HDMI Super Booster Plus
USER MANUAL
www.gefen.com
Technical Support:
Telephone (818) 772-9100
(800) 545-6900
Fax (818) 772-9120
Technical Support Hours:
8:00 AM to 5:00 PM Monday thru Friday.
Write To:
Gefen Inc.
C/O Customer Service
20600 Nordhoff St.
Chatsworth, CA 91311
support@gefen.com
www.gefen.com
Notice
Gefen Inc. reserves the right to make changes in the hard ware, packaging and any accompanying
doc u men ta tion without prior written notice.
The HDMI Super Booster Plus is a trademark of Gefen Inc.
© 2008 Gefen Inc., All Rights Reserved
Technical Support:
Telephone (818) 772-9100
(800) 545-6900
Fax (818) 772-9120
ASKING FOR ASSISTANCE
ASKING FOR ASSISTANCE
TABLE OF CONTENTS
TABLE OF CONTENTS
Introduction
Features
Panel Descriptions
Connecting and Operating the HDMI Super Booster Plus
Auto Equalization
Specifi cations
Warranty
Introduction
Features
Panel Descriptions
1
2
3
4
5
6
7
1
2
3
INTRODUCTION
INTRODUCTION
The Gefen HDMI Super Booster Plus is an attractive alternative to the traditional
sender/receiver solutions for HD extension. The HDMI Super Booster Plus enables
your standard “off the shelf” HDMI cable to transmit HDTV video plus multichannel
digital audio in a single cable way beyond the limited HDMI specifi cation of 15-feet.
Up to 200 feet can be easily traversed using your HDMI cable plus a HDMI Super
Booster Plus. The HDMI Super Booster Plus corrects any digital degradation that
occurs when HDMI is used to send digital audio/video signals beyond the HDMI
specifi cation of 15 feet.
How It Works
This plug and play installation takes mere seconds. You simply connect the HDMI
cable on one side of the HDMI Super Booster Plus and the display’s cable on the
other side. The HDMI Super Booster Plus sits between the end of your HDMI cable
and your display. You also have the option of connecting another HDMI cable to the
Booster, daisy chaining Boosters and cables for greater distances.
The Gefen HDMI Super Booster Plus is an attractive alternative to the traditional
sender/receiver solutions for HD extension. The HDMI Super Booster Plus enables
your standard “off the shelf” HDMI cable to transmit HDTV video plus multichannel
digital audio in a single cable way beyond the limited HDMI specifi cation of 15-feet.
1
FEATURES
FEATURES
Features
Perfect digital high defi nition video sent over long stretches of HDMI cables
Locate an HDMI display up to 200 feet away from any HDTV source
Supports resolutions up to 1080p, 2K, and 1920 x 1200
HDMI/HDCP compliant
Includes:
(1) HDMI Super Booster Plus
(1) 5V DC Power Supply
(1) User’s Manual
Features
Perfect digital high defi nition video sent over long stretches of HDMI cables
Locate an HDMI display up to 200 feet away from any HDTV source
•
•
•
•
•
•
2
Front Panel
Front Panel
Back Panel
Manual EQ
Adjustment
Power LED
Indicator
HDMI In
HDMI Out
+5V DC In
PANEL LAYOUT
PANEL LAYOUT
3
CONNECTING AND OPERATING THE
HDMI SUPER BOOSTER PLUS
CONNECTING AND OPERATING THE
HDMI SUPER BOOSTER PLUS
1.
2.
3.
4.
5.
1.
Connect the long HDMI cable from the source into the “HDMI In” on the front of
the HDMI Super Booster Plus. The HDMI Super Booster Plus is placed next to
your display to regenerate the HDMI cable.
Connect a short HDMI cable from the “HDMI Out” connection in the back of the
HDMI Super Booster Plus to your display or projector
Plug the 5V DC power supply into the HDMI Super Booster Plus.
Plug the 5VDC wall mount power supply into the wall outlet.
Adjust the trim pot on the front of the unit to tune the signal and eliminate any
video noise.
Note: Instead of manually adjusting the EQ to reduce image noise, the HDMI
Super Booster Plus has the ability to do auto equalization. To enable the Auto
EQ, remove the silver sticker on the bottom of the unit to reveal the service dip
switch. By default, the switches should both be in the OFF position. Flip dip
switch 1 to the ON position to enable Auto EQ. If the image is degraded or has
any video noise in this mode, please disable the Auto EQ and adjust the image
manually.
Connect the long HDMI cable from the source into the “HDMI In” on the front of
the HDMI Super Booster Plus. The HDMI Super Booster Plus is placed next to
your display to regenerate the HDMI cable.
4
Remove the silve
r
tape to expose th
e
Dip Switch Bank
Auto
Auto
EQ OF
EQ OFFF
(Default)
(Default)
Au
to EQ ON
1
1
ON
ON
2
2
1
ON
2
AUTO EQUALIZATION
AUTO EQUALIZATION
By default, both Dip Switches should be in the off position as shown above. To
enable the Auto EQ, please fl ip Dip Switch 1 to the ON position. You must then
proceed to manually adjust the EQ by turning the EQ trim pot on the front of the unit
in small increments. It is important to turn the dial in very small increments as the
“sweet spot” at which all video noise is eliminated can be very small.
5
Video Amplifi er Bandwidth ............................................................................ 165 MHz
Input Video Signal ....................................................................................1.2 Volts p-p
Input DDC Signal ............................................................................. 5 Volts p-p (TTL)
Maximum Single Link Range ....................................................... 1920 x 1200 x 60hz
HDMI Input/Output Connector Type ....................................................... HDMI Type A
Power Consumption ............................................................................. 5 Watts (max)
Power Supply…………………….. .................................................................... 5V DC
Dimensions .............................................................................. 1.75”W x 1”H x 2.25”D
Shipping Weight ................................................................................................. 2 Lbs
Video Amplifi er Bandwidth ............................................................................ 165 MHz
Input Video Signal ....................................................................................1.2 Volts p-p
SPECIFICATIONS
SPECIFICATIONS
6
