Gefen DVI FM 2000, Pro DVI FM 2000 User Manual
DVI FM 2000
GEF-DVI-FM2000
User Manual
DVI FM 2000
ASKING FOR ASSISTANCE
ASKING FOR ASSISTANCE
Technical Support:
Telephone (818) 772-9100
(800) 545-6900
Fax (818) 772-9120
Technical Support Hours:
Technical Support:
Telephone (818) 772-9100
(800) 545-6900
Fax (818) 772-9120
Technical Support Hours:
8:00 AM to 5:00 PM Monday thru Friday, Pacic Time
Write To:
Gefen, LLC
c/o Customer Service
20600 Nordhoff St
Chatsworth, CA 91311
www.gefenpro.com
support@gefenpro.com
Notice
Gefen, LLC reserves the right to make changes in the hardware, packaging, and any accompanying
documentation without prior written notice.
DVI FM 2000 Extender is a trademark of Gefen, LLC
© 2011 Gefen, LLC. All rights reserved.
All trademarks are the property of their respective owners.
Rev A6
CONTENTS
CONTENTS
1 Introduction
2 Operation Notes
3 Features
4 Sender unit Layout
5 Sender unit Descriptions
6 Receiver unit Layout
7 Receiver unit Descriptions
8 Connecting the DVI FM 2000
9 Wiring Diagram
10 Specifications
11 Warranty
1 Introduction
2 Operation Notes
3 Features
4 Sender unit Layout
1
INTRODUCTION
Congratulations on your purchase of the GefenPRO DVI FM 2000. Your complete satisfaction is very
important to us.
Gefen
Gefen delivers innovative, progressive computer and electronics add-on solutions that harness
integration, extension, distribution and conversion technologies. Gefen’s reliable, plug-and-play products
supplement cross-platform computer systems, professional audio/video environments, and HDTV
systems of all sizes with hard-working solutions that are easy to implement and simple to operate.
The GefenPRO DVI FM 2000
The Gefen DVI FM 2000 extends a Dual Link DVI source up to 1000 feet (300 meters) using a twostrand multi-mode (50 or 62.5 micron) ber optic cable. Resolutions up to 1080p Full HD and 3840 x
2400 at 60 Hz are supported.
How It Works
Connect the Sender unit to the Dual Link DVI source. Connect the Receiver unit to the Dual Link DVI
display. Use a two-strand SC-terminated ber optic cable to connect the Sender unit to the Receiver unit.
Use the included 5V DC power supply to connect the Receiver unit to an available electrical outlet.
Congratulations on your purchase of the GefenPRO DVI FM 2000. Your complete satisfaction is very
important to us.
Gefen
Gefen delivers innovative, progressive computer and electronics add-on solutions that harness
integration, extension, distribution and conversion technologies. Gefen’s reliable, plug-and-play products
