Gefran PY2 Data Sheet

PY2

RECTILINEAR DISPLACEMENT TRANSDUCER
WITH BALL TIP

Principal characteristics

• The side connection creates a through-rod structure with
double rod support, guaranteeing greater overall strength
of the transducer.

• The return spring automatically returns the rod to zero
position, making the transducer suitable for comparator
applications.

• The tip with stainless steel ball is suitable for applications
where the object to be measured is not subject to shifts
transverse to the transducer axle.

• Ideal for checking the flatness or thickness of panels
of various materials. Can also be used for valves or
mechanical parts when the rod cannot be attached to the
moving object.

TECHNICAL DATA MECHANICAL DIMENSIONS

Useful electrical stroke

(C.E.U.)

Resolution Infinite

Independent linearity

(within C.E.U.)

Displacement speed ≤ 10 m/s

Displacement force ≤ 4 N

Life

Vibrations

Shock 50 g, 11ms.

Tolerance on resistance ± 20%

Recommended cursor
current

Maximum cursor current 10mA

Maximum applicable
voltage

Electrical isolation >100MΩ a 500V=, 1bar, 2s

Dielectric strength < 100 mA a 500V~, 50Hz, 2s, 1bar

Dissipation at 40°C
(0W at 120°C)

Actual Temperature
Coefficient of the output
voltage

Working temperature -30...+100°C

Storage temperature -50...+120°C

Case material Anodised aluminium Nylon 66 G 25

Control rod material Stainless steel AISI 303

Fixing

Important: all the data reported in the catalogue linearity, lifetime, temperature coefficient are valid for a sensor utilization as a ratiometric device with a max

current across the cursor Ic ≤ 0.1 mA.

10/25/50/75/100

see table

>25x106m strokes,or 100x106

operations, whichever is less

(within C.E.U.)

5...2000Hz, Amax =0,75 mm amax.
= 20 g

< 0,1 mA

see table

see table

< 1,5ppm/°C

Brackets with variable longitudinal
axis

3 pole Cable

MECHANICAL / ELECTRICAL DATA

Model 10 25 50 75 100

Useful electrical stroke (C.E.U.) +1/-0 mm 10 25 50 76 101

Theoretical electrical stroke (C.E.T.) ±1 mm C.E.U. +1 76 101

Resistance (C.E.T.) kΩ 1 1 5 5 5

Independent linearity (within C.E.U.) ± % 0.3 0.2 0.1 0.1 0.1

Dissipation at 40° (0W at 120°C) W 0.2 0.6 1.2 1.8 2.4

Maximum applicable voltage V 14 25 60 60 60

Mechanical stroke (C.M.) mm C.E.U. + 5

Case length (A) mm C.E.U. + 38

Tip length (B) mm 32 32 40 40 40

Total length (C) mm 108 138 196 251 307

Quote (D) mm - - - 5 11

OPTIONAL FIXING KIT PKIT006ELECTRICAL CONNECTIONS

Connector

output

Connection

Side

Cable

output

Blue

Yellow

Brown

INSTALLATION INSTRUCTIONS

• Respect the indicated electrical connections (DO NOT
use the transducer as a variable resistance)

• When calibrating the transducer, be careful to set the
stroke so that the output does not drop below 1% or rise
beyond 99% of the supply voltage.

ORDER CODE

S

Displacement transducer PY2

3 pole PVC cable

output 3x0.25 1m

5 pole connector
output DIN 43322

Model

F

C

M

Cable length

(in metres)

This part of the code only
applies to the model with
cable output

No certificate

attached

Linearity curve to be
attached

Standard mounting

brackets (PKIT005)

Optional mounting

brackets (PKIT006)

0 0 0 X 0 0 0

0

L

X

S

0

Color of plastic heads
(green)

Color of plastic heads
(black)

0

N

Ex.:PY2 - C - 100
Displacement transducer model PY2, 5-pole connector output, useful electrical stroke (C.E.U.) 100mm.
