Page 1
1x4 HD Digital
Audio Splitter
USER MANUAL
www.gefen.com
Page 2
ASKING FOR ASSISTANCE
Technical Support:
Telephone (818) 772-9100
(800) 545-6900
Fax (818) 772-9120
Technical Support Hours:
8:00 AM to 5:00 PM Monday through Friday PST.
Write To:
Gefen Inc.
c/o Customer Service
20600 Nordhoff St.
Chatsworth, CA 91311
support@gefen.com
www.gefen.com
Gefen Inc. reserves the right to make changes in the hard ware, packaging and any
accompanying doc u men ta tion without prior written notice.
1x4 HD Digital Audio Splitter is a trademark of Gefen Inc.
© 2007 Gefen Inc., All Rights Reserved
Notice
Page 3
TABLE OF CONTENTS
Introduction
1
Features
2
Panel Descriptions
3
Connecting and Operating the 1x4 HD Digital Audio Splitter
4
Specifi cations
5
Warranty
6
Page 4
INTRODUCTION
Congratulations on your purchase of the ex•tend•it 1x4 HD Digital Audio Splitter. Your
complete satisfaction is very important to us.
Gefen’s line of HDTV switches, extenders, and splitters are designed to make your A/V
equipment use more comfortable, more productive and less expensive.
Gefen’s ex•tend•it 1x4 HD Digital Audio Splitter is a distribution hub that sends the same
video output to two or more HDTV digital screens. It is a fl exible solution that accommo-
dates multiple displays. When two or more 1x4 HD Digital Audio Splitters are connected
together, they can be used to create a larger distribution.
The 1x4 HD Digital Audio Splitter is connected using a HDMI cable from the HD source
to the 1x4 HD Digital Audio Splitter HD input. DVI output 1 is the primary
connection and is used for the main display. DVI output 2-4 follows the main display.
The digital audio is connected with SPDIF or TOSLINK. The 1x4 HD Digital Audio
Splitter will convert the input audio into TOSLINK for the output.
The 1x4 HD Digital Audio Splitter is HDCP compliant.
The ex•tend•it line offers solutions for noise, space and security concerns, data center
control, information distribution, conference room presentation, school and corporate
training environments.
Our Commitment
Gefen will always offer the fi nest quality product at the best possible price. Included in
that price is a lifetime of support from a team of outstanding engineers.
1
Page 5
FEATURES
Features
• Splits the HD signal to two or more DVI displays
• Maintains 480i, 480p, 720p, 720i, and 1080i, 1080p resolutions
• Maintains highest DVI single link video resolution
• Connects four or more HDTV displays at the same time to the same video source
• Supports HDCP compliant devices
• Supports DDWG standard for HD compliant monitors
• Extends any DVI compliant device by regenerating the DVI signal
• Uses a HDMI cable to connect to the input
• Uses DVI cables to connect to the output
• Converts S/PDIF to TOSLINK
• Installs in seconds
Includes:
(1) 1x4 HD Digital Audio Splitter
(1) 6’ HDMI cable (M-M)
(1) 6’ TOSLINK cable
(1) 5VDC Power Supply
2
Page 6
PANEL DESCRIPTIONS
5v Power
Input
DVI Out 1
HD In
DVI Out 2
Digital Audio
Output 1
Digital Audio
DVI Out 3
Digital Audio
Output 2
Inputs
Digital Audio
Output 3
DVI Out 4
Digital Audio
Output 4
3
Page 7
CONNECTING AND OPERATING THE 1X4 HD DIGITAL AUDIO SPLITTER
How to Connect the 1x4 HD Digital Audio Splitter to your devices
1- Connect the supplied HDMI cable from the HD device into the 1x4 HD Digital
Audio Splitter HD Input.
2- Connect the supplied TOSLINK cable from the Audio device into the 1x4 HD Digital
Audio Splitter Audio Input
3- Connect the cables from your displays (monitor or projector) into the DVI Out slots
in the back of the 1x4 HD Digital Audio Splitter
4- Connect TOSLINK cables from your audio receivers into the 1x4 HD Digital Audio
Splitter outputs.
5- Plug the 5v power supply into the 1x4 HD Digital Audio Splitter.
6- Plug the 5v wallmount power supply into the wall outlet.
NOTE: The 1x4 HD Digital Audio Splitter only passes digital video, and does not support
audio in HDMI.
4
Page 8
SPECIFICATIONS
Video Amplifi er Bandwidth ................................................................................. 1.65 GHz
Input Video Signal ......................................................................................... 1.2 volts p-p
Input DDC Signal .................................................................................... 5 volts p-p (TTL)
Maximum Single Link Range ............................................................ 1920 x 1200, 1080p
HDMI Input Connector ................................................................................ Type-A 19-pin
DVI Output Connector ............................................................................................. DVI-D
Power Consumption ................................................................................ 15 Watts (max.)
Power Supply .......................................................................................................... 5VDC
Dimensions ............................................................................................. 9”W x 1”H x 5”D
Shipping Weight ....................................................................................................... 5 Lbs
5
Page 9
WARRANTY
Gefen Inc. warrants the equipment it manufactures to be free from defects in material
and workmanship.
If equipment fails because of such defects and Gefen Inc. is notifi ed within two
(2) year from the date of shipment, Gefen Inc. will, at its option, repair or replace
the equipment, provided that the equipment has not been subjected to mechanical,
electrical, or other abuse or modifi cations.
Equipment that fails under conditions other than those covered will be repaired at the
current price of parts and labor in effect at the of repair. Such repairs are warranted for
ninety (90) days from the day of reshipment to the Buyer.
This warranty is in lieu of all other warranties expressed or implied, including without
limitation, any implied warranty or merchantability or fi tness for any particular purpose,
all of which are expressly disclaimed.
1. Proof of sale may be required in order to claim warranty.
2. Customers outside the US are responsible for shipping charges to and from Gefen.
3. Copper cables are limited to a 30 day warranty and cable must be free from any
scratches, markings, and neatly coiled.
The information in this manual has been carefully checked and is believed to be
accurate. However, Gefen Inc. assumes no responsibility for any inaccuracies that may
be contained in this manual. In no event will Gefen Inc., be liable for direct, indirect,
special, incidental, or consequential damages resulting from any defect or omission
in this manual, even if advised of the possibility of such damages. The technical
information contained herein regarding 1x4 HD Digital Audio Splitter features and
specifi cations is subject to change without notice.
6
