GE - General Electric 300-Line Starters Technical Data
NEMA Full Voltage Power Devices
00 023456781
9
Normal Starting Duty HP Rating
1
Single Phase
115V 60Hz
1/3 7 1/2 3 2 1
3 2 1
NA NA NA NA NA NA
230V 60Hz 7 1/2 15 NA NA NA NA NA NA
Three Phase
200V 60Hz
10 25 40 75 150
230V 60Hz 7 1/2
7 1/2
15 30 50 100 200 300 450 800
380-415V 50Hz 752510
10
5
5
3
3
5
50
25
50
10
25
50
150 300 500 750 1350
460V 60Hz 100 200 400 600 900 1600
575V 60Hz 100 200 400 600 900 1600
Plugging or Jogging HP Rating
1
Single Phase
115V 60H 1/2 521 NANA
NA
NA
NA
NA
NA
NA
NA NA NA NA NA
230V 60Hz
z
z
10 NA NA NA NA NA NA
Three Phase
200V 60Hz 15 25 60 125 NA NA NA
230V 60Hz 1 1/2
1 1/2 7 1/2 3
1 1/2
1 1/2
1 1/2
7530
50
60
60
30
30
30
15
15
15
5
5
5
2
2
20103 150 NA NA NA
380-415V 50H 1 1/2
1 2 5
2
2
125 250 NA NA NA
460V 60Hz 150 250 NA NA NA
575V 60Hz 150 250 NA NA NA
Continuous Current Max
Starters and Enclosed Contactors 135904527189 270 540 810 1215 2250
Open Contactors 10 20 30 50 100 150 300 600 900 1350 2500
Coil Burden (VA)
Inrush 2-Pole 151 151 151 528 1152 1248 2580 3360 1600 1500 2900
Holding 2-Pole 24 24 24 60 83 87 191 255 210 140 300
Inrush 3-Pole 151 151 151 528 1152 1248 2580 3360 1600 2900 3600
Holding 3-Pole 24 24 24 60 83 87 191 255 210 300 400
Inrush 4- and 5-Pole 151 151 151 576 1248 1356 3600 NA NA NA NA
Holding 4- and 5-Pole 24 24 24 75 87 95 276 NA NA NA NA
Control Power Transformer VA (Min) 50 50 50 100 200 250
500
2
500
2
1000
2
1500
2
1501
2
Coil Operating Voltage
% Minimum Pickup 85858585858585858585
% Maximum Dropout 63 63 63 68 65 65 65 65 50 50 50
Switching Delay 3-Pole
Pickup Typical (Milliseconds) 15-30 15-30 15-30 20-40 20-45 20-45 30-50 60-90 80-125 80-125
Dropout Typical (Milliseconds) 7-15 7-15 7-15 7-15 7-15 7-15 15-25
30-50
15-25 100-150 25-100 25-100
Mechanical Life Millions Nominal 20 20 20 10 0.5111555
Weight (Less Carton)
Contactor (Pounds) 2 3/4 2 3/4 2 3/4 6 1/2 15 14 3/4 48 79 203 302
Starter (Pounds) 3 3/4 3 3/4 3 3/4 7 1/2 17 3/4 17 1/2 53 106
48
75 263 365
Power Terminals
Wire Size Range (75 DEG) AWG 14-8 14-8 14-8 14-4 10-1/0 8-3/0 1/0-500kcmil 2 2/0-500kcmil 3 2-600kcmil 4 2-600kcmil NA
Torque (Pounds-Inches) 20 20 20 50 150 200 300 375 500 500 NA
Max. Noise (DBA) 50 50 50 50 50 50 65 65 65 65 65
1
When operation of the controller requires jogging (inching) or plug stopping or when normal operation requires continued operation in excess of 5 operations per minute or
10 operations in a 10-minute period, the plugging or jogging horsepower ratings must be followed.
2
In lieu of a 500 to 1500 VA control transformer, a 50 VA unit in conjunction with a control relay can be used as follows:
a. Wire control relay coil in control circuit on secondary side of control transformer.
b. Wire two poles of control relay in series with contactor coil at line voltage.
Description
Maximum Horsepower NEMA Size
85
300-Line Starters
Application Information and Technical Data
Mounting Position
Devices must be mounted to a sturdy vertical surface with the
line side terminals up. No other orientations are permitted.
Operating Temperature
Equipment is designed for ambient temperature outside of equipment enclosures to be –25° to 40°C. When contactor is energized,
temperatures will be above outside ambient in equipment
1-4
Product Number Selection Instructions: See page 1-8
Control Catalog
enclosures. Temperature rises inside the enclosures should be
limited so that internal air temperature does not exceed 65° for
sizes 00 to 6 and 60°C for sizes 7 to 9. If condensing moisture is
present, space heater kits should be used to prevent condensation when contactor is not energized.
Storage temperature should be –30° to 65°C. If equipment is
stored over 1 week, it may be necessary to cover the equipment
and provide a source of heat to prevent condensation.
Rev. 4/16
Prices and data subject to
change without notice
NEMA Full Voltage Power Devices
NEMA
Size Fuse Type
Maximum Symmetrical
rms Amperes
0-3 H, K
H, K
5,000
4, 5 10,000
0-5 J, RK-1, RK-5 100,000
6 J, L, RK-1, RK-5 100,000
300-Line Starters
Application Information and Technical Data
Short-Circuit Ratings
Fusible forms of combination magnetic starters equipped with UL
labeled, nonrenewable, NEC-type fuses listed in the table below,
are adequate for installation on motor branch circuits where the
available short-circuit current at the incoming line terminals of
the starter does not exceed the value shown.
Circuit breaker-type combination magnetic starters equipped
with the circuit breakers listed in the table at right are adequate
for installation on motor branch circuits where the available
short-
cir
cuit current at the incoming line terminals of the starter
does not exceed the value shown.
For either type, it is recognized that maintenance of some components may be required after a branch circuit fault and in some
cases a device may require replacement.
Fusible Combination Starters
Circuit Breaker Combination Starters
™
Spectra
RMS Molded Case Circuit Breaker or Spectra™RMS
Mag-Break Circuit Protector
Breaker NEMA Maximum Symmetrical RMS Amperes
Model Size 240V 480V 600V
SELA 0 - 3 65,000 65,000 25,000
SFLA 4 65,000 65,000 25,000
Circuit Breaker Combination Starters
Breaker Rating NEMA Maximum Symmetrical RMS Amperes
Type Amperes Size 240V 480V 600V
TJJ & TJK 225-600 5 10,000 10,000 10,000
THJK 225-400 5 35,000 35,000 25,000
THJK 450-600 5 10,000 10,000 10,000
TKM, TKC 300-800 6 42,000 30,000 22,000
THKM8 300-800 6 65,000 35,000 25,000
TB6, TBC 300-800 6 65,000 65,000 42,000
Rev. 4/16
Prices and data subject to
change without notice
Control Catalog
1-5
