GEIGER GEIGER-SoftZero-55, GEIGER-SOLIDline x/55 Series, GU4509/55, GU4512/55, GU4503/55 Operating Instructions Manual
...
1
www.geiger.de
EN
EN
DE
Bedienungsanleitung
Operating Instructions
Manuel d’utilisation
Manual de instrucciones
Istruzioni per l’uso
EN
FR
ES
IT
Tubular motor:
GEIGER-SOLIDline ../55
Motor control:
GEIGER-SoftZero-55 (GU45..E02)
for facade awnings, screens and ZIP screens
2
Gerhard Geiger GmbH & Co. KG | 100W0597 0818V000
en
EN
EN
Index
1. Characteristics of the GEIGER-SoftZero-55 ..................3
2. General information .........................................................4
3. Guarantee ..........................................................................4
4. Safety information ............................................................4
5. Intended use .....................................................................5
6. Installation instructions ...................................................6
7. Setting of the end stops ...................................................7
8. Correction of the end stops .............................................7
9. GEIGER Powertronic ........................................................8
10. Obstacle detection ...........................................................9
11. Technical data .................................................................10
12. Declaration of conformity ..............................................10
13. Information for the specialist electrician .....................11
14. Notes on waste disposal ...............................................11
15. What to do if… ................................................................12
3
www.geiger.de
EN
EN
1. Characteristics of the GEIGER-SoftZero-55
Universal electronic motor for facade awnings
• Facade awnings, screens and ZIP screens can be operated with the
GEIGER SoftZero-55.
Safety
• A safe locking of the facade awning/screen through torque shutoff
Fabric Protection
• GEIGER-Locking power minimisation (automatic function)
• GEIGER-Powertronic (manual function: power level)
...for a nice long lasting fabric.
Hanging Length Adjustment
• Modifications in fabric lengths are recognised and compensated for.
Obstacle Recognition
• Active obstacle detection when extending the installation
• Protection of the awning system by retracting the equipment
GEIGER-Operating Radius Identification
• Modern electronic control identifies the equipment’s torque curve,
and makes available to the motor the exact amount of power needed
during operation, and while closing.
4
Gerhard Geiger GmbH & Co. KG | 100W0597 0818V000
en
EN
EN
2. General information
Dear customer,
By purchasing a GEIGER tubular motor you have decided on a quality product from
GEIGER.
Thank you very much for your decision and the confidence placed in us.
Before you put this drive into operation please observe the following safety
information. It serves for the prevention of danger and for the avoidance of personal
injury and damage to property.
Please retain this information for future reference.
f For all facade awnings, screens and ZIP screens
f Drives are switchable in parallel
f Automatic detection of right/left installation
3. Guarantee
In the case of incorrect installation contrary to the operating instructions and/
or constructional modification, the legal and contractual guarantee for property
damage and product liability lapses.
4. Safety information
I
ATTENTION: Important safety information. For personal safety, it is
important to follow these instructions. The instructions should be
kept.
f This appliance is not to be used by persons (including children) whose
physical, sensorial or mental capacities are impaired, or who have no
expe rience or know-how, unless they have been supervised or been given
instructions on the use of the appliance by someone who is responsible for
their safety.
f Children must be supervised to make sure they do not play with the
appliance.
f The installation is to be checked regularly for defective balance, wear and
damage.
f Damaged connecting leads must be replaced by the GEIGER connecting
lead of the same wire type.
f During operation observe the danger zone.
f If people or objects are in the danger zone, do not use the installation.
f Urgently shut down damaged installations until repair.
f Unconditionally shut down the unit during maintenance and cleaning
operations.
f Pinching and shearing sites are to be avoided and to be safeguarded
against.
f When operating the manual actuator with the open sun protection system,
exercise caution as it can fall down quickly if springs expand or are broken.
5
www.geiger.de
EN
EN
f Do not operate the device if operations such as, for example, window
cleaning are to be carried out in the vicinity.
f Disconnect the device from the mains power supply if operations such as,
for example, window cleaning are being carried out in the vicinity.
