Page 1
HDTV CAT-5
Extender
USER MANUAL
www.gefen.com
Page 2
ASKING FOR ASSISTANCE
Technical Support:
Telephone (818) 772-9100
(800) 545-6900
Fax (818) 772-9120
Technical Support Hours:
8:00 AM to 5:00 PM Monday thru Friday.
Write To:
Gefen Inc.
c/o Customer Service
20600 Nordhoff Street
Chatsworth, CA 91311
www.gefen.com
support@gefen.com
Notice
Gefen Inc. reserves the right to make changes in the hard ware, packaging and any
accompanying doc u men ta tion without prior written notice.
The HDTV CAT-5 Extender is a trademark of Gefen Inc.
© 2005-2007 Gefen Inc., All Rights Reserved
Page 3
TABLE OF CONTENTS
1
Introduction
2
HDTV CAT-5 Extender Sender Front Panel Descriptions
3
HDTV CAT-5 Extender Receiver Front Panel Descriptions
4
How To Connect The HDTV CAT-5 Extender
5
Dip Switch Usage Guide
6
Mounting Plate Installation
7
Specifi cations
8
Warranty
Page 4
OPERATION NOTES
READ THESE NOTES BEFORE IN STALL ING
OR OPERATING THE HDTV CAT-5 EXTENDER
• The HDTV CAT-5 Extender is housed in a metal box for better RF shielding.
• Your CAT5 cable should not exceed 150 feet.
* CAT6 cable is suitable for high resolutions at 50 meters.
Page 5
INTRODUCTION
The HDTV CA T -5 Extender sender unit sits next to your computer , DVD player or any settop box with a HDMI output. The cable supplied with the HDTV CAT-5 Extender connects
your HDMI source to the send unit. The HDTV CAT-5 Extender receiver unit sits next to
your HDMI display - up to 150 feet away. The display plugs into the back of the HDTV
CAT-5 Extender receiver unit. Two CAT-5 cables connect the HDTV CAT-5 Extender-S
and the HDTV CAT-5 Extender-R units to each other.
CONTENTS
The HDTV CAT-5 Extender system consists of:
(1)HDTV CAT-5 Extender-S
(1) HDTV CAT-5 Extender-R
(1) HDMI to HDMI 6 foot
(1) 5 volt power supply
1
Page 6
HDTV CAT-5 Extender SENDER FRONT PANEL DESCRIPTIONS
Connects to 5 volt
power supply
HDMI input connects to
HDMI to HDMI cable
CAT5 carries
TMDS signals
CAT5 carries
DDC/HDCP signals
2
Page 7
HOW TO CONNECT THE HDTV CAT-5 Extender
Connect your display to the HDMI Extender receiver unit.
1
Connect your source to the HDMI Extender sender unit
2
Connect your CAT5 cables between the sender and the receiver
3
Plug the 5V power supply into the HDTV CAT-5 Extender sender unit.
4
You should now have picture. If you do not see a picture, try unplugging and re-
5
plugging the HDMI input on the HDMI Extender sender unit. Make sure your CAT5
cables are not crossed. Recycle the power on the unit.
4
Page 8
HDTV CAT-5 Extender RECEIVER FRONT PANEL DESCRIPTIONS
Connects to HDMI display
CAT5 carries
DDC/HDCP signals
CAT5 carries
TMDS signals
3
Page 9
DIP SWITCH USAGE GUIDE
Gefen CAT5 Extenders (sender and receiver) both contain a pair of dip switches
located on the board. These dip switches are used to select from a set of
confi gurations that will equalize the signal to best match the conditions in your setup.
How to open the HDTV CAT5 Extender:
1. Unscrew the four screws underneath the unit.
3. Slide the top plate off the base to expose the circuit board.
4. The dip switches are located directly on the circuit board.
Sender Dip Switches
Option No. Switch 1 Position Switch 2 Position Description
1 0 (OFF) 0 (OFF) Medium Boost
(Default)
2 1 (ON) 0 (OFF) Strong Boost
Receiver Dip Switches
Option No. Switch 1 Position Switch 2 Position Description
1 0 (OFF) 0 (OFF) EQ 0
(Default)
2 1 (ON) 0 (OFF) EQ 1
3 0 (OFF) 1 (ON) EQ 2
4 1 (ON) 1 (ON) EQ 3
Adjustment Guidelines:
1) Higher EQ level is used to equalize poor/low quality CAT-5e cables
2) Stronger boost is used to drive signals through longer cables
3) It is an optimal balance of Boost and EQ that will result in the best possible
picture.
5
Page 10
MOUNTING PLATE INSTALLATION
6
Page 11
SPECIFICATIONS
Video Amplifi er Bandwidth ................................................................................. 1.65 GHz
Single Link Range ......................................................................................... 1920 x 1200
Vertical Frequency Range ....................................................................................... 60 Hz
HDMI Output Connector Type .............................................................................. Types A
HDMI Input Connector Type ................................................................................... Type A
Power Consumption ................................................................................ 15 Watts (max.)
Dimensions ................................................................................ 3.4”W x 3.25”H x 1.25”D
Shipping Weight ....................................................................................................... 3 Lbs
7
Page 12
WARRANTY
Gefen Inc. warrants the equipment it manufactures to be free from defects in material
and workmanship.
If equipment fails because of such defects and Gefen Inc. is notifi ed within one (1)
year from the date of shipment, Gefen System will, at its option, repair or replace the
equipment, provided that the equipment has not been subjected to mechanical, electrical
or other abuse or modifi cations.
Equipment that fails under conditions other than those covered will be repaired at the
current price of parts and labor in effect at the time of repair. Such repairs are warranted
for ninety (90) days from the day of shipment to the Buyer.
This warranty is in lieu of all other warranties expressed or implied, including without
limitation, any implied warranty or merchantability or fi tness for any particular purpose,
all of which are expressly disclaimed.
The information in this manual has been carefully checked and is believed to be accurate.
However, Gefen Inc. assumes no responsibility for any inaccuracies that may be contained
in this manual. In no event will Gefen Inc., be liable for direct, indirect, special, incidental,
or consequential damages resulting from any defect or omission in this manual, even if
advised of the possibility of such damages. The technical information contained herein
regarding the HDTV CAT-5 Extender features and specifi cations is subject to change
without notice.
