020
Page | 1
Marks:
MODEL NUMBER:
5KS513SAA258B
Estimated Weight:
7150 Lbs
Outline Drawing:
239C6C00HE
Time Rating:
CONT
Connection Diagram:
GEM2034E-FIG20
Enclosure:
TEFC
Instruction Book:
GEI-56128
Encl Construction:
SD
Design Code:
50BD1241B
Ambient Max(°C):
40
Type:
KS
Alt Ambient Max(°C):
--
Frame:
5013S
Insulation Class:
F
Phases:
3
NEMA Design:
--
Poles:
4
Nominal Efficiency:
96.5 %
Output Power:
600HP 444KW
Guaranteed Efficiency:
95.8 %
RPM:
1785
3/4 Load Efficiency:
--
Voltage:
575
KVA Code:
E
Hertz:
60
Max KVAR:
95.7
Amps - FL:
514.0
Power Factor:
90.5
Service Factor:
1.15
Bearing - DE:
6320ZC3
Alt Service Factor:
--
Bearing - ODE:
6320ZC3
Enclosure is Totally Enclosed Fan-Cooled
Stamped Nameplate Notes:
TEMP CONT HTR LDS HE1-HE2 115V 200W
MAX SPACE HEATER SURFACE TEMPERATURE 160C
STAMP NP249A5564P075 AS BELOW:
MODEL:5KS513SAA258B
SN: XXX CSA CERTIFIED CSA.09.2216219
FOR CL I DIV2 GRP A,B,C,D T3 IN -40C<= TAMB<= 40C
1.0SF ON SINE-WAVE PWR OR ALTERNATE RATING
TEMP CODE T2C AT 1.15 SF ON SINE-WAVE PWR
OR -- VT PWM CONTROL 1.0 SF 40C AMB VT -- HZ.
FOR DIRECT COUPLED LOAD ONLY
Model Number:5KS513SAA258B
July 10, 2020
Page | 2
Additional Information:
4P - S EXTN - SPLIT LEAD
C/BOX 2500 CU IN - 2(4.00" NPT)
C/B GRD PLATE
OIL RESISTANT SLEEVING ON LEADS
115V TSTAT CTRLD HTR LDS TO AUX BOX OPP MAIN CONDUIT BOX
SPACE HEATER CAUTION NAMEPLATE
BEARING RTD PROVISION ON BOTH ENDS
NEMA TYPE GRD PAD
F1 MOUNTING
I-ALERT MOUNTED ON DE ENDSHIELD
Model Number:5KS513SAA258B
July 10, 2020
Page | 3
Performance Characteristics
1st Winding 1st Connection
Design: 50BD1241B
Marks:
LOAD %
125.0
115.0
100.0
75.0
50.0
25.0
0.0
% EFF
96.18
96.39
96.85
96.94
96.88
95.6
0.00
% PF
90.14
90.46
90.66
89.9
86.18
71.16
4.08
AMPS
647.69
592.51
512.01
386.65
269.04
165.09
106.77
TORQ(FL)#FT
1766.5
TORQ(LR)%FL
106.96
TORQ(BD)%FL
236.18
AMPS(LR)
2917.49
PF AT START
0.24
This motor is capable of two cold or one hot start with a maximum connected load inertia of 15618 Lb-Ft Sq (657.52 Kgmeter Sq)at 100% voltage, where the load torque varies with the square of the speed. Acceleration time with maximum
inertia and the above load type is 54 seconds. Safe stall time at 100% voltage is 108 seconds cold, 65 seconds hot. Rotor
inertia is 277.75 Lb-Ft Sq (11.69 Kg-meter Sq).
Open Circuit A-C:
1.384
Short Circuit D-C:
0.046
Short Circuit A-C:
0.045 X/R Ratio:
17.386
Stator Slots:
72 Rotor Slots:
58
Model Number: 5KS513SAA258B
July 10, 2020
Marks:
Model Number: 5KS513SAA258B
July 10, 2020
Page | 5
Marks:
Connection Diagram
Heater Connection
GEM2034E-FIG20
3027JE-1C
Model Number: 5KS513SAA258B
July 10, 2020
Page | 6
End shield Assembly
Part Description
DE Side Part#
ODE Side Part#
End Shield
115E5202DB1
115E5202AD1
Bearing
235A2523AF03
235A2523AF03
Slinger/Inproseal
149C4399G11
149C4399G11
Fan & Fan Cover Assembly
Part Description
Part#
Fan
148C8072AA1
Fan Cover
119D3661AA1
Conduit & Accessories Box Assembly
Part Description
Part#
Conduit Box
179B9098AF-G06
Mechanical Accessories
Part Description
Part#
Brake
Tachometer
