Product Technical Information
June 22, 2020
Data shown is for the current revision model #. Ensure your nameplate model # matches.
Model Number:
5KS405SAA208D9
Catalog Number:
M9924
Instruction Manual:
GEI-56128
Connection Diagram:
GEM2034E-FIG7
Outline Drawing:
239C6400AA
Accessory Connection Diagrams
Bearing Thermocouple:
None
Heater:
None
RTD:
None
Thermistor:
None
Thermostat:
None
Winding Thermocouple:
None
Bearing RTD:
None
Table of Contents
Specification
01
Performance Characteristics
02
Outline Drawing
03
Connection Drawing(s)
04
Spare parts
05
Model Number:5KS405SAA208D9
June 22, 2020
Page | 1
Marks:
MODEL NUMBER:
5KS405SAA208D9
Estimated Weight:
1460 Lbs
Outline Drawing:
239C6400AA
Time Rating:
CONT
Connection Diagram:
GEM2034E-FIG7
Enclosure:
TEFC
Instruction Book:
GEI-56128
Encl Construction:
X$D
Design Code:
40BD1159A
Ambient Max(°C):
40
Type:
KS
Alt Ambient Max(°C):
65
Frame:
405T
Insulation Class:
H
Phases:
3
NEMA Design:
B
Poles:
4
Nominal Efficiency:
95.4 %
Output Power:
100HP 74KW
Guaranteed Efficiency:
95.0 %
RPM:
1785
3/4 Load Efficiency:
95.6 %
Voltage:
460
KVA Code:
G
Hertz:
60
Max KVAR:
34.6
Amps - FL:
117.0
Power Factor:
83.5
Service Factor:
1.25
Bearing - DE:
6316ZC3
Alt Service Factor:
1.00
Bearing - ODE:
6316ZC3
Enclosure is Totally Enclosed Fan-Cooled
Stamped Nameplate Notes:
SF AMPS 144.2
STAMP NP249A5564P051 AS BELOW:
MODEL:5KS405SAA208D9 S/N: XXX
CSA CERTIFIED CSA09.2216219 FOR EX NA IIC 200 C GC
CL 1 ZONE2 AEX NA IIC 200C;CL 1 DIV2 GRP ABCD 200C
IN -40C <= AMB <= 40C, 1.0 SF ON SINE-WAVE PWR
SURF TEMP 215C AT 1.25SF ON SINE-WAVE PWR
OR 200C VT OR 230C CT OR 200C CHP PWM CONTROL
ALTERNATE RATING FOR PWM CONTROL 1.0SF 40C AMB
VT 0-60 HZ, CT 15-60 HZ, CHP 60-90 HZ.
Additional Information:
4P - T EXTN
700 CU IN - 3.00" NPT
OIL RESISTANT SLEEVING ON LEADS
F1 MOUNTING
Model Number:5KS405SAA208D9
June 22, 2020
Page | 2
Performance Characteristics
1st Winding 1st Connection
Design: 40BD1159A
Marks:
LOAD %
125.0
115.0
100.0
75.0
50.0
25.0
0.0
% EFF
94.93
95.13
95.58
95.57
95.2
92.81
0.00
% PF
85.46
84.81
83.3
78.51
68.1
45.2
3.16
AMPS
144.2
133.4
117.56
93.55
72.19
55.77
48.37
TORQ(FL)#FT
294.32
TORQ(LR)%FL
164.02
TORQ(BD)%FL
278.95
AMPS(LR)
715.84
PF AT START
0.32
This motor is capable of two cold or one hot start with a maximum connected load inertia of 2242 Lb-Ft Sq (94.39 Kg-meter
Sq)at 100% voltage, where the load torque varies with the square of the speed. Acceleration time with maximum inertia
and the above load type is 35 seconds. Safe stall time at 100% voltage is 75 seconds cold, 42 seconds hot. Rotor inertia
is 23.13 Lb-Ft Sq (0.97 Kg-meter Sq).
Open Circuit A-C:
0.673
Short Circuit D-C:
0.025
Short Circuit A-C:
0.041 X/R Ratio:
9.474
Stator Slots:
72 Rotor Slots:
58
Model Number: 5KS405SAA208D9
June 22, 2020
Marks:
Model Number: 5KS405SAA208D9
June 22, 2020
Page | 4
Marks:
Connection Diagram
GEM2034E-FIG7
Model Number: 5KS405SAA208D9
June 22, 2020
Page | 5
End shield Assembly
Part Description
DE Side Part#
ODE Side Part#
End Shield
115E4304AA1
115E4304LL1
Bearing
235A2518AC01
235A2518AC01
Slinger/Inproseal
149C4399G06
149C4399G06
Fan & Fan Cover Assembly
Part Description
Part#
Fan
159C7100AA2
Fan Cover
128D6832AA1
Conduit & Accessories Box Assembly
Part Description
Part#
Conduit Box
118D4408AD2
Mechanical Accessories
Part Description
Part#
Brake
Tachometer
