XT-HD-CP-FM1
0
r Man
ua
l
ASKING FOR ASSISTANC
E
ev
A1
echnical Suppor
t
Telephone (818) 772-910
0
(800) 545-690
0
Fax
(
818) 772-912
0
echnical Support Hours
:
:00 AM to 5:00 PM Monday through Friday, Pacifi c Tim
e
Write To
:
efen LL
C
o Customer Servic
e
2
0600
Nordhoff St
hatsworth, CA 9131
1
www.gefen.com
upport@gefen.com
Notic
e
efen LLC reserves the right to make changes in the hard ware, packaging, and
any accompanying doc u men ta tion without prior written notice.
HD Extender 1FO is a trademark o
f Gef
en LL
C
HDMI, the HDMI logo, and High-Defi nition Multimedia Interfac
e
are
trademarks or registered trademarks of HDMI Licensing in the United States and
ther
cou
ntries.
©
2012 Gefen, LLC. All rights reserved.
All trademarks are the property of their respective owners.
CONTENT
S
1 Intr
oduction
2
peration Notes
Featur
es
4
able Layou
t
C
able Descriptions
onnecting the HD Extender 1F
O
Wiring Diagram
7
O
perating the HD Extender 1F
O
pecifi cations
Warrant
y
ongratulations on your purchase of the Gefen HD Extender 1FO.
Your complete satisfaction is very important to us.
efen
efen delivers innovative, progressive computer and electronics add-on solutions
that harness integration, extension, distribution and conversion technologies.
efen’s reliable, plug-and-play products supplement cross-platform computer
stems, professional audio/video environments and HDTV systems of all sizes
with hard-working solutions that are easy to install and simple to operate.
he Gefen HD Extender 1FO
The HDMI fi ber optic pigtail module extender with HDCP support extends HDMI
p to 1000 feet (300 meters) using a single-strand 50/125m multimode (OM2)
-terminated fi ber optic cable. It supports resolutions up to 1080p Full HD and
D lossless audio formats like LCPM 7.1 audio, Dolby® Digital Plus, Dolby®
TrueHD, and DTS-HD® Master Audio™. Optical signal transmission provides
alvanic isolation and immunity to electromagnetic interference compared to
imilar copper based extension modules. The pigtail design of the Sender and
eceiver modules relieves stress and clutter on the source and displa
y
onnector panels. Their compact design makes them ideal for fi tting neatl
y
behind equipment for a clean installation, making it a great way to easily extend
DMI.
How It Works
The Sender pigtail end plugs into the HDMI source. The Receiver pigtail end
lugs into the HDTV display. Connect a single-strand 50/125m multimode
M2) SC-terminated fi ber optic cable from the Sender to the Receiver module.
Plug the power supply into the Receiver module and a vibrant Hi-Def picture will
appear on your display.
INTRODUCTIO
N
OPERATION NOTE
S
LEASE READ THESE NOTES BEFORE INSTALLING OR
OPERATING THE HD EXTENDER 1FO
• In most situations, the Sender pigtail module does not need to be externall
y
owered unless the source does not supply enough power through th
e
DMI connector. If the Sender requires a separate power supply only use
efen part no. EXT-PS52AIP-1.3. Using a different power supply other
than the recommended type may cause fatal damage to the Sender pigtail
le.
FEATURE
S
Features
• Extends HDMI up to 1000
f
eet (300 meters) using a single-strand 50/125m
ultimode (OM2) SC-terminated fi ber optic cabl
e
•
upports resolutions up 1080p Full HD
•
upports HD lossless audio: LCPM 7.1 audio, Dolby® Digital Plus, Dolby®
TrueHD, and DT
S
-HD® Master Audio™
• Fiber optic transmission eliminates electroma
g
netic interference (EMI
)
• Pigtail design relieves stress and clutter on the source and displa
y
onnector panels
• 3DTV pass-throu
gh
• DDC bidirectional suppor
t
•
DCP pass-throu
gh
•
upports Deep Color
•
ompact Sender and Receiver modules provide a clean, easy installatio
n
• FCC and CE compliant for EMI/RFI emissio
n
ackage Includes
1) HD Extender 1FO - Sender Pigtail modul
e
1) HD Extender 1FO - Receiver Pigtail modul
e
1) 5V DC power suppl
y
1) Quick-Start Guid
e
CABLE LAYOU
T
5
7
5
ower Indicator (Sender module
)
This LED will glow bright green when the Hi-Def source is supplying suffi cient
ower to the Sender module. If the LED fl ashes green, then the source is
nable to power the Sender module. See page 7 for more information.
Fiber Optic Connector (Sender module
)
onnect an SC-terminated fi ber optic cable from the Sender pigtail module to
the SC fi ber connector on the Receiver pigtail module.
HDMI Connector, male (Sender module
)
onnect this end of the Sender pigtail module to the Hi-Def source.
ower Indicator (Receiver module
)
This LED will glow bright green when one of the included 5V DC power supplies
is connected to the power receptacle on the Receiver module.
