Product Technical Information
June 22, 2020
Data shown is for the current revision model #. Ensure your nameplate model # matches.
Model Number:
5KS324SAA308D11
Catalog Number:
M9119
Instruction Manual:
GEI-56128
Connection Diagram:
GEM2034E-FIG7
Outline Drawing:
239C6000AE
Accessory Connection Diagrams
Bearing Thermocouple:
None
Heater:
None
RTD:
None
Thermistor:
None
Thermostat:
None
Winding Thermocouple:
None
Bearing RTD:
None
Table of Contents
Specification
01
Performance Characteristics
02
Outline Drawing
03
Connection Drawing(s)
04
Spare parts
05
Model Number:5KS324SAA308D11
June 22, 2020
Page | 1
Marks:
MODEL NUMBER:
5KS324SAA308D11
Estimated Weight:
660 Lbs
Outline Drawing:
239C6000AE
Time Rating:
CONT
Connection Diagram:
GEM2034E-FIG7
Enclosure:
TEFC
Instruction Book:
GEI-56128
Encl Construction:
X$D
Design Code:
32BD3099A
Ambient Max(°C):
40
Type:
KS
Alt Ambient Max(°C):
65
Frame:
324T
Insulation Class:
H
Phases:
3
NEMA Design:
B
Poles:
6
Nominal Efficiency:
93.0 %
Output Power:
25HP 18.5KW
Guaranteed Efficiency:
92.4 %
RPM:
1180
3/4 Load Efficiency:
93.4 %
Voltage:
460
KVA Code:
G
Hertz:
60
Max KVAR:
10.3
Amps - FL:
32.1
Power Factor:
78.5
Service Factor:
1.25
Bearing - DE:
6312ZC3
Alt Service Factor:
1.00
Bearing - ODE:
6312ZC3
Enclosure is Totally Enclosed Fan-Cooled
Stamped Nameplate Notes:
SF AMPS 39.2
STAMP NP249A5564P051 AS BELOW:
MODEL:5KS324SAA308D11 S/N: XXX
CSA CERTIFIED CSA09.2216219 FOR EX NA IIC 200 C GC
CL 1 ZONE2 AEX NA IIC 200C;CL 1 DIV2 GRP ABCD 200C
IN -40C <= AMB <= 40C, 1.0 SF ON SINE-WAVE PWR
SURF TEMP 215C AT 1.25SF ON SINE-WAVE PWR
OR 200C VT OR 200C CT OR 200C CHP PWM CONTROL
ALTERNATE RATING FOR PWM CONTROL 1.0SF 40C AMB
VT 0 - 60 HZ, CT 3-60 HZ, CHP 60-90 HZ.
Additional Information:
6P - T EXTN
346 CU IN - 3.00" NPT
OIL RESISTANT SLEEVING ON LEADS
F1 MOUNTING
Model Number:5KS324SAA308D11
June 22, 2020
Page | 2
Performance Characteristics
1st Winding 1st Connection
Design: 32BD3099A
Marks:
LOAD %
125.0
115.0
100.0
75.0
50.0
25.0
0.0
% EFF
92.2
92.56
93.21
93.38
92.92
89.56
0.00
% PF
81
80.3
78.6
73.26
62.21
40.3
4
AMPS
39.16
36.2
31.92
25.65
20.24
16.21
14.32
TORQ(FL)#FT
111.19
TORQ(LR)%FL
159.54
TORQ(BD)%FL
268.46
AMPS(LR)
184.74
PF AT START
0.33
This motor is capable of two cold or one hot start with a maximum connected load inertia of 2445 Lb-Ft Sq (102.93 Kgmeter Sq)at 100% voltage, where the load torque varies with the square of the speed. Acceleration time with maximum
inertia and the above load type is 62 seconds. Safe stall time at 100% voltage is 116 seconds cold, 75 seconds hot. Rotor
inertia is 8.87 Lb-Ft Sq (0.37 Kg-meter Sq).
Open Circuit A-C:
0.34 Short Circuit D-C:
0.018
Short Circuit A-C:
0.022 X/R Ratio:
6.623
Stator Slots:
54 Rotor Slots:
40
Model Number: 5KS324SAA308D11
June 22, 2020
Marks:
Model Number: 5KS324SAA308D11
June 22, 2020
Page | 4
Marks:
Connection Diagram
GEM2034E-FIG7
Model Number: 5KS324SAA308D11
June 22, 2020
Page | 5
End shield Assembly
Part Description
DE Side Part#
ODE Side Part#
End Shield
115E4200AA1
115E4200LA1
Bearing
235A2509AS01
235A2509AS01
Slinger/Inproseal
149C4399G04
149C4399G04
Fan & Fan Cover Assembly
Part Description
Part#
Fan
159C7000G01
Fan Cover
128D6800AA1
Conduit & Accessories Box Assembly
Part Description
Part#
Conduit Box
149C4429AA2
Mechanical Accessories
Part Description
Part#
Brake
Tachometer