I
ATTENTION: Important safety information. Follow all installation
instructions, as incorrect installation can lead to serious injuries.
f Connection must be carried out by a skilled electrician according to the
regulations in force locally.
f The mains plug of the tubular motor must be accessible after installation.
f On the installation of the tubular motor without mechanical protection of
the driven parts, the tubular motor must be installed at a height of at least
2.5 m above the ground or of another level which provides access to the
drive.
f Before the tubular motor is installed, all leads which are not needed are to
be removed and all equipment which is not needed for actuation is to be
put out of operation.
f If the tubular motor is controlled by a switch or pushbutton, the switch
or pushbutton must be mounted within eyeshot of the tubular motor. The
switch or pushbutton must not be located in the vicinity of moving parts.
The height of installa tion must be at least 1.5 m above the floor.
If the apparatus is equipped without a pin and a socket connector (STAS3K)
in the connecting lead, or other means for disconnecting from the mains
with at least a 3 mm contact opening on each pole, a disconnecting device
of this type must be incorporated into the permanently installed electrical
installation according to the wiring rules.
f Permanently installed control devices must be attached visibly.
f The correct dimensioning of the drive is to be observed.
5. Intended use
The tubular motors of the model range SOLIDline ../55 with the SoftZero -55
system are designed exclusively for the operation of facade awnings, screens and
ZIP screens.
If the tubular motors are used for other applications and/or modifications are
performed to the tubular motors, which have not been discussed with GEIGER
Antriebstechnik, then the manufacturer is not liable for personal injury and/or
damage to property and for consequential damage.
6
Gerhard Geiger GmbH & Co. KG | 100W0597 0818V000
en
EN
EN
6. Installation instructions
Before fixing, the strength of the masonry or of the subsurface is to be checked.
I
Caution: If the tube is screwed/riveted to the drive, the measure must be
taken from the tube end to the center of the drive and marked on the tube.
When drilling the winding shaft never drill into the
area of the tubular motor!
When inserting into the shaft, the tubular motor
must not be struck and must not be allowed to fall
into the shaft.
Installation into facade awnings and
screens:
Insert motor with a suitable adapter and drive into
the shaft up to the stop of the shaft adapter.
Fix the motor support on the awning. Fix the motor
together with the shaft on the motor support. The
bearer locks into place.
Depending on the selected motor head,
different fixation systems can be used:
– Place the motor with square insert in the star-
shaped bearer and lock with pin
– Place the motor into the existing engine bearer
and lock
– Place the motor in a compatible engine bearer with clip system and lock with
spring or rotating lever
7
www.geiger.de
EN
EN
7. Setting of the end stops
Connect the setting cable to the connecting cable of the GEIGER SoftZero-DG.
When doing so, take care to ensure that the colours of the different leads do tally
with each other. The assignment of the direction keys 1 and 2 to the direction of
rotation is dependent on the installation situation of the motor. Then connect the
setting cable to the 230V mains.
Setting of the lower end position
Press the programming key until the LED blinks 1 x, then release the programming
key. Run the motor with the direction keys to the desired lower end position. Press
the programming key - the LED blinks 2 x.
Setting of the upper end position (Torque shutoff)
Run the motor with the direction keys to the desired upper end position. When
the upper end position is reached, the motor turns off automatically the learning
process. The programming is finished and the motor returns to normal operation.
I
There is no need to first delete the end stops (memorised) if you wish to
modify them.
8. Correction of the end stops
If a lengthening/shortening of the hanging has resulted due to e.g. temperature
changes, this will be automatically corrected by closing the awning.
If, due to temperature changes, modified winding behaviour should arise and the
hangings should run against the stop, an immediate end position correction takes
place.
After the first reference run, the motor automatically identifies the torque necessary
to close the awning and closes it with the lowest possible power, so that the fabric
is optimally protected.
Mains:
230
VSetting cable
M56....
Service
terminals
Connecting cable
to limit stop12
Programming
key
LED
Hirschmann coupling
Adaption cable
M56B265
8
Gerhard Geiger GmbH & Co. KG | 100W0597 0818V000
en
EN
EN
9. GEIGER Powertronic
The GEIGER Powertronic enables the user to change the motor’s closing characteristics. The user can raise or reduce the closing power applied through the motor. This
way, he or she influences the closing characteristics of the casing. A rise in the closing
power causes a tighter closing of the casing with increased stress on the fabric; a
reduction in the closing power causes a looser closing and less strain to the fabric.
Closing power levels: from level 0 to level 7
GEIGER-delivery setting: level 0
I
Caution: By manually raising the closing power (e.g. from level 0 to
level 3) the fabric endures more strain.