Fiber Optic Connector (Receiver module
)
onnect the SC-terminated fi ber optic cable from the Sender pigtail module to
the SC fi ber connector on the Receiver pigtail module.
HDMI Connector, male (Receiver module
)
onnect this end of the Receiver pigtail module to the HDTV display.
ower Receptacle (Sender / Receiver module
)
onnect the included 5V DC power supply to this power receptacle. Both the
ender and Receiver module have power receptacles. However, the Sender
odule does not need to be externally powered unless the source does not
upply enough power through the HDMI connector.
CABLE DESCRIPTION
S
How to Connect the HD Extender 1FO
1.
onnect the Sender pigtail module to the Hi-Def source.
2.
onnect the Receiver pigtail module to the HDTV display.
.
onnect a single strand of SC-terminated fi ber optic cable between the fi ber
optic connectors on the Sender and Receiver pigtail modules.
4.
onnect the included 5V DC power supply to power receptacle on the
eceiver pigtail module.
. Power-on the display and Hi-Def source.
Wiring Diagram for the HD Extender 1FO
CONNECTING THE HD EXTENDER 1FO
NOTE
:
The Sender module does not need to be externally powered
nless the Hi-Def source does not supply enough power through the
DMI connector. The Receiver module must always be powere
d
sing the included 5V DC power supply.
Computer
HD
Display
Sender
Receiver
HDMI
EXT-HD-CP-FM10
FIBER OPTIC CABLE
e
r
cei
ver
7
OPERATING THE HD EXTENDER 1FO
ower Indicators
The power indicators on both the Sender and Receiver modules of the HD
Extender 1F
O
provide information about the current power state.
Normal operation
If the power indicator on both the Sender and Receiver module glows bright
reen, then both the Sender and Receiver module have suffi cient power.
Sender module Receiver modul
e
No power / insuffi cient power on the Sender module
If the Hi-Def source is unable to supply the required 5V to the Sender module,
then the power indicator on the Sender module will fl ash bright green. If this is
the case, then connect a secondary 5V DC power supply to the power receptacle
on the Sender module (use Gefen part no. EXT-PS52AIP-1.3).
Sender modul
e
aximum Pixel Clock............................................................................... 225 MH
z
Video Input Connector (Sender)............................. (1) HDMI Type-A, 19-pin, mal
e
Video Output Connector (Receiver)....................... (1) HDMI Type-A, 19-pin, mal
e
Link Connector (Sender/Receiver).......................... (1) Type SC fi ber (50 /125m
)
Power Supply (Receiver)....................................................................... 5V / 2A D
C
Power Supply (Sender).................. 5V / 2A DC (not needed for most applications
)
Power Consumption (Receiver)........................................................... 1.5W (max.
)
perating Temperature.................................................. 0 to +122 °F (0 to +50
°C)
torage Temperature................................................. -4 to +158 °F (-20 to +70
°C)
elative Humidity................................................................................. 10% to 80
%
Dimensions (W x H x D)........................................................ 1.18” x 0.47” x 10.71”
(
29.97mm x 11.93mm x 272.03mm
)
hipping Weight.................................................................................. 1lb (0.45 k
g)
SPECIFICATION
S
efen warrants the equipment it manufactures to be free from defects in material
and workmanship.
I
f
equipment fails because of such defects and Gefen is notifi ed within two (2)
y
ears from the date of shipment, Gefen will, at its option, repair or replace the
quipment, provided that the equipment has not been subjected to mechanical,
lectrical, or other abuse or modifi cations. Equipment that fails under conditions
other than those covered will be repaired at the current price of parts and labor in
ect at the time of repair. Such repairs are warranted for ninety (90) days from
the day of reshipment to the Buyer.
This warranty is in lieu of all other warranties expressed or implied, including
without limitation, any implied warranty or merchantability or fi tness for any
articular purpose, all of which are expressly disclaimed.
1. Proof of sale may be required in order to claim warranty.
2.
ustomers outside the US are responsible for shipping charges to and from
efen.
.
opper cables are limited to a 30 day warranty and cables must be in their
original condition.
The information in this manual has been carefully checked and is believed to
be accurate. However, Gefen assumes no responsibility for any inaccuracies
that may be contained in this manual. In no event will Gefen be liable for
direct, indirect, special, incidental, or consequential damages resulting from
any defect or omission in this manual, even if advised of the possibility of such
damages. The technical information contained herein regarding the features and
pecifi cations is subject to change without notice.
For the latest warranty coverage information, refer to the Warranty and Return
Policy under the Support section of the Gefen Web site at www.gefen.com.
RODUCT REGISTRATIO
N
lease register your product online by visiting the Register Product page
nder the Support section of the Gefen Web site
.
Rev A
1
Pb
This product uses UL or CE listed power supplies.