In which situations is the GEIGER Powertronic applied?
• If the casing does not completely close.
• If the closing operation should be optimised for better fabric protection.
When can the GEIGER Powertronic be applied?
• Anytime; this function can be activated during initial operation, as well as at a
later date.
Which resources are necessary?
• GEIGER setting cable M56K144 (D), M56F150 (CH) or M56F151 (D with service
terminal)
Please note:
• The stop positions are not affected when the GEIGER Powertronic is activated.
• The selected power level is not affected when the end stop positions are changed
• Only activate the GEIGER Powertronic after the stop positions have been
taught-in and a complete reference run has been conducted.
GEIGER Powertronic – changing the power levels
Connect the setting cable to the connecting cable of the motor. When doing so,
take care to ensure that the colours of the different leads do tally with each other.
Then connect the setting cable to the 230V mains.
Activating the GEIGER Powertronic
Press the programming key about 8 seconds until the LED blinks 3 x, then release
the programming key.
Changing the power levels
The motor is delivered with the power level 0. In order to increase the force press
key 2. Press key at least 2 seconds and stop at least 2 seconds. In order to
reduce the force press key 1. In order to store the selected level, press shortly the
programming key – the LED lights up. The adjustment process is finished.
9
www.geiger.de
EN
EN
10. Obstacle detection
If, after teaching-in, the first complete, uninterrupted run from one stop position to
the other is conducted, the necessary torque will be taught-in.
With each successive complete and uninterrupted run from one stop position to
the other, the necessary torque is automatically readjusted. Slow changes to the
equipment through aging, contamination, the cold or heat are accounted for in this
regard. This process takes place for both running directions independently of one
another.
Should UPWARD movement be blocked by an obstruction, the motor turns off and
a short reverse movement occurs.
The direction of movement in which the obstruction was detected is locked.
The device will be unlocked if the motor is run for a short time period in the opposite direction. The obstruction must also be removed before the motor can be rerun
in the direction of the obstruction.
I
Because of the motor sensitive obstacle detection, the correct
dimensioning of the torque for the respective installation size is
essential.
In the following table please find a selection aid to find out the right motor size:
These are estimated values so please check the correct functioning of the
installation.
I
When using a wind sensor the correct functioning of the retract
command under wind load should be checked by the manufacturer of
the sun protection before commissioning.
1 2 3 4 5 6 8 10 12 15 20 25 30
0,2 0,5 0,7 1,0 1,2 1,5 2,0 2,5 2,9 3,7 4,9 6,1 7,4
0,3 0,5 0,8 1,1 1,3 1,6 2,2 2,7 3,2 4,0 5,4 6,7 8,1
0,3 0,6 0,9 1,2 1,5 1,8 2,4 2,9 3,5 4,4 5,9 7,4 8,8
0,3 0,6 1,0 1,3 1,6 1,9 2,6 3,2 3,8 4,8 6,4 8,0 9,6
0,3 0,7 1,0 1,4 1,7 2,1 2,7 3,4 4,1 5,2 6,9 8,6 10,3
0,4 0,7 1,1 1,5 1,8 2,2 2,9 3,7 4,4 5,5 7,4 9,2 11,0
0,4 0,8 1,2 1,6 2,0 2,4 3,1 3,9 4,7 5,9 7,8 9,8 11,8
0,4 0,8 1,3 1,7 2,1 2,5 3,3 4,2 5,0 6,3 8,3 10,4 12,5
0,4 0,9 1,3 1,8 2,2 2,6 3,5 4,4 5,3 6,6 8,8 11,0 13,2
0,5 0,9 1,4 1,9 2,3 2,8 3,7 4,7 5,6 7,0 9,3 11,6 14,0
0,5 1,0 1,5 2,0 2,5 2,9 3,9 4,9 5,9 7,4 9,8 12,3 14,7
0,5 1,1 1,6 2,2 2,7 3,2 4,3 5,4 6,5 8,1 10,8 13,5 16,2
Weight of bottom bar [kg]
3 Nm 6 Nm 9 Nm 12 Nm
Winding diameter [mm]
50
55
60
65
70
75
80
85
90
95
100
110
10
Gerhard Geiger GmbH & Co. KG | 100W0597 0818V000
en
EN
EN
11. Technical data
Technical data of short motor SOLIDline (GU45..)
GU4503/55 GU4506/55 GU4509/55 GU4512/55
Voltage
230 V~/50 Hz 230 V~/50 Hz 230 V~/50 Hz 230 V~/50 Hz
Current
0,47 A 0,63 A 0,8 A 1,0 A
Cos Phi (cosj)
>0,95 >0,95 >0,95 >0,95
Inrush current
(factor)
x 1,2 x 1,2 x 1,2 x 1,2
Power
105 W 140 W 180 W 220 W
Torque
3 Nm 6 Nm 9 Nm 12 Nm
Speed of rotation
55 1/min 55 1/min 55 1/min 55 1/min
Protection type
IP 44 IP 44 IP 44 IP 44
Total length
1)
515,5 mm 545,5 mm 565,5 mm 585,5 mm
Operating type
S2 4 min S2 5 min S2 4 min S2 4 min
Diameter
45 mm 45 mm 45 mm 45 mm
Weight
approx.
1,9 kg
approx.
2,2 kg
approx.
2,4 kg
approx.
2,7 kg
1)
SOLIDline-ZN/-KS: +1 mm / SOLIDline-COM/-SIC + 4,5 mm / SOLIDline-SOC: + 4 mm
Subject to technical modifications
12. Declaration of conformity
We herewith explicitly declare that this product complies with the essential requirements and relevant directives. It is authorised for use in all EC member states and
in Switzerland without any need of prior registration. The Declaration of Conformity
concerning this product is available on our website:
www.geiger-antriebstechnik.de.
11
www.geiger.de
EN
EN
13. Information for the specialist electrician
H
Caution: Wrong installation and
wrong connection can lead to serious injuries.
The adjusting cable M56K144, M56F150 or M56F151 must
be used for the adjustment processes.
If required, use the adapter cable with service clamps
M56B265.
The operations with the service clamps must only be carried
out by a skilled electrician.
The parallel operation of several SOLIDline SoftZero
motors is possible. Please observe the rating of the control
switch used.
Please do not use any installation switch which allows
simultaneous up and down controls.
PVC cables are not suitable for equipment used outdoors or
exposed to prolonged high levels of UV radiation.
These cables should not be used if they are likely to touch
metal parts that can heat up to temperatures exceeding
100°C.
Connecting cables with plug connectors of the Hirschmann
Company, type STAS 3K or the Phoenix Mecano Company,
type GLS/3+PE may only be used in connection with the
Hirschmann cable socket STAK 3K.
14. Notes on waste disposal
Recycling of packaging materials
In the interest of environmental protection, please contact your local government’s
recycling or solid waste management department to learn more about the services
it provides.
Waste disposal of electric and electronic equipment
Electronic equipment or batteries cannot be discarded along with the normal
household waste. Keep for more information on the recycling and disposal
methods envisaged by the local regulations in your area.
12 3
PE N
L1
N
PE
Electronic /
mechanical
limit stop
blue
brown
black
green/yellow
Mains: 230V / 50Hz
12
Gerhard Geiger GmbH & Co. KG | 100W0597 0818V000
en
EN
EN
For technical questions, please call our service team at: +49 (0) 7142 938-333.
They will be happy to assist you.
Gerhard Geiger GmbH & Co. KG
Schleifmühle 6
D-74321 Bietigheim-Bissingen
Telephone: +49 (0) 7142 938-0
Telefax: +49 (0) 7142 938-230
E-Mail: info@geiger.de
Internet: www.geiger.de
15. What to do if…
Problem Solution
Motor does not run.
• Motor not plugged in.
Please check the plug connection.
• Check connecting cable for possible
damage.
• Check the mains voltage and allow
the cause of the voltage break down
to be tested by a specialist
electrician.
Instead of in the upwards direction,
motor runs downwards.
• The control leads are interchanged.
Exchange black/brown control leads.
Motor only runs in one
direction.
• Motor in the end position.
Run motor in the opposite direction.
After running several times,
the motor breaks down and
no longer responds.
• The motor became too hot and has
switched off.
Try it again after a cooling time of
about 15 min.
The motor «hums» when the
programming key is actuated.
The LED lights weakly.
• The control leads in the STAS
3 connector are interchanged.
Exchange black/brown control leads.
The motor stops between the upper
and the lower end stop.
• The motor has detected an obstacle.
Please remove the obstacle. The
device will be unlocked if the motor
is run for a short time period in the
opposite direction.
Loading...
